2APDTN4BTGTXScorpius-N4BTG

WIRELESS NUMERICAL KEYPAD MOUSE SCORPIUS-N4BTG On-the-fly switchable 2.4GHz / Bluetooth wireless connectivity Switchable numerical keypad / mouse function 1000 DPI optical sensor Up to 100 hrs battery life with AAA battery *2 KEYPAD RECEIVER N4BTG-RC FCC ID: 2APDTRX KEYPAD MOUSE N4BTG FCC ID: 2APDTN4BTGTX © 2021 ione® .All rights reserved. ione®, the ione logo, and product names referred to herein are the registered trademarks of Ione Technology Inc. All other trademarks are the property of their respective owners. IONE ELECTRONIC TECHNOLOGY CO., LTD. TAIWAN BRANCH Manufactured in China. www.ione.com.tw / ione@ ione.com.tw www.ione-europe.com / info@ ione-europe.com www.ione-usa.com / support@ ione-usa.com www.ione-cn.com / [email protected] www.ione-th.com / [email protected] 產 地：中 國 制造商：薩摩亞商愛旺電子科技有限公司台灣分公司 EN: 2.4GHz / Bluetooth dual wireless connectivity 1000 DPI numerical keypad mouse TC: 2.4GHz / 藍牙雙無線連接1000 DPI數字鍵盤滑鼠 SC: 2.4GHz / 蓝牙双无线连接1000 DPI数字键盘鼠标 DE: 2,4 GHz / Bluetooth Kabelloser Dual-Modus-Netzwerkverbindung 1000 DPI Nummerblock mit intergrierter Maus SYSTEM REQUIREMENTS PC with Windows 10 OSor Host device can support BT5.0 mouse PACKAGE CONTENTS • Keypad Mouse •2.4GHz Dongle • 2 x AAA Batteries •User’s Guide EANUPC WirelessBluetooth 5.0 BT SCORPIUS-N4-BTG NUMMERNBLOCK MIT INTEGRIERTER MAUS Vielen Dank, dass Sie sich für die Scorpius-N4BTG Nummernblock mit integrierter Maus entschieden haben. Bitte lesen Sie die Anleitung und befolgen Sie die Anweisung. Bitte bewahren Sie es nach dem Lesen in der Verpackung auf. Bei Fragen wenden Sie sich bitte an www.ione.com.tw oder www.ione-usa.com oder www.ione-europe.com. NUMMERNBLOCK MIT INTEGRIERTER MAUS UND ZUBEHÖR Nummernblock 2,4 GHz USB Empfängergerät Bedienungsanleitung AAA-Batterie x 2 SYSTEM ANFORDERUNGEN Erfordert Microsoft Windows 10 zu betreiben, oder Host-Gerät unterstützt Bluetooth Version 5.0 A. Linke Maustaste B. Mittlere Mausaste und Mausrad C. Rechter Mausaste D. Zifferntasten E. Modischalter F. Netzschalter G. Pairing H. Batterieabdeckung HARDWARE-INSTALLATION Schritt 1: Schalten Sie den Computer ein und stecken Sie den Dongle in den USB-Anschluss. Schritt 2: Öffnen Sie die Batterieabdeckung und legen Sie die Batterie in die Nummerblock. Schritt 3: Schieben Sie den Netzschalter auf "Ein". Die Anzeige zeigt Rot an. Schritt 4: Wenn sich die Nummerblock im RF-Modus befindet, können Sie beim Umschalten der Modischalter drei verschiedene Arbeitsmodi ändern. Die drei verschiedenen Modi sind unten dargestellt. BLUETOOTH-MODI Schritt 1: Vergewissern Sie sich, dass der Akku in der Nummernblock installiert ist und sich der Netzschalter in der Position „On“ befindet. Schritt 2: Drücken Sie 3 Sekunden lang auf „Mode Switch“. Die Anzeige wechselt zu blauer Farbe. Schritt 3: Drücken Sie die Pairing-Taste unter der Nummernblock. Das Bluetooth-Gerät wird nach Pairing durchsucht, wenn die blaue LED blinkt Schritt 4: Suchen Sie im RF-Modus nach „Keypad MS“, dannnach wird Bluetooth verbunden. Schritt 5: Nachden die Bluetooth-Pairing abgeschlossen ist, können Sie die Nummernblock im BT-Modi verwenden. DEUTSCH BLUETOOTH WIRELESS MODE (BLUE INDICATOR) Step 1: Insert (2)AAA batteries into the compartment. Step 2: Press “Mode Switch” for 3 seconds and the indicator will change to blue color. Step 3: Push the “CONNECT” button under the keypad. The blue LED indicator will flash indicates the device is on discoverable mode. Step 4: Open Bluetooth settings or Bluetooth device manager on your device and pair with “KEYPAD MS”. 2.4 GHZ WIRELESS MODE (RED INDICATOR) Step 1: Insert the dongle into USB port. Step 2: Insert (2)AAA batteries into the compartment. Step 3: Slide the power switch to “ON” position from underside. Num Lock Indicator Mouse Indicator Keypad Indicator Numerical Keypad with Mouse Numerical Keypad only Mouse only Mode Indicator Mode Num Lock Indicator Mouse Indicator Keypad Indicator ON ON OFF ON OFF ON ON ON OFF SCORPIUS-N4BTG KEYPAD MOUSE Thank you for purchasing Scorpius-N4BTG Keypad Mouse. Please read the instruction and follow the steps for use. After reading this instruction, please keep it inside the box. If you have any questions, please contact us at www.ione.com.tw or www.ione-usa.com or www.ione-europe.com. KEYPAD MOUSE AND ACCESSORIES Keypad Mouse 2.4GHz Dongle User’s guide AAA Battery x 2 SYSTEM REQUIREMENTS PC with Windows 10 OSor Host device with the support of BT5.0 mouse A. Left Button B. Middle Button and Scroll Wheel C. Right Button D. Numerical Buttons E. Mode Switch F. Power Slide switch G. Pairing H. Battery Cover ENGLISH B A C E H G D F CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. RADIATION EXPOSURE STATEMENT: The product comply with the FCC portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available. FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipme…

Text truncated - open the document above for the full version.

Test report No. : 4789992451-EP Page : 1 of 21 Issued date : 2021/7/13 Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Product Photos External Photos Test report No. : 4789992451-EP Page : 2 of 21 Issued date : 2021/7/13 Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Test report No. : 4789992451-EP Page : 3 of 21 Issued date : 2021/7/13 Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Test report No. : 4789992451-EP Page : 4 of 21 Issued date : 2021/7/13 Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948

N4BTG_Model_Label_iONE Size: W31.6mm x H20.6mm 裁切線 N4BTG210300001 序號 “年份” 代碼 2020 → 20 2021 → 21 S/N 說明 產品名生產年月 1個空格 流水號 31.6 mm 20.6 mm Product Name: Scorpius-N4BTG Model Name: N4BTG FCC ID: 2APDTN4BTGTX Rating: 3V , 100mA Made in China N4BTG_Model_Label_iONE 裁切線 N4BTG210300001 序號 “年份” 代碼 2020 → 20 2021 → 21 S/N 說明 產品名生產年月 1個空格 流水號 31.6 mm 20.6 mm label location: attached on the bottom of the device

Test report No. : 4789992451-EP Page : 7 of 21 Issued date : 2021/7/13 Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Internal Photos Test report No. : 4789992451-EP Page : 8 of 21 Issued date : 2021/7/13 Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Test report No. : 4789992451-EP Page : 9 of 21 Issued date : 2021/7/13 Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Test report No. : 4789992451-EP Page : 10 of 21 Issued date : 2021/7/13 Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Test report No. : 4789992451-EP Page : 11 of 21 Issued date : 2021/7/13 Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Test report No. : 4789992451-EP Page : 12 of 21 Issued date : 2021/7/13 Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Test report No. : 4789992451-EP Page : 13 of 21 Issued date : 2021/7/13 Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Test report No. : 4789992451-EP Page : 14 of 21 Issued date : 2021/7/13 Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Test report No. : 4789992451-EP Page : 15 of 21 Issued date : 2021/7/13 Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Test report No. : 4789992451-EP Page : 16 of 21 Issued date : 2021/7/13 Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Test report No. : 4789992451-EP Page : 17 of 21 Issued date : 2021/7/13 Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Test report No. : 4789992451-EP Page : 18 of 21 Issued date : 2021/7/13 Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Test report No. : 4789992451-EP Page : 19 of 21 Issued date : 2021/7/13 Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Test report No. : 4789992451-EP Page : 20 of 21 Issued date : 2021/7/13 Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Test report No. : 4789992451-EP Page : 21 of 21 Issued date : 2021/7/13 Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 RF Antenna RF CHIP

Test report No. : 4789992451-US-R2-V0 Page : 1 of 9 Issued date : 2021/7/13 FCC ID : 2APDTN4BTGTX Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX) :+886-3-583-7948 Doc No: 17-EM-F0864 / 5.0 Maximum Permissible Exposure Report Product : Scorpius-N4BTG Model Name : N4BTG FCC ID : 2APDTN4BTGTX Test Regulation : 47 CFR FCC Part 2.1093 Received Date : 2021/6/9 Test Date : 2021/6/9 ~ 2021/6/16 Issued Date : 2021/7/13 Applicant : IONE ELECTRONIC TECHNOLOGY CO., LTD. TAIWAN BRANCH 8F-2, #75, Sec. 1, Hsin Tai Wu Rd., Hsi Chih District, New Taipei City, Taiwan, R.O.C. (Far East World Center- Bldg.A) Issued By : Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report are responsible of the test sample(s) provided by the client only and are not to be used to indicate applicability to other similar products. Test report No. : 4789992451-US-R2-V0 Page : 2 of 9 Issued date : 2021/7/13 FCC ID : 2APDTN4BTGTX Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX) :+886-3-583-7948 Doc No: 17-EM-F0864 / 5.0 REVISION HISTORY Original Test Report No.: 4789992451-US-R2-V0 Rev. Test report No. Date Page revised Contents Original 4789992451-US-R2-V0 2021/7/13 - Initial issue Test report No. : 4789992451-US-R2-V0 Page : 3 of 9 Issued date : 2021/7/13 FCC ID : 2APDTN4BTGTX Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX) :+886-3-583-7948 Doc No: 17-EM-F0864 / 5.0 Table of Contents 1. Attestation of Test Results ......................................................................................... 4 2. Test Methodology and Reference Procedures ......................................................... 5 3. Facilities and Accreditation ...................................................................................... 5 4. Equipment Under Test .............................................................................................. 6 4.1. Description of EUT .............................................................................................. 6 4.2. Description of Available Antennas ...................................................................... 7 5. Requirement ............................................................................................................... 8 6. Radio Frequency SAR Test Exclusion Thresholds ................................................. 9 Test report No. : 4789992451-US-R2-V0 Page : 4 of 9 Issued date : 2021/7/13 FCC ID : 2APDTN4BTGTX Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX) :+886-3-583-7948 Doc No: 17-EM-F0864 / 5.0 1. Attestation of Test Results APPLICANT: IONE ELECTRONIC TECHNOLOGY CO., LTD. TAIWAN BRANCH 8F-2, #75, Sec. 1, Hsin Tai Wu Rd., Hsi Chih District, New Taipei City, Taiwan, R.O.C. (Far East World Center-Bldg.A) EUT DESCRIPTION: Scorpius-N4BTG BRAND: iOne MODEL: N4BTG SAMPLE STAGE: Engineering Verification Test sample APPLICABLE STANDARDS STANDARD Test Results 47 CFR FCC PART 2.1093 PASS Underwriters Laboratories Taiwan Co., Ltd. tested the above equipment in accordance with the requirements set forth in the above standards. All indications of Pass/Fail in this report are opinions expressed by Underwriters Laboratories Taiwan Co., Ltd. based on interpretations and/or observations of test results. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by Underwriters Laboratories Taiwan Co., Ltd. and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Underwriters Laboratories Taiwan Co., Ltd. will constitute fraud and shall nullify the document. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, any agency of the Federal Government, or any agency of any government. Prepared By: Approved and Authorized By: Sally Lu Date : 2021/7/13 Mike Cai Date : 2021/7/13 Project Handler Engineer Project Associate Test report No. : 4789992451-US-R2-V0 Page : 5 of 9 Issued date : 2021/7/13 FCC ID : 2APDTN4BTGTX Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX) :+886-3-583-7948 Doc No: 17-EM-F0864 / 5.0 2. Test Methodology and Reference Procedures The tests documented in this report were performed in accordance with KDB 447498 D01 General RF Exposure Guidance v06. 3. Facilities and Accreditation Test Location Underwriters Laboratories Taiwan Co., Ltd. Address Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Accreditation Certificate Underwriters Laboratories Taiwan Co., Ltd. is accredited by TAF, Laboratory Code 3398. The full scope of accreditation can be viewed at http://accreditation.taftw.org.tw/taf/public/basic/viewApplyI tems.action?unitNo=3398 Test report No. : 4789992451-US-R2-V0 Page : 6 of …

Text truncated - open the document above for the full version.

Test report No. : 4789992451-US-R0-V0 Page : 1 of 49 Issued date : 2021/7/13 FCC ID : 2APDTN4BTGTX Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Doc No: 17-EM-F0876 / 6.0 RADIO TEST REPORT Product : Scorpius-N4BTG Model Name : N4BTG FCC ID : 2APDTN4BTGTX Test Regulation : FCC 47 CFR Part 15 Subpart C (Section 15.247) Received Date : 2021/6/9 Test Date : 2021/6/9 ~ 2021/6/16 Issued Date : 2021/7/13 Applicant : IONE ELECTRONIC TECHNOLOGY CO., LTD. TAIWAN BRANCH 8F-2, #75, Sec. 1, Hsin Tai Wu Rd., Hsi Chih District, New Taipei City, Taiwan, R.O.C. (Far East World Center- Bldg.A) Issued By : Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report are responsible of the test sample(s) provided by the client only and are not to be used to indicate applicability to other similar products. Test report No. : 4789992451-US-R0-V0 Page : 2 of 49 Issued date : 2021/7/13 FCC ID : 2APDTN4BTGTX Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Doc No: 17-EM-F0876 / 6.0 REVISION HISTORY Original Test Report No.: 4789992451-US-R0-V0 Rev. Test report No. Date Page revised Contents Original 4789992451-US-R0-V0 2021/7/13 - Initial issue Test report No. : 4789992451-US-R0-V0 Page : 3 of 49 Issued date : 2021/7/13 FCC ID : 2APDTN4BTGTX Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Doc No: 17-EM-F0876 / 6.0 Table of Contents 1. Attestation of Test Results .............................................................................................4 2. Summary of Test Results ...............................................................................................5 3. Test Methodology and Reference Procedures.............................................................6 4. Facilities and Accreditation ...........................................................................................6 5. Measurement Uncertainty .............................................................................................7 6. Equipment under Test ...................................................................................................8 6.1. Description of EUT .............................................................................................. 8 6.2. Channel List ......................................................................................................... 9 6.3. Test Condition ...................................................................................................... 9 6.4. Description of Available Antennas ...................................................................... 9 6.5. Test Mode Applicability and Tested Channel Detail ......................................... 10 6.6. Duty cycle .......................................................................................................... 11 7. Test Equipment ............................................................................................................ 12 8. Description of Test Setup ............................................................................................ 14 9. Test Results ................................................................................................................... 16 9.1. 6dB Bandwidth .................................................................................................. 16 9.2. Conducted Output Power ................................................................................... 19 9.3. Power Spectral Density ...................................................................................... 21 9.4. Conducted Out of Band Emission ...................................................................... 24 9.5. Radiated Spurious Emission .............................................................................. 29 Appendix I Radiated Band Edge Measurement .............................................................. 44 Appendix II Radiated Spurious Emission Measurement ............................................... 48 Test report No. : 4789992451-US-R0-V0 Page : 4 of 49 Issued date : 2021/7/13 FCC ID : 2APDTN4BTGTX Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Doc No: 17-EM-F0876 / 6.0 1. Attestation of Test Results APPLICANT: IONE ELECTRONIC TECHNOLOGY CO., LTD. TAIWAN BRANCH 8F-2, #75, Sec. 1, Hsin Tai Wu Rd., Hsi Chih District, New Taipei City, Taiwan, R.O.C. (Far East World Center-Bldg.A) EUT DESCRIPTION: Scorpius-N4BTG BRAND: iOne MODEL: N4BTG SAMPLE STAGE: Engineering Verification Test sample DATE of TESTED: 2021/6/9 ~ 2021/6/16 APPLICABLE STANDARDS STANDARD Test Results FCC 47 CFR PART 15 Subpart C (Section 15.247) PASS Underwriters Laboratories Taiwan Co., Ltd. tested the above equipment in accordance with the requirements set forth in the above standards. All indications of Pass/Fail in this report are opinions expressed by Underwriters Laboratories Taiwan Co., Ltd. based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. The test results show that the equipment tested is capab…

Text truncated - open the document above for the full version.

Test report No. : 4789992451-US-R1-V0 Page : 1 of 38 Issued date : 2021/7/13 FCC ID : 2APDTN4BTGTX Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Doc No: 17-EM-F0876 / 6.0 RADIO TEST REPORT The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report are responsible of the test sample(s) provided by the client only and are not to be used to indicate applicability to other similar products. Product : Scorpius-N4BTG Model Name : N4BTG FCC ID : 2APDTN4BTGTX Test Regulation : FCC 47 CFR Part 15 Subpart C (Section 15.247) Received Date : 2021/6/9 Test Date : 2021/6/9 ~ 2021/6/16 Issued Date : 2021/7/13 Applicant : IONE ELECTRONIC TECHNOLOGY CO., LTD. TAIWAN BRANCH 8F-2, #75, Sec. 1, Hsin Tai Wu Rd., Hsi Chih District, New Taipei City, Taiwan, R.O.C. (Far East World Center- Bldg.A) Issued By : Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Test report No. : 4789992451-US-R1-V0 Page : 2 of 38 Issued date : 2021/7/13 FCC ID : 2APDTN4BTGTX Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Doc No: 17-EM-F0876 / 6.0 REVISION HISTORY Original Test Report No.: 4789992451-US-R1-V0 Rev. Test report No. Date Page revised Contents Original 4789992451-US-R1-V0 2021/7/13 - Initial issue Test report No. : 4789992451-US-R1-V0 Page : 3 of 38 Issued date : 2021/7/13 FCC ID : 2APDTN4BTGTX Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Doc No: 17-EM-F0876 / 6.0 Table of Contents 1. Attestation of Test Results .............................................................................................4 2. Summary of Test Results ...............................................................................................5 3. Test Methodology and Reference Procedures.............................................................6 4. Facilities and Accreditation ...........................................................................................6 5. Measurement Uncertainty .............................................................................................7 6. Equipment under Test ...................................................................................................8 6.1. Description of EUT .............................................................................................. 8 6.2. Channel List ......................................................................................................... 9 6.3. Test Condition .................................................................................................... 10 6.4. Description of Available Antennas .................................................................... 10 6.5. Test Mode Applicability and Tested Channel Detail ......................................... 11 6.6. Duty cycle .......................................................................................................... 12 7. Test Equipment ............................................................................................................ 13 8. Description of Test Setup ............................................................................................ 15 9. Test Results ................................................................................................................... 17 9.1. 6dB Bandwidth .................................................................................................. 17 9.2. Conducted Output Power ................................................................................... 19 9.3. Power Spectral Density ...................................................................................... 21 9.4. Conducted Out of Band Emission ...................................................................... 23 9.5. Radiated Spurious Emission .............................................................................. 26 Appendix I Radiated Band Edge Measurement .............................................................. 36 Appendix II Radiated Spurious Emission Measurement ............................................... 38 Test report No. : 4789992451-US-R1-V0 Page : 4 of 38 Issued date : 2021/7/13 FCC ID : 2APDTN4BTGTX Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsimile (FAX ) :+886-3-583-7948 Doc No: 17-EM-F0876 / 6.0 1. Attestation of Test Results APPLICANT: IONE ELECTRONIC TECHNOLOGY CO., LTD. TAIWAN BRANCH 8F-2, #75, Sec. 1, Hsin Tai Wu Rd., Hsi Chih District, New Taipei City, Taiwan, R.O.C. (Far East World Center-Bldg.A) EUT DESCRIPTION: Scorpius-N4BTG BRAND: iOne MODEL: N4BTG SAMPLE STAGE: Engineering Verification Test sample DATE of TESTED: 2021/6/9 ~ 2021/6/16 APPLICABLE STANDARDS STANDARD Test Results FCC 47 CFR PART 15 Subpart C (Section 15.247) PASS Underwriters Laboratories Taiwan Co., Ltd. tested the above equipment in accordance with the requirements set forth in the above standards. All indications of Pass/Fail in this report are opinions expressed by Underwriters Laboratories Taiwan Co., Ltd. based on interpretations and/or observations of test results. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results docume…

Text truncated - open the document above for the full version.

Page : 1 of 2 Issued date : 2021/7/13 FCC ID : 2APDTN4BTGTX Underwriters Laboratories Taiwan Co., Ltd. Building B and Building E, No. 372-7, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County, Taiwan Telephone :+886-2-7737-3000 Facsim…

Text truncated - open the document above for the full version.
