2APEW-EFC004OHaloLock 2-in-1 Magnetic Wireless Charger
Electronic Silk Road (Shenzhen) Tech Co., Ltd
Click to zoom
Application Details
- Equipment Class
- DCD - Part 15 Low Power Transmitter Below 1705 kHz
- Date of Grant
- Feb 06, 2021
- Application Purpose
- Original Equipment
- Date of Application
- Feb 06, 2021
- Equipment Note
- HaloLock 2-in-1 Magnetic Wireless Charger
- Frequency Range
- 0.11100000 - 0.20500000
- Country
- China
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
External Photos
FCCID:2APEW-EFC004O .
ID Label/Location Info
LabelLocationOnEUT Label ProductName:HaloLock2-in-1MagneticWirelessCharger ModelNo.:EFC004O FCCID:2APEW-EFC004O ThisdevicecomplieswithPart15oftheFCCRules.Operationis subjecttothefollowingtwoconditions: (1)Thisdevicemaynotcauseharmfulinterference,and (2)Thisdevicemustacceptanyinterferencereceived,including interferencethatmaycauseundesiredoperation.
Internal Photos
FCCID:2APEW-EFC004O ANT1ANT2 .
Operational Description
version01 ElectronicSilkRoad(Shenzhen)TechCo.,Ltd DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.:EFC004O FCCID:2APEW-EFC004O fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsfor internal antennatype(s) describedbelow: ModelNo.ofantenna: N/A Typeofantenna:InductiveloopcoilAntenna Gainoftheantenna:0dBi Frequencyrange:111-205KHz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Companyname:ElectronicSilkRoad(Shenzhen)TechCo.,Ltd Address:7thF,Building10B,TaihuaWutongIndustrialPark,GushuDevelopment Zones,XixiangStreet,Bao'anArea,Shenzhen,China City:Shenzhen ZIP/Postalcode:/ Country:China Place:ShenzhenDate:2/1/2021 Signature:
RF Exposure Info
ReportNo.:18220WC00152202FCCID:2APEW-EFC004OPage1of13 Code:AB-RF-05-a FCCTESTREPORT ClientName:ElectronicSilkRoad(Shenzhen)TechCo.,Ltd Address: 7thF,Building10B,TaihuaWutongIndustrialPark,Gushu DevelopmentZones,XixiangStreet,Bao'anArea, Shenzhen,China ProductName:HaloLock2-in-1MagneticWirelessCharger Date:Feb.01,2021 ShenzhenAnbotekComplianceLaboratoryLimited ReportNo.:18220WC00152202FCCID:2APEW-EFC004OPage2of13 Code:AB-RF-05-a Contents 1.GeneralInformation ............................................................................................................................................... 4 1.1.ClientInformation ....................................................................................................................................... 4 1.2.DescriptionofDevice(EUT) ..................................................................................................................... 4 1.3.AuxiliaryEquipmentUsedDuringTest ................................................................................................... 5 1.4.TestEquipmentList .................................................................................................................................... 5 1.5.MeasurementUncertainty ......................................................................................................................... 5 1.6.DescriptionofTestFacility ........................................................................................................................ 6 2.MeasurementandResult ..................................................................................................................................... 7 2.1.Requirements .............................................................................................................................................. 7 2.2.TestSetup .................................................................................................................................................... 8 2.3.TestProcedure ............................................................................................................................................ 8 2.4.TestResult ................................................................................................................................................... 8 2.4.1.EquipmentApprovalConsiderationsitem5.bofKDB680106D01v03. ...................................... 8 2.4.2.EnvironmentalevaluationandexposurelimitaccordingtoFCCCFR47part1,1.1307(b), 1.1310 ................................................................................................................................................................ 10 APPENDIXI--TESTSETUPPHOTOGRAPH ................................................................................................... 11 ReportNo.:18220WC00152202FCCID:2APEW-EFC004OPage3of13 Code:AB-RF-05-a TESTREPORT Applicant: ElectronicSilkRoad(Shenzhen)TechCo.,Ltd Manufacturer: ElectronicSilkRoad(Shenzhen)TechCo.,Ltd ProductName:HaloLock2-in-1MagneticWirelessCharger ModelNo.:EFC004O TradeMark: ESR Rating(s): Input:DC5V/3A,DC9V/2A(viaadapterinput:100-240V~,50-60Hz,0.5AMax) Wirelessoutput1:5W/7.5W/10W Wirelessoutput2:5W/7.5W/10W 2-in-1Totalpower:10W(MAX) TestStandard(s): FCCPart1.1310,1.1307(b) TestMethod(s): KDB680106D01RFExposureWirelessChargingAppsv03 ThedevicedescribedaboveistestedbyShenzhenAnbotekComplianceLaboratoryLimitedto determinethemaximumemissionlevelsemanatingfromthedeviceandtheseverelevelsofthedevice canendureanditsperformancecriterion.Themeasurementresultsarecontainedinthistestreportand ShenzhenAnbotekComplianceLaboratoryLimitedisassumedfullofresponsibilityfortheaccuracy andcompletenessofthesemeasurements.Also,thisreportshowsthattheEUT(EquipmentUnder Test)istechnicallycompliantwiththeFCCPart1.1307&KDB680106D01requirements. Thisreportappliestoabovetestedsampleonlyandshallnotbereproducedinpartwithoutwritten approvalofShenzhenAnbotekComplianceLaboratoryLimited. DateofReceipt Oct.22,2020 DateofTest Oct.22,2020~Jan.28,2021 PreparedBy (Engineer/YiliaZhong) Reviewer (Supervisor/BiboZhang) Approved&AuthorizedSigner (Manager/KingkongJin) ReportNo.:18220WC00152202FCCID:2APEW-EFC004OPage4of13 Code:AB-RF-05-a 1.GeneralInformation 1.1.ClientInformation Applicant: ElectronicSilkRoad(Shenzhen)TechCo.,Ltd Address: 7thF,Building10B,TaihuaWutongIndustrialPark,GushuDevelopment Zones,XixiangStreet,Bao'anArea,Shenzhen,China Manufacturer: ElectronicSilkRoad(Shenzhen)TechCo.,Ltd Address : 7thF,Building10B,TaihuaWutongIndustrialPark,GushuDevelopment Zones,XixiangStreet,Bao'anArea,Shenzhen,China Factory:ElectronicSilkRoad(Shenzhen)TechCo.,Ltd Address: 7thF,Building10B,TaihuaWutongIndustrialPark,GushuDevelopment Zones,XixiangStreet,Bao'anArea,Shenzhen,China 1.2.DescriptionofDevice(EUT) ProductName: HaloLock2-in-1MagneticWirelessCharger ModelNo.: EFC004O TradeMark: ESR TestPowerSupply: AC120V,60Hzforadapter TestSampleNo.: 1-2-1(NormalSample),1-2-2(EngineeringSample) Product Description : OperationFrequency:111-205KHz ModulationType:FSK AntennaType:InductiveloopcoilAntenna AntennaGain(Peak):0dBi Remark:1)Foramoredetailedfeaturesdescription,pleaserefertothemanufacturer’sspecifications ortheUser’sManual. ReportNo.:18220WC00152202FCCID:2APEW-EFC004OPage5of13 Code:AB-RF-05-a 1.3.AuxiliaryEquipmentUsedDuringTest N/A 1.4.TestEquipmentList ItemEquipmentManufacturerModelNo.SerialNo.LastCal.Cal.Interval 1MagneticfieldmeterNARDAELT-400423623Dec.24,20183Year 2E-FieldProbeNardaEF0391Q15221Nov.17,20203Year 3H-FieldProbeNardaHF3061Q15835Nov.17,20203Year 1.5.MeasurementUncertainty RadiationUncertainty: Ur=3.9dB(Horizontal) Ur=3.8dB(Vertical) ConductionUncertainty: Uc=3.4dB ReportNo.:18220WC00152202FCCID:2APEW-EFC004OPage6of13 Code:AB-RF-05-a 1.6.DescriptionofTestFacility Thetestfacilityisrecognized,certified,oraccreditedbythefollowingorganizations: FCC-RegistrationNo.:184111 ShenzhenAnbotekComplianceLaboratoryLimited,EMCLaboratoryhasbeenregistedandfully describedinareportfiledwiththe…
Text truncated - open the document above for the full version.
Test Report
ReportNo.:18220WC00152201FCCID:2APEW-EFC004OPage1of30 Code:AB-RF-05-a FCCTESTREPORT ClientName:ElectronicSilkRoad(Shenzhen)TechCo.,Ltd Address: 7thF,Building10B,TaihuaWutongIndustrialPark,Gushu DevelopmentZones,XixiangStreet,Bao'anArea, Shenzhen,China ProductName:HaloLock2-in-1MagneticWirelessCharger Date:Feb.01,2021 ShenzhenAnbotekComplianceLaboratoryLimited ReportNo.:18220WC00152201FCCID:2APEW-EFC004OPage2of30 Code:AB-RF-05-a Contents 1.GeneralInformation ............................................................................................................................................... 4 1.1.ClientInformation ....................................................................................................................................... 4 1.2.DescriptionofDevice(EUT) ..................................................................................................................... 4 1.3.AuxiliaryEquipmentUsedDuringTest ................................................................................................... 5 1.4.DescriptionofTestModes ........................................................................................................................ 5 1.5.DescriptionOfTestSetup ......................................................................................................................... 6 1.6.TestEquipmentList .................................................................................................................................... 7 1.7.MeasurementUncertainty ......................................................................................................................... 8 1.8.DescriptionofTestFacility ........................................................................................................................ 8 2.SummaryofTestResults ..................................................................................................................................... 9 3.ConductedEmissionTest ................................................................................................................................... 10 3.1.TestStandardandLimit .......................................................................................................................... 10 3.2.TestSetup .................................................................................................................................................. 10 3.3.TestProcedure .......................................................................................................................................... 10 3.4.TestData .................................................................................................................................................... 10 4.RadiationSpuriousEmission ............................................................................................................................. 15 4.1.TestStandardandLimit .......................................................................................................................... 15 4.2.TestSetup .................................................................................................................................................. 15 4.3.TestProcedure .......................................................................................................................................... 16 4.4.TestData .................................................................................................................................................... 16 5.AntennaRequirement ......................................................................................................................................... 21 5.1.TestStandardandRequirement ............................................................................................................ 21 5.2.AntennaConnectedConstruction .......................................................................................................... 21 APPENDIXI--TESTSETUPPHOTOGRAPH ................................................................................................... 22 APPENDIXII--EXTERNALPHOTOGRAPH ..................................................................................................... 24 APPENDIXIII--INTERNALPHOTOGRAPH ..................................................................................................... 28 ReportNo.:18220WC00152201FCCID:2APEW-EFC004OPage3of30 Code:AB-RF-05-a TESTREPORT Applicant: ElectronicSilkRoad(Shenzhen)TechCo.,Ltd Manufacturer: ElectronicSilkRoad(Shenzhen)TechCo.,Ltd ProductName:HaloLock2-in-1MagneticWirelessCharger ModelNo.:EFC004O TradeMark: ESR Rating(s): Input:DC5V/3A,DC9V/2A(viaadapterinput:100-240V~,50-60Hz,0.5AMax) Wirelessoutput1:5W/7.5W/10W Wirelessoutput2:5W/7.5W/10W 2-in-1Totalpower:10W(MAX) TestStandard(s): FCCPart15SubpartC,Paragraph15.209 TestMethod(s): ANSIC63.10:2013 ThedevicedescribedaboveistestedbyShenzhenAnbotekComplianceLaboratoryLimitedto determinethemaximumemissionlevelsemanatingfromthedeviceandtheseverelevelsofthedevice canendureanditsperformancecriterion.Themeasurementresultsarecontainedinthistestreportand ShenzhenAnbotekComplianceLaboratoryLimitedisassumedfullofresponsibilityfortheaccuracy andcompletenessofthesemeasurements.Also,thisreportshowsthattheEUT(EquipmentUnder Test)istechnicallycompliantwiththeFCCPart15SubpartCrequirements. Thisreportappliestoabovetestedsampleonlyandshallnotbereproducedinpartwithoutwritten approvalofShenzhenAnbotekComplianceLaboratoryLimited. DateofReceiptOct.22,2020 DateofTestOct.22,2020~Jan.28,2021 PreparedBy (Engineer/YiliaZhong) Reviewer (Supervisor/BiboZhang) Approved&AuthorizedSigner (Manager/KingkongJin) ReportNo.:18220WC00152201FCCID:2APEW-EFC004OPage4of30 Code:AB-RF-05-a 1.GeneralInformation 1.1.ClientInformation Applicant: ElectronicSilkRoad(Shenzhen)TechCo.,Ltd Address: 7thF,Building10B,TaihuaWutongIndustrialPark,GushuDevelopment Zones,XixiangStreet,Bao'anArea,Shenz…
Text truncated - open the document above for the full version.
Test Setup Photos
FCCID:2APEW-EFC004O PhotoofConductedEmissionMeasurement PhotoofRadiationEmissionTest PhotoofMPEMeasurement
Contact Information
Applicant
Serena Jiang
Test Firm
Shenzhen Anbotek Compliance Laboratory LimitedJeff Zhu
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 0.111 MHz - 0.205 MHz | - |
