2APUZ-SW7Smart Switch

Shenzhen Cuco Smart Technology Co., Ltd Feb.23, 2022 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Explanation of differences between product types FCC ID : 2APUZ-SW7 Model Number: SW7, SW7-A, SW7-B, SW7-C To Whom It May Concern: We, The Shenzhen Cuco Smart Technology Co., Ltd hereby declare that the models are identical except the model names and the color of appearance. Except for the different above, no other modification is performed. Sincerely, Signature: ShenZhen CuCo Smart Technology Co., Ltd. Contact person: lizs Dai

Shenzhen Cuco Smart Technology Co., Ltd Agent Authorization Company: Shenzhen Cuco Smart Technology Co., Ltd Address: 2F, No.14, XinWuYuan Industrial Area, DiFu Road, GuShu, Xi'Xiang Town, Bao'An District, Shenzhen, 518000, China Product Name: Smart Switch Model Number(s): SW7, SW7-A, SW7-B, SW7-C Product Description: Smart Switch We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2022-02-22 Name: lizs Dai Company: ShenZhen CuCo Smart Technology Co., Ltd.

Report No.: AGC10625220205AP02 Page 1 of 3 EXTERNAL PHOTOS TOP VIEW OF EUT BOTTOM VIEW OF EUT Report No.: AGC10625220205AP02 Page 2 of 3 FRONT VIEW OF EUT BACK VIEW OF EUT Report No.: AGC10625220205AP02 Page 3 of 3 LEFT VIEW OF EUT RIGHT VIEW OF EUT ****************************************End of Report****************************************

FCC ID Label Location 60mm&40mm FCC ID: 2APUZ-SW7

Report No.: AGC10625220205AP02 Page 1 of 6 INTERNAL PHOTOS OPEN VIEW OF EUT (FIGURE 1) OPEN VIEW OF EUT (FIGURE 2) Report No.: AGC10625220205AP02 Page 2 of 6 OPEN VIEW OF EUT (FIGURE 3) OPEN VIEW OF EUT (FIGURE 4) Report No.: AGC10625220205AP02 Page 3 of 6 OPEN VIEW OF EUT (FIGURE 5) INTERNAL VIEW OF EUT (FIGURE 1) Report No.: AGC10625220205AP02 Page 4 of 6 INTERNAL VIEW OF EUT (FIGURE 2) INTERNAL VIEW OF EUT (FIGURE 3) Report No.: AGC10625220205AP02 Page 5 of 6 INTERNAL VIEW OF EUT (FIGURE 4) INTERNAL VIEW OF EUT (FIGURE 5) INTERNAL VIEW OF EUT (FIGURE 6) Antenna Report No.: AGC10625220205AP02 Page 6 of 6 ****************************************End of Report****************************************

RF EXPOSURE EVALUATION 1. PRODUCT INFORMATION Product Description Smart Switch Model Name SW7, SW7-A, SW7-B, SW7-C FCC ID 2APUZ-SW7 2. EVALUATION METHOD AND LIMIT Human exposure to RF emissions from mobile devices (47 CFR §2.1091) may be evaluated based on the MPE limits adopted by the FCC for electric and magnetic field strength and/or power density, as appropriate, since exposures are assumed to occur at distances of 20 cm or more from persons. LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE Frequency Range (MHz) E-field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Time |E| 2 , |H| 2 or S (Minutes) 0.3 -- 1.34 614 1.63 (100)* 30 1.34 -- 30 824/f 2.19/f (180/f 2 )* 30 30 -- 300 27.5 0.073 0.2 30 300 -- 1500 -- -- f/1500 30 1500 -- 100,000 -- -- 1.0 30 *Note: 1. f= Frequency in MHz * Plane-wave Equivalent Power Density 2. The averaging time for General Population/Uncontrolled exposure to fixed transmitters is not applicable for mobile and portable transmitters. See 47 CFR §§2.1091 and 2.1093 on source-based time-averaging requirement for mobile and portable transmitters. S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna CALCULATION A minimum test separation distance ≥ 20 cm is required between the antenna and radiating structures of the device and nearby persons to apply mobile device exposure limits. The distance must be at least 20 cm and fully supported by the operating and installation configurations of the transmitter and its antenna(s), according to the source-based time-averaged maximum power requirements of § 2.1091(d)(2). In cases where cable losses or other attenuations are applied to determine compliance, the most conservative operating configurations and exposure conditions must be evaluated. Antenna Gain=2dBi (Numeric 1.58), π=3.14 Note: 1. Only the worst case recorded. Frequency Output Power Output Power Power Density Power Density Limit MHz dBm mW mW/cm 2 mW/cm 2 2412 12.06 16.07 0.0051 1

Page 1 of 70 Report No.: AGC10625220205FE05 FCC ID : 2APUZ-SW7 APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : Smart Switch BRAND NAME : Gosund, GHome, WISEBOT, GHome Smart, OHMAXX MODEL NAME : SW7, SW7-A, SW7-B, SW7-C APPLICANT : Shenzhen Cuco Smart Technology Co., Ltd DATE OF ISSUE : Feb. 22, 2022 STANDARD(S) TEST PROCEDURE(S) : FCC Part 15.247 REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd FCC Test Report Report No.: AGC10625220205FE05 Page 2 of 70 REPORT REVISE RECORD Report Version Revise Time Issued Date Valid Version Notes V1.0 / Feb. 22, 2022 Valid Initial Release Report No.: AGC10625220205FE05 Page 3 of 70 TABLE OF CONTENTS 1. VERIFICATION OF CONFORMITY .................................................................................................................. 5 2. GENERAL INFORMATION .............................................................................................................................. 6 2.1. PRODUCT DESCRIPTION ........................................................................................................................ 6 2.2. TABLE OF CARRIER FREQUENCYS ....................................................................................................... 7 2.3. IEEE 802.11N MODULATION SCHEME .................................................................................................... 8 2.4. RELATED SUBMITTAL(S) / GRANT (S) .................................................................................................... 8 2.5. TEST METHODOLOGY ............................................................................................................................. 8 2.6. SPECIAL ACCESSORIES ......................................................................................................................... 8 2.7. EQUIPMENT MODIFICATIONS ................................................................................................................. 8 2.8. ANTENNA REQUIREMENT....................................................................................................................... 9 3. MEASUREMENT UNCERTAINTY ................................................................................................................. 10 4. DESCRIPTION OF TEST MODES ................................................................................................................. 11 5. SYSTEM TEST CONFIGURATION ................................................................................................................ 12 5.1. CONFIGURATION OF EUT SYSTEM ...................................................................................................... 12 5.2. EQUIPMENT USED IN EUT SYSTEM ..................................................................................................... 12 5.3. SUMMARY OF TEST RESULTS .............................................................................................................. 12 6. TEST FACILITY .............................................................................................................................................. 13 7. OUTPUT POWER ........................................................................................................................................... 14 7.1. MEASUREMENT PROCEDURE ............................................................................................................. 14 7.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................... 14 7.3. LIMITS AND MEASUREMENT RESULT .................................................................................................. 15 8. BANDWIDTH .................................................................................................................................................. 16 8.1. MEASUREMENT PROCEDURE ............................................................................................................. 16 8.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................... 16 8.3. LIMITS AND MEASUREMENT RESULTS ............................................................................................... 17 9. CONDUCTED SPURIOUS EMISSION........................................................................................................... 28 9.1. MEASUREMENT PROCEDURE ............................................................................................................. 28 9.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................... 28 9.3. MEASUREMENT EQUIPMENT USEDJN ................................................................................................ 28 9.4. LIMITS AND MEASUREMENT RESULT .................................................................................................. 28 Report No.: AGC10625220205FE05 Page 4 of 70 10. MAXIMUM CONDUCTED OUTPUT POWER SPECTRAL DENSITY ........................................................ 40 10.1 MEASUREMENT PROCEDURE ............................................................................................................ 40 10.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ................................................................... 40 10.3 MEASUREMENT EQUIPMENT USED ................................................................................................... 40 10.4 LIMITS AND MEASUREMENT RESULT ................................................................................................. 40 11. RADIATED EMISSION ................................................................................................................................. 46 11.1. MEASUREMENT PROCEDURE............................................................................................................ 46 11.2. TEST SETUP ...................................................…

Text truncated - open the document above for the full version.

Report No.: AGC10625220205FE05 Page 41 of 70 Test Graphs of Conducted Output Power Spectral Density Test_Graph_802.11b_ANT1_2412_1Mbps_PSD Test_Graph_802.11b_ANT1_2437_1Mbps_PSD Report No.: AGC10625220205FE05 Page 42 of 70 Test_Graph_802.11b_ANT1_2462_1Mbps_PSD Test_Graph_802.11g_ANT1_2412_6Mbps_PSD Report No.: AGC10625220205FE05 Page 43 of 70 Test_Graph_802.11g_ANT1_2437_6Mbps_PSD Test_Graph_802.11g_ANT1_2462_6Mbps_PSD Report No.: AGC10625220205FE05 Page 44 of 70 Test_Graph_802.11n20_ANT1_2412_MCS0_PSD Test_Graph_802.11n20_ANT1_2437_MCS0_PSD Report No.: AGC10625220205FE05 Page 45 of 70 Test_Graph_802.11n20_ANT1_2462_MCS0_PSD Report No.: AGC10625220205FE05 Page 46 of 70 11. RADIATED EMISSION 11.1. MEASUREMENT PROCEDURE 1. The EUT was placed on the top of the turntable 0.8 or 1.5 meter above ground. The phase center of the receiving antenna mounted on the top of a height-variable antenna tower was placed 3 meters far away from the turntable. 2. Power on the EUT and all the supporting units. The turntable was rotated by 360 degrees to determine the position of the highest radiation. 3. The height of the broadband receiving antenna was varied between one meter and four meters above ground to find the maximum emissions field strength of both horizontal and vertical polarization. 4. For each suspected emission, the antenna tower was scan (from 1 M to 4 M) and then the turntable was rotated (from 0 degree to 360 degrees) to find the maximum reading. 5. Set the test-receiver system to Peak or CISPR quasi-peak Detect Function with specified bandwidth under Maximum Hold Mode. 6. For emissions above 1GHz, use 1MHz RBW and 3MHz VBW for peak reading. Place the measurement antenna away from each area of the EUT determined to be a source of emissions at the specified measurement distance, while keeping the measurement antenna aimed at the source of emissions at each frequency of significant emissions, with polarization oriented for maximum response. The measurement antenna may have to be higher or lower than the EUT, depending on the radiation pattern of the emission and staying aimed at the emission source for receiving the maximum signal. The final measurement antenna elevation shall be that which maximizes the emissions. The measurement antenna elevation for maximum emissions shall be restricted to a range of heights of from 1 m to 4 m above the ground or reference ground plane. 7. When the radiated emissions limits are expressed in terms of the average value of the emissions, and pulsed operation is employed, the measurement field strength shall be determined by averaging over one complete pulse train, including blanking intervals, as long as the pulse train does not exceed 0.1 seconds. As an alternative (provided the transmitter operates for longer than 0.1 seconds) or in cases where the pulse train exceeds 0.1 seconds, the measured field strength shall be determined from the average absolute voltage during a 0.1 second interval during which the field strength is at its maximum values. 8.If the emissions level of the EUT in peak mode was 3 dB lower than the average limit specified, then testing will be stopped and peak values of EUT will be reported, otherwise, the emissions which do not have 3 dB margin will be repeated one by one using the quasi-peak method for below 1GHz. 9. For testing above 1GHz, the emissions level of the EUT in peak mode was lower than average limit (that means the emissions level in peak mode also complies with the limit in average mode), then testing will be stopped and peak values of EUT will be reported, otherwise, the emissions will be measured in average mode again and reported. 10. In case the emission is lower than 30MHz, loop antenna has to be used for measurement and the recorded data should be QP measured by receiver. High - Low scan is not required in this case. Report No.: AGC10625220205FE05 Page 47 of 70 11.2. TEST SETUP Radiated Emission Test-Setup Frequency Below 30MHz RADIATED EMISSION TEST SETUP 30MHz-1000MHz RADIATED EMISSION TEST SETUP ABOVE 1000MHz Report No.: AGC10625220205FE05 Page 48 of 70 11.3. LIMITS AND MEASUREMENT RESULT 15.209(a) Limit in the below table has to be followed Frequencies (MHz) Field Strength (microvolts/meter) Measurement Distance (meters) 0.009~0.490 2400/F(kHz) 300 0.490~1.705 24000/F(kHz) 30 1.705~30.0 30 30 30~88 100 3 88~216 150 3 216~960 200 3 Above 960 500 3 Note: All modes were tested for restricted band radiated emission, the test records reported below are the worst result compared to other modes. 11.4. TEST RESULT Radiated emission below 30MHz The amplitude of spurious emissions from 9kHz to 30MHz which are attenuated more than 20 dB below the permissible value need not be reported. Report No.: AGC10625220205FE05 Page 49 of 70 Radiated emission from 30MHz to 1000MHz EUT Smart Switch Model Name SW7 Temperature 25°C Relative Humidity 58% Pressure 960hPa Test Voltage Normal Voltage Test Mode 802.11n20 with date rate 1 2462MHz Antenna Horizontal NO. Freq. [MHz] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Polarity 1 52.31 24.55 11.49 40.00 15.45 100 327 Horizontal 2 159.98 28.17 14.94 43.50 15.33 100 26 Horizontal 3 239.52 30.50 13.59 46.00 15.50 100 244 Horizontal 4 400.54 37.58 17.29 46.00 8.42 100 338 Horizontal 5 480.08 35.71 16.98 46.00 10.29 100 73 Horizontal 6 910.76 34.32 27.74 46.00 11.68 100 52 Horizontal RESULT: PASS Report No.: AGC10625220205FE05 Page 50 of 70 EUT Smart Switch Model Name SW7 Temperature 25°C Relative Humidity 58% Pressure 960hPa Test Voltage Normal Voltage Test Mode 802.11n20 with date rate 1 2462MHz Antenna Vertical NO. Freq. [MHz] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Polarity 1 35.82 31.48 10.73 40.00 8.52 100 237 Vertical 2 41.64 32.84 10.89 40.00 7.16 100 64 Vertical 3 239.52 27.79 13.64 46.00 18.21 100 339 Vertical 4 400.54 39.23 17.30 46.00 6.77 100 198 Vertical 5 480.08 37.60 18.58 46.00 8.40 100 195 Vertical 6 720.64 3…

Text truncated - open the document above for the full version.

Report No.: AGC10625220205AP01 Page 1 of 2 TEST SETUP PHOTOS RADIATED EMISSION TEST SETUP BELOW 1GHz RADIATED EMISSION TEST SETUP ABOVE 1GHz Report No.: AGC10625220205AP01 Page 2 of 2 AC POWER LINE CONDUCTED TEST SETUP RF CONDUCTED TEST SETUP ****************************************End of Report*************************************
