SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR220500103003 Page: 1 of 12 Parlam Zhan Laboratory Manager 1 Cover Page RF Exposure Evaluation Report Application No.: SHCR2205001030AT FCC ID: 2APV2-CSE68C5 Applicant: Hangzhou Ezviz Software Co., Ltd. Address of Applicant: Room 302,Unit B,Building 2,399 Danfeng Road,Binjiang District,Hangzhou,Zhejiang Manufacturer: Hangzhou Ezviz Software Co., Ltd. Address of Manufacturer: Room 302,Unit B,Building 2,399 Danfeng Road,Binjiang District,Hangzhou,Zhejiang Equipment Under Test (EUT): EUT Name: Smart Home Camera Model No.: CS-E6,CS-E6 (5W2F,4mm),CS-E6-R100-8C5W2F Trade mark: EZVIZ Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2022-05-26 Date of Test: 2022-06-13 to 2022-06-15 Date of Issue: 2022-06-27 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR220500103003 Page: 2 of 12 Revision Record Version Chapter Date Modifier Remark 01 2022-06-27 Original Authorized for issue by: Micheal Niu/Project Engineer Parlam Zhan/Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR220500103003 Page: 3 of 12 2 Contents Page 1 COVER PAGE .................................................................................................................................... 1 2 CONTENTS ........................................................................................................................................ 3 3 GENERAL INFORMATION ................................................................................................................ 4 3.1 GENERAL DESCRIPTION OF E.U.T. ................................................................................................ 4 3.2 DETAILS OF E.U.T. ....................................................................................................................... 4 3.3 TEST LOCATION ............................................................................................................................ 5 3.4 TEST FACILITY .............................................................................................................................. 5 4 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS .......................................................... 6 4.1 BLANKET 1 MW BLANKET EXEMPTION ........................................................................................... 6 4.2 MPE-BASED EXEMPTION .............................................................................................................. 6 4.3 SAR-BASED EXEMPTION ............................................................................................................... 7 5 MEASUREMENT AND CALCULATION .......................................................................................... 10 5.1 MAXIMUM TRANSMIT POWER ....................................................................................................... 10 5.2 RF EXPOSURE CALCULATION ...................................................................................................... 12 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR220500103003 Page: 4 of 12 3 General Information 3.1 General Description of E.U.T. Power supply: DC 5V,2A,10W MAX by Adapter 3.2 Details of E.U.T. 2.4G Wi-Fi Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz;802.11n(HT40): 2422MHz to 2452MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK);802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels: 802.11b/g/n(HT20):11;802.11n(HT40):7 Channel Spacing: 5MHz Antenna Type: FPC antenna Antenna Gain: 2.89dBi(Provided by manufacturer) 5G Wi-Fi Operation Frequency (20MHz): U-NII-1: 5180-5240MHz; U-NII-3: 5745-5825MHz Operation Frequency (40MHz): U-NII-1: 5190-5230MHz; U-NII-3: 5755-5795MHz Moudulation Type: 802.11a: OFDM (64QAM, 16QAM, QPSK, BPSK); 802.11n: OFDM (BPSK, QPSK, 16QAM, 64QAM) Channel Spacing: 802.11a/n(HT20)/ac(HT20): 20MHz; 802.11n(HT40)/ac(HT40): 40MHz DFS Function: Without DFS function TPC Function: Without TPC function Antenna Type: FPC antenna Antenna Gain: Band U-NII-1:1.99dBi; Band U-NII-3:3.44dBi; (Provided by manufacturer) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR220500103003 Page: 5 of 12 3.3 Test Location All tests were performed at: Compliance Certification Services (Kunshan) Inc. No.10 Weiye Rd, Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China. Tel: +86 512 5735 5888 Fax: +86 512 5737 0818 No tests were sub-contracted. Note: 1.SGS is not responsible for wrong test results due to incorrect information (e.g. max. clock frequency, highest internal frequency, antenna gain, cable loss, etc ) is provided by the applicant. (if applicable). 2.SGS is not responsible for the authenticity, integrity and the validity of the conclusion based on results of the data provided by applicant. (if applicable). 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • CNAS (No. CNAS L4354) CNAS has accredited Compliance Certification Services (Kunshan) Inc. to ISO/IEC 17025:2017 General Requirements for the Competence of Testing and Calibration Laboratories (CNAS-CL01 Accreditation Criteria for the Competence of Testing and Calibration Laboratories) for the competence in the field of testing. • A2LA (Certificate No. 2541.01) Compliance Certification Services (Kunshan) Inc. is accredited by the American Association for Laboratory Accreditation (A2LA). Certificate No. 2541.01. • FCC (Designation Number: CN1172) Compliance Certification Services (Kunshan) Inc. has been recognized as an accredited testing laboratory. Designation Number: CN1172. • ISED (CAB identifier: CN0072) Compliance Certification Services (Kunshan) Inc. has been recognized by Innovation, Science and Economic Deve…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 51 Appendix B for SHCR220500103002 1. Duty Cycle 1.1 Ant1 1.1.1 Test Result Ant1 Mode TX Type Frequency (MHz) T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) Max. DC Variation (%) 802.11a SISO 5180 2.025 2.526 80.17 0.96 0.03 5200 2.024 2.526 80.13 0.96 0.03 5240 2.025 2.526 80.17 0.96 0.03 5745 2.024 2.526 80.13 0.96 0.03 5785 2.024 2.526 80.13 0.96 0.03 5825 2.024 2.526 80.13 0.96 0.03 802.11n (HT20) SISO 5180 1.889 2.390 79.04 1.02 0.03 5200 1.888 2.390 79.00 1.02 0.04 5240 1.889 2.390 79.04 1.02 0.03 5745 1.889 2.390 79.04 1.02 0.03 5785 1.889 2.390 79.04 1.02 0.03 5825 1.889 2.391 79.00 1.02 0.04 802.11n (HT40) SISO 5190 0.929 1.430 64.97 1.87 0.03 5230 0.929 1.430 64.97 1.87 0.03 5755 0.928 1.430 64.90 1.88 0.03 5795 0.929 1.430 64.97 1.87 0.03 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 51 1.1.2 Test Graph 802.11a_LCH_5180MHz_Ant1_NTNV 802.11a_MCH_5200MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 51 802.11a_HCH_5240MHz_Ant1_NTNV 802.11a_LCH_5745MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 51 802.11a_MCH_5785MHz_Ant1_NTNV 802.11a_HCH_5825MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 5 of 51 802.11n(HT20)_LCH_5180MHz_Ant1_NTNV 802.11n(HT20)_MCH_5200MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 6 of 51 802.11n(HT20)_HCH_5240MHz_Ant1_NTNV 802.11n(HT20)_LCH_5745MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 7 of 51 802.11n(HT20)_MCH_5785MHz_Ant1_NTNV 802.11n(HT20)_HCH_5825MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 8 of 51 802.11n(HT40)_LCH_5190MHz_Ant1_NTNV 802.11n(HT40)_HCH_5230MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 9 of 51 802.11n(HT40)_LCH_5755MHz_Ant1_NTNV 802.11n(HT40)_HCH_5795MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 10 of 51 2. Bandwidth 2.1 OBW 2.1.1 Test Result Mode TX Type Frequency (MHz) ANT 99% Occupied Bandwidth (MHz) Verdict Result 802.11a SISO 5180 1 17.406 Pass 5200 1 17.453 Pass 5240 1 17.436 Pass 5745 1 17.250 Pass 5785 1 17.302 Pass 5825 1 17.247 Pass 802.11n (HT20) SISO 5180 1 18.427 Pass 5200 1 18.348 Pass 5240 1 18.242 Pass 5745 1 18.397 Pass 5785 1 18.383 Pass 5825 1 18.318 Pass 802.11n (HT40) SISO 5190 1 36.333 Pass 5230 1 36.233 Pass 5755 1 36.006 Pass 5795 1 36.067 Pass SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 11 of 51 2.1.2 Test Graph 802.11a_LCH_5180MHz_Ant1_NTNV 802.11a_MCH_5200MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 12 of 51 802.11a_HCH_5240MHz_Ant1_NTNV 802.11a_LCH_5745MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 13 of 51 802.11a_MCH_5785MHz_Ant1_NTNV 802.11a_HCH_5825MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 14 of 51 802.11n(HT20)_LCH_5180MHz_Ant1_NTNV 802.11n(HT20)_MCH_5200MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 15 of 51 802.11n(HT20)_HCH_5240MHz_Ant1_NTNV 802.11n(HT20)_LCH_5745MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 16 of 51 802.11n(HT20)_MCH_5785MHz_Ant1_NTNV 802.11n(HT20)_HCH_5825MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 17 of 51 802.11n(HT40)_LCH_5190MHz_Ant1_NTNV 802.11n(HT40)_HCH_5230MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 18 of 51 802.11n(HT40)_LCH_5755MHz_Ant1_NTNV 802.11n(HT40)_HCH_5795MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 19 of 51 2.2 6dB BW 2.2.1 Test Result Mode TX Type Frequency (MHz) ANT 6dB Bandwidth (MHz) Verdict Result Limit 802.11a SISO 5745 1 16.338 >=0.5 Pass 5785 1 16.318 >=0.5 Pass 5825 1 16.327 >=0.5 Pass 802.11n (HT20) SISO 5745 1 17.155 >=0.5 Pass 5785 1 17.570 >=0.5 Pass 5825 1 17.510 >=0.5 Pass 802.11n (HT40) SISO 5755 1 35.133 >=0.5 Pass 5795 1 34.369 >=0.5 Pass SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 20 of 51 2.2.2 Test Graph 802.11a_LCH_5745MHz_Ant1_NTNV 802.11a_MCH_5785MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 21 of 51 802.11a_HCH_5825MHz_Ant1_NTNV 802.11n(HT20)_LCH_5745MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 22 of 51 802.11n(HT20)_MCH_5785MHz_Ant1_NTNV 802.11n(HT20)_HCH_5825MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 23 of 51 802.11n(HT40)_LCH_5755MHz_Ant1_NTNV 802.11n(HT40)_HCH_5795MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 24 of 51 2.3 26dB BW 2.3.1 Test Result Mode TX Type Frequency (MHz) ANT 26dB Bandwidth (MHz) Verdict Result 802.11a SISO 5180 1 24.259 Pass 5200 1 29.840 Pass 5240 1 22.627 Pass 802.11n (HT20) SISO 5180 1 22.815 Pass 5200 1 23.598 Pass 5240 1 23.178 Pass 802.11n (HT40) SISO 5190 1 48.900 Pass 5230 1 47.238 Pass SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 25 of 51 2.3.2 Test Graph 802.11a_LCH_5180MHz_Ant1_NTNV 802.11a_MCH_5200MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 26 of 51 802.11a_HCH_5240MHz_Ant1_NTNV 802.11n(HT20)_LCH_5180MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 27 of 51 802.11n(HT20)_MCH_5200MHz_Ant1_NTNV 802.11n(HT20)_HCH_5240MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 28 of 51 802.11n(HT40)_LCH_5190MHz_Ant1_NTNV 802.11n(HT40)_HCH_5230MHz_Ant1_NTNV SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 29 of 51 3. Maximum Conducted Output Power 3.1 Power 3.1.1 Test Result Mode TX Type Frequency (MHz) Maximum Average Conducted Output Power (dBm) Verdict ANT1 Limit 802.11a SISO 5180 10.93 <=23.98 Pass 5200 10.80 <=23.98 Pass 5240 10.73 <=23.98 Pass 5745 12.05 <=30 Pass …

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR220500103002 Page: 1 of 93 Parlam Zhan Laboratory Manager TEST REPORT Application No.: SHCR2205001030AT FCC ID: 2APV2-CSE68C5 Applicant: Hangzhou Ezviz Software Co., Ltd. Address of Applicant: Room 302,Unit B,Building 2,399 Danfeng Road,Binjiang District,Hangzhou,Zhejiang Manufacturer: Hangzhou Ezviz Software Co., Ltd. Address of Manufacturer: Room 302,Unit B,Building 2,399 Danfeng Road,Binjiang District,Hangzhou,Zhejiang Equipment Under Test (EUT): EUT Name: Smart Home Camera Model No.: CS-E6,CS-E6 (5W2F,4mm),CS-E6-R100-8C5W2F♣ ♣ Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Trade Mark: EZVIZ Standard(s) : 47 CFR Part 15, Subpart E 15.407 Date of Receipt: 2022-05-26 Date of Test: 2022-06-13 to 2022-06-15 Date of Issue: 2022-06-27 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR220500103002 Page: 2 of 93 Revision Record Version Chapter Date Modifier Remark 01 2022-06-27 Original Authorized for issue by: Micheal Niu / Project Engineer Parlam Zhan / Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR220500103002 Page: 3 of 93 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart E 15.407 N/A 47 CFR Part 15, Subpart C 15.203 Pass Transmission in the Absence of Data N/A 47 CFR Part 15, Subpart E 15.407 (c) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart E 15.407 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 & Subpart E 15.407 b(6) Pass Duty Cycle KDB 789033 II B 1 KDB 789033 D02 II B 1 Pass 99% Bandwidth KDB 789033 II D N/A Pass 26dB Emission bandwidth KDB 789033 D02 II C 1 47 CFR Part 15, Subpart E 15.407 (a) Pass Minimum 6 dB bandwidth (5.725- 5.85 GHz band ) KDB 789033 D02 II C 2 47 CFR Part 15, Subpart E 15.407 (e) Pass Maximum Conducted output power KDB 789033 D02 II E 47 CFR Part 15, Subpart E 15.407 (a) Pass Peak Power spectrum density KDB 789033 D02 II F 47 CFR Part 15, Subpart E 15.407 (a) Pass Radiated Emissions (Above 1GHz) KDB 789033 D02 II G 47 CFR Part 15, Subpart C 15.209 & Subpart E 15.407(b) Pass Radiated Emissions which fall in the restricted bands KDB 789033 D02 II G 47 CFR Part 15, Subpart C 15.209 & Subpart E 15.407(b) Pass Frequency Stability ANSI C63.10 (2013) Section 6.8 47 CFR Part 15, Subpart E 15.407 (g) Pass Radiated Emissions (Below 1GHz) KDB 789033 D02 II G 47 CFR Part 15, Subpart C 15.209 & Subpart E 15.407(b) Pass There are series models mentioned in this report and they are identical on circuitry design, PCB layout, electrical components used, internal wiring and functions. Only the model CS-E6 (5W2F,4mm) was tested since their differences are model No., appearance colour and silkscr…
