For additional information and resources, please visit the EZVIZ support.ezvizlife.com or email our support team at [email protected]. Get the EZVIZ APP Connect your mobile phone to Wi-Fi. Search for “EZVIZ” in App Store or Google Play . Download and install the EZVIZ app. Launch the app, and register an EZVIZ account. Follow the detailed User Manual to set your device: Get the detailed user manual Power on your device. Connect the device to the LAN port of your router with the Ethernet cable (Optional). 1. 2. 3. 4. Add your device to your EZVIZ account Notice Log in to your EZVIZ account. On the Home screen, tap “+” on the upper-right corner to go to the Scan QR Code interface. Scan the QR code on the cover of this paper or on the body of your device. Follow the wizard to add your device to the EZVIZ app. QR Code Please delete this device from your account in advance, if you need to return it to purchasing point or change its ownership. 1. 2. 3. 4. 1. 2. English TM 102026336 , B Deutsch EZVIZ-App herunterladen 1. Verbinden Sie Ihr Mobiltelefon mit einem WLAN. 2. Suchen Sie im App Store oder bei Google Play TM nach „EZVIZ“. 3. Laden Sie die EZVIZ-App herunter und installieren Sie sie. 4. Starten Sie die App und registrieren Sie ein EZVIZ-Konto. Gehen Sie wie im Benutzerhandbuch beschrieben vor, um Ihr Gerät zu konfigurieren: 1. Schalten Sie das Gerät ein. 2. Verbinden Sie das Gerät über ein Netzwerkkabel (optional) mit dem LAN-Anschluss Ihres Routers. Laden Sie das ausführliche Benutzerhandbuch herunter Das Gerät zu Ihrem EZVIZ-Konto hinzufügen 1. Melden Sie sich bei Ihrem EZVIZ-Konto an. 2. Tippen Sie auf der Startseite oben rechts auf „+“, um das Menü „QR-Code scannen“ aufzurufen. 3. Scannen Sie den QR-Code auf dem Umschlag dieses Benutzerhandbuchs oder auf dem Gehäuse des Geräts. 4. Folgen Sie dem Assistenten, um das Gerät zur EZVIZ-App hinzuzufügen. Weitere Informationen und Ressourcen finden Sie auf der Website von EZVIZ support.ezvizlife.com oder senden Sie eine E-Mail an unser Supportteam unter [email protected]. Hinweis QR-Code Entfernen Sie zuerst dieses Gerät von Ihrem Konto, wenn Sie es an den Händler zurückgeben oder verkaufen möchten. Scan the QR code for detailed user manual. Scannen Sie den QR-Code, um das ausführliche Benutzerhandbuch herunterzuladen. Escanee el código QR para obtener el manual de usuario detallado. Scannez le code QR pour accéder aux instructions détaillées du manuel d’utilisation. Scansionare il QR code per accedere al manuale d'uso dettagliato. Scan de QR-code voor de gedetailleerde gebruikershandleiding. Aby uzyskać Podręcznik użytkownika, zeskanuj kod QR. Σαρώστε τον κωδικό QR για να αποκτήσετε το λεπτομερές εγχειρίδιο χρήσης. Podrobnou uživatelskou příručku získáte naskenováním kódu QR. Podrobnú používateľskú príručku získate po naskenovaní QR kódu. Skanna QR-koden för den detaljerade bruksanvisningen. Scan QR-koden for en komplet brugervejledning. Skannaa QR-koodi saadaksesi yksityiskohtaiset käyttöohjeet. Skanne QR-koden for detaljert bruksanvisning. Scan the QR code with the EZVIZ App to add the device to your account. Please keep it for further reference. Scan the QR code for detailed User Manual by using supported QR code scan tools (such as Facebook, Safari, Chorme) Español Obtenga la aplicación EZVIZ 1. Conecte su teléfono móvil a la red wifi. 2. Busque «EZVIZ» en la App Store o en Google Play TM . 3. Descargue e instale la aplicación EZVIZ. 4. Inicie la aplicación y registre una cuenta de EZVIZ. Consulte el manual de usuario detallado para configurar su dispositivo: 1. Encienda su dispositivo. 2. Conecte el dispositivo al puerto LAN de su enrutador utilizando un cable Ethernet (opcional). Obtenga el manual de usuario detallado Añada su dispositivo a su cuenta de EZVIZ 1. Inicie sesión en su cuenta EZVIZ. 2. En la pantalla de inicio, pulse «+» en la esquina superior derecha para acceder a la interfaz de escaneo de códigos QR. 3. Escanee el código QR que se encuentra en la portada de este documento o en la carcasa de su dispositivo. 4. Siga las indicaciones del asistente para añadir su dispositivo a la aplicación EZVIZ. Para obtener información y recursos adicionales, visite el sitio web support.ezvizlife.com de EZVIZ o envíe un mensaje de correo electrónico a [email protected]. Aviso Código QR Elimine este dispositivo de su cuenta de antemano si necesita devolverlo al punto de compra o cambiar de propietario. Français Obtenir l’application EZVIZ 1. Connectez votre téléphone mobile au réseau Wi-Fi. 2. Recherchez « EZVIZ » dans l’App Store ou Google Play TM . 3. Téléchargez et installez l’application EZVIZ. 4. Lancez l’application et créez un compte EZVIZ. Suivez les instructions détaillées du manuel d’utilisation pour configurer votre appareil : 1. Allumez votre appareil. 2. Connectez l’appareil au port LAN (réseau local) de votre routeur à l’aide du câble Ethernet (facultatif). Suivez les instructions détaillées du manuel d’utilisation Ajouter votre appareil à votre compte EZVIZ 1. Connectez-vous à votre compte EZVIZ. 2. Dans l’écran d’accueil, appuyez sur le bouton « + » situé dans le coin supérieur droit pour accéder à l’interface de numérisation du code QR. 3. Scannez le code QR figurant sur la couverture de ce document ou sur le boîtier de votre appareil. 4. Laissez-vous guider par l’assistant pour ajouter votre appareil dans l’application EZVIZ. Pour des informations et des ressources supplémentaires, veuillez visiter le site Internet d’EZVIZ à l’adresse support.ezvizlife.com ou envoyer un e-mail à notre équipe technique à l’adresse [email protected]. Attention Code QR Veuillez supprimer au préalable cet appareil de votre compte, si vous devez le retourner à votre point d’achat ou modifier son propriétaire. Italiano Download dell'app EZVIZ 1. Connettere il cellulare alla rete Wi-Fi. 2. Cercare "EZVIZ" nell'App Store o in Google Play TM . 3. Scaricare e installare l'app EZVIZ. 4. Avviare l'app e creare un accou…

Text truncated - open the document above for the full version.

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Hangzhou Ezviz Sofeware Co., Ltd. Address Room 302,Unit B,Building 2,No. 399,Danfeng Road Binjiang District China Grantee Code 2APV2 FCC ID 2APV2-CSC6WI Authorized Contact Name Weiliang Bu Contact Email [email protected] Contact Phone 0571-88075988 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date:2020-07-26 Print Name: Weiliang Bu Title: Global Certification Team Lead *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

Hangzhou Ezviz Sofeware Co., Ltd. Date: 2020-07-26 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2APV2-CSC6WI To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Hangzhou Ezviz Sofeware Co., Ltd. This authorization is valid until further written notice from the applicant. Name (Printed):Weiliang Bu Title: Global Certification Team Lead Signature: On behalf of Company: Hangzhou Ezviz Sofeware Co., Ltd. Telephone: +86-0571-88075998-62460

Hangzhou Ezviz Sofeware Co., Ltd. To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Hangzhou Ezviz Sofeware Co., Ltd. 2-1-10,No.700 Dongliu Road,Binjiang District Hangzhou,China Regarding: Confidentiality Request regarding application for FCC ID: 2APV2-CSC6WI LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions NII Software Security Info The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name (on file with the FCC associated with the Grantee Code): Weiliang Bu Title: Global Certification Team Lead Company Name: Hangzhou Ezviz Sofeware Co., Ltd.

SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 1 of 4 Page 1 of 4 External Photos Applicant: Hangzhou Ezviz Software Co., Ltd. Address of Applicant: Room 302,Unit B,Building 2,399 Danfeng Road,Binjiang District,Hangzhou,Zhejiang Equipment Under Test (EUT): Product Name: Smart Home Camera Model No.: CS-C6W SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 2 of 4 Page 2 of 4 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 3 of 4 Page 3 of 4 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 4 of 4 Page 4 of 4 End

Label location FCC warning

SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 1 of 17 Page 1 of 17 Internal Photos Applicant: Hangzhou Ezviz Software Co., Ltd. Address of Applicant: Room 302,Unit B,Building 2,399 Danfeng Road,Binjiang District,Hangzhou,Zhejiang Equipment Under Test (EUT): Product Name: Smart Home Camera Model No.: CS-C6W SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 2 of 17 Page 2 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 3 of 17 Page 3 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 4 of 17 Page 4 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 5 of 17 Page 5 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 6 of 17 Page 6 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 7 of 17 Page 7 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 8 of 17 Page 8 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 9 of 17 Page 9 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 10 of 17 Page 10 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 11 of 17 Page 11 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 12 of 17 Page 12 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 13 of 17 Page 13 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 14 of 17 Page 14 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 15 of 17 Page 15 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 16 of 17 Page 16 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Page: 17 of 17 Page 17 of 17 End

SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SHEM200600517603 Page: 1 of 11 Parlam Zhan E&E Section Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. 1 Cover Page RF MPE REPORT Application No.: SHEM2006005176CR FCC ID: 2APV2-CSC6WI Applicant: Hangzhou Ezviz Software Co., Ltd. Address of Applicant: Room 302,Unit B,Building 2,399 Danfeng Road,Binjiang District,Hangzhou,Zhejiang Manufacturer: Hangzhou Ezviz Software Co., Ltd. Address of Manufacturer: Room 302,Unit B,Building 2,399 Danfeng Road,Binjiang District,Hangzhou,Zhejiang Equipment Under Test (EUT): EUT Name: Smart Home Camera Model No.: CS-C6W Add Model No.: CS-C6Wi Trade mark: EZVIZ Standard(s) : FCC Rules 47 CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 Date of Receipt: 2020-06-30 Date of Test: 2020-07-10 to 2020-07-20 Date of Issue: 2020-07-21 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SHEM200600517603 Page: 2 of 11 Revision Record Version Description Date Remark 00 Original 2020-07-21 / Authorized for issue by: Micheal Niu / Project Engineer Parlam Zhan / Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SHEM200600517603 Page: 3 of 11 2 Contents Page 1 COVER PAGE ................................................................................................................................................. 1 2 CONTENTS ..................................................................................................................................................... 3 3 GENERAL INFORMATION........................................................................................................................... 4 3.1 GENERAL DESCRIPTION OF E.U.T. ......................................................................................................... 4 3.2 TECHNICAL SPECIFICATIONS ................................................................................................................... 4 3.3 TEST LOCATION ....................................................................................................................................... 6 3.4 TEST FACILITY .......................................................................................................................................... 6 4 TEST STANDARDS AND LIMITS ............................................................................................................... 7 4.1 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS: ......................................................................... 7 5 MEASUREMENT AND CALCULATION .................................................................................................... 8 5.1 MAXIMUM TRANSMIT POWER ................................................................................................................... 8 5.2 MPE CALCULATION ............................................................................................................................... 10 SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SHEM200600517603 Page: 4 of 11 3 General Information 3.1 General Description of E.U.T. Power supply: DC 5V by Adapter 3.2 Technical Specifications 2.4GHz Antenna Gain: Antenna 1: -0.17dBi Antenna 2: -0.17dBi Directional gain:2.84dBi Antenna Type: Antenna 1: PIFA Antenna Antenna 2: PIFA Antenna Channel Spacing: 5MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK) 802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels: 802.11b/g/n(HT20):11 802.11n(HT40):7 Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz 802.11n(HT40): 2422MHz to 2452MHz SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SHEM200600517603 Page: 5 of 11 5GHz Operation Frequency: Band Mode Frequency Range(MHz) Number of channels Band 1 802.11a/n(HT20)/ac(HT20) 5180-5240 4 802.11n(HT40)/ac(HT40) 5190-5230 2 802.11ac(HT80) 5210 1 Band 4 802.11a/n(HT20)/ac(HT20) 5745-5825 5 802.11n(HT40)/ac(HT40) 5755-5795 2 802.11ac(HT80) 5775 1 Modulation Type: 802.11a: OFDM (64QAM, 16QAM, QPSK, BPSK) 802.11n: OFDM (BPSK, QPSK, 16QAM, 64QAM) 802.11ac: OFDM (BPSK, QPSK, 16QAM, 64QAM, 256QAM) Channel Spacing: 802.11a/n(HT20)/ac(HT20): 20MHz 802.11n(HT40)/ac(HT40): 40MHz 802.11ac(HT80): 80MHz Data Rate: 802.11a: 6/9/12/18/24/36/48/54Mbps 802.11n: MCS0-7 802.11ac: MCS0-9 Antenna Gain: Antenna 1: 2.39dBi; Antenna 2: 2.39dBi Directional gain: 5.40dBi Antenna Type: Antenna 1: PIFA Antenna Antenna 2: PIFA Antenna SGS-CSTC Standards Technical Services Co., Ltd. Shanghai Branch Report No.: SHEM200600517603 Page: 6 of 11 3.3 Test Location All tests were performed at: Compliance Certification Services (Kunshan) Inc. No.10 Weiye Rd, Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China. Tel: +86 512 5735 5888 Fax: +86 512 5737 0818 No tests were sub-contracted. 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • CNAS (No. CNAS L4354) CNAS has accredited Compliance Certification Services (Kunshan) Inc. to ISO/IEC 17025:2017 General Requirements for the Competence of Testing and Calibration Laboratories (CNAS-CL01 Accreditation Criteria for the Competence of Testing and Calibration Laboratories) for the competence in the field of testing. • A2LA (Certificate No. 2541.01) Compliance C…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Appendix A for SHEM200600517601 1. Duty Cycle 1.1 Test Result Test Mode Channel Frequency(M Hz) TX Type ANT No. T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) 802.11b 2412 SISO 1 12.375 12.517 98.87 0.05 2437 SISO 1 12.375 12.541 98.68 0.06 2462 SISO 1 12.375 12.541 98.68 0.06 802.11g 2412 SISO 1 2.003 2.151 93.12 0.31 2437 SISO 1 2.004 2.169 92.39 0.34 2462 SISO 1 2.004 2.169 92.39 0.34 802.11n(HT20) 2412 MIMO 1 1.864 1.994 93.48 0.29 2437 MIMO 1 1.865 2.004 93.06 0.31 2462 MIMO 1 1.921 2.046 93.89 0.27 802.11n(HT40) 2422 MIMO 1 0.945 1.062 88.98 0.51 2437 MIMO 1 0.945 1.061 89.07 0.50 2452 MIMO 1 0.944 1.052 89.73 0.47 1.2 Test Graph SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 2. Bandwidth 2.1 Test Result Test Mode Frequency (MHz) TX Type ANT No. 6dB Bandwidth Verdict Test Result (MHz) Limits (MHz) 802.11b 2412 SISO 1 9.600 ≥0.5 PASS 2 10.080 ≥0.5 PASS 2437 SISO 1 9.627 ≥0.5 PASS 2 9.595 ≥0.5 PASS 2462 SISO 1 10.058 ≥0.5 PASS 2 10.080 ≥0.5 PASS 802.11g 2412 SISO 1 16.411 ≥0.5 PASS 2 16.416 ≥0.5 PASS 2437 SISO 1 16.418 ≥0.5 PASS 2 16.414 ≥0.5 PASS 2462 SISO 1 16.414 ≥0.5 PASS 2 16.420 ≥0.5 PASS 802.11n(HT20) 2412 MIMO 1 17.634 ≥0.5 PASS 2 17.640 ≥0.5 PASS 2437 MIMO 1 17.603 ≥0.5 PASS 2 17.614 ≥0.5 PASS 2462 MIMO 1 17.648 ≥0.5 PASS 2 17.633 ≥0.5 PASS 802.11n(HT40) 2422 MIMO 1 35.743 ≥0.5 PASS 2 35.854 ≥0.5 PASS 2437 MIMO 1 35.760 ≥0.5 PASS SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 2 35.533 ≥0.5 PASS 2452 MIMO 1 35.985 ≥0.5 PASS 2 35.720 ≥0.5 PASS Test Mode Frequency (MHz) TX Type ANT No. 99% Occupied Bandwidth Test Result (MHz) 802.11b 2412 SISO 1 15.082 Only for Report Use 2 15.068 Only for Report Use 2437 SISO 1 15.096 Only for Report Use 2 15.075 Only for Report Use 2462 SISO 1 15.084 Only for Report Use 2 15.067 Only for Report Use 802.11g 2412 SISO 1 16.902 Only for Report Use 2 16.919 Only for Report Use 2437 SISO 1 16.955 Only for Report Use 2 16.997 Only for Report Use 2462 SISO 1 16.973 Only for Report Use 2 16.981 Only for Report Use 802.11n(HT20) 2412 MIMO 1 18.046 Only for Report Use 2 18.060 Only for Report Use 2437 MIMO 1 18.130 Only for Report Use 2 18.175 Only for Report Use 2462 MIMO 1 18.000 Only for Report Use 2 18.046 Only for Report Use 802.11n(HT40) 2422 MIMO 1 36.688 Only for Report Use 2 36.693 Only for Report Use 2437 MIMO 1 36.519 Only for Report Use 2 36.473 Only for Report Use 2452 MIMO 1 36.683 Only for Report Use 2 36.612 Only for Report Use 2.2 Test Graph - 6dB Bandwidth SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 2.3 Test Graph - 99% Occupied Bandwidth SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 3. Maximum Conducted Output Power 3.1 Test Result Test Mode Frequency (MHz) Tx Type Measured Peak Output Power (dBm) Limits (dBm) Verdict Ant 1 Ant 2 Total 802.11b 2412 SISO 16.09 17.02 / 30 PASS 2437 SISO 15.88 17.28 / 30 PASS 2462 SISO 17.10 17.42 / 30 PASS 802.11g 2412 SISO 16.76 17.25 / 30 PASS 2437 SISO 17.00 17.00 / 30 PASS 2462 SISO 17.32 17.36 / 30 PASS 802.11n(HT20) 2412 MIMO 15.99 16.58 19.31 30 PASS 2437 MIMO 16.72 16.96 19.85 30 PASS 2462 MIMO 16.96 16.97 19.98 30 PASS 802.11n(HT40) 2422 MIMO 15.14 15.55 18.36 30 PASS 2437 MIMO 15.43 15.17 18.31 30 PASS 2452 MIMO 15.73 15.94 18.85 30 PASS 3.2 Test Graph SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 4. Maximum Power Spectral Density (PSD) 4.1 Test Result Test Mode Frequency (MHz) Tx Type Maximum Power Spectral Density (dBm/3KHz) Limits (dBm/3kHz) Verdict Ant 1 Ant 2 Total 802.11b 2412 SISO -8.54 -7.37 / ≤8 PASS 2437 SISO -9.54 -9.27 / ≤8 PASS 2462 SISO -8.90 -7.78 / ≤8 PASS 802.11g 2412 SISO -…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM200600517601 Page: 1 of 73 Parlam Zhan E&E Section Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. TEST REPORT Application No.: SHEM2006005176CR FCC ID: 2APV2-CSC6WI Applicant: Hangzhou Ezviz Software Co., Ltd. Address of Applicant: Room 302,Unit B,Building 2,399 Danfeng Road,Binjiang District,Hangzhou,Zhejiang Manufacturer: Hangzhou Ezviz Software Co., Ltd. Address of Manufacturer: Room 302,Unit B,Building 2,399 Danfeng Road,Binjiang District,Hangzhou,Zhejiang Equipment Under Test (EUT): EUT Name: Smart Home Camera Model No.: CS-C6W, CS-C6Wi¤ ¤ Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Trade mark: EZVIZ Standard(s) : 47 CFR Part 15, Subpart C 15.247 RSS-247 Issue 2, February 2017 RSS-Gen Issue 5, March 2019 Amendment 1 Date of Receipt: 2020-06-30 Date of Test: 2020-07-10 to 2020-07-20 Date of Issue: 2020-07-21 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM200600517601 Page: 2 of 73 Revision Record Version Description Date Remark 00 Original 2020-07-21 / Authorized for issue by: Micheal Niu / Project Engineer Parlam Zhan / Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM200600517601 Page: 3 of 73 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Minimum 6dB Bandwidth 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Conducted Peak Output Power 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Power Spectrum Density 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.209 & 15.247(d) Pass Radiated Spurious Emissions 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.4,6.5,6.6 47 CFR Part 15, Subpart C 15.209 & 15.247(d) Pass 99% Bandwidth RSS-247 Issue 2, February 2017 ANSI C63.10 Section 6.9.3 RSS-Gen Section 6.7 Pass Declaration of EUT Family Grouping: Note 1: There are series models mentioned in this report, and they are the similar in electrical and electronic characters. Only the model CS-C6W was tested since their differences were the model number, trade name and appearance. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM200600517601 Page: 4 of 73 3 Contents Page 1 COVER PAGE........................................................…
