Shenzhen CTB Testing Co., Ltd. FCC ID:2APRQ-M3 Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. EDR: Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 3.126 2.05 3±1 4.00 2.51 <5 0.77860 3.00 YES 2.441 3.48 2.23 3±1 4.00 2.51 <5 0.78490 3.00 YES 2.480 3.455 2.22 3±1 4.00 2.51 <5 0.79114 3.00 YES 2.402 3.911 2.46 3±1 4.00 2.51 <5 0.77860 3.00 YES 2.441 4.08 2.56 4±1 5.00 3.16 <5 0.98813 3.00 YES 2.480 4.16 2.61 4±1 5.00 3.16 <5 0.99599 3.00 YES 2.402 4.17 2.61 4±1 5.00 3.16 <5 0.98020 3.00 YES 2.441 4.368 2.73 4±1 5.00 3.16 <5 0.98813 3.00 YES 2.480 4.481 2.81 4±1 5.00 3.16 <5 0.99599 3.00 YES GFSK π /4DQPSK 8DQPSK BLE:1M Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 3.19 2.08 3±1 4.00 2.51 <5 0.77860 3.00 YES 2.44 3.531 2.25 3±1 4.00 2.51 <5 0.78474 3.00 YES 2.480 3.53 2.25 3±1 4.00 2.51 <5 0.79114 3.00 YES GFSK 2M Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 3.249 2.11 3±1 4.00 2.51 <5 0.77860 3.00 YES 2.44 3.626 2.30 3±1 4.00 2.51 <5 0.78474 3.00 YES 2.480 3.639 2.31 3±1 4.00 2.51 <5 0.79114 3.00 YES GFSK Conclusion: For the max result : 0.99599≤ FCC Limit 3.0 for 1g SAR.

Product specification Quick Reference Date Antenna module on the system board Frequenc Range 2400 ~ 2500MHz Ant. Port Input Pwr. (dBm) 0 (Typ. BT class 2 output power) Tot. Rad. Pwr. (dBm) -1.2 (Input pwr – loss pwr) Peak EIRP(dBm) 1.2 Directivity (dBi) 1 (all direction antenna) Efficiency (dB) 6 0.2 % Gain (dBi) 1.2 (Avg Gain XY-plane) Maximum Power (dBm) 1.7 (XY-plane) Minimum Power (dBm) -4(XY-plane) Avg. Power (dBm) -0.5(XY-plane) Input Impendence(ohm) 50 Polarization Type V ertical & Horizontal V . S .W . R < 1.4 All the technical data and information contained herein are subject to ch ange without prior notice Antenna Layout & module on the system board Antenna Gain Gain Table Unit in dBi @2.44GHz XY-plane XZ-plane YZ-plane Efficiency Peak Avg. Peak Avg. Peak Avg. Module Board 1.2 -0.51.9 -3.61.1 -3.06 0.2 % Retum Loss The Environment of Antenna Radiation Pattem 3D radiation pattern diagram XY-plane XZ-plane YZ-plane
