2AP3Q-FG2116WBSmart Body Fat Scale

User Manual SMART SCALE Caution Safety precautions: When using digital scale, certain basic safety precautions must be followed, including the following: 1. The Bluetooth scale should not be used to diagnose or treat any medical condition. You should consult a doctor when undertaking any diet or exercise program. 2. lf you are pregnant or have a pacemaker or other internal device,you should not over rely on the data provided by this product. All data is for reference and is not a substitute for advise from a licensed health care professional. 3. lf the scale malfunctions, first check the batteries and replace if needed. 4. Check the device before each use. Do not use the device if damaged. The continuous use of a damaged unit may cause injury or improper results. Note: 1. Scale is a high-precision measuring device. Never jump or stamp on the scale or disassemble. Please handle the scale carefully to avoid breakage. 2. Place the scale on a hard, flat surface during use. Using the scale on a soft surface like carpet or linoleum may affect the accuracy of the scale readings. 3. To ensure weighing accuracy, please gently step on the scale to wake it up and wait at least 10 seconds before weighing on the 2 scale. You must also wake up the scale if it has been moved. Take your measurements at the same time each day to ensure the most accurate results. 4. When not in use, please remove the batteries and place the device in a dry room and protect it against extreme moisture, heat, lint, dust and direct sunlight. Never place any heavy objects on the equipment. 5. Before using the scale, make sure you have entered all your personal data through the Fitdays app. 6. Use the scale while barefoot. The scale cannot measure body fat percentage if you're wearing shoes or socks. 7. Make sure your feet are dry before weighing yourself. 8. This scale is not waterproof; never immerse the scale in water. To clean the surface, use a damp cloth or glass cleaner. Do not use soap or other chemicals. Specifications Size: 278 x 278 x 24.5mm Batteries: 3*1.5 V AAA Capacity: 400lb/180 kg Division: 0.1lb/100g Unit: lb / kg / st 3 For body weight: Place the scale on an even surface and wait at least 10seconds before stepping on the scale. The reading should display 0.0 kg before stepping on. Accuracy Range Trouble shooting Functioning normallyChange battery Change batteryOverload Calibrating 4 For body fat and other body composition analysis: Stand straight on scale and uniformly touched the electrodes with bare and dry feet as shown below. The Bluetooth Scale can connect with your mobile phone (Android 6.0+ & IOS 8.0+) or iPad via Bluetooth 4.0. Download the ‘Fitdays’ app free from the App Store or Google Play. Operating instructions Conductive areas 5 Turn on Bluetooth on your smartphone. Location also needs to be turned on for Android 6.0 or higher. Download " Fitdays " via App Store or Google Play. Press [Device] and Device Management to enter measuring page and find device. Power on the scale, press[+] to select your device to add the device. Come back to measure page. Step on the scale and keep standing for 5-10 seconds with bare feet. The weighing has finished after the analysing datas come out. Install the original battery set. Please note the batteries offered are trial version. We recommend replacing them within 3 months and removing the batteries when not using for a long time. Register your own ID, then add personal data and confirm OK. Download App and install the batteries Pairing the scale with your smartphone Pairing Your Device 6 Click " Chart " to view your progress history. Enter it into the calendar to form a list and select a dataset or all data you want to delete. You can also select different date datas to contrast and share to friend via facebook,instagram, or SMS by click button View reports, deleted data, set reference data, share progress by recently,weekly,month and year. 7 At the bottom, you will find a bar where you can select different types of data to display. You can share your fitness data with friends via Facebook, Instagram, or SMS by clicking the share button [+] and Share on the Measuring page. Under " Mine " you can add user(s) " " . To delete an account, swipe the account to the left and select " Delete " . Themes, Set goals, Weight units, Weighing done sounds, Languages, Passwords can all be set under the Setting " " page. Please note that you can change the weighing unit under Press the Unit button,then if will control the unit of App. Add/Delete Users & Basic Settings 8 Fitdays Fitdays Fitdays 1)Open the " Health " app on your iPhone, select 'Data Sources. 2) Select " Fitdays " from the sources list. 3)Turn on all categories to allow the Fitdays app to work. 1) Enter Setting " " page, select " Google Fit " 2) Turn on " Google Fit " button, login to your Google account. 3)It will now automatically redirect you to the " Google Fit " page. 4) After the connection has been established, the data " Weight " will sync to Google Fit. Apple Health Google Fit Sync to fitness app Fitdays 9 Fitbit App 1) Enter Setting " " page, select Fitbit 2) Turn on Fitbit button, login to your Fitbit account. 3) Select " Allow " to access Fitbit App. 4) After connection, the data (Weight, Body Fat%, BMI) will sync to Fitbit app. You can view both on app and web. 10 If the scale has been moved or flipped up side down, It must be recalibrated to ensure accurate results. 1.Place the scale on a hard, flat surface. 2.Step on the scale with one foot until the digits appear on the display, then, step off. 3.The scale will show “0.00”, indicating that the calibration process is complete. Recalibrating the scale Maintenance 11 1.Why doesn't the scale work? Why does the data on screen disappear in a flash? - Please check the batteries are installed properly, replace batteries if necessary. 2. The scale cannot connect with App. - Check that the phone's software is iOS 8.0 or higher or Android6.0 or higher. - Dow…

Text truncated - open the document above for the full version.

Guangdong Welland Technology Co., Ltd. Agent Authorization Company: Guangdong Welland Technology Co., Ltd Address: No.85 MinKe East Road, MinYing Science and Technology Park, ShiQi District, Zhongshan, China Product Name: Smart Body Fat Scale Model Number(s): FG2116WB Product Description: Smart Body Fat Scale We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2021-12-30 Name: Hillary Chan Company: Guangdong Welland Technology Co., Ltd.

Report No.: AGC06164211202AP02 Page 1 of 4 EXTERNAL PHOTOS TOP VIEW OF EUT BOTTOM VIEW OF EUT Report No.: AGC06164211202AP02 Page 2 of 4 FRONT VIEW OF EUT BACK VIEW OF EUT Report No.: AGC06164211202AP02 Page 3 of 4 LEFT VIEW OF EUT RIGHT VIEW OF EUT Report No.: AGC06164211202AP02 Page 4 of 4 PORT VIEW OF EUT ****************************************End of Report****************************************

FCC ID Label Location 50mm&25mm FCC ID: 2AP3Q-FG2116WB

Report No.: AGC06164211202AP02 Page 1 of 3 INTERNAL PHOTOS OPEN VIEW OF EUT (FIGURE 1) ANTENNA CLOSE-UP PHOTO-1 BT Antenna Report No.: AGC06164211202AP02 Page 2 of 3 INTERNAL VIEW OF EUT (FIGURE 1) INTERNAL VIEW OF EUT (FIGURE 2) Report No.: AGC06164211202AP02 Page 3 of 3 INTERNAL VIEW OF EUT (FIGURE 3) INTERNAL VIEW OF EUT (FIGURE 4) ****************************************End of Report****************************************

RF EXPOSURE EVALUATION 1. PRODUCT INFORMATION Product Description Smart Body Fat Scale Model Name FG2116WB FCC ID 2AP3Q-FG2116WB 2. EVALUATION METHOD According to 447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 3. CALCULATION P t = -4.679dBm=0.34mW The value of the Maximum output power P t is referred to the test report of the CFR47 §15.247. The result for RF exposure evaluation SAR=(0.34mW / 5mm).[√2.480GHz)]=0.11<3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. 4. CONCLUSION The SAR evaluation is not required.

Page 1 of 42 FCC Test Report Report No.: AGC06164211202FE02 FCC ID : 2AP3Q-FG2116WB APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : Smart Body Fat Scale BRAND NAME : N/A MODEL NAME : FG2116WB APPLICANT : Guangdong Welland Technology Co., Ltd. DATE OF ISSUE : Dec. 29, 2021 STANDARD(S) : FCC Part 15.247 REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd Report No.: AGC06164211202FE02 Page 2 of 42 REPORT REVISE RECORD Report Version Revise Time Issued Date Valid Version Notes V1.0 / Dec. 29, 2021 Valid Initial Release Report No.: AGC06164211202FE02 Page 3 of 42 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE .................................................................................................................. 5 2. GENERAL INFORMATION .............................................................................................................................. 6 2.1. PRODUCT DESCRIPTION ........................................................................................................................ 6 2.2. TABLE OF CARRIER FREQUENCYS ....................................................................................................... 6 2.3. RELATED SUBMITTAL(S)/GRANT(S) ....................................................................................................... 7 2.4. TEST METHODOLOGY ............................................................................................................................. 7 2.5. SPECIAL ACCESSORIES .......................................................................................................................... 7 2.6. EQUIPMENT MODIFICATIONS ................................................................................................................. 7 2.7. ANTENNA REQUIREMENT ....................................................................................................................... 7 3. MEASUREMENT UNCERTAINTY ................................................................................................................... 8 4. DESCRIPTION OF TEST MODES ................................................................................................................... 9 5. SYSTEM TEST CONFIGURATION ................................................................................................................ 10 5.1. CONFIGURATION OF TESTED SYSTEM ............................................................................................... 10 5.2. EQUIPMENT USED IN TESTED SYSTEM .............................................................................................. 10 5.3. SUMMARY OF TEST RESULTS .............................................................................................................. 10 6. TEST FACILITY ............................................................................................................................................... 11 7. PEAK OUTPUT POWER ................................................................................................................................ 12 7.1. MEASUREMENT PROCEDURE .............................................................................................................. 12 7.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................... 12 7.3. LIMITS AND MEASUREMENT RESULT .................................................................................................. 13 8. BANDWIDTH .................................................................................................................................................. 15 8.1. MEASUREMENT PROCEDURE .............................................................................................................. 15 8.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................... 15 8.3. LIMITS AND MEASUREMENT RESULTS ............................................................................................... 15 9. CONDUCTED SPURIOUS EMISSION........................................................................................................... 19 9.1. MEASUREMENT PROCEDURE .............................................................................................................. 19 9.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................... 19 9.3. MEASUREMENT EQUIPMENT USED .................................................................................................... 19 9.4. LIMITS AND MEASUREMENT RESULT .................................................................................................. 19 10. MAXIMUM CONDUCTED OUTPUT POWER SPECTRAL DENSITY ........................................................ 26 Report No.: AGC06164211202FE02 Page 4 of 42 10.1. MEASUREMENT PROCEDURE ............................................................................................................ 26 10.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................. 26 10.3. MEASUREMENT EQUIPMENT USED .................................................................................................. 26 10.4. LIMITS AND MEASUREMENT RESULT................................................................................................ 26 11. RADIATED EMISSION ................................................................................................................................. 28 11.1. MEASUREMENT PROCEDURE ............................................................................................................ 28 11.2. TEST SETUP .......................................................................................................................................... 29 11.3. LIMITS AND MEASUREMENT RESULT..............................................................................…

Text truncated - open the document above for the full version.

Report No.: AGC06164211202AP01 Page 1 of 2 TEST SETUP PHOTOS RADIATED EMISSION TEST SETUP BELOW 1GHz RADIATED EMISSION TEST SETUP ABOVE 1GHz Report No.: AGC06164211202AP01 Page 2 of 2 RF CONDUCTED TEST SETUP ****************************************End of Report*************************************
