2AP93-DS63XSound bar

DS6301G/HDS6301MDS6301N（2.0CH） DS6341N DS6341DS6441（2.1CH） E-mail:[email protected] UserManual Sound bar by Sine Audio EN-1 >ImportantNotes Toavoidhearingdistortedsound,turnoffyourTVspeakers(exceptfortheheadphone socketconnection),checkthesoundisonlycomingfromthesoundbar. Foroptical(SPDIF)connection,pleasechangeyourTVaudiooutputtooptical,and changetheaudioformatsettingtoPCM,andmakesuretheprotectivecapsatthe endsoftheopticalcableareremovedbeforepluggingitin. TheIRcodeoftheremotecontrolisnotcompatiblewithuniversalremoteandTV remote,anditiseffectivewithin5meters.BassandTrebleNotAdjustable. ThesoundbardoesnotsupportDolbyandDTS,pleasekindlydisablethe DolbyandDTSviayourTVaudiosettingorstreamingvideoAPPaudiosetting. LipsyncoraudiodelayissuecouldbefixedviaTVsaudiodelaysettings. Forthebettersoundquality,pleasesetthevolumeofthesoundbarto80percentof maximum（Note:themaximumvolumedrop2levelsis80percent）andsetthevolume ofyoursourcedevicetoasuitablelevel. Togetabettersoundeffect,pressthemovie,musicornewsbuttonontheremote controltoselectasuitablesoundmode. Therecommendedsoundmodeselectionsasbelow: ProgramsourceSoundmodeProgramsourceSoundmode StrongbassfilmMusicornewsStrongbassmusicMusicornews GeneralfilmMovieormusicPopmusicMovieorMusic DocumentaryMusicornewsLightmusicMusicornews VarietyshowMusicornewsNews/DialogMusicornews Foraudiocableconnection,youcanboost/restorethevolumebydoubleclickingthe boostbuttonontheremotecontrol. Theaudiooutputofthesoundbarisaffectedbythesettingsoftheconnectedsource.If necessary,adjustthesettingsofthesourcetoimprovetheaudiooutput. Notallremotecontrolfunctionbuttonscanbefoundonthesoundbar.Pleasekeepthe remotecontrolproperly. Disconnectthepoweradapterfromtheelectricaloutlettopoweroffyoursoundbarcompletely. Thelightningflashwitharrowheadsymbolwithinanequilateraltriangle alertstheusertothepresenceofuninsulated,dangerousvoltagewithinthe systemenclosurethatmaybeofsufficientmagnitudetoconstituteariskof electricshock. Theexclamationpointwithinanequilateraltriangle,asmarkedonthe system,isintendedtoalerttheusertothepresenceofimportantoperating andmaintenanceinstructionsinthisusermanual. EN-2 Donotmakeunauthorizedalterationstothesystem,doingsomay compromisesafety,regulatorycompliance,andmayvoidthewarranty. Thissystemcontainsmagneticmaterial,contactyourphysicianifyouhave questionsonwhetherthismightaffecttheoperationofyourimplantablemedicaldevice. >WarrantyInformation Thewarrantyperiodforthisproductis12monthsfromthedateofitsoriginalpurchase.If manufacturingdefectsoccur,pleasecontactyourdealeratthefirsttime,wewillinstruct youonhowtoreturnthedefectiveunitbacktousforrepairorreplacement. ThefollowingareexcludedfromtheSineAudiowarrantycoverage: Productoverwarranty. Damageresultedfrommisuseandabusiveaction. Damageresultedfromchemical,fire,radioactivesubstance,andpoison,liquid. Damageresultedfromnaturaldisaster. >FCCInformation Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowing twoconditions:(1)thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemust acceptanyinterferencereceived,includinginterferencethatmaycauseundesired operation. Changersormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliance couldvoidtheuser’sauthoritytooperatethisequipment. Note:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassB digitaldevice,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovide reasonableprotectionagainstharmfulinterferenceinaresidentialinstallation.This equipmentgenerates,uses,andcanradiateradiofrequencyenergyand,ifnotinstalled andusedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradioor televisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,the userisencouragedtotrytocorrecttheinterferencebyoneofmoreofthefollowing measure: Reorientorrelocatethereceivingantenna. Increasetheseparationbetweentheequipmentandreceiver. Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthe receiverisconnected. Consultthedealeroranexperiencedradio/TVtechnicianforhelp. ThisdevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.Thedevice canbeusedinportableexposureconditionwithoutrestriction. EN-3 Product Model: DS6441S PMN: Sound bar ISED statement English: This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. French: Cet appareil contient des émetteurs/récepteurs exempts de licence qui sont conformes aux RSS exemptés de licence d'Innovation, Sciences et Développement économique Canada. L'exploitation est soumise aux deux conditions suivantes : (1) Cet appareil ne doit pas provoquer d'interférences. (2) Cet appareil doit accepter toute interférence, y compris les interférences susceptibles de provoquer un fonctionnement indésirable de l'appareil. This device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance with RSS 102 RF exposure, users can obtain Canadian information on RF exposure and compliance. cet appareil est conforme à l'exemption des limites d'évaluation courante dans la section 2.5 du cnr - 102 et conformité avec rss 102 de l'exposition aux rf, les utilisateurs peuvent obtenir des données canadiennes sur l'exposition aux champs rf et la conformité. This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. Cet équipement est conforme aux limites d'exposition aux rayonnements du Canada établies pour un environnement non contrôlé. The device has been evaluated to meet general RF exposure requirement. This equipment should be installed and operated with minimum distance 0mm between the radiator & your body. L'appareil a été évalué pour répondre aux exigences générales d'exposition aux RF. Cet équipem…

Text truncated - open the document above for the full version.

Shenzhen Saiyin Electronics Co., Ltd. 205, No.28, Xintang Road, Xintian Community, Fuhai Street, Bao’an District, Shenzhen,China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024/7/19 U.S. Agent Designation Shenzhen Saiyin Electronics Co., Ltd. acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2AP93-DS63X): Name and company of U.S. agent: Formates LLC Physical U.S. address of agent: 1400 Hudson St, Hoboken, New Jersey, 07030, USA FRN of U.S. agent: 0033456468 Email address of U.S. agent: [email protected] Formates LLC acknowledges their obligation to accept service of process on behalf of Shenzhen Saiyin Electronics Co., Ltd.. Shenzhen Saiyin Electronics Co., Ltd. with the FRN [0027647783] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Danielle He Shenzhen Saiyin Electronics Co., Ltd. Signature Abi Aribisala Project Manager Formates LLC 48_[mo del] US_Agent_2.911(d)(7) - U, V0 5

Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 1 of 4 EXTERIOR PHOTOGRAPHS OF EUT Fig.1 Fig.2 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 2 of 4 Fig.3 Fig.4 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 3 of 4 Fig.5 Fig.6 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 4 of 4 Fig.7 Fig.8

Label Location: FCC ID: 2AP93-DS63X

Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 1 of 2 INTERIOR PHOTOGRAPHS OF EUT Fig.1 Fig.2 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 2 of 2 Fig.3 Fig.4 Bluetooth Antenna

Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 1 of 3 RADIO FREQUENCY EXPOSURE Limit According to section B.4 of 447498 D04 Interim General RF Exposure Guidance v01 SAR-based thresholds are derived based on frequency, power, and separation distance of the RF source. The formula defines the thresholds in general for either available maximum time-averaged power or maximum time-averaged ERP, whichever is greater. If the ERP of a device is not easily determined, such as for a portable device with a small form factor, the applicant may use the available maximum time-averaged power exclusively if the device antenna or radiating structure does not exceed an electrical length of λ/4. As for devices with antennas of length greater than λ/4 where the gain is not well defined, but always less than that of a half-wave dipole (length λ/2), the available maximum time-averaged power generated by the device may be used in place of the maximum time-averaged ERP, where that value is not known. The separation distance is the smallest distance from any part of the antenna or radiating structure for all persons, during operation at the applicable ERP. In the case of mobile or portable devices, the separation distance is from the outer housing of the device where it is closest to the antenna. The SAR-based exemption formula of § 1.1307(b)(3)(i)(B), repeated here as Formula (B.2), applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power or effective radiated power (ERP), whichever is greater, of less than or equal to the threshold Pth (mW). This method shall only be used at separation distances from 0.5 cm to 40 cm and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by Formula (B.2). Where and f is in GHz, d is the separation distance (cm), and ERP 20cm is per Formula (B.1). Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 2 of 3 The example values shown in Table B.2 are for illustration only. Frequency (MHz) Distance (mm) 5 10 15 20 25 30 35 40 45 50 300 39 65 88 110 129 148 166 184 201 217 450 22 44 67 89 112 135 158 180 203 226 835 9 25 44 66 90 116 145 175 207 240 1900 3 12 26 44 66 92 122 157 195 236 2450 3 10 22 38 59 83 111 143 179 219 3600 2 8 18 32 49 71 96 125 158 195 5800 1 6 14 25 40 58 80 106 136 169 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 3 of 3 Conducted Power Results Test Mode Antenna Frequency[MHz] Result[dBm] DH5 Ant1 2402 -1.07 DH5 Ant1 2441 -0.51 DH5 Ant1 2480 -0.71 2DH5 Ant1 2402 -0.82 2DH5 Ant1 2441 -0.24 2DH5 Ant1 2480 -0.51 3DH5 Ant1 2402 -0.31 3DH5 Ant1 2441 0.29 3DH5 Ant1 2480 0.09 Manufacturing tolerance GFSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) -1.5 -1.0 -1.0 Tolerance ±(dB) 1 1 1 π/4-DQPSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) -1.5 -0.5 -1 Tolerance ±(dB) 1 1 1 8-DPSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) -1 0 -0.5 Tolerance ±(dB) 1 1 1 Results Test Mode Max Conducted Tune Up Power(dBm) Max of ERP and Conducted Power including Tune Up (dBm) Max of ERP and Conducted Power including Tune Up (mW) Exemption Limit(mW) GFSK 0 0.0 1.00 3 π/4-DQPSK 0.5 0.5 1.12 3 8DPSK 1 1.0 1.26 3 Max of ERP and Conducted Power including Tune Up (dBm) = Max Conducted Tune Up Power(dBm) and Max Conducted Tune Up Power(dBm) + Antenna Gain(dBi)-2.15), whichever is greater. The antenna gain of the EUT for BT is -0.58dBi (Max). the Maximum Eirp is used for Routine Evaluation Exemption according to B.4 of 447498 D04 Interim General RF Exposure Guidance v01. So, the SAR evaluation is not required.

Inverted F Antenna Specification Summary ITEMANT SPEC Model Name 2.4G ANT HorizontalVertical 2400MHz 2400MHz2500MHz2400MHz2400MHz 2500MHz Center Frequency -1.26-0.76-0.58-5.25-2.46-1.86 MAX. Gain -0.58dBi PolarizationHorizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance50 Ohm Antenna Length 38.20mm Manufacture ZHUHAI JIELI TECHNOLOGY CO.,LTD Antenna Photo & Length (mm) Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -1.26174 -30.0801 -7.18716 2450 -0.765802 -36.5604 -7.48023 2500 -0.585582 -22.0315 -6.59127 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -5.2537 -22.1424 -12.4294 2450 -2.4652 -24.5837 -10.4702 2500 -1.86120 -29.5214 -9.20432 ANT Test Labs：Attestation of Global Compliance Co., Ltd.

Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 1 of 46 Appendix Test Data for BT(BDR/EDR) (Conducted Measurement) Product Name: Sound bar Trade Mark: SineAudio, Saiyin, RIOWOIS, Anpharala Test Model: DS6441S FCC ID: 2AP93-DS63X Environmental Conditions Temperature: 23.8°C Relative Humidity: 58% ATM Pressure: 100.0 kPa Test Engineer: Allen Lai Supervised by: Hugo Chen NOTE N/A Appendix A: 20dB Emission Bandwidth Test Result TestMode Antenna Frequency[MHz] 20db EBW[MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.963 2401.547 2402.510 --- --- DH5 Ant1 2441 0.963 2440.547 2441.510 --- --- DH5 Ant1 2480 0.948 2479.547 2480.495 --- --- 2DH5 Ant1 2402 1.287 2401.382 2402.669 --- --- 2DH5 Ant1 2441 1.293 2440.379 2441.672 --- --- 2DH5 Ant1 2480 1.281 2479.385 2480.666 --- --- 3DH5 Ant1 2402 1.308 2401.361 2402.669 --- --- 3DH5 Ant1 2441 1.284 2440.364 2441.648 --- --- 3DH5 Ant1 2480 1.302 2479.370 2480.672 --- --- Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 2 of 46 Test Graphs DH5-Ant1-2402 DH5-Ant1-2441 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 3 of 46 DH5-Ant1-2480 2DH5-Ant1-2402 2DH5-Ant1-2441 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 4 of 46 2DH5-Ant1-2480 3DH5-Ant1-2402 3DH5-Ant1-2441 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 5 of 46 3DH5-Ant1-2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 6 of 46 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.87955 2401.5780 2402.4576 --- --- DH5 Ant1 2441 0.89029 2440.5731 2441.4634 --- --- DH5 Ant1 2480 0.87157 2479.5814 2480.4529 --- --- 2DH5 Ant1 2402 1.1779 2401.4249 2402.6028 --- --- 2DH5 Ant1 2441 1.1805 2440.4239 2441.6044 --- --- 2DH5 Ant1 2480 1.1761 2479.4251 2480.6012 --- --- 3DH5 Ant1 2402 1.1841 2401.4235 2402.6076 --- --- 3DH5 Ant1 2441 1.1813 2440.4260 2441.6073 --- --- 3DH5 Ant1 2480 1.1836 2479.4240 2480.6076 --- --- Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 7 of 46 Test Graphs DH5-Ant1-2402 DH5-Ant1-2441 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 8 of 46 DH5-Ant1-2480 2DH5-Ant1-2402 2DH5-Ant1-2441 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 9 of 46 2DH5-Ant1-2480 3DH5-Ant1-2402 3DH5-Ant1-2441 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 10 of 46 3DH5-Ant1-2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 11 of 46 Appendix C: Maximum peak conducted output power Test Result Test Mode Antenna Frequency[MHz] Conducted Peak Power[dBm] Conducted Limit[dBm] Verdict DH5 Ant1 2402 -1.07 ≤20.97 PASS DH5 Ant1 2441 -0.51 ≤20.97 PASS DH5 Ant1 2480 -0.71 ≤20.97 PASS 2DH5 Ant1 2402 -0.82 ≤30 PASS 2DH5 Ant1 2441 -0.24 ≤30 PASS 2DH5 Ant1 2480 -0.51 ≤30 PASS 3DH5 Ant1 2402 -0.31 ≤20.97 PASS 3DH5 Ant1 2441 0.29 ≤20.97 PASS 3DH5 Ant1 2480 0.09 ≤20.97 PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 12 of 46 Test Graphs DH5-Ant1-2402-PASS DH5-Ant1-2441-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 13 of 46 DH5-Ant1-2480-PASS 2DH5-Ant1-2402-PASS 2DH5-Ant1-2441-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 14 of 46 2DH5-Ant1-2480-PASS 3DH5-Ant1-2402-PASS 3DH5-Ant1-2441-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 15 of 46 3DH5-Ant1-2480-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 16 of 46 Appendix D: Carrier frequency separation Test Result TestMode Antenna Frequency[MHz] Result[MHz] Limit[MHz] Verdict DH5 Ant1 Hop 0.668 ≥0.642 PASS 2DH5 Ant1 Hop 1.316 ≥1.293 PASS 3DH5 Ant1 Hop 1.028 ≥0.872 PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 17 of 46 Test Graphs DH5-Ant1-Hop-PASS 2DH5-Ant1-Hop-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 18 of 46 3DH5-Ant1-Hop-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 19 of 46 Appendix E: Time of occupancy Test Result TestMode Antenna Frequency[MHz] BurstWidth [ms] TotalHops [Num] Result[s] Limit[s] Verdict DH5 Ant1 Hop 2.885 110 0.317 ≤0.4 PASS 2DH5 Ant1 Hop 2.889 120 0.347 ≤0.4 PASS 3DH5 Ant1 Hop 2.892 120 0.347 ≤0.4 PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 20 of 46 Test Graphs DH5-Ant1-Hop-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 21 of 46 2DH5-Ant1-Hop-PASS 3DH5-Ant1-Hop-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 22 of 46 Appendix F: Number of hopping channels Test Result TestMode Antenna Frequency[MHz] Result[Num] Limit[Num] Verdict DH5 Ant1 Hop 79 ≥15 PASS 2DH5 Ant1 Hop 79 ≥15 PASS 3DH5 Ant1 Hop 79 ≥15 PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 23 of 46 Test Graphs DH5-Ant1-Hop-PASS 2DH5-Ant1-Hop-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 24 of 46 3DH5-Ant1-Hop-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2AP93-DS63X Report No.: TZ240605926-BT Page 25 of 46 Appendix G: Band edge measurements Test Result TestMode Antenna ChName Frequency[MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 Low 2402 -1.48 -50.11 ≤-21.48 PASS DH5 Ant1 High 2480 -1.24 -49.19 ≤-21.24 PASS DH5 Ant1 Low Hop_2402 -2.08 -49.96 ≤-22.08 PASS DH5 Ant1 High Hop_2480 -1.13 -48.81 ≤-21.13 PASS 2DH5 Ant1 Low 2402 -2.74 -50.19 ≤-22.74 PASS 2DH5 Ant1 High 2480 -2.05 -49.42 ≤-22.05 PASS 2DH5 A…
