2AP7LR1010.1 inch Quad Core 4G Tablet PC

510W/kg. This 10.1 inch Quad Core 4G Tablet PC

WHOOP INTERNATIONAL TRADING LIMITED Covered Equipment Certification Attestation Letter 3/27/2023 ATTN.: Reviewing Engineer FCC ID: 2AP7LR10 WHOOP INTERNATIONAL TRADING LIMITED (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. WHOOP INTERNATIONAL TRADING LIMITED (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Kang Ping Title: President Company Name: WHOOP INTERNATIONAL TRADING LIMITED Date: 3/27/2023

JOC Australia Inc * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 3/29/2023 ATTN.: Reviewing Engineer Per section 2.911(d)(7) of the FCC rules, WHOOP INTERNATIONAL TRADING LIMITED (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: JOC Australia Inc Physical U.S. Company Address: 18351 Colima Road Ste 585 Rowland Heights, California, 91748 United States of America Agent contact name/Title : Benjamin.Smith/Vice President Agent Email Address: [email protected]/[email protected] Tel No.: +1(626) 217 4778 FRN No.: 0033379421 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Agent Signed (if different to Applicant): Signed: Signed: Printed name: Kang Ping Printed name: Benjamin. Smith Title: President Title: Vice President Company Name: WHOOP INTERNATIONAL Company Name: JOC Australia Inc TRADING LIMITED Date: 3/29/2023 Date: 3/29/2023

WHOOP INTERNATIONAL TRADING LIMITED Agent Authorization Company: WHOOP INTERNATIONAL TRADING LIMITED Address: Flat-B 8/F Chong Gming Building 72 Cheung Sha Wan Road, Kowloon, Hong Kong Product Name: 10.1 inch Quad Core 4G Tablet PC Model Number(s): R10 Product Description: 10.1 inch Quad Core 4G Tablet PC FCC ID: 2AP7LR10 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023.03.27 Name: Kang Ping Title: Manager Company: WHOOP INTERNATIONAL TRADING LIMITED

WHOOP INTERNATIONAL TRADING LIMITED Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023.03.27 Subject; Request for Confidentiality FCC ID: 2AP7LR10 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES Part List In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: WHOOP INTERNATIONAL TRADING LIMITED Title: Manager

Page 1 of 5 Report No.: STS2301306 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: R10 Photo 1 Photo 2 Page 2 of 5 Report No.: STS2301306 Photo 3 Photo 4 Page 3 of 5 Report No.: STS2301306 Photo 5 Photo 6 Page 4 of 5 Report No.: STS2301306 Photo 7 Photo 8 Page 5 of 5 Report No.: STS2301306 Photo 9 Photo 10

FCC Label 10.1 inch Quad Core 4G Tablet PC Model name: R10 FCC ID: 2AP7LR10 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 50mm 40mm

Page 1 of 5 Report No.: STS2301306 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: R10 Photo 1 Photo 2 4G RX ANT 2G/3G/4G Antenna BT/2.4/5.2GWIFI ANT Antenna Page 2 of 5 Report No.: STS2301306 Photo 3 Photo 4 Page 3 of 5 Report No.: STS2301306 Photo 5 Photo 6 Page 4 of 5 Report No.: STS2301306 Photo 7 Photo 8 Page 5 of 5 Report No.: STS2301306 Photo 9

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No.: STS2301306H01 Issued for WHOOP INTERNATIONAL TRADING LIMITED Flat-B 8/F Chong Gming Building 72 Cheung Sha Wan Road, Kowloon, Hong Kong Product Name: 10.1 inch Quad Core 4G Tablet PC Brand Name: ROVER Model Name: R10 Series Model: N/A FCC ID: 2AP7LR10 Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 Max. Report SAR (1g): Body: 1.510 W/kg S T L A B S Page 2 of 85 Report No.: STS2301306H01 Test Report Certification Applicant’s name ................. : WHOOP INTERNATIONAL TRADING LIMITED Address ................................. : Flat-B 8/F Chong Gming Building 72 Cheung Sha Wan Road, Kowloon, Hong Kong Manufacturer's Name .......... : Shenzhen Teleone Technology Co., Ltd Address ................................. : Tower B 5/F, Shanshui Building, Nanshan Yungu Innovation Industry Park, 4093 Liuxian Avenue, Shenzhen, China Product description Product name ........................ : 10.1 inch Quad Core 4G Tablet PC Brand name ......................... : ROVER Model name ......................... : R10 Series Model .......................... : N/A Standards ............................. : ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test ........................................... : Date (s) of performance of tests ............. : 28 Feb. 2023 ~ 06 Mar. 2023 Date of Issue .......................................... : 08 Mar. 2023 Test Result.............................................. : Pass Testing Engineer : (Shifan. Long) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 85 Report No.: STS2301306H01 Table of Contents 1. General Information 5 1.1 EUT Description 5 1.2 Test Environment 7 1.3 Test Factory 7 2. Test Standards and Limits 8 3. SAR Measurement System 9 3.1 Definition of Specific Absorption Rate (SAR) 9 3.2 SAR System 9 4. Tissue Simulating Liquids 12 4.1 Simulating Liquids Parameter Check 12 5. SAR System Validation 15 5.1 Validation System 15 5.2 Validation Result 15 6. SAR Evaluation Procedures 16 7. EUT Antenna Location Sketch 17 7.1 SAR test exclusion consider table 18 8. EUT Test Position 23 8.1 Body-worn Position Conditions 23 9. Uncertainty 24 9.1 Measurement Uncertainty 24 10. Conducted Power Measurement 25 10.1 Test Result 25 11. EUT and Test Setup Photo 43 11.1 EUT Photo 43 11.2 Setup Photo 46 12. SAR Result Summary 49 12.1 Body-worn and Hotspot SAR 49 13. Equipment List 59 Appendix A. System Validation Plots 60 Appendix B. SAR Test Plots 72 Appendix C. Probe Calibration and Dipole Calibration Report 85 Page 4 of 85 Report No.: STS2301306H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 08 Mar. 2023 STS2301306H01 ALL Initial Issue Page 5 of 85Report No.: STS2301306H01 1.General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Product Name 10.1 inch Quad Core 4G Tablet PC Brand Name ROVER Model Name R10 Series Model N/A Model Difference N/A Battery Rated Voltage:3.8V Charge Limit Voltage: 4.35V Capacity: 5100mAH Device Category Portable Product stage Production unit RF Exposure Environment General Population / Uncontrolled Hardware Version J865_610&310_D3EF_V1.1 Software Version ROVER_R10_12_V01_20221229 Frequency Range GSM 850: 824 MHz ~ 849 MHz PCS1900: 1850 MHz ~ 1910 MHz WCDMA Band II: 1850 MHz ~ 1910 MHz WCDMA Band V: 824 MHz ~ 849 MHz LTE Band 2: 1850 MHz ~ 1910 MHz LTE Band 4: 1710 MHz ~ 1755 MHz LTE Band 5: 824 MHz ~ 849 MHz LTE Band 12: 699 MHz ~ 716 MHz LTE Band 66: 1710 MHz ~ 1780 MHz WLAN802.11b/g/n20: 2412 MHz ~ 2462 MHz WLAN 802.11a/n20/n40/ac20/ac40/ac80: 5150 ~ 5250 MHz Bluetooth: 2402 MHz to 2480 MHz Max. Reported SAR(1g): (Limit:1.6W/kg) Band Mode Body Worn and Hotspot(W/kg) PCE GSM 850 0.728 PCE GSM 1900 1.510 PCE WCDMA Band II 1.273 PCE WCDMA Band V 1.194 PCE WCDMA Band lV 1.218 PCE LTE Band 2 0.938 PCE LTE Band 4 0.685 PCE LTE Band 5 1.034 PCE LTE Band 12 1.113 PCE LTE Band 66 1.032 DTS 2.4G WLAN 0.309 DSS BT 0.042 NII 5.2G WLAN 0.436 1-g Sum SAR1.577 FCC Equipment Class Licensed Portable Transmitter Held to Ear (PCE) Part 15 Spread Spectrum Transmitter (DSS) Digital Transmission System (DTS) Unlicensed National Information Infrastructure TX(NII) Page 6 of 85 Report No.: STS2301306H01 Operating Mode: GSM: GPRS/EGPRS Class 12 WCDMA: RMC, HSDPA, HSUPA Release 6 LTE: QPSK, 16QAM 2.4G WLAN : 802.11b(DSSS):CCK,DQPSK,DBPSK 802.11g(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM 5G WLAN: 802.11a(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11ac(OFDM):BPSK,QPSK,16-QAM,64-QAM,256-QAM Bluetooth: GFSK +π/4DQPSK+8DPSK BLE: GFSK Antenna Specification: GSM/WCDMA/LTE: PIFA Antenna Bluetooth: PIFA Antenna WLAN: PIFA Antenna SIM Card Support dual-SIM, dual standby, the multiple SIM card with two lines cannot transmitting at the same time Hotspot Mode Support DTM Mode Not Suppor…

Text truncated - open the document above for the full version.

Page: 1/10 Ref : ACR.60.17.23.MVGB.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F, BUILDING 2, ZHUOKE SCIENCE PARK, CHONGQING ROAD FUYONG, BAO’ AN DISTRICT, SHENZHEN,CHINA MVG COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 07/21 EPGO352 Calibrated at MVG Z.I. de la pointe du diable Technopôle Brest Iroise – 295 avenue Alexis de Rochon 29280 PLOUZANE - FRANCE Calibration date: 02/24/2023 Accreditations #2-6789 and #2-6814 Scope available on www.cofrac.fr Summary: This document presents the method and results from an accredited COMOSAR E-Field Probe calibration performed at MVG, using the CALIPROBE test bench, for use with a MVG COMOSAR system only. The test results covered by accreditation are traceable to the International System of Units (SI). COMOSAR E-Field Probe Calibration Report COMOSAR E-FIELD PROBE CALIBRATION REPORT Page: 3/10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vH This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Linearity ________________________________________________________________ 4 3.2 Sensitivity _______________________________________________________________ 5 3.3 Lower Detection Limit _____________________________________________________ 5 3.4 Isotropy _________________________________________________________________ 5 3.1 Boundary Effect __________________________________________________________ 5 4 Measurement Uncertainty .......................................................................................... 6 5 Calibration Measurement Results .............................................................................. 6 5.1 Sensitivity in air __________________________________________________________ 6 5.2 Linearity ________________________________________________________________ 7 5.3 Sensitivity in liquid ________________________________________________________ 8 5.4 Isotropy _________________________________________________________________ 9 6 List of Equipment .................................................................................................... 10 Ref: ACR.60.17.23.MVGB.A COMOSAR E-FIELD PROBE CALIBRATION REPORT Page: 4/10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vH This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer MVG Model SSE2 Serial Number SN 07/21 EPGO352 Product Condition (new / used) Used Frequency Range of Probe 0.15 GHz-6GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.227 M Dipole 2: R2=0.203 M Dipole 3: R3=0.195 M 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION MVG’s COMOSAR E field Probes are built in accordance to the IEEE 1528, FCC KDB865664 D01, CENELEC EN62209 and CEI/IEC 62209 standards. Figure 1 – MVG COMOSAR Dosimetric E field Dipole Probe Length 330 mm Length of Individual Dipoles 2 mm Maximum external diameter 8 mm Probe Tip External Diameter 2.5 mm Distance between dipoles / probe extremity 1 mm 3 MEASUREMENT METHOD The IEEE 1528, FCC KDB865664 D01, CENELEC EN62209 and CEI/IEC 62209 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their affect. All calibrations / measurements performed meet the fore mentioned standards. 3.1 LINEARITY The evaluation of the linearity was done in free space using the waveguide, performing a power sweep to cover the SAR range 0.01W/kg to 100W/kg. Ref: ACR.60.17.23.MVGB.A COMOSAR E-FIELD PROBE CALIBRATION REPORT Page: 5/10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vH This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 3.2 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards. 3.3 LOWER DETECTION LIMIT The lower detection limit was assessed using the same measurement set up as used for the linearity measurement. The required lower detection limit is 10 mW/kg. 3.4 ISOTROPY The axial isotropy was evaluated by exposing the probe to a reference wave from a standard dipole with the dipole mounted under the flat phantom in the test configuration suggested for system validations and checks. The probe was rotated along its main axis from 0 to 360 degrees in 15- degree steps. The hemispherical isotropy is determined by inserting the probe in a thin plastic box filled with tissue-equivalent liquid, with the plastic box illuminated with the fields from a half wave dipole. The dipole is rotated about its axis (0°–180°) in 15° increments. At each step the probe is rotated about its axis (0°–360°). 3.1 BOUNDARY EFFECT The boundary effect is defined as the deviation between the SAR measured data and the expected exponential decay in the liquid when the probe is oriented normal to the interface. To evaluate this effect, the liquid …

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC Part 15B TEST REPORT Report No.: STS2301306E01 Issued for WHOOP INTERNATIONAL TRADING LIMITED Flat-B 8/F Chong Gming Building 72 Cheung Sha Wan Road, Kowloon, Hong Kong Product Name: 10.1 inch Quad Core 4G Tablet PC Brand: ROVER Model Number: R10 Series Model(s): N/A FCC ID: 2AP7LR10 Test Standard: FCC 47 CFR Part 15: Subpart B S T L A B S Page 2 of 21 Report No.: STS2301306E01 TEST RESULT CERTIFICATION Applicant’s Name .................: WHOOP INTERNATIONAL TRADING LIMITED Address ..................................: Flat-B 8/F Chong Gming Building 72 Cheung Sha Wan Road, Kowloon, Hong Kong Manufacture's Name ............: Shenzhen Teleone Technology Co., Ltd Address ..................................: Tower B 5/F, Shanshui Building, Nanshan Yungu Innovation Industry Park, 4093 Liuxian Avenue, Shenzhen, China Product Description .............: Product Name ........................: 10.1 inch Quad Core 4G Tablet PC Brand ....................................: ROVER Model Number ........................: ... : R10 Series Model(s) ......................: N/A Standards..............................: FCC 47 CFR Part 15: Subpart B Test Procedure.....................: ANSI C63.4-2014 This device described above has been tested by STS, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test .......................................... : Date of Receipt of Test Item ................... : 09 Jan. 2023 Date of Performance of Tests ............... : 09 Jan. 2023 ~ 09 Feb. 2023 Date of Issue ........................................ : 09 Feb. 2023 Test Result ........................................... : Pass Testing Engineer : (Jane Chen) Technical Manager : (Bulun) Authorized Signatory : (Bovey Yang) Page 3 of 21 Report No.: STS2301306E01 Table of Contents 1. SUMMARY OF THE TEST RESULTS 5 1.1 TEST FACTORY 5 1.2 MEASUREMENT UNCERTAINTY 5 2. GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF THE EUT 6 2.2 DESCRIPTION OF THE TEST MODES 8 2.3 DESCRIPTION OF THE TEST SETUP 9 2.4 EQUIPMENTS LIST FOR ALL TEST ITEMS 10 3. EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.2 RADIATED EMISSION MEASUREMENT 15 Page 4 of 21 Report No.: STS2301306E01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 09 Feb. 2023 STS2301306E01 ALL Initial Issue Page 5 of 21 Report No.: STS2301306E01 1. SUMMARY OF THE TEST RESULTS Test procedures according to the technical standards: EMISSION Standard Item Result Remarks FCC 47 CFR Part 15 Subpart B Conducted Emission PASS Meet Class B limit Radiated Emission PASS Meet Class B limit NOTE: (1) N/A=Not Applicable. 1.1 TEST FACTORY Company Name: SHENZHEN STS TEST SERVICES CO.,LTD. Address: A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China Telephone: +86-755 3688 6288 Fax: +86-755 3688 6277 Registration No.: FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission (9KHz-150KHz) ±2.14dB 2 Conducted Emission (150KHz-30MHz) ±2.54dB 3 All emissions,radiated(<1G) 30MHz-1000MHz ±3.94dB 4 All emissions,radiated(>1G) 1GHz-6GHz ±4.59dB 5 All emissions,radiated(>1G) 6GHz-18GHz ±5.22dB Page 6 of 21 Report No.: STS2301306E01 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name 10.1 inch Quad Core 4G Tablet PC Brand ROVER Model Number R10 Series Model(s) N/A Model Difference N/A Frequency Bands GSM 850: 824~849MHz 1900: 1850~1910MHz WCDMA Band II: 1850~1910MHz Band IV: 1710~1755MHz Band V: 824~849MHz LTE Band 2: 1850~1910MHz Band 4: 1710~1755MHz Band 5: 824~849MHz Band 12: 699~716MHz Band 66: 1710~1780MHz Bluetooth 2402~2480MHz 2.4G WLAN 802.11b/g/n 20: 2412~2462 MHz 5G WLAN IEEE 802.11a/ n(HT20)/ac(VHT20): 5.180GHz-5.240GHz IEEE 802.11n(HT40)/ac(VHT40): 5.190GHz-5.230GHz IEEE 802.11ac(VHT80): 5.210GHz Modulation Mode GSM GMSK for GPRS; GMSK and 8PSK for EDGE WCDMA WCDMA: QPSK; HSDPA:QPSK/16QAM; HSUPA:BPSK LTE QPSK/16QAM; Bluetooth GFSK(1Mbps) BLE GFSK 2.4G WLAN 802.11b(DSSS):CCK,DQPSK,DBPSK 802.11g(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM 5G WLAN 802.11a(OFDM): BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM): BPSK,QPSK,16-QAM,64-QAM 802.11ac(OFDM): BPSK,QPSK,16-QAM,64-QAM,256-QAM Adapter Input: AC 100-240V, 0.3A, 50-60Hz Output: DC 5V, 1500mA Battery Rated Voltage:3.8V Charge Limit Voltage: 4.35V Capacity: 5100mAH Hardware Version Number J865_610&310_D3EF_V1.1 Page 7 of 21 Report No.: STS2301306E01 Software Version Number ROVER_R10_12_V01_20221229 Note: For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Page 8 of 21 Report No.: STS2301306E01 2.2 DESCRIPTION OF THE TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration m…

Text truncated - open the document above for the full version.

第 1 页 Specification of R10 antenna Customer Specs R10 Part Number AW006-PD005D-021-A0 AW006-PD005D-022-A0 AW006-PD005D-023-A0 Frequency Band GSM2/3/5/8/W2/4/5/FDD2/4/5/12/17/66/71 Color Black Edition REV:A0 Salesperson Design Structure Confirm Date Signing Date Customer confirmation: Join hands to create the future 第 2 页 Contents 一、Product specification 二、Electrical performance 1.specification standards 2.The matching circuit of the antenna 三、Parameter testing 1.Test setup 2.Test result 四、Setup for active testing 1.Test site 2.Test result 3.Environmental enrichment 五、Structural drawings 第 3 页 一、Product specification The report mainly provides the parameter test of R10 antenna performance. The antenna is 4G antenna 图1 R10 Ant 二、Electrical performance 1.specification standards The working frequency band of R10 antenna is 700M~960M and 1700M~2700M the resonance occurs in this frequency band. 2.The matching circuit of the antenna The structure of the antenna: FPC （Matching circuit）： 第 4 页 三、Parameter testing 1.Test setup The VSWR test device is connected in turn: E5071B network analyzer→50 ohm coaxial Cable→110mmcopper pipe→test fixture Treatment of test fixtures： A hard cable is used to lead out the SMA-J connector from the 50 ohm test point of the antenna on the tablet PCB, which is connected with the copper tube with a choke, and then connected to other devices in turn 2.Test result all going well 四、Setup for active testing The active test device is connected in turn Agilent8960→50ohm coaxial Cable→Satimo SG16test system→The tablet to be tested 第 5 页 1.Test site AW Microwave anechoic chamber: The test frequency range is 400MHz—6GHz,The range of static zone is 40cm circle,The reflectivity is less than -90 dB 2.Test result The maximum radiated power and the maximum receiving sensitivity reflect the maximum radiated power and the best receiving performance of the antenna in the whole radiated space.TRP and TIS reflect the average radiated power and average receiving sensitivity of the antenna, that is, the overall receiving performance of the antenna. Channel TRP（dBm） TIS（dBm） FDD B2 L 19.6 M 19.6 H 19.33 -92.35 FDD B4 L 19.5 M 19.85 H 19.2 -92.4 FDD B5 L 19.3 M 19.38 H 19.4 -90.46 FDD B12 L 17.1 M 17.2 H 17.42 -90.16 FDD B17 L 17.2 M 17.24 H 17.4 -90.32 FDD B66 L 18.4 M 18.65 H 18.5 -91.34 FDD B71 L 16.47 M 16.7 H 16.86 -90.2 第 6 页 Channel TRP（dBm） TIS（dBm） WCDMA B2 L 19.44 M 19.33 H 19.4 -105.35 WCDMA B4 L 18.4 M 18.38 H 18.2 -105.4 WCDMA B5 L 19.45 M 19.5 H 19.5 -104.6 GSM 850 L 28.3 M 28.5 H 29.42 -104.16 PCS 1900 L 26.7 M 25.48 H 25.38 -104.34 第 7 页 WIFI efficiency： frequency(MHz) gain(dBi) mingain(dBi) efficiency(dBi) efficiency(%) 2400 -1.05 -21.21 -5.56 27.82 2450 1.80 -26.56 -4.2 38.04 2500 0.79 -30.43 -4.78 33.25 5100 1.17 -30.89 -6.61 21.84 5200 2.30 -33.38 -5.54 27.90 5300 2.14 -33.15 -5.34 29.21 5500 1.79 -30.43 -4.78 33.25 5700 -0.86 -26.69 -6.85 20.65 5800 -0.22 -28.67 -6.47 22.52 第 8 页 Environmental enrichment： 第 9 页 五、structural drawings 第 10 页 第 11 页

R10_JBP Setup photo RE (Below 1GHz) RE (Above 1GHz) CE

2AP7LR10_SAR Setup photos Body Back side(separation distance is 0mm) Body Left side(separation distance is 0mm) Body Right Side (separation distance is 0mm) Body Top Side (separation distance is 0mm) Body Bottom Side (separation distance is 0mm)
