2AP93-DS6X2Sound bar

Shenzhen Saiyin Electronics Co.,Ltd. 201, No.145-5 Furui Road, Xintian Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Attestation Statements Not Covered Entity Applicant & Not Covered Equipment To: Federal Communications Commission Date: Nov. 18, 25 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(i) & (ii) FCC ID: 2AP93-DS6X2 Shenzhen Saiyin Electronics Co.,Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List, established pursuant to § 1.50002 of reference chapter, as an entity producing “covered” communication equipment. The equipment for which authorization is sought is not “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List that prohibited from receiving an equipment authorization pursuant to section § 2.903 of the FCC rules. Sincerely yours, Applicant Signature Printed Name: Danielle He Title: Manager Address: 201, No.145-5 Furui Road, Xintian Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel.: 0755-33532477 Email: [email protected]

Shenzhen Saiyin Electronics Co.,Ltd. 201, No.145-5 Furui Road, Xintian Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China 1 | P a g e Attestation Statements To: Federal Communications Commission Date: Nov. 18, 25 7435 Oakland Mills Road, Columbia, MD 21046, USA Subject: Attestation of Compliance with FCC Covered List Software Requirements FCC ID: 2AP93-DS6X2 Product Name: Sound bar This letter serves as an attestation that the equipment identified above ☐ is / ☒ is not (select one) "covered" software as defined under the Federal Communications Commission (FCC) Covered List requirements, as outlined in FCC 22-84 and KDB 986446. Specifically, the undersigned certifies that the equipment for which authorization is sought: 1. Does not contain cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors, assignees, parents, subsidiaries, affiliates, or any entity that has rebranded or relabeled software produced by the aforementioned entities. 2. Does not have the capability to store, run, or deliver any software identified on the FCC Covered List, including but not limited to cybersecurity and anti-virus software. To support this attestation, the appendix evaluation documentation has been prepared and is included in the certification filing. This attestation is based on a thorough evaluation of the device's design, functionality, and software environment. The undersigned affirms that the information provided is accurate and complete to the best of their knowledge. Sincerely yours, Applicant Signature Printed Name: Danielle He Title: Manager Address: 201, No.145-5 Furui Road, Xintian Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel.: 0755-33532477 Email: [email protected] Shenzhen Saiyin Electronics Co.,Ltd. 201, No.145-5 Furui Road, Xintian Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China 2 | P a g e Evaluation regarding to the Covered List Software: Compliance Methodology Evaluation Process Results Device is Inherent compliance ☒ The Chipset(s) used is limited to run the Cybersecurity or anti-virus software. Compliance ☒ The Memory used is limited to run the Cybersecurity or anti-virus software. Compliance ☒ There is storage capacity limitation for store or install the Cybersecurity or anti-virus software. Compliance ☒ Operating system used is limited to run, install or deliver the Cybersecurity or anti-virus software. Compliance Device is not Inherent compliance ☐ Evaluation Based on Software Bill of Materials (SBoM) See attached “SBoM“ Note:The SBoM content is limited to the scope of covered list software (e.g. antivirus and cybersecurity software). ☐ Evaluation Based on Scan for Software on the device ☐ Evaluation Based on Filesystem scan ☐ Evaluation Based on Running software check

Shenzhen Saiyin Electronics Co.,Ltd. 201, No.145-5 Furui Road, Xintian Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Date: 2025/11/18 Dear Sir/Madam, We, Shenzhen Saiyin Electronics Co.,Ltd., Hereby declares the following statement, all models have the same functions, software, and circuitry; only the appearance and model names differ. Test sample model DS6442G2 Pro: Product name: Sound bar FCC ID: 2AP93-DS6X2 Model no.: DS6442G2 Pro, DS6302, DS6402, DS6502, DS6302L, DS6302S, DS6302G2, DS6302G2 Pro, DS6302LG2, DS6302SG2, DS6342, DS6442, DS6542, DS6442L, DS6442S, DS6442LG2, DS6442SG2, DS6442G2, DS6302G3, DS6302G3 Pro, DS6302G4, DS6302G4 Pro, DS6442G3, DS6442G3 Pro, DS6442G4, DS6442G4 Pro Sincerely, Name/Title： Danielle He / Manager Company: Shenzhen Saiyin Electronics Co.,Ltd. Address: 201, No.145-5 Furui Road, Xintian Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Phone: 0755-33532477 Fax: N/A E-Mail: [email protected]

Shenzhen Saiyin Electronics Co.,Ltd. 201, No.145-5 Furui Road, Xintian Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China November 18, 2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request for: FCC ID: 2AP93-DS6X2 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request permanent confidential treatment of the exhibits accompanying this certification application as outlined below : ⎯ Block Diagram ⎯ Schematics ⎯ Operational Description The above exhibits contain trade secrets and/or proprietary information that are not publicly available and materials that the Applicant has spent considerable efforts in developing. Public disclosure of these may be harmful to the Applicant and give an unfair advantage to competitors on the market. Pursuant to DA 04-1705, the applicant also requests temporary confidential treatment of the exhibits outlined below for a period of 45 days from the date of equipment authorization and prior to marketing in the United States to prevent the premature release of any sensitive information. Applicant is aware of their responsibility to notify DERYCOM in the event information regarding the product or the product is made available to the public before the requested period has expired. ⎯ User Manual ⎯ Internal Photos Sincerely, Title: Manager Address: 201, No.145-5 Furui Road, Xintian Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel.: 0755-33532477 Email: [email protected]

Shenzhen Saiyin Electronics Co.,Ltd. 201, No.145-5 Furui Road, Xintian Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China November 18, 2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization for FCC ID: 2AP93-DS6X2 I, the undersigned, hereby authorize Shenzhen Tongzhou Testing Co.,Ltd. to act on our behalf in all matters relating to this application for equipment certification. Any act carried out by Shenzhen Tongzhou Testing Co.,Ltd. shall have the same effect as our own and I acknowledge that all responsibility for complying with the terms and conditions of certification, as specified by DERYCOM CERTIFICATION SERVICES, INC., still resides with Shenzhen Saiyin Electronics Co.,Ltd.. We certify that we are not subject to a denial of federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862, and that no party to the application, as defined in 47 CFR §1.2002(b), is subject to a denial of federal benefits that includes FCC benefits pursuant to that section. Sincerely, Danielle He Manager Tel: 0755-33532477 Fax: N/A Email: [email protected]

Report No.: TZ0031250801PH02 Page 1 of 9 External Photographs of EUT External Photo 1 External Photo 2 Report No.: TZ0031250801PH02 Page 2 of 9 External Photo 3 External Photo 4 Report No.: TZ0031250801PH02 Page 3 of 9 External Photo 5 External Photo 6 Report No.: TZ0031250801PH02 Page 4 of 9 External Photo 7 External Photo 8 Report No.: TZ0031250801PH02 Page 5 of 9 External Photo 9 External Photo 10 Report No.: TZ0031250801PH02 Page 6 of 9 External Photo 11 External Photo 12 Report No.: TZ0031250801PH02 Page 7 of 9 External Photo 13 External Photo 14 Report No.: TZ0031250801PH02 Page 8 of 9 External Photo 15 External Photo 16 Report No.: TZ0031250801PH02 Page 9 of 9 External Photo 17

Label Location FCC ID: 2AP93-DS6X2

FCC ID: 2AP93-DS6X2 Page 1 of 2 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd RADIO FREQUENCY EXPOSURE Limit According to section B.4 of 447498 D04 Interim General RF Exposure Guidance v01 SAR-based thresholds are derived based on frequency, power, and separation distance of the RF source. The formula defines the thresholds in general for either available maximum time-averaged power or maximum time-averaged ERP, whichever is greater. If the ERP of a device is not easily determined, such as for a portable device with a small form factor, the applicant may use the available maximum time-averaged power exclusively if the device antenna or radiating structure does not exceed an electrical length of λ/4. As for devices with antennas of length greater than λ/4 where the gain is not well defined, but always less than that of a half-wave dipole (length λ/2), the available maximum time-averaged power generated by the device may be used in place of the maximum time-averaged ERP, where that value is not known. The separation distance is the smallest distance from any part of the antenna or radiating structure for all persons, during operation at the applicable ERP. In the case of mobile or portable devices, the separation distance is from the outer housing of the device where it is closest to the antenna. The SAR-based exemption formula of § 1.1307(b)(3)(i)(B), repeated here as Formula (B.2), applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power or effective radiated power (ERP), whichever is greater, of less than or equal to the threshold Pth (mW). This method shall only be used at separation distances from 0.5 cm to 40 cm and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by Formula (B.2). Where and f is in GHz, d is the separation distance (cm), and ERP 20cm is per Formula (B.1). FCC ID: 2AP93-DS6X2 Page 2 of 2 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Results RF Exposure at Separation distance (cm): 0.5 Mode Antenna Frequency [MHz] Conducted Power [dBm] Manufacturing tolerance Antenna Gain [dBi] Max of ERP and Conducted Power including Tune Up SAR- based exemption threshold Pth [mW] Target Power [dBm] Tolerance ±[dB] [dBm] [mW] DH5 Ant1 2402 0.85 0.5 1 -0.58 1.5 1.41 2.79 DH5 Ant1 2441 0.29 0 1 -0.58 1 1.26 2.75 DH5 Ant1 2480 -1.48 -2 1 -0.58 -1 0.79 2.72 2DH5 Ant1 2402 0.72 0 1 -0.58 1 1.26 2.79 2DH5 Ant1 2441 0.19 -0.5 1 -0.58 0.5 1.12 2.75 2DH5 Ant1 2480 -1.61 -2 1 -0.58 -1 0.79 2.72 3DH5 Ant1 2402 0.86 0.5 1 -0.58 1.5 1.41 2.79 3DH5 Ant1 2441 0.45 0 1 -0.58 1 1.26 2.75 3DH5 Ant1 2480 -1.53 -2 1 -0.58 -1 0.79 2.72 Max of ERP and Conducted Power including Tune Up (dBm) = Max Conducted Tune Up Power(dBm) and Max Conducted Tune Up Power(dBm) + Antenna Gain(dBi)-2.15), whichever is greater. The Maximum Erp is used for Routine Evaluation Exemption according to B.4 of 447498 D04 Interim General RF Exposure Guidance v01. So, the SAR evaluation is not required.

Inverted F Antenna Specification Summary ITEMANT SPEC Model Name 2.4G ANT HorizontalVertical 2400MHz 2400MHz2500MHz2400MHz2400MHz 2500MHz Center Frequency -1.26-0.76-0.58-5.25-2.46-1.86 MAX. Gain -0.58dBi PolarizationHorizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance50 Ohm Antenna Length 38.20mm Manufacture ZHUHAI JIELI TECHNOLOGY CO.,LTD Antenna Photo & Length (mm) Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -1.26174 -30.0801 -7.18716 2450 -0.765802 -36.5604 -7.48023 2500 -0.585582 -22.0315 -6.59127 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -5.2537 -22.1424 -12.4294 2450 -2.4652 -24.5837 -10.4702 2500 -1.86120 -29.5214 -9.20432 ANT Test Labs：Attestation of Global Compliance Co., Ltd.

Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 1 of 56 Appendix Test Data for BT(BDR/EDR) (Conducted Measurement) Product Name: Sound bar Trade Mark: SineAudio Saiyin RIOWOIS Anpharala WebsLand, Kerglory Test Model: DS6442G2 Pro FCC ID: 2AP93-DS6X2 Environmental Conditions Temperature: JH23.5°C Relative Humidity: 58% ATM Pressure: 100.0 kPa Test Engineer: Allen Lai Supervised by: Max Zhang NOTE N/A Appendix A: 20dB Emission Bandwidth Test Result Test Mode Antenna Frequency [MHz] 20db EBW [MHz] FL [MHz] FH [MHz] Limit [MHz] Verdict DH5 Ant1 2402 0.984 2401.487 2402.471 --- --- DH5 Ant1 2441 1.005 2440.454 2441.459 --- --- DH5 Ant1 2480 0.939 2479.499 2480.438 --- --- 2DH5 Ant1 2402 1.314 2401.313 2402.627 --- --- 2DH5 Ant1 2441 1.308 2440.319 2441.627 --- --- 2DH5 Ant1 2480 1.299 2479.316 2480.615 --- --- 3DH5 Ant1 2402 1.293 2401.313 2402.606 --- --- 3DH5 Ant1 2441 1.284 2440.328 2441.612 --- --- 3DH5 Ant1 2480 1.263 2479.331 2480.594 --- --- Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 2 of 56 Test Graphs DH5-Ant1-2402 DH5-Ant1-2441 Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 3 of 56 DH5-Ant1-2480 2DH5-Ant1-2402 Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 4 of 56 2DH5-Ant1-2441 2DH5-Ant1-2480 Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 5 of 56 3DH5-Ant1-2402 3DH5-Ant1-2441 Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 6 of 56 3DH5-Ant1-2480 Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 7 of 56 Appendix B: Occupied Channel Bandwidth Test Result Test Mode Antenna Frequency [MHz] OCB [MHz] FL [MHz] FH [MHz] Limit [MHz] Verdict DH5 Ant1 2402 0.87842 2401.5359 2402.4143 --- --- DH5 Ant1 2441 0.86611 2440.5291 2441.3952 --- --- DH5 Ant1 2480 0.87805 2479.5195 2480.3975 --- --- 2DH5 Ant1 2402 1.1906 2401.3738 2402.5644 --- --- 2DH5 Ant1 2441 1.2014 2440.3656 2441.5670 --- --- 2DH5 Ant1 2480 1.1940 2479.3580 2480.5520 --- --- 3DH5 Ant1 2402 1.2073 2401.3715 2402.5788 --- --- 3DH5 Ant1 2441 1.1982 2440.3680 2441.5662 --- --- 3DH5 Ant1 2480 1.1905 2479.3597 2480.5502 --- --- Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 8 of 56 Test Graphs DH5-Ant1-2402 DH5-Ant1-2441 Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 9 of 56 DH5-Ant1-2480 2DH5-Ant1-2402 Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 10 of 56 2DH5-Ant1-2441 2DH5-Ant1-2480 Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 11 of 56 3DH5-Ant1-2402 3DH5-Ant1-2441 Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 12 of 56 3DH5-Ant1-2480 Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 13 of 56 Appendix C: Maximum peak conducted output power Test Result Test Mode Antenna Frequency [MHz] Conducted Peak Power [dBm] Conducted Limit [dBm] Verdict DH5 Ant1 2402 0.85 ≤20.97 PASS DH5 Ant1 2441 0.29 ≤20.97 PASS DH5 Ant1 2480 -1.48 ≤20.97 PASS 2DH5 Ant1 2402 0.72 ≤20.97 PASS 2DH5 Ant1 2441 0.19 ≤20.97 PASS 2DH5 Ant1 2480 -1.61 ≤20.97 PASS 3DH5 Ant1 2402 0.86 ≤20.97 PASS 3DH5 Ant1 2441 0.45 ≤20.97 PASS 3DH5 Ant1 2480 -1.53 ≤20.97 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 14 of 56 Test Graphs DH5-Ant1-2402-PASS DH5-Ant1-2441-PASS Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 15 of 56 DH5-Ant1-2480-PASS 2DH5-Ant1-2402-PASS Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 16 of 56 2DH5-Ant1-2441-PASS 2DH5-Ant1-2480-PASS Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 17 of 56 3DH5-Ant1-2402-PASS 3DH5-Ant1-2441-PASS Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 18 of 56 3DH5-Ant1-2480-PASS Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 19 of 56 Appendix D: Carrier frequency separation Test Result Test Mode Antenna Frequency [MHz] Result [MHz] Limit [MHz] Verdict DH5 Ant1 Hop 0.994 ≥0.670 PASS 2DH5 Ant1 Hop 1.01 ≥0.876 PASS 3DH5 Ant1 Hop 0.978 ≥0.862 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 20 of 56 Test Graphs DH5-Ant1-Hop-PASS 2DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 21 of 56 3DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 22 of 56 Appendix E: Time of occupancy Test Result Test Mode Antenna Frequency [MHz] Burst Width [ms] TotalHops [Num] Result [s] Limit [s] Verdict DH5 Ant1 Hop 2.891 120 0.347 ≤0.4 PASS 2DH5 Ant1 Hop 2.885 130 0.375 ≤0.4 PASS 3DH5 Ant1 Hop 2.887 120 0.346 ≤0.4 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 23 of 56 Test Graphs DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 24 of 56 2DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 25 of 56 3DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 26 of 56 Appendix F: Number of hopping channels Test Result Test Mode Antenna Frequency [MHz] Result [Num] Limit [Num] Verdict DH5 Ant1 Hop 79 ≥15 PASS 2DH5 Ant1 Hop 79 ≥15 PASS 3DH5 Ant1 Hop 79 ≥15 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 27 of 56 Test Graphs DH5-Ant1-Hop-PASS 2DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 28 of 56 3DH5-Ant1-Hop-PASS Appendix Test Data of the Report No.: TZ0031250801FRF01 Page 29 of 56 Appendix G: Band edge measurements Test Result Test Mode Antenna Ch.Name Frequency [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 Low 2402 0.40 -46.4 ≤-19.6 PASS DH5 Ant1 High 2480 -1.96 -48.15 ≤-21.96 PASS DH5 Ant1 Low Hop_2402 -0.53 -46.67 ≤-20.53 PASS DH5 Ant1 High Hop_2480 -1.96 -45.92 ≤-21.96 PASS 2DH5 Ant1 Low 2402 0.33 -47.98 ≤-19.67 P…
