1 Rover Mox 4G SMARTPHONE 2 Quick Start Guide 3 Dear Customer, Congratulations on becoming a proud owner of Rover product. Every Rover product goes through a rigorous process of sample evaluation and approval before commercial launch. We look forward to your patronage. It would be our pleasure to receive feedback and suggestions you may have for improvements in the product(s) you are using. SAFETY TIPS  Use of wireless hands-free system (headphone, headset) with a low power BT emitter.  Keep your calls short or send a text message (SMS) instead. This advice applies especially to children, adolescents and pregnant women.  Use cell phone when the signal quality is good.  People having active medical implants should preferably keep the cell phone at least 15 cm away from the implant. 4 Contents I. Warning ................................................................................................................................. 5 1 Safety information .................................................................................................................. 5 2 Cautions on mobile phone use ............................................................................................... 6 2.1 Interference ........................................................................................................................ 6 2.2 Reasonable use ................................................................................................................... 6 2.3 Qualified maintenance service ............................................................................................. 6 2.4 Water-resistance ................................................................................................................. 6 2.5 Emergency calls ................................................................................................................... 6 3 Precautions for use of battery ................................................................................................ 6 4 Cautions for children .............................................................................................................. 7 II. Appearance ........................................................................................................................... 7 III. Start to use ........................................................................................................................... 8 1 Insert SIM card ....................................................................................................................... 8 2 Insert Memory card ................................................................................................................ 8 3 Charge the battery ................................................................................................................. 8 IV. Basic functions ..................................................................................................................... 9 1 Lock and unlock the screen ..................................................................................................... 9 2 Make it yours ....................................................................................................................... 10 3 Make a call ........................................................................................................................... 13 4 Call log ................................................................................................................................. 14 5 Reject a call by SMS .............................................................................................................. 15 6 Add a contact ....................................................................................................................... 16 7 Send and Receive message(s) ............................................................................................... 17 8 Browser the Web ................................................................................................................. 17 5 9 Enjoy music .......................................................................................................................... 17 10 Download applications on Google Play ............................................................................... 18 11 Manage Applications .......................................................................................................... 18 12 Applications and Utility ....................................................................................................... 18 V. Technical Information ......................................................................................................... 19 I. Warning Please read the concise rules. The breach of the rules may result in danger or violation of law. 1 Safety information 1.1 Traffic safety first Please use the mobile phone carefully when you drive a car. Park your car at roadside and then use the mobile phone if the driving condition is bad. 1.2 Turn off in hospital Please abide by relevant provisions or regulations. Please turn off your mobile phone near medical equipment. 1.3 Turn off in airplane Wireless equipment has disturbance to the airplane, so the use of the mobile phone in airplane is dangerous and illegal. 6 1.4 Turn off when refueling Please don’t use the mobile phone in gas station or near fuels or chemicals. 1.5 Turn off near blasting sites Don’t use the mobile phone in blasting sites. Please observe relevant restrictions and carry out rules or regulations. 2 Cautions on mobile phone use 2.1 Interference All phones may be interfered, which affect phone calls. 2.2 Reasonable use Use only in the normal position. Do not touch the antenna area unnecessarily. 2.3 Qualified maintenance service Only qualified personnel may install or repair this product. 2.4 Water-resistance Your device is not water resistant. Keep it dry. 2.5 Emergency calls E…

Text truncated - open the document above for the full version.

WHOOP INTERNATIONAL TRADING LIMITED 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: WHOOP INTERNATIONAL TRADING LIMITED Address: Flat-B 8/F Chong Gming Building 72 Cheung Sha Wan Road, Kowloon, Hong Kong, China. Product Name: 4G SMARTPHONE FCC ID: 2AP7LMOX Model(s): MOX 2.911(d)(5)(i) Equipment Type We, [WHOOP INTERNATIONAL TRADING LIMITED] (“the applicant”) certify that the equipment for which authorization is sought through certification is not: • Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules. • Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: KANG PING Date: 2023.12.05 Title and Company name: Manager / WHOOP INTERNATIONAL TRADING LIMITED NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

WHOOP INTERNATIONAL TRADING LIMITED 2.911 (d)(5)(ii) Applicant Attestation v1.3 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: WHOOP INTERNATIONAL TRADING LIMITED Address: Flat-B 8/F Chong Gming Building 72 Cheung Sha Wan Road, Kowloon, Hong Kong, China. Product Name: 4G SMARTPHONE FCC ID: 2AP7LMOX Model(s): MOX 2.911(d)(5)(ii) Applicant filing We, [WHOOP INTERNATIONAL TRADING LIMITED] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: KANG PING Date: 2023.12.05 Title and Company name: Manager / WHOOP INTERNATIONAL TRADING LIMITED NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

WHOOP INTERNATIONAL TRADING LIMITED Agent Authorization Company: WHOOP INTERNATIONAL TRADING LIMITED Address: Flat-B 8/F Chong Gming Building 72 Cheung Sha Wan Road, Kowloon, Hong Kong Product Name: 4G SMARTPHONE Model Number(s): MOX Product Description: 4G SMARTPHONE FCC ID: 2AP7LMOX We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023.12.06 Name: Kang Ping Title: Manager Company: WHOOP INTERNATIONAL TRADING LIMITED

WHOOP INTERNATIONAL TRADING LIMITED Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023.12.06 Subject; Request for Confidentiality FCC ID: 2AP7LMOX To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES Part List In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: WHOOP INTERNATIONAL TRADING LIMITED Title: Manager

Page 1 of 9 Report No.: CTA231120008 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: MOX Photo 1 Photo 2 Page 2 of 9 Report No.: CTA231120008 Photo 3 Photo 4 Page 3 of 9 Report No.: CTA231120008 Photo 5 Photo 6 Page 4 of 9 Report No.: CTA231120008 Photo 7 Photo 8 Page 5 of 9 Report No.: CTA231120008 Photo 9 Photo 10 Page 6 of 9 Report No.: CTA231120008 Photo 11 Photo 12 Page 7 of 9 Report No.: CTA231120008 Photo 13 Photo 14 Page 8 of 9 Report No.: CTA231120008 Photo 15 Photo 16 Page 9 of 9 Report No.: CTA231120008 Photo 17

FCC Label Size：30mm*15mm 4G SMARTPHONE Model name: MOX FCC ID: 2AP7LMOX

Page 1 of 6 Report No.: CTA231120008 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: MOX Photo 1 Photo 2 2G/3G/4G Antenna LTE RX Antenna WiFi/BT Antenna Page 2 of 6 Report No.: CTA231120008 Photo 3 Photo 4 Page 3 of 6 Report No.: CTA231120008 Photo 5 Photo 6 Page 4 of 6 Report No.: CTA231120008 Photo 7 Photo 8 Page 5 of 6 Report No.: CTA231120008 Photo 9 Photo 10 Page 6 of 6 Report No.: CTA231120008 Photo 11 Photo 12

Page 1 of 190 FCC ID: 2AP7LMOX Report No.: LCSA11223028E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity SAR TEST REPORT For WHOOP INTERNATIONAL TRADING LIMITED 4G SMARTPHONE Test Model: MOX Prepared for : WHOOP INTERNATIONAL TRADING LIMITED Address : Flat-B 8/F Chong Gming Building 72 Cheung Sha Wan Road, Kowloon, Hong Kong, China. Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Date of receipt of test sample : Oct. 24, 2023 Number of tested samples : 1 Sample No. A11223028-1 Serial number : Prototype Date of Test : Oct. 26, 2023~ Nov. 13, 2023 Date of Report : Nov 25, 2023 Page 2 of 190 FCC ID: 2AP7LMOX Report No.: LCSA11223028E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity SAR TEST REPORT Report Reference No. ............... : LCSA11223028E Date Of Issue .............................. : Nov 25, 2023 Testing Laboratory Name ........ : Shenzhen LCS Compliance Testing Laboratory Ltd. Address ....................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Applicant’s Name ...................... : WHOOP INTERNATIONAL TRADING LIMITED Address ....................................... : Flat-B 8/F Chong Gming Building 72 Cheung Sha Wan Road, Kowloon, Hong Kong, China. Test Specification: Standard ...................................... : IEEE Std C95.1, 2019& IEEE Std 1528™-2013&FCC Part 2.1093 Test Report Form No. ................. : LCSEMC-1.0 TRF Originator ........................... : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF ................................. : Dated 2011-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes noresponsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test Item Description. .............. : 4G SMARTPHONE Trade Mark ................................. : ROVER Model/Type Reference ............... : MOX Operation Frequency ................... : GSM 850/PCS1900,WCDMA Band 2/4/5 ; LTE Band 2/4/5/12/13/25/26/41/66/71; WLAN2.4Gand Bluetooth4.2. Ratings ........................................ : Input: 5V1A For AC Adapter Input: 100-240V~, 50/60Hz, 0.3A Adapter Output: 5V1A DC 3.8V by Rechargeable Li-ion Battery, 3750mAh Result ......................................... : Positive Compiled by: Supervised by: Approved by: Jay Zhan / File administrators Cary Luo / Technique principal Gavin Liang/ Manager Page 3 of 190 FCC ID: 2AP7LMOX Report No.: LCSA11223028E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity SAR -- TEST REPORT Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCSA11223028E Nov 25, 2023 Date of issue Type / Model......................... : MOX EUT....................................... : 4G SMARTPHONE Applicant.............................. : WHOOP INTERNATIONAL TRADING LIMITED Address.................................. : Flat-B 8/F Chong Gming Building 72 Cheung Sha Wan Road, Kowloon, Hong Kong, China. Telephone.............................. : / Fax......................................... : / Manufacturer....................... : Shenzhen Teleone Technology Co., Ltd Address.................................. : Tower B 5/F, Shanshui Building, Nanshan Yungu Innovation Industry Park, 4093 Liuxian Avenue, Shenzhen, China Telephone.............................. : / Fax......................................... : / Factory.................................. : / Address.................................. : / Telephone.............................. : / Fax......................................... : / Page 4 of 190 FCC ID: 2AP7LMOX Report No.: LCSA11223028E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Revison History Revision Issue Date Revision Content Revised By 000 Nov 25, 2023 Initial Issue --- Page 5 of 190 FCC ID: 2AP7LMOX Report No.: LCSA11223028E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity TABLE OF CONTENTS 1. TEST STANDARDS AND TEST DESCRIPTION .....................................................................................................................6 1.1. TEST STANDARDS ..........................................................................................…

Text truncated - open the document above for the full version.

Page 96 of 190 FCC ID: 2AP7LMOX Report No.: LCSA11223028E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity #18 Test Mode: LTE Band 12, 1RB, Mid channel (Body Back Side) Product Description: 4G SMARTPHONE Model: MOX Test Date: Oct 26, 2023 Medium(liquid type) HSL _750 Frequency (MHz) 704 Relative permittivity (real part) 41.2 Conductivity (S/m) 0.86 E-Field Probe SN 25/22 EPGO376 Crest Factor 1.0 Conversion Factor 1.69 Sensor 4mm Area Scan dx=15mm dy=15mm Zoom Scan 5x5x7,dx=8mm dy=8mm dz=5mm Variation (%) -0.280000 SAR 10g (W/Kg) 0.243004 SAR 1g (W/Kg) 0.318863 SURFACE SAR VOLUME SAR Page 97 of 190 FCC ID: 2AP7LMOX Report No.: LCSA11223028E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity #19 Test Mode: LTE Band 13, 1RB, Mid channel(Head Left Cheek) Product Description: 4G SMARTPHONE Model: MOX Test Date: Oct 26, 2023 Medium(liquid type) HSL _750 Frequency (MHz) 782.0000 Relative permittivity (real part) 41.2 Conductivity (S/m) 0.86 E-Field Probe SN 25/22 EPGO376 Crest Factor 1.0 Conversion Factor 1.69 Sensor 4mm Area Scan dx=15mm dy=15mm Zoom Scan 5x5x7,dx=8mm dy=8mm dz=5mm Variation (%) -0.350000 SAR 10g (W/Kg) 0.288665 SAR 1g (W/Kg) 0.462287 SURFACE SAR VOLUME SAR Page 98 of 190 FCC ID: 2AP7LMOX Report No.: LCSA11223028E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity #20 Test Mode: LTE Band 13, 1RB, Mid channel(Body Back Side) Product Description: 4G SMARTPHONE Model: MOX Test Date: Oct 26, 2023 Medium(liquid type) HSL _750 Frequency (MHz) 782.0000 Relative permittivity (real part) 41.2 Conductivity (S/m) 0.86 E-Field Probe SN 25/22 EPGO376 Crest Factor 1.0 Conversion Factor 1.69 Sensor 4mm Area Scan dx=15mm dy=15mm Zoom Scan 5x5x7,dx=8mm dy=8mm dz=5mm Variation (%) 0.020000 SAR 10g (W/Kg) 0.147754 SAR 1g (W/Kg) 0.192424 SURFACE SAR VOLUME SAR Page 99 of 190 FCC ID: 2AP7LMOX Report No.: LCSA11223028E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity #21 Test Mode: LTE Band 25, 1RB, Mid channel(Head Left Cheek) Product Description: 4G SMARTPHONE Model: MOX Test Date: Nov 07, 2023 Medium(liquid type) HSL_1900 Frequency (MHz) 1882.5000 Relative permittivity (real part) 39.8 Conductivity (S/m) 1.41 E-Field Probe SN 25/22 EPGO376 Crest Factor 1.0 Conversion Factor 2.39 Sensor 4mm Area Scan dx=15mm dy=15mm Zoom Scan 5x5x7,dx=8mm dy=8mm dz=5mm Variation (%) -0.010000 SAR 10g (W/Kg) 0.122449 SAR 1g (W/Kg) 0.190993 SURFACE SAR VOLUME SAR #22 Page 100 of 190 FCC ID: 2AP7LMOX Report No.: LCSA11223028E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Mode: LTE Band 25, 1RB, Mid channel(Body Back Side) Product Description: 4G SMARTPHONE Model: MOX Test Date: Nov 07, 2023 Medium(liquid type) HSL_1900 Frequency (MHz) 1882.5000 Relative permittivity (real part) 39.8 Conductivity (S/m) 1.41 E-Field Probe SN 25/22 EPGO376 Crest Factor 1.0 Conversion Factor 2.39 Sensor 4mm Area Scan dx=15mm dy=15mm Zoom Scan 5x5x7,dx=8mm dy=8mm dz=5mm Variation (%) -0.010000 SAR 10g (W/Kg) 0.444208 SAR 1g (W/Kg) 0.832956 SURFACE SAR VOLUME SAR Page 101 of 190 FCC ID: 2AP7LMOX Report No.: LCSA11223028E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity #23 Test Mode: LTE Band 26, 1RB, Low channel(Head Left Cheek) Product Description: 4G SMARTPHONE Model: MOX Test Date: Oct 30, 2023 Medium(liquid type) HSL_835 Frequency (MHz) 831.5000 Relative permittivity (real part) 41.6 Conductivity (S/m) 0.94 E-Field Probe SN 25/22 EPGO376 Crest Factor 1.0 Conversion Factor 2.39 Sensor 4mm Area Scan dx=15mm dy=15mm Zoom Scan 5x5x7,dx=8mm dy=8mm dz=5mm Variation (%) -0.010000 SAR 10g (W/Kg) 0.203022 SAR 1g (W/Kg) 0.272352 SURFACE SAR VOLUME SAR Page 102 of 190 FCC ID: 2AP7LMOX Report No.: LCSA11223028E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity #24 Test Mode: LTE Band 26, 1RB, Low channel(Body Back Side) Product Description: 4G SMARTPHONE Model: MOX Test Date: Oct 30, 2023 Medium(liquid type) HSL_835 Frequency (MHz) 831.5000 Relative permittivity (real part) 41.6 Conductivity (S/m) 0.94 E-Field Probe SN 25/22 EPGO376 Crest Factor 1.0 Conversion Factor 2.39 Sensor 4mm Area Scan dx=15mm dy=15mm Zoom Scan 5x5x7,dx=8mm dy=8mm dz=5mm Variation (%) -0.010000 SAR 10g (W/Kg) 0.173760 SAR 1g (W/Kg) 0.230332 SURFACE SAR VOLUME SAR Page 103 of 190 FCC ID: 2AP7LMOX Report No.: LCSA11223028E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industr…

Text truncated - open the document above for the full version.

Report No: CTA231120008W04_Appendix GSM 1 15 Peak-to-Average Ratio Band Channel Frequency (MHz) Result (dB) high Limit (dB) Verdict EGPRS1900 512 1850.2 6.758858131 13.00 PASS EGPRS1900 661 1880 6.560812183 13.00 PASS EGPRS1900 810 1909.8 6.977403846 13.00 PASS EGPRS850 128 824.2 9.087571802 13.00 PASS EGPRS850 190 836.6 8.865498489 13.00 PASS EGPRS850 251 848.8 9.107694444 13.00 PASS EGPRS1900 Channel=512 EGPRS1900 Channel=661 Report No: CTA231120008W04_Appendix GSM 2 EGPRS1900 Channel=810 EGPRS850 Channel=128 Report No: CTA231120008W04_Appendix GSM 3 EGPRS850 Channel=190 EGPRS850 Channel=251 Report No: CTA231120008W04_Appendix GSM 4 16 Occupied bandwidth Band Channel Frequency (MHz) 99% OBW (kHz) -26dB EBW (kHz) Verdict EGPRS1900 512 1850.2 239.093 293.088 PASS EGPRS1900 661 1880 247.514 306.582 PASS EGPRS1900 810 1909.8 240.391 313.424 PASS EGPRS850 128 824.2 251.017 314.163 PASS EGPRS850 190 836.6 247.901 314.228 PASS EGPRS850 251 848.8 237.469 299.389 PASS EGPRS1900 Channel=512 Report No: CTA231120008W04_Appendix GSM 5 EGPRS1900 Channel=661 EGPRS1900 Channel=810 Report No: CTA231120008W04_Appendix GSM 6 EGPRS850 Channel=128 EGPRS850 Channel=190 Report No: CTA231120008W04_Appendix GSM 7 EGPRS850 Channel=251 17 Band edge Report No: CTA231120008W04_Appendix GSM 8 Band Channel Frequency (MHz) Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict EGPRS1900 512 1850.2 1849.99 -36.97 -13 PASS EGPRS1900 810 1909.8 1910.02 -35.93 -13 PASS EGPRS850 128 824.2 823.99 -35.07 -13 PASS EGPRS850 251 848.8 849.02 -32.62 -13 PASS EGPRS1900 Channel=512 EGPRS1900 Channel=810 Report No: CTA231120008W04_Appendix GSM 9 EGPRS850 Channel=128 EGPRS850 Channel=251 Report No: CTA231120008W04_Appendix GSM 10 18 Out-of-band emissions Band Channel Frequency (MHz) Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict EGPRS1900 512 1850.2 19026.46 -24.00 -13 PASS EGPRS1900 661 1880 16325.52 -24.39 -13 PASS EGPRS1900 810 1909.8 19044.93 -22.37 -13 PASS EGPRS850 128 824.2 6206.91 -29.09 -13 PASS EGPRS850 190 836.6 6223.11 -29.61 -13 PASS EGPRS850 251 848.8 5761.25 -29.02 -13 PASS EGPRS1900 Channel=512 Report No: CTA231120008W04_Appendix GSM 11 EGPRS1900 Channel=661 EGPRS1900 Channel=810 Report No: CTA231120008W04_Appendix GSM 12 EGPRS850 Channel=128 EGPRS850 Channel=190 Report No: CTA231120008W04_Appendix GSM 13 EGPRS850 Channel=251 09 Peak-to-Average Ratio Report No: CTA231120008W04_Appendix GSM 14 Band Channel Frequency (MHz) Result (dB) high Limit (dB) Verdict GPRS1900 512 1850.2 2.847317708 13.00 PASS GPRS1900 661 1880 2.835997537 13.00 PASS GPRS1900 810 1909.8 2.839113514 13.00 PASS GPRS850 128 824.2 2.756363636 13.00 PASS GPRS850 190 836.6 2.760017825 13.00 PASS GPRS850 251 848.8 2.759661538 13.00 PASS GPRS1900 Channel=512 GPRS1900 Channel=661 Report No: CTA231120008W04_Appendix GSM 15 GPRS1900 Channel=810 GPRS850 Channel=128 Report No: CTA231120008W04_Appendix GSM 16 GPRS850 Channel=190 GPRS850 Channel=251 Report No: CTA231120008W04_Appendix GSM 17 10 Occupied bandwidth Band Channel Frequency (MHz) 99% OBW (kHz) -26dB EBW (kHz) Verdict GPRS1900 512 1850.2 250.917 316.839 PASS GPRS1900 661 1880 243.354 318.137 PASS GPRS1900 810 1909.8 244.572 315.951 PASS GPRS850 128 824.2 246.763 314.632 PASS GPRS850 190 836.6 249.202 327.821 PASS GPRS850 251 848.8 244.801 319.826 PASS GPRS1900 Channel=512 Report No: CTA231120008W04_Appendix GSM 18 GPRS1900 Channel=661 GPRS1900 Channel=810 Report No: CTA231120008W04_Appendix GSM 19 GPRS850 Channel=128 GPRS850 Channel=190 Report No: CTA231120008W04_Appendix GSM 20 GPRS850 Channel=251 11 Band edge Report No: CTA231120008W04_Appendix GSM 21 Band Channel Frequency (MHz) Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict GPRS1900 512 1850.2 1849.98 -29.52 -13 PASS GPRS1900 810 1909.8 1910.03 -29.83 -13 PASS GPRS850 128 824.2 823.98 -27.19 -13 PASS GPRS850 251 848.8 849.02 -26.24 -13 PASS GPRS1900 Channel=512 GPRS1900 Channel=810 Report No: CTA231120008W04_Appendix GSM 22 GPRS850 Channel=128 GPRS850 Channel=251 Report No: CTA231120008W04_Appendix GSM 23 12 Out-of-band emissions Band Channel Frequency (MHz) Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict GPRS1900 512 1850.2 18962.06 -23.91 -13 PASS GPRS1900 661 1880 16526.72 -23.02 -13 PASS GPRS1900 810 1909.8 16585.63 -23.65 -13 PASS GPRS850 128 824.2 3199.46 -29.07 -13 PASS GPRS850 190 836.6 5377.16 -29.02 -13 PASS GPRS850 251 848.8 2572.60 -28.71 -13 PASS GPRS1900 Channel=512 Report No: CTA231120008W04_Appendix GSM 24 GPRS1900 Channel=661 GPRS1900 Channel=810 Report No: CTA231120008W04_Appendix GSM 25 GPRS850 Channel=128 GPRS850 Channel=190 Report No: CTA231120008W04_Appendix GSM 26 GPRS850 Channel=251 03 Peak-to-Average Ratio Report No: CTA231120008W04_Appendix GSM 27 Band Channel Frequency (MHz) Result (dB) high Limit (dB) Verdict GSM1900 512 1850.2 2.79 13 PASS GSM1900 661 1880 2.80 13 PASS GSM1900 810 1909.8 2.80 13 PASS GSM850 128 824.2 2.76 13 PASS GSM850 190 836.6 2.72 13 PASS GSM850 251 848.8 2.72 13 PASS GSM1900 Channel=512 GSM1900 Channel=661 Report No: CTA231120008W04_Appendix GSM 28 GSM1900 Channel=810 GSM850 Channel=128 Report No: CTA231120008W04_Appendix GSM 29 GSM850 Channel=190 GSM850 Channel=251 Report No: CTA231120008W04_Appendix GSM 30 04 Occupied bandwidth Band Channel Frequency (MHz) 99% OBW (kHz) -26dB EBW (kHz) Verdict GSM1900 512 1850.2 247.830 315.184 PASS GSM1900 661 1880 245.386 310.625 PASS GSM1900 810 1909.8 247.060 315.912 PASS GSM850 128 824.2 249.286 314.288 PASS GSM850 190 836.6 248.165 313.832 PASS GSM850 251 848.8 248.809 315.106 PASS GSM1900 Channel=512 Report No: CTA231120008W04_Appendix GSM 31 GSM1900 …
