2APBP-CS20Mobile Smart POS

Smart & Reliable www.ciontek.com [email protected] Mobile Smart POS CS20 1 st Qualcomm Octa-Core POS, Fits in Your Pocket Perfectly. Highlights  Qualcomm Octa-Core ARM Cortex-A53 1.8GHz;  Safedroid OS (based on Android 10.0);  Massive memory: 2G RAM + 16G ROM;  5.7 inch TFT IPS LCD, resolution 1440*720;  Full bands for global coverage: 4G/3G/2G, WLAN, Bluetooth, VPN;  Dual camera for quickly QR code scan & Symbol 2D scanner as option;  The grand 3.8V/3500mAH battery + extraordinary power management design ensures a full day duration;  One-stop payment of MSR/ICCR/NFC,with PCI PTS 6.X, EMV L1&L2,Paypass,Paywave,Amex,TQM certified.  NFC for full scenarios such as transportation, logistic, and ID control. Smart & Reliable www.ciontek.com [email protected] Specifications Basic Characteristics OS Safedroid OS (based on Android 10.0) CPU Qualcomm Octa-Core ARM Cortex-A53 1.8GHz ROM 16GB ROM EMMC RAM 2G RAM LPDDR3 Display 5.7 inch TFT IPS LCD, resolution 1440*720 Panel Ultra sensitive capacitive touch screen, can work with gloves and wet fingers Dimensions 163mmX77mmX17.5mm (max 21.8mm) Weight 300g (Battery included) Keys Physical keys: Power on/off, Volume + /-, Scan1/ Scan2 Input Chinese/English, and supports handwriting and soft keyboard Radio Communication WIFI IEEE 802.11 a/b/g/n, support dual Band 2.4GHZ and 5GHZ Bluetooth BT 4.2 LE and earlier 4G European version(Default): FDD-LTE: B1/B2/B3/B4/B5/B7/B8/B20/B28 TDD-LTE: B38/B39/B40/B41 American version(Optional): FDD-LTE: B2/B4/B5/B12/B13/B17/B25/B26 TDD-LTE: B38/B40/B41 3G European version(Default): WCDMA: B1/B2/B4/B5/B8 TD-SCDMA: B34/B39 American version(Optional): WCDMA: B2/B4/B5 2G GSM/GPRS/EDGE: 850/900/1800/1900MHZ Payment Magcard reader Supports ISO7811/7812/7813, and supports triple track (tracks 1/2/3), bi-directional Smart Card reader Supports ISO7816 standard Contactless Card reader Supports 14443A/ 14443B Expansion and peripherals Camera 5MP camera with LED flash and auto-focus function Satellite Positioning Support GPS(A-GPS)/ Bei-Dou/ Glonass or Galileo Sensor G-Sensor LEDS 3PCS for indicate Audio Speaker, Buzzer, Microphone Interfaces Micro SD Card Slot 1 PCS support up to 128GB SIM Card Slot 1 PCS MICRO SIM PSAM Card Slot 2 PCS Conforms to ISO7816 standard USB Port 1PCS TYPE C USB Smart & Reliable www.ciontek.com [email protected] Power Battery Li-ion battery, 3.8V/3500mAH Charging Port Type C USB Port, 5V DC/2A Environment Operating Temperature -10°C to 50°C Storage Temperature -20°C to 70°C Humidity 5% to 95% Relative Humidity, Non-Condensing Certification Electromagnetic CE, Rohs, FCC Payment PCI PTS 6.X, EMV L1&L2, Paypass, Paywave, Amex, TQM Optional Fingerprint (Extended support on the charging cradle) Printer High-Speed Thermal Printer(Extended support on the charging cradle) ESIM Card support Sensor ALS-Sensor, PS-Sensor Audio Receiver Front camera 2 Megapixel Fixed Focal Camera Barcode Scanner Symbol 4710 2D Image Engine, Support 1D and 2D symbologies Smart & Reliable www.ciontek.com [email protected] This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party. Responsible for compliance could void the user’s authority to operate this equipment. (Exampleuse only shielded interface cables when connecting to computer or peripheral devices). This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Specific Absorption Rate (SAR) information: This Communicator meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement the SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: Communicator has also been tested against this SAR limit. This device was tested for typical body-worn operations with the back of the phone kept 0mm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain an 0mm separation distance between the user's body and the back of the phone. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. Ciontek Technology Corp. Disclaimer: This product specification is subject to change without prior notice. In addition, images shown throughout this brochure are for illustrative purposes only and may differ from the ac…

Text truncated - open the document above for the full version.

Ciontek Technology Corp. Add: B501, Chanxueyan Building Wuhan University, No.6 Of Yuexing 2nd Road, Yuehai Street, Nanshan District, Shenzhen, China Date: 2020-12-15 FCC ID: 2APBP-CS20 Dear Sir/Madam, We, Ciontek Technology Corp. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: Mobile Smart POS Model no.: CS20, CS20A, CS20B, CS20C, CS21, CS20PRO, CS20LITE, CS20S, CS20V, CS20MINI Sincerely, Name/Title： Haoping Xing/ Product Research Director Company: Ciontek Technology Corp. Address: B501, Chanxueyan Building Wuhan University, No.6 Of Yuexing 2nd Road, Yuehai Street, Nanshan District, Shenzhen, China Phone: 86 755-86168406 Fax: 86 755-86168631 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:< 2020-12-15> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2APBP-CS20 CS20 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Haoping Xing/ Product Research Director Company: Ciontek Technology Corp. Address: B501, Chanxueyan Building Wuhan University, No.6 Of Yuexing 2nd Road, Yuehai Street, Nanshan District, Shenzhen, China Phone: 86 755-86168406 Fax: 86 755-86168631 E-Mail: [email protected]

Ciontek Technology Corp. B501, Chanxueyan Building Wuhan University, No.6 Of Yuexing 2nd Road, Yuehai Street, Nanshan District, Shenzhen, China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2020-12-15 To whom it may concern: We, Ciontek Technology Corp. the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2APBP-CS20 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Haoping Xing/ Product Research Director Company: Ciontek Technology Corp. Address: B501, Chanxueyan Building Wuhan University, No.6 Of Yuexing 2nd Road, Yuehai Street, Nanshan District, Shenzhen, China Phone: 86 755-86168406 Fax: 86 755-86168631 E-Mail: [email protected]

Page: 3 of 12 FCC ID: 2APBP-CS20 TB-RF-074-1.0 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT Page: 4 of 12 FCC ID: 2APBP-CS20 TB-RF-074-1.0 Photo 3 Appearance of EUT Photo 4 Appearance of EUT Page: 5 of 12 FCC ID: 2APBP-CS20 TB-RF-074-1.0 Photo 5 Appearance of EUT Photo 6 Appearance of EUT

Page: 1 of 12 FCC ID: 2APBP-CS20 TB-RF-074-1.0 Appendix IFCC ID Label Size for the label: 32mm X 20mm Page: 2 of 12 FCC ID: 2APBP-CS20 TB-RF-074-1.0 Appendix II ID Label Location ID LOCATION

Page: 6 of 12 FCC ID: 2APBP-CS20 TB-RF-074-1.0 Appendix IV EUT Internal Photographs Photo 7 Internal of EUT Photo 8 Internal of EUT WIFI/BT ANT. 2/3/4G DIV ANT. Page: 7 of 12 FCC ID: 2APBP-CS20 TB-RF-074-1.0 Photo 9 Internal of EUT Photo 10 Internal of EUT 2/3/4G Main ANT. NFC ANT. Page: 8 of 12 FCC ID: 2APBP-CS20 TB-RF-074-1.0 Photo 11 Appearance of Battery Photo 12 Appearance of Adapter Page: 9 of 12 FCC ID: 2APBP-CS20 TB-RF-074-1.0 Photo 13 Appearance of PCB Photo 14 Appearance of PCB Page: 10 of 12 FCC ID: 2APBP-CS20 TB-RF-074-1.0 Photo 15 Appearance of PCB Photo 16 Appearance of PCB

Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC176391 Page: 1 of 30 TB-RF-074-1.0 1A/F., Bldg.6, Yusheng Industrial Zone, The National Road No.107 Xixiang Section 467, Xixiang, Bao’an, Shenzhen, China Tel: +86 75526509301 Fax: +86 75526509195 FCC Radio Test Report FCC ID: 2APBP-CS20 Original Grant Report No. : TB-FCC176391 Applicant : Ciontek Technology Corp. Equipment Under Test (EUT) EUT Name : Mobile Smart POS Model No. : CS20 Series Model No. : CS20A, CS20B, CS20C, CS21, CS20PRO, CS20LITE, CS20S, CS20V, CS20MINI Brand Name : Ciontek Sample ID : TBBJ-20200916-08_1-01& TBBJ-20200916-08_1-02 Receipt Date : 2020-09-29 Test Date : 2020-09-30 to 2020-12-14 Issue Date : 2020-12-14 Standards : FCC Part 15, Subpart C 15.225 Test Method : ANSI C63.10: 2013 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above, Test/Witness Engineer : Rebeca Engineer Supervisor : Ivan Su Engineer Manager : Ray Lai This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TB-FCC176391 Page: 2 of 30 TB-RF-074-1.0 Contents CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT ............................................................................. 5 1.1 Client Information ................................................................................................................. 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 6 1.4 Description of Support Units .............................................................................................. 6 1.5 Description of Test Mode .................................................................................................... 7 1.6 Description of Test Software Setting ................................................................................ 8 1.7 Measurement Uncertainty .................................................................................................. 8 1.8 Test Facility ........................................................................................................................... 9 2. TEST SUMMARY ..................................................................................................................... 10 3. TEST SOFTWARE ................................................................................................................... 10 4. TEST EQUIPMENT .................................................................................................................. 11 5. CONDUCTED EMISSION TEST ........................................................................................... 12 5.1 Test Standard and Limit .................................................................................................... 12 5.2 Test Setup ........................................................................................................................... 12 5.3 Test Procedure ................................................................................................................... 13 5.4 Deviation From Test Standard ......................................................................................... 13 5.5 EUT Operating Mode ........................................................................................................ 13 5.6 Test Data ............................................................................................................................. 13 6. RADIATED EMISSION TEST ................................................................................................ 14 6.1 Test Standard and Limit .................................................................................................... 14 5.2 Test Setup ........................................................................................................................... 14 6.3 Test Procedure ................................................................................................................... 15 6.4 Deviation From Test Standard ......................................................................................... 15 6.5 EUT Operating Condition ................................................................................................. 15 6.6 Test Data ............................................................................................................................. 15 7. ELECTRIC FIELD STRENGTH OF FUNDAMENTAL AND OUTSIDE THE ALLOCATED BANDS ......................................................................................................................... 16 7.1 Test Standard and Limit .................................................................................................... 16 7.2 Test Setup ........................................................................................................................... 17 7.3 Test Procedure ................................................................................................................... 17 7.4 Deviation From Test Standard ......................................................................................... 17 7.5 EUT Operating Condition ................................................................................................. 17 7.6 Test Data ............................................................................................................................. 17 8. OCCUPIED BANDWIDTH TEST .........................................................................................…

Text truncated - open the document above for the full version.

Page: 11 of 12 FCC ID: 2APBP-CS20 TB-RF-074-1.0 Appendix V EUT Test Photographs 15C Test Setup Photo of Setup for Radiated Emission (Above 1 GHz) Photo of Setup for Radiated Emission (Below 1 GHz) Page: 12 of 12 FCC ID: 2APBP-CS20 TB-RF-074-1.0 Photo of Setup for Radiated Emission (Below 30MHz) Photo of Setup for Conducted Emission -----END OF REPORT-----
