2AP8SK28RLASER RANGEFINDER

OWNERS MANUAL KILO ® KILO2800™ 6x22 mm LASER RANGEFINDER WITH BALLISTIC DATA XCHANGE™ KILO ® 2.0 2.0 2 3 sigsauer.com INTRODUCTION Congratulations on the purchase of your SIG SAUER ® Laser Rangefinder. Your KILO ® is one of the most compact, advanced and simple to use rangefinders on the market. All of SIG SAUER’s rangefinders feature the fastest digital signal processing engine while streamlining the user interface for a no hassle, out of box experience. TABLE OF CONTENTS Please visit sigsauer.com for Owners Manual downloads, or download to your Smart device with the SIG BDX App. Introduction ........................................................3 Contents ..........................................................4 Key Features .......................................................5 Product Identification ................................................6 Operation ........................................................20 Display Information .................................................25 Changing Modes of Operation ........................................27 Programming Sequence .............................................28 Frequently Asked Questions (FAQs) ....................................46 Specifications .....................................................48 SIG SAUER ® Electro-Optics Infinite Guarantee ® / Limited Lifetime Warranty .....54 SIG SAUER Electronic Component Limited 5-Year Warranty .................56 Scan mode refreshes at ultra-fast 4x/second Twist eyecup for individualized, custom fit Rear-loading CR2 Battery Compact form factor easily fits in pocket 4 5 sigsauer.com KEY FEATURES: • SIG SAUER’S Patent Pending Ballistic Data Xchange™ Technology utilizes, low energy Bluetooth with embedded Applied Ballistics Ultralight and the free BDX™ App to sync custom gun profiles and environmental conditions to your KILO ® and pair your KILO to any BDX enabled riflescope or sight for shots out to 800 meters. • 6x22 mm monocular with SpectraCoat™ anti-reflection coatings for superior light transmission and optical clarity. • Revolutionary Lightwave™ DSP Technology for the fastest and longest distance rangefinder engine. • HyperScan provides 4 range updates per second in scan mode while RangeLock reports the last range result when ranging distant targets. • Features line of sight or angle modified range. Units in yards or meters to tenth Y/M resolution. • Projected, segmented transparent OLED display for daytime and low light use. • Lumatic TM Display automatically calibrates display brightness to changing ambient light conditions. • Compact, aluminum housing and eyecup with integral diopter adjustment. • Simplified user interface with RANGE and MODE buttons only. • Rangefinder configuration can now be done through the free SIG BDX™ App. • Displays windage and elevation within KILO HUD for every target that is scanned. • BDX 2.0® with 8 onboard, embedded ballistic groups along with QuickBOND® to bond your KILO with a SIERRA riflescope without having to use the BDX App. CONTENTS: • KILO2800™ Digital Laser Rangefinder • CR2 Battery (1) • Premium Padded Ballistic Nylon Case • Lanyard • Quick Start Guide • Ballistic Group Card 6 7 sigsauer.com LIGHTWAVE™ DSP TECHNOLOGY SIG SAUER’s proprietary Lightwave DSP engine leverages HyperScan – an advanced power management technique that provides the fastest refresh rate in scan mode (4 times per second) even at distances up to a mile. Our DSP engine uses the latest generation field programmable gate array (FPGA) running sophisticated signal processing algorithms to reduce false positives while finding weak or distant targets. RANGING ACCURACY, RESOLUTION AND MAXIMUM RANGES The KILO2800™ provides line of sight or angle modified range information accurate to ±0.5 yards or meters out to 500 yards; ±1 yard from 500 - 1000 yards and ±2 yards beyond 1000 yards. Range is displayed in 0.1 yard or meter resolution. RANGING PERFORMANCE IN HYPERSCAN MODE ReflectiveTreesDeer KILO2800Up to 2,800 ydsUp to 1,500 ydsUp to 1,200 yds PRODUCT IDENTIFICATION: A- Power / Range Button B- Eyecup / Diopter Focus Adjustment C- Mode Button D- Battery Compartment E- Lanyard Attachment Point A B C E D 8 9 sigsauer.com SIG SAUER BALLISTIC DATA XCHANGE 2.0 (BDX 2.0) SIG SAUER’s Patent Pending BDX system takes the guesswork out of determining the proper range and ballistics solution for hitting your target with the first round. Low Energy Bluetooth combined with an embedded ballistic calculator (Applied Ballistics Ultralight) allows the user to configure up to 25, custom bullet profiles on the free BDX App and sync to your KILO. Line of sight range, elevation and wind hold information is calculated instantly and displayed based on the active profile. When combined with one of SIG SAUER’s BDX enabled riflescopes, the user ranges a target and the firing solution is instantly shared with the BDX riflescope where the holdover dot is selectively illuminated. BDX 2.0 has several new features for customers that want to get up and running without using the BDX smartphone App. Your KILO has 8 embedded ballistic groups. The first 6 groups are for centerfire rifles. Group 1 is the flattest shooting group with the least amount of drop. As the group numbers increase, so does the bullet drop. Using the included Ballistic Groups card, locate your caliber from the provided list. If your rounds are impacting low then move to a higher numbered group. If your rounds are impacting high then move to a lower numbered group. Group 7 represents common muzzleloaders and Group 8 represents an average crossbow. You can access these ballistic groups through the normal rangefinder configuration process by turning on the KILO and holding down the MODE button to enter programming mode. QuickBOND™ allows you to quickly bond your KILO to a SIERRA riflescope. On the SIERRA riflescope, insert the batteries and turn on to illumination setting 1. Then turn on the KILO by pressing and releasing the RA…

Text truncated - open the document above for the full version.

COMPANY LETTERHEAD Covered Equipment Certification Attestation Letter 8/18/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2AP8SK28R SIG SAUER INC. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List , the applicant should include an explanation on why the equipment is not “covered” equipment. SIG SAUER INC. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Joseph Fruechtel Title: Director, Product Development Company Name: SIG SAUER INC. Date: 8/18/2023

COMPANY LETTERHEAD * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 8/18/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2AP8SK28R Per section 2.911(d)(7) of the FCC rules, SIG SAUER INC. (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: SIG SAUER INC. FCC Registration Number (FRN): 0026202853 Physical U.S. Company Address: 12100 SW Tualatin Road Tualatin, OR 97062, USA. Contact Person: Aaron Schooley Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Signed: Printed name: Joseph Fruechtel Title: Director, Product Development Company Name: SIG SAUER INC. Date: 8/18/2023

DATE: 2023-08-18 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act asAgent On our behalf, I appoint DONGGUAN SHUOXIN ELECTRONIC TECHNOLOGY CO., LTD. Zone A, 1F, No. 6, XinGang Road YuanGang Street, XinAn District, ChangAn Town, DongGuan City, GuangDong, China (Name of Agent company name and address) to actas our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agentsigns the application for certification on our behalf, Iacknowledge that all responsibility for complying with the terms and conditions for certification, still resides with SIG SAUER INC.; 12100 SW Tualatin Road Tualatin, OR 97062, USA. (Applicant Name and address). <Signature> Name: Joseph Fruechtel Title: Director, Product Development Applicant Company: SIG SAUER INC.

DATE : 2023-08-18 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AP8SK28R Product Name: LASER RANGEFINDER Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature>: Name: Joseph Fruechtel Title: Director, Product Development Applicant Company: SIG SAUER INC.

1 / 2 External photos 2 / 2 END

This product complies with IEC 60825-1:2014-05 Ed. 3.0 and complies with FDA performance standards for laser products except for conformance with IEC 60825-1 Ed.3., as described in Laser Notice No.56, dated May 8, 2019. Pp 2120 HVIN:KILO2800 SIG SAUER Inc. 12100 SW Tualatin Road Tualatin, Oregon 97062 CLASS 3R CONSUMER LASER PRODUCT INVISIBLE LASER RADIATION AVIOD DIRECT EYE EXPOSURE EN 50689:2021 FCC ID: 2AP8SK28R IC: 24032-K28R 3 0 1 2023.02.15 2023.03.30 2023.08.14 2023.08.21 RSSAB0455 RB045501599 新 印刷更改 印刷更改 印刷更改 规作成 2 3 4 產品序號: 字體:Arial 5.8 pt 99V000001AAE 此字母代表年分: 如: 此字母代表月分: 如: 此字母代表產品系列名: 此A代表KILO 根據訂單數量及順序來編訂: 根第一批訂單是KILO2800機種1500台,編碼為99V000001A A E- 99V001500A A E以此類推 固定字母 此字母代表製作商產地: V代表Myanmar A B C D E F G H JK MN 1 23456789101112 B C D E F G H 171819202122 K MN P R T UV J W X Y 23 242526272829 1516 30 313233

1 / 1 Label Location

1 / 11 Internal photos 2 / 11 3 / 11 Bluetooth Antenna 4 / 11 5 / 11 6 / 11 7 / 11

8 / 11 9 / 11 10 / 11 11 / 11 ----------------------- BLANK BELOW -------------------------

RF EXPOSURE REPORT FCC ID: 2AP8SK28R Report Reference No. ................ : 23EFSS05066 04251 Date of issue .............................. : 2023-06-16 Applicant’s name ......................... : SIG SAUER INC. Address ....................................... : 12100 SW Tualatin Road Tualatin, OR 97062, USA. Manufacturer ............................... : SIG SAUER INC. Equipment ................................... : LASER RANGEFINDER Trade Mark .................................. : Model ........................................ : KILO2800 Ratings ........................................ : Input: DC 3V Testing Laboratory ...................... : DongGuan ShuoXin Electronic Technology Co., Ltd. Address ....................................... : Zone A, 1F, No. 6, XinGang Road YuanGang Street, XinAn District, ChangAn Town, DongGuan City, Guan gDong, China According .................................... : KDB 447498 D04 Interim General RF Exposure Guidance v01 Test Engineer: Blue Qiu Responsible Engineer : Smile Wang Authorized Signatory: King Wang MPE CALCULATION METHOD: Antenna gain =-0.65dBi MAX Output Power：-7.228dBm@2480MHz ERP=-7.228+(-0.65)-2.15=-10.028dBm WORSE CASE: 10^-0.7228=0.189mW <3mW Then SAR evaluation is not required END

FCC & ISED Radio Test Report FCC ID: 2AP8SK28R IC: 24032-K28R The report concerns: Original Grant Report Reference No. ................. : 23EFSS05066 04241 Date Sample(s) Received ........... : 2023-06-01 Date of Tested ............................. : 2023-06-02 to 2023-06-16 Date of issue ............................... : 2023-06-16 Testing Laboratory ...................... : DongGuan ShuoXin Electronic Technology Co., Ltd. Address ...................................... : Zone A, 1F, No. 6, XinGang Road YuanGang Street, XinAn District, ChangAn Town, DongGuan City, GuangDong, China Applicant’s name ........................ : SIG SAUER INC. Address ...................................... : 12100 SW Tualatin Road Tualatin, OR 97062, USA. Manufacturer............................... : SIG SAUER INC. Equipment................................... : LASER RANGEFINDER Trade Mark ................................. : Model ........................................ : KILO2800 Ratings ....................................... : Input: DC 3V Output: -- Test Engineer: Blue Qiu Responsible Engineer : Smile Wang Authorized Signatory: King Wang Report No.: 23EFSS05066 04241 Page 2 of 38 Table of Contents Page 1 TEST REPORT DECLARE 4 2 SUMMARY OF TEST RESULTS 5 2.1 MEASUREMENT UNCERTAINTY 6 3 GENERAL INFORMATION 7 3.1 GENERAL DESCRIPTION OF EUT 7 3.2 DESCRIPTION OF TEST MODES 9 3.3 PARAMETERS OF TEST SOFTWARE 9 3.4 BLOCK DIAGRAM SHOWINGTHECONFIGURATIONOFSYSTEM TESTED 10 3.5 SUPPORT UNITS 10 3.6 TEST ENVIRONMENT CONDITIONS 10 4 RADIATED EMISSION TEST 11 4.1 LIMIT 11 4.2 TEST PROCEDURE 12 4.3 MEASUREMENT INSTRUMENTS LIST 13 4.4 TESTSETUP 13 4.5 EUT OPERATING CONDITIONS 14 4.6 TEST RESULT- 9KHZ TO 30MHZ 15 4.7 TEST RESULT- 30MHZ TO 1000MHZ 16 4.8 TEST RESULT- ABOVE 1000MHZ(BAND EDGE) 18 4.9 TEST RESULTS - ABOVE 1000MHZ(HARMONIC) 22 5 BANDWIDTH TEST 28 5.1 LIMIT 28 5.2 TEST PROCEDURE AND SETTING 28 5.3 MEASUREMENT INSTRUMENTS LIST 28 5.4 TEST SETUP 28 5.5 EUT OPERATION CONDITIONS 28 5.6 TESTRESULTS 29 6 MAXIMUM OUTPUT POWER 30 6.1 LIMIT 30 6.2 TEST PROCEDURE 30 6.3 MEASUREMENT INSTRUMENTS LIST 30 6.4 TEST SETUP 30 6.5 EUT OPERATION CONDITIONS 30 6.6 TESTRESULTS 31 Report No.: 23EFSS05066 04241 Page 3 of 38 Table of Contents Page 7 CONDUCTED SPURIOUS EMISSION 32 7.1 LIMIT 32 7.2 TEST PROCEDURE 32 7.3 MEASUREMENT INSTRUMENTS LIST 32 7.4 TEST SETUP 32 7.5 EUT OPERATION CONDITIONS 32 7.6 TEST RESULTS 33 8 POWER SPECTRAL DENSITY TEST 35 8.1 LIMIT 35 8.2 TEST PROCEDURE 35 8.3 MEASUREMENT INSTRUMENTS LIST 35 8.4 TEST SETUP 35 8.5 EUT OPERATION CONDITIONS 35 8.6 TEST RESULTS 36 9 FREQUENCY STABILITY MEASUREMENT 37 9.1 LIMIT 37 9.2 TEST PROCEDURE 37 9.3 MEASUREMENT INSTRUMENTS LIST 37 9.4 TEST SETUP 37 9.5 EUT OPERATION CONDITIONS 37 9.6 TEST RESULTS 38 Report No.: 23EFSS05066 04241 Page 4 of 38 1 TEST REPORT DECLARE Applicant SIG SAUER INC. Address 12100 SW Tualatin Road Tualatin, OR 97062, USA. Manufacturer SIG SAUER INC. Address 12100 SW Tualatin Road Tualatin, OR 97062, USA. Factory BURST TRANSMISSION CO., LTD Address Mandalay - Lashio Road, Yatanarpon Myothit, Plot No. 3,4,11, Pyin Oo Lwin Township, Mandalay Region, Myanmar. Equipment LASER RANGEFINDER Model No. KILO2800 Trade Mark Standard FCC Part15, Subpart C (15.247) RSS-247 Issue 2, Feb. 2017 RSS-Gen Issue 5, Mar. 2019 ANSI C63.10-2013 We Declare: The equipment described above is tested by DongGuan ShuoXin Electronic Technology Co., Ltd(ATT). and in the configuration tested the equipment complied with the standards specified above. The test results are contained in this test report and DongGuan ShuoXin Electronic Technology Co., Ltd.(ATT) is assumed of full responsibility for the accuracy and completeness of these tests. ATT is not responsible for the sampling stage, so the results only apply to the sample as received. ATT's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. ATT shall have no liability for any declarations, inferences or generalizations drawn by the client or others from ATT issued reports. Report No.: 23EFSS05066 04241 Page 5 of 38 2 SUMMARY OF TEST RESULTS The EUT have been tested according to the applicable standards as referenced below: Standard(s) Section Test Item Judgment Remark FCC ISED 15.207 RSS-Gen8.8 AC Power Line Conducted Emissions N/A ------ 15.247(d) 15.205(a) 15.209(a) RSS-247 5.5 RSS-Gen8.9 RSS-Gen8.10 Radiated Emissions PASS ------ 15.247(a)(2) RSS-247 5.2 (a) RSS-Gen6.7 Bandwidth PASS ------ 15.247(b)(3) RSS-247 5.4 (d) Maximum Output Power PASS ------ 15.247(d) RSS-247 5.5 ConductedSpurious EmissionPASS ------ 15.247(e) RSS-247 5.2 (b) Power Spectral Density PASS ------ - RSS-Gen 6.11 Frequency Stability PASS ------ 15.203 - Antenna Requirement PASS Note(2) Note: (1) “N/A” denotes test is not applicable to this device. (2) The device what use a permanently attached antenna were considered sufficient tocomply with the provisions of 15.203. Report No.: 23EFSS05066 04241 Page 6 of 38 2.1 MEASUREMENT UNCERTAINTY Test Item Uncertainty Uncertainty for Conduction emission test (9kHz-150kHz) 3.7 dB Uncertainty for Conduction emission test (150kHz-30MHz) 3.3 dB Uncertainty for Radiation Emission test (30MHz-200MHz) 4.60 dB (Polarize: V) 4.60 dB (Polarize: H) Uncertainty for Radiation Emission test (200MHz-1GHz) 6.10 dB (Polarize: V) 5.08 dB (Polarize: H) Uncertainty for Radiation Emission test (1GHz-6GHz) 5.01 dB (Polarize: V) 5.01 dB (Polarize: H) Uncertainty for Radiation Emission test (6GHz-18GHz) 5.26 dB (Polarize: V) 5.26 dB (Polarize: H) Uncertainty for Radiation Emission test (18GHz-40GHz) 5.06 dB (Polarize: V) 5.06 dB (Polarize: H) Uncertainty for radio frequency ±0.048kHz Uncertainty for conducted RF Power ±0.32dB Note: This uncertainty represents an expanded uncertainty expressed at approximately the 95%confidence level using a coverage factor o…
