2APK7-92219462410Infrared (IR) Bin

Rev. 2/7/2023 Page 1 of 19 ` FAST Bin User Manual Contents Trademark Information ................................................................................................................................. 2 Support Information ..................................................................................................................................... 2 System Description ....................................................................................................................................... 4 System Operation ......................................................................................................................................... 5 Infrared (IR) Bins ....................................................................................................................................... 5 Radio Frequency Identification (RFID) Bins .............................................................................................. 6 Reader ....................................................................................................................................................... 7 Controller .................................................................................................................................................. 7 Repeater .................................................................................................................................................... 8 Indicator Lights .............................................................................................................................................. 8 Controller .................................................................................................................................................. 8 Repeater .................................................................................................................................................... 8 Reader ....................................................................................................................................................... 9 Device Labels [Controller and Reader] ......................................................................................................... 9 Controller Label ......................................................................................................................................... 9 Reader Label ............................................................................................................................................. 9 Installation Instructions .............................................................................................................................. 11 IR Bins ...................................................................................................................................................... 11 RFID Enclosure ........................................................................................................................................ 11 Repeater .................................................................................................................................................. 11 Controller ................................................................................................................................................ 12 Technical Specifications [Controller and Reader] ....................................................................................... 12 Controller ................................................................................................................................................ 12 Reader ..................................................................................................................................................... 13 Device Labels [Repeater] ............................................................................................................................ 13 Repeater Label ........................................................................................................................................ 13 Technical Specifications [Repeater] ............................................................................................................ 14 Repeater .................................................................................................................................................. 14 Rev. 2/7/2023 Page 2 of 19 ` Device Labels [IR Bins] ................................................................................................................................ 15 IR Bin Labels ............................................................................................................................................ 15 Technical Specifications [IR Bins] ................................................................................................................ 16 IR 220 Bin ................................................................................................................................................ 16 IR 230 Bin ................................................................................................................................................ 17 IR 240 Bin ................................................................................................................................................ 18 IR 250 Bin ................................................................................................................................................ 19 Compliance Information ............................................................................................................................. 20 FCC Compliance Statement ..................................................................................................................... 20 FCC Statement .................................................................................................................................…

Text truncated - open the document above for the full version.

TO: Federal Communication Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Rd Columbia, MD 21046 5/22/2023 Pursuant to FCC 22-84 Report and Order and KDB 986446 D01 Covered Equipment v01, the Commission adopted new FCC requirements to protect the nation’s networks and supply chains from equipment that poses an unacceptable risk to national security or the safety of U.S. persons. Specifically, the Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List. Certifications FCC ID: 2APK7-92219462410 concerning “covered” equipment. Section 2.911(d)(5)(i)-(ii). Fastenal Company (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Fastenal Company certifies that as of the date of the filing of the application, the applicant is not identified on the covered list as an entity producing covered equipment. Thank you. Regards, 5/22/2023 Tony McIntosh

TO: Federal Communication Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Rd Columbia, MD 21046 Date: 2/10/2023 Pursuant to FCC 22-84 Report and Order and KDB 986446 D01 Covered Equipment v01, the Commission adopted new FCC requirements to protect the nation’s networks and supply chains from equipment that poses an unacceptable risk to national security or the safety of U.S. persons. Specifically, the Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List. Certification designating a U.S. agent for service of process. As required by section 2.911(d)(7), the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. Fastenal Company (“the applicant”) consent to accept the service of process. Fastenal Company FRN: 0027435023 2001 Theurer Blvd Winona, Minnesota 55987 USA Fastenal Company acknowledges to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Regards, Signature: Date: 2/10/2023 Signed by (printed name): Tony McIntosh

4-28-2023 Attention: Application Examiner RE: Request for Confidentiality Applicant: Fastenal Company FCC ID: 2APK7-922194624 To Whom It May Concern: Permanent Confidentiality Request Request is hereby submitted by the Fastenal Company to withhold permanently from public review ce1iain p01iions of the application for equipment ce1iification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: • Schematics • Detailed Block Diagrams • Detailed Operational/Functional Description • Parts List & Placement/BOM Rationale for request for confidentiality: The Fastenal Company has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products but would also disclose successful implementation of unpublished, leading edge technology developed by us. Our Detailed Operational/Functional Description, Block Diagram, Schematics are designed for internal company use only. Tony McIntosh Fast Solutions Product Manager

TO: Federal Communication Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Rd Columbia, MD 21046 ATTENTION: Federal Communication Commission Equipment Authorization To whom it may concern, We would like to submit for Certification to FCC: [2APK7-92219462410]. Please find in the following application all related documentation to support this New Single Certification. We would appreciate your prompt attention to the submittal. Applicant Company name: Fastenal Contact Name: Tony McIntosh Address: 8918 Beckett Road, West Chester, OH 45069 Telephone No: 513-644-0074 Fax No: Email: [email protected] FCC ID Number: 0027435023 Signature: Date: 4-28-2023 Signed by (printed name): Tony McIntosh

Engineering Test Report No. 2103912-13 Rev. B Report Date June 30, 2022 Manufacturer Name Fastenal Manufacturer Address 2001 Theurer Blvd Winona, MN 55987 Product Name Brand/Model No. Infrared Bin, Model Nos. IR220, IR230, IR240, IR250 Date Received December 7, 2021 Assessment Date June 30, 2022 Specifications FCC 47 CFR Part 2.1093 KDB, 447498 D01 OET Bulletin 65:1997 RSS-102 EN 62311 EN 62479 AS/NZS 2772.2 RSP 3 Test Facility Elite Electronic Engineering, Inc. 1516 Centre Circle, Downers Grove, IL 60515 Signature Tested by Mark E. Longinotti Signature Approved by Raymond J. Klouda, Registered Professional Engineer of Illinois – 44894 PO Number 01N9964-112921-0906 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. This report shall not be reproduced, except in full, without the written approval of Elite Electronic Engineering Inc. Engineering Test Report No. 2103912-13 Rev. B This report shall not be reproduced, except in full, without the written approval of Elite Electronic Engineering Inc. Page 2 of 19 Table of Contents 1. Report Revision History ............................................................................................................................ 3 2. Introduction ............................................................................................................................................... 4 3. Subject of Investigation ............................................................................................................................. 4 4. Standards and Requirements ................................................................................................................... 4 5. Sample Calculations ................................................................................................................................. 5 6. Photographs of EUT .................................................................................................................................. 6 7. Limits and Requirements .......................................................................................................................... 9 7.1. Requirements mandated by the FCC ....................................................................................................... 9 7.2. Requirements mandated by Innovation, Science and Economic Development Canada ....................... 11 7.3. Requirements mandated by the European Union and outlined in EN 62311 ......................................... 13 7.4. Requirements mandated by Australia/New Zealand and outlined in AS/NZS 2772.2 ............................ 14 8. Assessment Results ................................................................................................................................ 15 8.1. RF Exposure Evaluation Relevant to the Requirements of the FCC ...................................................... 15 8.2. RF Exposure Evaluation Relevant to the Requirements of the ISED ..................................................... 15 8.3. RF Exposure Evaluation Relevant to the Requirements of the EU ........................................................ 15 8.4. RF Exposure Evaluation Relevant to the Requirements of Australia/New Zealand ............................... 15 8.5. RF Exposure Evaluation Relevant to the Requirements of the FCC ...................................................... 16 8.6. RF Exposure Evaluation Relevant to the Requirements of the ISED ..................................................... 16 8.7. RF Exposure Evaluation Relevant to the Requirements of the EU ........................................................ 16 8.8. RF Exposure Evaluation Relevant to the Requirements of Australia/New Zealand ............................... 16 8.9. RF Exposure Evaluation Relevant to the Requirements of the FCC ...................................................... 17 8.10. RF Exposure Evaluation Relevant to the Requirements of the ISED ................................................. 17 8.11. RF Exposure Evaluation Relevant to the Requirements of the EU .................................................... 17 8.12. RF Exposure Evaluation Relevant to the Requirements of Australia/New Zealand ........................... 17 8.13. RF Exposure Evaluation Relevant to the Requirements of the FCC .................................................. 18 8.14. RF Exposure Evaluation Relevant to the Requirements of the ISED ................................................. 18 8.15. RF Exposure Evaluation Relevant to the Requirements of the EU .................................................... 18 8.16. RF Exposure Evaluation Relevant to the Requirements of Australia/New Zealand ........................... 18 9. Statement of Compliance ........................................................................................................................ 19 Engineering Test Report No. 2103912-13 Rev. B Page 3 of 19 1. Report Revision History Revision Date Descrip…

Text truncated - open the document above for the full version.

1516 Centre Circle, Downers Grove IL 60515 ANTENNA EXHIBIT Manufacturer Name Fastenal Manufacturer Address 2001 Theurer Blvd Winona, MN 55987 Model No. IR250 Specifications FCC “Code of Federal Regulations” Title 47 Part 2.1033(b)(4), 15.203, 15.212, 15.217, 15.219, 15.255 and 15.256 KDB 353028 D01 v01 f01 Industry Canada RSS-GEN Test Facility Elite Electronic Engineering, Inc. 1516 Centre Circle, Downers Grove, IL 60515 FCC Reg. Number: 269750 IC Reg. Number: 2987A CAB Identifier: US0107 Requirement All part 15 applications will need to show how the antenna gain was derived either from a manufacturer data sheet or a measurement. Where the gain of the antenna is inherently accounted for as a result of the measurement, such as field strength measurements on a part 15.249 or 15.231 device, so the gain does not necessarily need to be verified. However, enough information regarding the construction of the antenna shall be provided. Such information maybe photographs, length of wire antenna etc. The antenna gain information shall be made public (not confidential). Any proprietary information such as construction maybe stripped from the gain information report and held confidential. The main antenna information we require is the maximum gain of the antenna for the band of operation. This information must be provided as a data sheet or a measurement report. 1516 Centre Circle, Downers Grove IL 60515 Meandering Inverted F Antenna ½ inch in length.

Engineering Test Report No. 2103912-04 Report Date April 21, 2023 Manufacturer Name Fastenal Manufacturer Address 2001 Theurer Blvd Winona, MN 55987 Product Name Brand/Model No. Infrared Bin, Model No. IR250 Date Received December 7, 2021 Test Dates December 7, 2021 through December 13, 2021 Specifications FCC "Code of Federal Regulations" Title 47 Part 15, Subpart C, Section 15.247 FCC “Code of Federal Regulations” Title 47, Part 15, Subpart 15B Innovation, Science, and Economic Development Canada, RSS-247 Innovation, Science, and Economic Development Canada, RSS-GEN Test Facility Elite Electronic Engineering, Inc. 1516 Centre Circle, Downers Grove, IL 60515 FCC Reg. Number: 269750 IC Reg. Number: 2987A CAB Identifier: US0107 Signature Tested by Mark E. Longinotti Signature Approved by Raymond J. Klouda, Registered Professional Engineer of Illinois – 44894 PO Number 01N9964-112921-0906 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. This report shall not be reproduced, except in full, without the written approval of Elite Electronic Engineering Inc. Elite Electronic Engineering Incorporated certifies that the information contained in this report was obtained under conditions which meet or exceed those specified in the FCC "Code of Federal Regulations" Title 47 Part 15, Subpart C, Section 15.247 and Innovation, Science, and Economic Development Canada, RSS-247 test specifications. The data presented in this test report pertains to the EUT on the test dates specified. Any electrical or mechanical modifications made to the EUT subsequent to the specified test date will serve to invalidate the data and void this certification. This report must not be used to claim product certification, approval, or endorsement by A2LA, NIST, or any agency of the Federal Government. Engineering Test Report No. 2103912-04 This report shall not be reproduced, except in full, without the written approval of Elite Electronic Engineering Inc. Page 2 of 59 Table of Contents 1. Report Revision History ............................................................................................................................ 3 2. Introduction ............................................................................................................................................... 4 2.1. Scope of Tests .......................................................................................................................................... 4 2.2. Purpose ..................................................................................................................................................... 4 2.3. Identification of the EUT ............................................................................................................................ 4 3. Power Input ............................................................................................................................................... 5 4. Grounding ................................................................................................................................................. 5 5. Support Equipment ................................................................................................................................... 5 6. Interconnect Leads .................................................................................................................................... 5 7. Modifications Made to the EUT ................................................................................................................. 5 8. Modes of Operation ................................................................................................................................... 5 9. Test Specifications .................................................................................................................................... 5 10. Test Plan ................................................................................................................................................... 6 11. Deviation, Additions to, or Exclusions from Test Specifications ............................................................... 6 12. Laboratory Conditions ............................................................................................................................... 6 13. Summary ................................................................................................................................................... 6 14. Sample Calculations ................................................................................................................................. 6 15. Statement of Conformity ........................................................................................................................... 7 16. Certification ......................................................................................................................…

Text truncated - open the document above for the full version.

Engineering Test Report No. 2103912-04 Page 34 of 59 Test Setup for Spurious Radiated Emissions, 30-1000MHz – Antenna Polarization Horizontal Test Setup for Spurious Radiated Emissions, 30-1000MHz – Antenna Polarization Vertical Engineering Test Report No. 2103912-04 Page 35 of 59 Test Setup for Spurious Radiated Emissions, 1GHz to 18GHz – Antenna Polarization Horizontal Test Setup for Spurious Radiated Emissions,1GHz to 18GHz – Antenna Polarization Vertical Engineering Test Report No. 2103912-04 Page 36 of 59 Test Setup for Spurious Radiated Emissions,18GHz to 25GHz – Antenna Polarization Vertical
