2AOWKGQ3090Mobile Phone

1 Mobile Phone GQ3090 ulefone User Guide 2 Contents I. CAUTIONS ON MOBILE PHONE USE ............................................................................................................... 4 1.1 INTERFERENCE ......................................................................................................................................... 4 1.2 REASONABLE USE .................................................................................................................................... 4 1.3 QUALIFIED MAINTENANCE SERVICE .......................................................................................................... 4 1.4 WATER-RESISTANCE................................................................................................................................. 4 1.5 EMERGENCY CALLS .................................................................................................................................. 4 2 PRECAUTIONS FOR USE OF BATTERY ........................................................................................................... 4 3 CAUTIONS FOR CHILDREN............................................................................................................................ 5 II. KEYS AND PARTS ........................................................................................................................................ 5 III. START TO USE ........................................................................................................................................... 5 3.1 TO INSERT SIM CARD(S): ........................................................................................................................ 5 3.2 CHARGE THE BATTERY ............................................................................................................................. 6 IV. BASIC FUNCTIONS ..................................................................................................................................... 6 1. LOCK AND UNLOCK THE SCREEN ................................................................................................................ 6 2. MAKE IT YOURS .......................................................................................................................................... 8 3. SWITCH TO RECENTLY USED APPLICATION ...............................................................................................14 4. MAKE A CALL ............................................................................................................................................15 3 5. CALL LOG ..................................................................................................................................................16 6. ANSWERING PHONE CALLS AND REJECTION ..............................................................................................17 7. ADD A CONTACT ........................................................................................................................................18 8. SEND AND RECEIVE MESSAGE(S) ..............................................................................................................19 9. BROWSER THE WEB ..................................................................................................................................21 10. ENJOY MUSIC ..........................................................................................................................................21 11. DOWNLOAD APPLICATIONS FROM PLAY STORE .......................................................................................22 12. MANAGE APPLICATIONS ..........................................................................................................................23 13. APPLICATIONS & UTILITIES .............................................................................................................24 14. SETTINGS ................................................................................................................................................24 V. TECHNICAL INFORMATION .........................................................................................................................29 4 I. Cautions on mobile phone use 1.1 Interference All phones may be interfered, which affect phone calls. 1.2 Reasonable use Use only in the normal position. Do not touch the antenna area unnecessarily. 1.3 Qualified maintenance service Only qualified personnel may install or repair this product. 1.4 Water-resistance Your device is non water-resistant. Keep it dry. 1.5 Emergency calls Ensure the phone is switched on and in service. Enter the emergency number and press the Dialer icon. 2 Precautions for use of battery 2.1 Do not dispose of batteries near or in a fire to avoid dangers. 2.2 Do not dispose of batteries in the garbage. Dispose of batteries to assigned battery recycling center. 5 3 Cautions for children Keep your device out the reach of children in case of accidental injury caused by incorrect use of the device as toys. II. Keys and parts  1. Audio jack  2. USB Connector  3. Front Camera  4. Receiver  5. Light sensor / Proximity sensor  6. LCD  7. Mic  8. Adjust volume key  9. Power key  10. Rear Camera  11. Flashlight  12. Speaker III. Start to use 3.1 To insert SIM card(S): Insert the SIM card correctly in the card slot(s) (See figure below), suggest switch off the phone when you insert SIM card. Insert the Micro SD card into the slot with the correct direction (See figure below), suggest switch 6 off the phone when you insert SIM card. Note: Use only compatible memory cards with this device. Incompatible memory cards may damage the card or the device and corrupt the data stored in the card. 3.2 Charge the battery During charging, the battery indicator on the phone is a thunder icon. If the device is switched off during charging, there will still be a charging indication on the scree…

Text truncated - open the document above for the full version.

Shenzhen Gotron Electronic CO.,LTD. Agent Authorization Letter (2020-07-20) MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park Sanwei, Xixiang, Bao'an District, Shenzhen, Guangdong, China Alex.li [email protected] to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, tangyongbin / Manager Date/City: 2020-07-20/Shenzhen Phone: 0755-83895989 Fax: 0755-83895909 E-mail: [email protected]

Shenzhen Gotron Electronic CO.,LTD. Family models difference declaration Mobile Phone Model: GQ3090, Armor 8, Armor 8E, Armor 8S, Armor 8P, Armor 8X, Armor 8A, Armor 8 Pro, Armor 8 Lite Difference declaration: All models are the same circuit and RF module, except the model name. Regards, Signature Name: Tangyongbin Date: 2020-07-20

Shenzhen Gotron Electronic CO.,LTD. Long Term Confidentiality Request Letter (2020-07-20) MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR Product: Mobile Phone Model No.: GQ3090, Armor 8, Armor 8E, Armor 8S, Armor 8P, Armor 8X, Armor 8A, Armor 8 Pro, Armor 8 Lite To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the  Schematic Diagram  Block Diagram  Part List / BOM  Operational Description  Tune-up Procedure  FCC Software Configuration Control Declaration  FCC Software Security Requirements for UNII devices Required to be submitted with this application be permanently withheld from public review. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Please contact me if there is any information you may need. Sincerely, Tangyongbin / Manager Date/City: 2020-07-20/Shenzhen Phone: 0755-83895989 Fax: 0755-83895909 E-mail: [email protected]

Shenzhen Gotron Electronic CO.,LTD. Short Term Confidentiality Request Letter (2020-07-20) MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Short Term Confidentiality Request For Product: Mobile Phone Model No.: GQ3090, Armor 8, Armor 8E, Armor 8S, Armor 8P, Armor 8X, Armor 8A, Armor 8 Pro, Armor 8 Lite FCC ID: 2AOWKGQ3090 To Whom It May Concern: In accordance with sections 0.457 and 0.459 of CFR 47, < Shenzhen Gotron Electronic CO.,LTD. >. requests short-term Confidentiality of following sections of this application for a period of 45 days after grant is issued. Test setup photos External photos Internal photos User’s manual These documents contain detailed system and equipment descriptions and related information about the product, which < Shenzhen Gotron Electronic CO.,LTD. > considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, < Shenzhen Gotron Electronic CO.,LTD. > feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Tangyongbin / Manager Date/City: 2020-07-20/Shenzhen Phone: 0755-83895989 Fax: 0755-83895909 E-mail: [email protected]

STR200610002 Model: GQ3090 N20191017V1 Photo 1 Photo 2 STR200610002 Model: GQ3090 N20191017V1 Photo 3 Photo 4 STR200610002 Model: GQ3090 N20191017V1 Photo 5 Photo 6 STR200610002 Model: GQ3090 N20191017V1 Photo 7 Photo 8 STR200610002 Model: GQ3090 N20191017V1 Photo 9 Photo 10

Mobile Phone Model Name: GQ3090 FCC ID: 2AOWKGQ3090 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

STR200610002 Model: GQ3090 N20191017V1 Photo 1 Photo 2 NFC Antenna STR200610002 Model: GQ3090 N20191017V1 Photo 3 Photo 4 2/3/4G Main ANT WIFI BT GPS ANT STR200610002 Model: GQ3090 N20191017V1 Photo 5 Photo 6 2/3/4G DIV ANT STR200610002 Model: GQ3090 N20191017V1 Photo 7 Photo 8 STR200610002 Model: GQ3090 N20191017V1 Photo 9 Photo 10 STR200610002 Model: GQ3090 N20191017V1 Photo 11 Photo 12 STR200610002 Model: GQ3090 N20191017V1 Photo 13 Photo 14

Report No.: STR200610002008E Version.1.2 Page 1 of 19 FCC Test Report FCC ID: 2AOWKGQ3090 Product: Mobile Phone Trade Mark: ulefone Model Number: GQ3090 Family Model: Armor 8, Armor 8E, Armor 8S, Armor 8P, Armor 8X, Armor 8A, Armor 8 Pro, Armor 8 Lite Report No.: STR200610002008E Prepared for Shenzhen Gotron Electronic CO.,LTD. 518, 5F, R&D building, Tsinghua Hi-Tech park, Nanshan district, Shenzhen 518057 P.R.China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-755-6115 6588 Fax.: +86-755-6115 6599 Website:http://www.ntek.org.cn Report No.: STR200610002008E Version.1.2 Page 2 of 19 TEST RESULT CERTIFICATION Applicant’s name.................. : Shenzhen Gotron Electronic CO.,LTD. Address .................................. : 518, 5F, R&D building, Tsinghua Hi-Tech park, Nanshan district, Shenzhen 518057 P.R.China Manufacturer's Name ........... : Shenzhen Gotron Electronic CO.,LTD. Address .................................. : 518, 5F, R&D building, Tsinghua Hi-Tech park, Nanshan district, Shenzhen 518057 P.R.China Product description Product name ............................ : Mobile Phone Model and/or type reference . : GQ3090 Family Model ............................. : Armor 8, Armor 8E, Armor 8S, Armor 8P, Armor 8X, Armor 8A, Armor 8 Pro, Armor 8 Lite Standards ............................. : FCC Part15B ANSI C63.4:2014 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with Part 15 of FCC Rules. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personnel only, and shall be noted in the revision of the document. Date of Test ........................................... : Date (s) of performance of tests ............. : 10 Jun. 2020 ~ 03 Jul, 2020 Date of Issue .......................................... : 03 Jul, 2020 Test Result .............................................. : Pass Testing Engineer : (Mary Hu) Technical Manager : (Jason Chen) Authorized Signatory : (Sam Chen) Report No.: STR200610002008E Version.1.2 Page 3 of 19 Table of Contents Page 1 . TEST SUMMARY 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST SETUP 8 2.3 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 9 2.4 MEASUREMENT INSTRUMENTS LIST 10 3 . EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.1.1 POWER LINE CONDUCTED EMISSION 11 3.1.2 TEST PROCEDURE 12 3.1.3 TEST SETUP 12 3.1.4 EUT OPERATING CONDITIONS 12 3.1.5 TEST RESULTS 13 3.2 RADIATED EMISSION MEASUREMENT 15 3.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT 15 3.2.2 TEST PROCEDURE 15 3.2.3 TEST SETUP 16 3.2.4 TEST RESULTS 17 3.2.5 TEST RESULTS(1000~26500MHz) 19 Report No.: STR200610002008E Version.1.2 Page 4 of 19 1. TEST SUMMARY Test procedures according to the technical standards: EMC Emission Standard Test Item Limit Judgment Remark FCC Part15B ANSI C63.4: 2014 Conducted Emission Class B PASS Radiated Emission Class B PASS NOTE: (1) ’N/A’ denotes test is not applicable in this Test Report (2) For client’s request and manual description, the test will not be executed. Report No.: STR200610002008E Version.1.2 Page 5 of 19 1.1 TEST FACILITY Shenzhen NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen 518126 P.R. China. IC-Registration The Certificate Registration Number is 9270A. CAB identifier:CN0074 FCC- Accredited Test Firm Registration Number: 463705. Designation Number: CN1184 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. A. Conducted Measurement : Test Site Method Measurement Frequency Range U,(dB) NOTE NTEKC01 ANSI 150 KHz ~ 30MHz ±2.80dB B. Radiated Measurement : Test Site Method Measurement Frequency Range U,(dB) NOTE NTEKA01 ANSI 30MHz~1000MHz ±2.64dB 1GHz~6GHz ±2.40dB 6GHz~26.5GHz ±2.52dB Report No.: STR200610002008E Version.1.2 Page 6 of 19 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Mobile Phone Trade Mark ulefone Model Name GQ3090 Family Model Armor 8, Armor 8E, Armor 8S, Armor 8P, Armor 8X, Armor 8A, Armor 8 Pro, Armor 8 Lite Model Difference All the model are the same circuit and RF module, except the Model names. Product Description The EUT is a Mobile Phone. Connecting I/O port: Micro USB, Earphone Operation Frequency: 1.3GHz Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Power Source DC 3.8V/5580mAh from battery or DC 5V from Adapter. Adapter Model: HJ-0503000K7-US Input: 100-240V~50/60Hz 0.6A Output: 5V3A HW Version X70_01 SW Version Armor 8_RH2_EEA_V01 Report No.: STR200610002008E Version.1.2 Page 7 of 19 2.1.1 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 USB Data Transmission Mode 2 TF card Playing Mode 3 REC Mode 4 FM Mode 5 GPS For Conducted Test Final Test Mode Description Mode 1 USB Data Transmission Mode 2 TF card Playing Mode 3 REC Mode 4 FM Mode 5 GPS For Radiated Test Final Test Mode Description Mode 1 USB Data Transmission Mode 2 TF card Playing Mode 3 REC Mode …

Text truncated - open the document above for the full version.

FCC ID: 2AOWKGQ3090 Radiated Measurement Photos FCC ID: 2AOWKGQ3090 AC Conducted Measurement Photos
