2APEW-2B513ESR 15W Car Charger with MagSafe + CryoBoost

70.3 Electrical Accessories integrating a MagSafe Charger Module shall comply with the electrical requirements in this section. 70.3.1 Power Accessories integrating a MagSafe Charger Module shall provide power from either: ● An internal power supply. ● An external USB power source. If the accessory integrates an Internal Power Supply (page 629), it: ● May accept external power using any of the following integrated connectors so long as the accessory actively conditions and regulates the power: ● USB-C Receptacle (page 831). ● USB-C Plug (page 829). ● Non-USB connector. ● May consume some of the external power for its own purposes so long as all MagSafe Charger Module power requirements are met. If the accessory relies on an External USB Power Source (page 629) to provide power to the MagSafe Charger Module and does not contain its own internal power supply, it: ● Shall connect to the external USB power source using a USB-C Plug (page 829). ● Shall not consume any power from the external USB power source. ● Shall not monitor or modify the USB D+/D- or CC signals from the external USB power source. The accessory shall integrate reverse voltage protection (RVP) between the MagSafe Charger Module power and ground. The MagSafe Charger Module maximum average current is 2.5 A at 9 V. The current is further limited based on the power source identification (for example, USB PD, USB D+/D- resistor network values, or USB enumeration). The MagSafe Charger Module includes: ● Overvoltage protection (OVP). ● Overcurrent protection (OCP). ● Overtemperature protection (OTP). ● Foreign object detection (FOD). 2022-10-26 | Copyright © 2022 Apple Inc. All Rights Reserved. 628 70. Apple MagSafe Charger Module 70.3 Electrical 70.3.1.1 Internal Power Supply A MagSafe Charger Module powered by an accessory's internal power supply shall be configured to operate in 9 V mode using the PowerMode (page 635) command. After configuration, the USB D+/D- and CC pads shall be left Not Connected (NC) as specified in Pads and Assignments (page 630). The accessory's internal power supply for the MagSafe Charger Module shall: ● Support a load of 0 W to 20 W (2.22 A at 9 V). Apple recommends supporting up to 22.5 W (2.5 A at 9 V). ● Regulate input voltage at the PWR pad of the MagSafe Charger Module to 9.0 V ±5% under any supported load. ● Hold PWR ripple below: ● 180 mVpp from 1 kHz to 4 kHz under any supported load. ● 400 mVpp below 1 kHz or above 4 kHz under any supported load. ● Have a PWR rise time (10% to 90%) of less than 10 ms during power on. ● Tolerate a transient current up to 4.5 A for up to 1 ms. 70.3.1.2 External USB Power Source A MagSafe Charger Module powered by an external USB power source shall be configured to operate in USB mode using the PowerMode (page 635) command. Accessories relying on an external USB power source to provide power to the MagSafe Charger Module shall: ● Have maximum 112 mΩ round trip DCR (USB VBUS to Ground) between the MagSafe Charger Module connector and the accessory's USB-C Plug (page 829). ● Have a VBUS DCR less than 92 mΩ assuming 1 m cable. ● Have a GND DCR less than 20 mΩ assuming 1 m cable. ● Have a D+/D- DCR less than 1013 mΩ assuming 1 m cable. ● Have a CC DCR less than 5580 mΩ assuming 1 m cable. ● Pass the USB-IF Full Speed signal quality test. See Full Speed USB (page 826) and Full Speed USB (page 837). ● Meet the USB-IF inrush current specification of 51.5 μC. See the USB-IF Full and Low Speed Electrical and Interoperability Compliance Test Procedure and Gold Suite Test Procedure for USB-IF test procedures. If the accessory implements additional OCP, the maximum round trip DCR shall include the on-resistance of the OCP circuit. If the accessory bundles an external USB power source, it shall provide at least 20 W (2.22 A at 9 V). Apple recommends supporting up to 22.5 W (2.5 A at 9 V). 2022-10-26 | Copyright © 2022 Apple Inc. All Rights Reserved. 629 70. Apple MagSafe Charger Module 70.3 Electrical 70.3.1.3 Charging Efficiency Accessories integrating a MagSafe Charger Module shall not impair device's ability to efficiently charge from provided power. 70.3.2 Pads and Assignments The module pad assignments are shown in dimensional drawings. Table 70-1MagSafe Charger Module Pads 9 V Mode AssignmentUSB Mode AssignmentNamePad 9 VUSB VBUSPWR1 NCUSB D-USB D-2 NCUSB D+USB D+3 NCUSB CCUSB CC4 GroundGroundGND5 The module housing is grounded internally and shall not be directly connected to an external ground. Care should be taken to ensure any connection to the GND pad does not short to the enclosure. Signals from the USB D+ and D- pads shall be routed as a differential pair. All pads support up to 20 AWG wires. 70.3.3 ESD Accessories shall ensure there is no arcing path to the MagSafe Charger Module housing. Air gaps between the accessory housing and the module should be covered using a non-conductive coating or other material to prevent arcing. If air gaps cannot be covered, the module's metal housing near the gap should be insulated with a coating, such as: ● >250 μm polyurethane. ● >100 μm parylene. 70.3.4 EMC Accessories integrating the MagSafe Charger Module should be designed for Electromagnetic Compatibility (EMC) (page 328). 2022-10-26 | Copyright © 2022 Apple Inc. All Rights Reserved. 630 70. Apple MagSafe Charger Module 70.3 Electrical The wires connected to the module pads should be part of a shielded cable. The shield and drain/ground wires should be tied together and connected to the GND pad of the module. The shield shall not be connected to the module housing. Avoid coupling from the accessory enclosure to the module housing. Cable bundles should be physically isolated from the module housing to minimize unwanted coupling. A spacer or absorber material may be placed between the cable bundle and the module housing for additional isolation. The material should be 1 mm thick and should be one of the following: ● RF absorber material effective at 30-100 MHz. ● Spacer w…

Text truncated - open the document above for the full version.

The MagSafe Charger Module enables accessories to wirelessly charge MagSafe-capable devices. Examples of accessories benefiting from including the MagSafe Charger Module include charging cables, docks, and Battery Packs (page 150). 70.1 Accessory Integration All MagSafe Charger Module accessories shall: ● Provide power to the device. See Electrical (page 628). ● Permit the device to move relative to the MagSafe Charger Module. The MagSafe Charger Module is available in the following variants: ● MagSafe Charger Module (C222). ● MagSafe Charger Module (C222x) for increased design flexibility. ● MagSafe Charger Module (C223) with increased attach force. Examples of accessories benefiting from the increased attach force of the MagSafe Charger Module (C223) include vent mounted chargers, battery packs, and tripod mounts. Figure 70-1 MagSafe Charger Module (C222) 70. Apple MagSafe Charger Module 2022-10-26 | Copyright © 2022 Apple Inc. All Rights Reserved. 625 Figure 70-2 MagSafe Charger Module (C222x) Figure 70-3 MagSafe Charger Module (C223) 70.2 Mechanical See the following for dimensional drawings: ● MagSafe Charger Module (C222) Dimensions 1 of 2 (page 638) ● MagSafe Charger Module (C222) Dimensions 2 of 2 (page 639) ● MagSafe Charger Module (C222x) Dimensions (page 640) ● MagSafe Charger Module (C223) Dimensions 1 of 2 (page 641) ● MagSafe Charger Module (C223) Dimensions 2 of 2 (page 642) The accessory shall not interfere with or cause Scratches and Damage (page 53) to the device. To avoid interference with devices, accessories shall: ● Mount the MagSafe Charger Module (C222) or MagSafe Charger Module (C223) so its surface is proud of the accessory surface. 2022-10-26 | Copyright © 2022 Apple Inc. All Rights Reserved. 626 70. Apple MagSafe Charger Module 70.2 Mechanical ● Not exceed 30 mm from the center of the MagSafe Charger Module surface towards the top edge of the device for all supported device orientations. If the device can be attached in any orientation, the accessory shall not exceed 30 mm in radius around the center of the MagSafe Charger Module surface. ● Maintain a clearance of 5 mm from the back of the device (mating surface) for any part of the accessory past the 30 mm keep-in constraint. ● Meet enclosure integration requirements found in module dimensional drawings. Figure 70-4 MagSafe Charger Module accessory clearance Non axisymmetricAxisymmetric To avoid interference with wireless charging, accessories: ● Shall not cover the MagSafe Charger Module (C222x) with radio frequency absorbing Materials and Coatings (page 64). ● Should not mount the MagSafe Charger Module near ferromagnetic metals or alloys. Accessory mounts designed for use in vehicles shall include an Orientation Magnet (page 368) unless the mating surface is guaranteed to be horizontal (such as when integrated into the vehicle or permanently mounted), in which case an orientation magnet is not required. Mounting designs should consider factors such as mount stiffness and mounting location. Accessories integrating the MagSafe Charger Module (C222x) should have a mating surface with a kinetic friction coefficient against stainless steel greater than 0.35. MagSafe Charger Module storage temperature range is from -20 °C to 40 °C. 2022-10-26 | Copyright © 2022 Apple Inc. All Rights Reserved. 627 70. Apple MagSafe Charger Module 70.2 Mechanical

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: Sahara Case LLC FRN: 0033710385 Contact Name: Paul Address: 199 E 52nd St, Suite 100 Telephone No: 208 941 3448 Email: [email protected] Applicant: Company name: Electronic Silk Road (Shenzhen) Tech Co., Ltd Product Description: ESR 15W Car Charger with MagSafe+ CryoBoost Grantee code: 2APEW FCC ID: 2APEW-2B513 Contact Name: Serena Jiang Address: 439, Building A7, Fuhai Xinxigang, Xinhe Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Telephone No: +86-15019213421 Email: [email protected] [Electronic Silk Road (Shenzhen) Tech Co., Ltd] certifies that, as of the date of this filing of the application with the TCB, [Sahara Case LLC] is our designated US agent for service of process for the above referenced FCC ID. [Electronic Silk Road (Shenzhen) Tech Co., Ltd] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [Sahara Case LLC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 06.26.2023 Applicant’s Name: Serena Jiang US Agent’s Name: Paul Title: Engineer Title: Manager Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Electronic Silk Road (Shenzhen) Tech Co., Ltd Grantee code: 2APEW FCC ID: 2APEW-2B513 Contact Name: Serena Jiang Address: 439, Building A7, Fuhai Xinxigang, Xinhe Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Telephone No: +86-15019213421 Fax No: Email: [email protected] i. [Electronic Silk Road (Shenzhen) Tech Co., Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [ Electronic Silk Road (Shenzhen) Tech Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. Electronic Silk Road (Shenzhen) Tech Co., Ltd. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Date: 06.26.2023 Applicant’s Name: Serena Jiang Title: Engineer Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Electronic Silk Road (Shenzhen) Tech Co., Ltd Address: 439, Building A7, Fuhai Xinxigang, Xinhe Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Product Name: ESR 15W Car Charger with MagSafe+ CryoBoost Model Number: 2B513 FCC Identifier: 2APEW-2B513 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Serena Jiang Date: 6/26/2023 Title: Engineer Signature of applicant:

C5266091_X10_Ed.1 1/1 Electronic Silk Road (Shenzhen) Tech Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 6/26/2023 Subject: Request for Confidentiality FCC ID: 2APEW-2B513 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Serena Jiang Date: 6/26/2023 Title: Engineer

Page 1 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Appendix - Ext Photos Model: 2B513 Page 2 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Page 3 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Page 4 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] ----End of Report----

红色区域镭雕 位置居中 H:5.5mmH:3mm 2B513-MFM风冷车载-LOGO菲林图 5.39 mm 4 2 . 8 5 m m 6.39 mm 4 1 . 1 2 m m 红色区域镭雕 位置居中 SN码根据生产日期修改 2B513-MFM风冷车载-产品信息菲林图 m

Page 1 of 6 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Appendix - Int Photos Model: 2B513 Page 2 of 6 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] ANT Page 3 of 6 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Page 4 of 6 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Page 5 of 6 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Page 6 of 6 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] ----End of Report----

Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 We b : www.mtitest.com E-mail: [email protected] Test Report Report No.: MTi230522009-01E2 Date of issue: 2023-06-16 Applicant: Electronic Silk Road (Shenzhen) Tech Co., Ltd Product: ESR 15W Car Charger with MagSafe+ CryoBoost Model(s): 2B513 FCC ID: 2APEW-2B513 Shenzhen Microtest Co., Ltd. http://www.mtitest.com Page 2 of 13 Report No.: MTi230522009-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 13 Report No.: MTi230522009-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Contents 1 General Description ........................................................................................................................ 5 1.1 Description of the EUT ....................................................................................................................................... 5 1.2 Description of test modes ................................................................................................................................... 5 1.3 Description of support units ................................................................................................................................ 6 2 Measurement uncertainty ............................................................................................................... 6 3 Test facilities and accreditations .................................................................................................... 7 3.1 Test laboratory .................................................................................................................................................... 7 4 List of test equipment ..................................................................................................................... 8 5 Test result ........................................................................................................................................ 9 5.2 Test setup ......................................................................................................................................................... 10 5.3 Test Procedures ................................................................................................................................................ 10 5.4 Equipment Approval Considerations item 5 b) of KDB 680106 D01 v03r01 .................................................... 11 5.5 Test results ....................................................................................................................................................... 12 Photographs of the Test Setup ............................................................................................................ 13 Photographs of the EUT....................................................................................................................... 13 Page 4 of 13 Report No.: MTi230522009-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Test Result Certification Applicant: Electronic Silk Road (Shenzhen) Tech Co., Ltd Address: 439, Building A7, Fuhai Xinxigang, Xinhe Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Manufacturer: Electronic Silk Road (Shenzhen) Tech Co., Ltd Address: 439, Building A7, Fuhai Xinxigang, Xinhe Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Product description Product name: ESR 15W Car Charger with MagSafe+ CryoBoost Trademark: ESR Model name: 2B513 Series Model: N/A Standards: FCC CFR 47 PART 1, § 1.1310 Test method: KDB 680106 v03r01 Date of Test Date of test: 2023-05-24 ~ 2023-06-16 Te s t result: Pass Test Engineer : (David Lee) Reviewed By: : (Leon Chen) Approved By: : (Tom Xue) Page 5 of 13 Report No.: MTi230522009-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] 1 General Description 1.1 Description of the EUT Product name: ESR 15W Car Charger with MagSafe+ CryoBoost Model name: 2B513 Series Model: N/A Model difference: N/A Electrical rating: Input: DC 9V/3A Wireless Output: 15W Accessories: 1. Type-C to Type-C cable 100cm Hardware version: V1.1 Software version: V1.0 RF specification: Operation frequency: 360 kHz Modulation type: ASK Antenna type: Coil Antenna 1.2 Description of test modes All the test modes were carried out with the EUT in normal operation, the final test mode of the EUT was the worst test mode for emission test, which was shown in this report and defined as: No. Emission test modes Mode 1 Wireless Output(15W) Mode 2 Stand-by The test data only show worst test mode: Mode 1 Page 6 of 13 Report No.: MTi230522009-01E2 Address: 101, No. 7, Zone 2, Xinxi…

Text truncated - open the document above for the full version.

Page1 of 2 産品型號 Coil specification ： DESC 版本 Rev：A.0 客戶CUST: 客户料号CUSTP/N: 一、尺寸DIMENSION:(mm) A 20±1.0 B 49±1.0 C 20±1.0 D 44±1.0 E 1±0.1 F 1±0.1 G 2.5±0.1 Note: 1.Cross out cables; 2.Coil stick round hard magnetic sheet with slot,magnetic sheet size0±1mm, b o r e5.3mm,the thickness is1±0.1mm 3.aggregate thickness 2. 5MM C223 Page2 of 2 二、原理图SCHEMATICDIAGRAM: 三、绕线参数WindingSpecification: 序号 NO. 端子 TERMINAL 线径 WIRE 圈数 Turns 绕线方向 WindingDirection 1SF丝包线0.08*70P11TsCCW 四、电气特性ELECTRICALCHARACTERISTICS: 温度TEMPERATURE:25±10°C,湿度RELATIVEHUMIDITY:65±20% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TESTFREQUENCY 测试仪器 TESTEQUIPMENTS 1IND.S-F4.6uH±20%单独线圈100KHz/1.0VLCZMETER1062B 2IND.S-F8.3uH±10%加磁片100KHz/1.0VLCZMETER1062B 3DCRS-F≤105mΩ100KHz/1.0VLCZMETER502B 4QS-F≤45100KHz/1.0VLCZMETER502B ManufacturerDONGGUAN KIMCHEN INDUSTRY INTL LIMITED AddressNo67, Baihua Road, Chongkou, Shijie Town, Dongguan City 523290 Guangdong Province China

Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Test Report Report No.: MTi230522009-01E1 Date of issue: 2023-06-16 Applicant: Electronic Silk Road (Shenzhen) Tech Co., Ltd Product: ESR 15W Car Charger with MagSafe+ CryoBoost Model(s): 2B513 FCC ID: 2APEW-2B513 Shenzhen Microtest Co., Ltd. http://www.mtitest.com Page 2 of 22 Report No.: MTi230522009-01E1 Address: 101, No. 7, Zone2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 22 Report No.: MTi230522009-01E1 Address: 101, No. 7, Zone2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Table of contents 1. General Description ........................................................................................................................ 5 1.1 Description of the EUT ....................................................................................................................................... 5 1.2 Description of test modes ................................................................................................................................... 5 1.3 Description of support units ................................................................................................................................ 6 1.4 Environmental conditions ................................................................................................................................... 6 2. Measurement uncertainty ............................................................................................................... 7 3. Test laboratory ................................................................................................................................. 7 4. Summary of Test Result .................................................................................................................. 8 5. List of test equipment ..................................................................................................................... 9 6. Test Results ................................................................................................................................... 10 6.1 Antenna requirement .................................................................................................................................. 10 6.2 AC power line conducted emissions ........................................................................................................... 11 6.3 Radiated emissions..................................................................................................................................... 14 6.4 Occupied bandwidth test ............................................................................................................................ 21 Photographs of the test setup ............................................................................................................. 22 Photographs of the EUT....................................................................................................................... 22 Page 4 of 22 Report No.: MTi230522009-01E1 Address: 101, No. 7, Zone2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Test Result Certification Applicant: Electronic Silk Road (Shenzhen) Tech Co., Ltd Address: 439, Buil…
