2APUQ-LM1097PTablet

Quick Start Guide Quick Start Guide 2 In The Box USB-C cable Input: 100-240V~50/60Hz,0.3A Output:5.0V 2.0A Charger 10.1 " TabletQuick Start Guide 1 2 3 4 56 7 7 9 1. Volume Control 2. Power On/Off 3. Reset 4. TYPE-C 5. SIM Card Slot+TF Card Slot (2xNano SIM card or 1x Nano SlM+1xMicro SD) 6. Earphonejack 7. Speaker 8. Mic 9. Camera(Rear) 10. Flashlight 11. Camera(Front) 8 10 11 3 Get to Know Your Tablet 4 Charging Your Tablet It is recommended to fully charge the tablet before frst use.To charge the tablet, 1) plug the USB cable into the AC adapter, 2) attach the other end to the USB-C input on the tablet, 3) plug the AC adapter into a wall outlet. When the tablet is ON and charging, the battery icon will pulsate. It is normal for the tablet to get warm while charging, playing games, or streaming video. Battery life will vary depending on usage. Note: Leave tablet in a well ventilated area while charging. Important Safety Instructions 1. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 2.WARNING:Only use attachments/accessories specifed or provided by the manufacturer(such as the exclusive supply adapter, battery etc). 3.WARNING:The mains plug should be kept in a state that can be disconnected at anytime to avoid emergency situation. 4.WARNING:The apparatus should not be exposed to dripping or splashing. Objects flled with liquids, such as vases or drinking glasses, should not be placed on the apparatus 5.WARNING:Please refer the electrical and safety information on tablet and uer manual before installing or operating the apparatus. Use the device where the ambient temperature is between 0° and 35° C (32° to 95° F). Low-Or high-temperature conditions might cause the device to change its behavior to requlate its temperature. Using your tablet in very cold conditions outside of its operating range might temporarily shorten the battery life and could cause the deyice to turn off. Battery life will return to normal when you bring the device back to higher ambient temperatures. Using the device in very hot conditions can permanently shorten battery life. 5 6 FCC statements: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. ‐ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐ Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Specific Absorption Rate (SAR) information The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. This model (FCC ID: 2APUQ-LM1097P) has also been tested against this SAR limited. The highest SAR value reported under this standard during product certification for use at the body is 1.205W/kg. For U-NII devices (5G WIFI) Working temperature: 0 ̊C to 45 ̊C Working voltage: 3.8V ± 15% The device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems. 7

Form: RFT-AMER-TCB-OP-19o Revision: 1 Page 1 of 1 Date: 1/25/2023 HUNAN GREATWALL COMPUTER SYSTEM CO.,LTD. Attention: Application Examiner Re: Certification designating a U.S. agent for service of process pursuant to section 2.911(d)(7) of the FCC rules To whom it may concern, This letter is to confirm both [THREE STONES MEDIA LLC] (“Agent”) and [HUNAN GREATWALL COMPUTER SYSTEM CO.,LTD.] (“Applicant”) acknowledge consent to obligations of each party pursuant to 47 CFR part §2.911(d)(7) of the FCC rules in regard to the agent for service of process. I [zhengde zhang] HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant. I further acknowledge the requirement to maintain an agent extends for no less than one year after the termination of all marketing and importation or the conclusion of and commission-related proceeding involving the equipment and agree to immediately notify the FCC and Intertek if there is any change in the status identified above. Applicant Company Name : HUNAN GREATWALL COMPUTER SYSTEM CO.,LTD. Contact Name : zhengde zhang Address : Hunan GreatWall Industrial Park, Xiangyun Middle Road, Tianyuan District, Zhuzhou, Hunan Province, China Telephone No : 8618823876936 Email : [email protected] FCC ID : 2APUQ-LM1097P Applicant FRN : 0027509892 Signature: Date: 2024.7.15 I [Sijie Zhang] HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Agent. I consent to the obligation to accept service of process on behalf of the applicant in regard to the FCC ID designated above. Agent Company Name : THREE STONES MEDIA LLC Contact Name : Sijie Zhang Address : 1200 Broadway St. APT 329, Los Angeles, CA90015 Telephone No : +1 267 909 3692 Email : [email protected] Agent FRN : 0033401761 Signature: Date: 2024.7.15

Form: RFT-AMER-TCB-OP-19n Revision: 1 Page 1 of 1 Date: 1/25/2023 HUNAN GREATWALL COMPUTER SYSTEM CO.,LTD. Attention: Application Examiner Re: Covered List, located at https://www.fcc.gov/supplychain/coveredlist and 47 CFR parts §2.903 and §2.911(d)(5)(ii) of the FCC rules Applicant: HUNAN GREATWALL COMPUTER SYSTEM CO.,LTD. FCC ID: 2APUQ-LM1097P To whom it may concern, HUNAN GREATWALL COMPUTER SYSTEM CO.,LTD. (“Applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to 47 CFR part §2.903 of the FCC rules and does not originate directly or indirectly from any company named on the covered list located in the link above or any subsidiary or affiliate thereof. Applicant further certifies that, as of the date of the filing of the application, the Applicant is not identified on the Covered List as an entity producing “covered” equipment and is not a subsidiary or affiliate of any such entity pursuant to 47 CFR part §1.50002 and required by 47 CFR part §2.911(d)(5)(ii) of the FCC rules. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant and agree to immediately notify Intertek if there is any change in the status identified above. zhengde zhang [Title]Sr. Manager [Date]2023.12.4

HUNAN GREATWALL COMPUTER SYSTEM CO.,LTD. 2023.12.4 Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement HUNAN GREATWALL COMPUTER SYSTEM CO.,LTD. FCC ID: 2APUQ-LM1097P To Whom It May Concern: We, HUNAN GREATWALL COMPUTER SYSTEM CO.,LTD. hereby authorized Intertek Testing Services to act as our Agent for the purpose of preparing application for FCC ID number 2APUQ- LM1097P under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is 04 December 2023. The Limited Agency Agreement expires on 04 December 2024, unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, zhengde zhang [Title]Sr. Manager [Date]2023.12.4

1(2) HUNAN GREATWALL COMPUTER SYSTEM CO.,LTD. Attention: Certification reviewer RE: Request for Confidentiality FCC ID: 2APUQ-LM1097P To Whom It May Concern: Permanent Confidentiality [Complete this section if permanent confidentiality is requested] Request to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: [Select one or more of items below, as appropriate] Schematics Block Diagrams Operational Description Tune-up Procedure Parts List Internal Photos (see note) Users Manual (see note) Note 1: Internal Photos may be held confidential 1) if the circuit board or internal components are not accessible to users. For example, it is acceptable if the circuit board is enclosed in epoxy. 2) Also, it is acceptable if the device is not accessible to the public, for example, a device mounted on the top of a large tower (or in a fenced enclosure) such that it is only serviceable by professional designated technicians under a Non-Disclosure Agreement (NDA). All sales for these devices must be under a NDA restricting the disclosure of the propriety information, including internal photos. Users Manual may be held confidential only when the manual contains proprietary technical information intended for professional technicians obligated under a NDA. All sales and distribution of the user’s manual must be under a NDA that restricts the disclosure of the information. In the application cover letter requesting permanent confidentiality the following additional description and the NDA exhibit is required: 1. Describe in detail how internal photos and/or users manual information are controlled to prevent them from becoming public or disclosed to unauthorized persons. 2. Describe how public access is restricted for products serviceable by professional designated technicians. 3. A statement that all sales of the non-consumer device will be under a NDA to include third party sales and that the final user of the device is subject to the NDA. 4. Provide an example of the NDA between the grantee and a purchaser. The request for confidentiality must Note 2: For scanning receiver, the schematics, block diagrams, operational description, tune-up procedure, parts list and internal photos are always held permanently confidential. Short-term Confidentiality [Complete this section if short-term confidentiality is requested] Request to withhold from public review for a period of [please enter 1 to 180] days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept short-term confidential for a period above from the date of the grant [Select one or more of items below that are not selected in the list above, as appropriate] Schematics Block diagrams Operational Description Tune-up Procedure 2(2) Parts List Test Setup Photos External Photos Internal Photos Users Manual Rationale for request for confidentiality: We have invested considerable time and materials in research and development to produce the referenced product. Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. Short-term confidentiality: Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development. If you have questions or need further information, please contact the undersigned. Sincerely, zhengde zhang [Title]Sr. Manager [Date]2023.12.4

UNII Device Declaration Letter To whom it may concern, We have declared below featured for FCC equipment authorization, Device FCC ID: 2APUQ-LM1097P (1) DFS Device: Master Client with Radar detection capability Client without Radar detection capability Non-DFS Device (2) Active/Passive Scanning, adhoc mode access point capability Frequency Band (MHz) Active Scanning (the device can transmit a probe(beacon)) Passive scanning (where the device can listen only with no probes) Ad Hoc Mode capability Access point capacility 2412-2462 Yes No Yes No Yes No Yes No 2422-2452 Yes No Yes No Yes No Yes No 5180-5240 Yes No Yes No Yes No Yes No 5190-5230 Yes No Yes No Yes No Yes No 5210-5210 Yes No Yes No Yes No Yes No 5260-5320 Yes No Yes No Yes No Yes No 5270-5310 Yes No Yes No Yes No Yes No 5290-5290 Yes No Yes No Yes No Yes No 5745-5825 Yes No Yes No Yes No Yes No 5755-5795 Yes No Yes No Yes No Yes No 5775-5775 Yes No Yes No Yes No Yes No (3) Country code selection ability Yes No If yes, pls explain how it was implemented. (4) Meet 15.202 requirement Yes No Please check below: A master device is defined as a device operating in a mode in which it has the capability to transmit without receiving an enabling signal. In this mode it is able to select a channel and initiate a network by sending enabling signals to other devices. A client device is defined as a device operating in a mode in which the transmissions of the device are under the control of the master. A device in client mode is not able to initiate a network. (5) For client devices that have software configuration control to operate in different modes(active scanning in some and passive scanning in others) in different bands(devices with multiple equipment classes or those that operate on non-DFS frequencies) or modular devices which configure the modes of operations through software, the application must provide software and operations description on how the software and /or hardware is implemented to ensure that proper operations modes cannot be modified by end user or an installer. Apply Does not apply (If apply, pls help to provide explanation on it was implement, and how software was controlled) zhengde zhang [Title]Sr. Manager [Date]2023.12.4

TEST REPORT TEST REPORT TEST REPORT TEST REPORT

Label and location Size：50*22 mm

TEST REPORT Main ANT GBW ANT DIV ANT(RX) TEST REPORT TEST REPORT TEST REPORT TEST REPORT TEST REPORT TEST REPORT TEST REPORT

HUNAN GREATWALL COMPUTER SYSTEM CO.,LTD. TEST REPORT SCOPE OF WORK FCC TESTING– LM1097P, LM1097P-A, LM1097P-B, LM1097P-C REPORT NUMBER 231204042SZN-006 ISSUE DATE [REVISED DATE] 22 July 2024 [--------------------] PAGES 172 DOCUMENT CONTROL NUMBER FCC SAR_b © 2017 INTERTEK TEST REPORT Intertek Report No.: 231204042SZN-006 • This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results referenced from this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. • The test report only allows to be revised only within the report defined retention period unless further standard or the requirement was noticed Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, ShenZhen, P.R. China Telephone: 86-755-8601 6288 Fax: 86-755-8601 6751 TRF No.: FCC SAR_b Page 1 of 172 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, Shenzhen, P.R. China. Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 www.intertek.com SAR TEST REPORT For HUNAN GREATWALL COMPUTER SYSTEM CO.,LTD. Product Description: Tablet FCC ID: 2APUQ-LM1097P Model No.: LM1097P, LM1097P-A, LM1097P-B, LM1097P-C Report No.: 231204042SZN-006 Issue Date: 22 July 2024 Prepared and Checked by: Approved by: Draven Li Project Engineer Peter Kang Sr. Technical Supervisor 22 July 2024 TEST REPORT Intertek Report No.: 231204042SZN-006 TRF No.: FCC SAR_b Page 2 of 172 Table of Contents 1. GENERAL INFORMATION ......................................................................................................... 3 2. EQUIPMENT UNDER TEST (EUT) TECHNICAL DESCRIPTION ........................................................ 4 3. AUXILIARY EQUIPMENT DETAILS .............................................................................................. 8 4. TEST FACILITY .......................................................................................................................... 8 5. GUIDANCE STANDARD ............................................................................................................. 9 6. EUT ANTENNA LOCATIONS .................................................................................................... 10 7. POWER REDUCTION BY PROXIMITY SENSING ......................................................................... 12 8. RF EXPOSURE ........................................................................................................................ 18 9. SPECIFIC ABSORPTION RATE (SAR) ......................................................................................... 20 10. SAR MEASUREMENTS SYSTEM CONFIGURATION ................................................................ 21 11. MEASUREMENT PROCEDURES ........................................................................................... 36 12. TEST RESULTS .................................................................................................................... 43 13. MEASUREMENT UNCERTAINTY ........................................................................................ 170 14. MAIN TEST INSTRUMENT ................................................................................................. 171 ANNEX A: TEST LAYOUT AND SETUP ............................................................................................ 172 ANNEX B: SYSTEM CHECK RESULTS .............................................................................................. 172 ANNEX C: MAXIMUM GRAPH RESULTS ........................................................................................ 172 ANNEX D: SYSTEM VALIDATION .................................................................................................. 172 ANNEX E: EUT PHOTO ................................................................................................................. 172 ANNEX F: PROBE CALIBRATION CERTIFICATE ............................................................................... 172 ANNEX G: DIPOLE CALIBRATION CERTIFICATE .............................................................................. 172 ANNEX H: DAE CALIBRATION CERTIFICATE................................................................................... 172 TEST REPORT Intertek Report No.: 231204042SZN-006 TRF No.: FCC SAR_b Page 3 of 172 1. GENERAL INFORMATION Applicant: HUNAN GREATWALL COMPUTER SYSTEM CO.,LTD. Hunan GreatWall Industrial Park, Xiangyun Middle Road, Tianyuan District, Zhuzhou, Hunan Province, China Manufacturer: HUNAN GREATWALL COMPUTER SYSTEM CO.,LTD. Hunan GreatWall Industrial Park, Xiangyun Middle Road, Tianyuan District, Zhuzhou, Hunan Province, China Product Description: Tablet Model Number: LM1097P, LM1097P-A, LM1097P-B, LM1097P-C File Number: 231204042SZN-006 Date of Test: 04 December 2023 to 29 February 2024 The above equipment was tested by Intertek Testing Services Shenzhen Ltd. Longhua Branch. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in IEEE 1528-2013 and KDB 865664. This device is in compliance with Specific Absorption Rate (SAR) for general population/uncontrolled exposur…
