2APWR-WT-868Wireless & Wired Timer Remote Control

Shenzhen JinJiaCheng Photography Equipment Co., Ltd.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Apr 07, 2022
Application Purpose: Original Equipment
Date of Application: Apr 07, 2022
Equipment Note: Wireless & Wired Timer Remote Control
Frequency Range: 2401.00000000 - 2456.00000000
Company: Shenzhen JinJiaCheng Photography Equipment Co., Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Model: WT-868 Wireless & Wired Timer Remote Control Product User Manual Thank you for purchasing JJC WT-868 Wireless & Wired Timer Remote Control. For the best performance, please read this instruction carefully before using. You must read it thoroughly and fully understand this manual to avoid improper operation which may result in damage to the product. JJC WT-868 Wireless & Wired Timer Remote is excellent for flower blooming, sunset, moonrise, etc. photography. The remote is equipped to handle a long list of timer functions: self-timer, long exposure timer, interval timer, controlling the number of shots as well as multi-exposure timer. An exposure as long as 99 hours, 59 minutes and 59 seconds can be programmed and number of exposures is up to 999 or unlimited. The transmitter works at a distance up to 100m (328 feet) on any one of 56 channels over a reliable 2.4GHz frequency. WT-868 not only can be used wirelessly, but also can be used as a wired remote. The remote has a wide range of compatibility. Just change the connecting cables (sold separately), and it will work with most cameras with a remote socket. All the features of WT-868 remote make it a good helper for you to take creative pictures. Package Contents Transmitter x 1 Receiver x 1 CR2 3V lithium battery x 1 AAA 1.5V battery x 2 This instruction manual x 1 Connecting cable brochure x 1 Warranty card x 1 Specifications Frequency FSK 2.4GHz Operating distance 100 meters(328 feet) Channel 56 channels Dimensions (W x H x D) Transmitter: 118 x 49 x 27mm Receiver: 68 x 48 x 29mm Weight (without battery) Transmitter: 59g Receiver: 41g Identifying Each Part of WT-868 ⚫ Receiver 1. Indicator Light 2. Control Panel 3. Power Switch 4. Channel ＋ 5. Channel － 6. Battery Compartment 7. ACC Socket 8. Lock Nut 9. Cold Shoe Mount 10. 1/4"-20 Tripod Mount Socket ⚫ Transmitter 1. Control Panel 2. Shutter Release Button 3. LED Light / Lock Button 4. Arrow Buttons 5. Indicator Light 6. Timer Start/Stop Button 7. SET Button 8. ACC Socket 9. Power Switch 10. Selection Cursor 11. Timer Display 12. LOCK Indicator 13. Timer Active Indicator 14. Speaker ON/OFF 15. SET Indicator 16. Release Indicator 17. Number of Shots 18. Delay/Self Timer 19. BULB/Long Exposure 20. Interval Timer 21. Number of Shots 22. Speaker 23. Multi-Exposure Indicator 24. Channel Display Replacing Batteries of Transmitter and Receiver 1. Slide open the battery covers of transmitter and receiver respectively in the direction of the red arrow shown in the following pictures. 2. Install two AAA batteries into the battery compartment of transmitter, and one CR2 battery into compartment of the receiver, following the”＋” and “－” marks as shown in the picture below. Do not install batteries in the reverse direction as this could cause the batteries to leak corrosive liquids, generate heat or explode. 3. Make sure batteries are fully in place and slide back the battery covers of the transmitter and the receiver respectively. Mastering Functions and Usage of the Controls Receiver ⚫ ON/OFF Switch Move the button to “ON”, and the receiver will be turned on; move it to “OFF”, and the receiver will be turned off. ⚫ Channel (CH) ＋/－ Press Channel (CH) ＋/－buttons to adjust channels. Transmitter ⚫ ON/OFF Switch Move the button to “ON”, and the transmitter will be turned on; move it to “OFF”, and the transmitter will be turned off. ⚫ Five Icons Above the LCD Screen of Transmitter There are five icons, namely “DE”, “BU”, “INT”, “N” and above the LCD screen of transmitter. The following chart has illustrated their functions. Icon Function Description Settings Supported DE Delay/Self Timer Just like the self timer on your camera, WT-868 transmitter allows you to set any delay (in 1 second increments) up to 99 hours, 99 minutes and 99 seconds. 0s to 99hrs 59min 59s BU BULB/Long Exposure It allows you to take exposures up to 99 hours, 99 minutes and 99 seconds in length. 0s to 99hrs 59min 59s INT Interval Timer The interval timer can be set to any time period up to 99 hours, 99 minutes and 99 seconds as well. For example, If you set it to 10 minutes, one exposure will be taken every 10 minutes until the Exposure Count limit has been reached. 1s to 99hrs 59min 59s N Number of Shots This setting permits you to set the number of exposures up to 999 shots. 1 shot to 999 shots or unlimited Speaker Speaker ON/OFF ON/OFF ⚫ Shutter Release Button (HOLD) Press the button halfway to focus, and the rest of the way down to take a picture. ⚫ LED Light/Lock Button Press the button momentarily to turn on or turn off the backlight. Press and hold the button for about 2 seconds to lock or release the following buttons: Start/Stop Button, Arrow Button and SET Button. ⚫ “START/STOP” Button Press this button to start or stop the timer. ⚫ Arrow Buttons and SET Button Use arrow buttons to set the timer. Press ◄ or ► to select an item, ▲ or ▼ to adjust an item. The current selection is indicated by the selection cursor. At any time, press the SET button to begin editing or save the current setting. Then press ◄ or ► to view other settings. The selection cursor will move and indicate the current setting. Using the Arrow Buttons and SET button to adjust “DE”, “BU”, “INT”, “N” and : 1. (DE) Delay/Self Timer (Time until shooting starts) Hours Minutes Seconds 2. (BU) BULB/Long Exposure (Exposure Time) Hours Minutes Seconds 3. (INT) Interval Timer Hours Minutes Seconds 4. (N) Number of Shots 5. Speaker ON OFF NOTE: The remote defaults: Interval Time (INT) = Exposure Time (BU) + Time from the moment this shot ends to the moment next shot starts. So when taking long exposure pictures, to make the camera have enough time to focus, interval time (INT) should be at least 2 seconds longer than exposure time (BU). When using autofocus function, make sure delay/self timer is 2 seconds or longer to leave the camera enough time to focus. When using long exposure noise reduction, the interval should be at least twice the exposure time. A…

Text truncated - open the document above for the full version.

Cover Letter(s)

Shenzhen JinJiaCheng Photography Equipment Co., Ltd. Add: RM1305 East Block, Tian'an High-Tech Plaza Phase II, Tian'an Cyber Park, Futian District, Shenzhen China Date: 2022-4-8 FCC ID: 2APWR-WT-868 Dear Sir/Madam, We, Shenzhen JinJiaCheng Photography Equipment Co., Ltd. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: Wireless & Wired Timer Remote Control Model no.: WT-868, WT-868+CABLE-A, WT-868+CABLE-B, WT-868+CABLE-C, WT-868+CABLE-D, WT-868+CABLE-F, WT-868+CABLE-F2, WT-868+CABLE-J, WT-868+CABLE- K, WT-868+CABLE-M, WT-868+CABLE-N, WT-868+CABLE-O, WT-868+CABLE-R, WT-868+CABLE-I2, WT-868+CABLE-R2, WT-868+CABLE-PK1 Sincerely, Name/Title： Miao Ling Zhou /Manager Company: Shenzhen JinJiaCheng Photography Equipment Co., Ltd. Address: RM1305 East Block, Tian'an High-Tech Plaza Phase II, Tian'an Cyber Park, Futian District, Shenzhen China Phone: (86) 0755-82359938 Fax: (86) 0755-82359938 E-Mail: [email protected]

Cover Letter(s)

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2022-4-8> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2APWR-WT-868 WT-868 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Miao Ling Zhou /Manager Company: Shenzhen JinJiaCheng Photography Equipment Co., Ltd. Address: RM1305 East Block, Tian'an High-Tech Plaza Phase II, Tian'an Cyber Park, Futian District, Shenzhen China Phone: (86) 0755-82359938 Fax: (86) 0755-82359938 E-Mail: [email protected]

Cover Letter(s)

Shenzhen JinJiaCheng Photography Equipment Co., Ltd. RM1305 East Block, Tian'an High-Tech Plaza Phase II, Tian'an Cyber Park, Futian District, Shenzhen China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2022-4-8 To whom it may concern: We, Shenzhen JinJiaCheng Photography Equipment Co., Ltd. the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2APWR-WT-868 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Miao Ling Zhou /Manager Company: Shenzhen JinJiaCheng Photography Equipment Co., Ltd. Address: RM1305 East Block, Tian'an High-Tech Plaza Phase II, Tian'an Cyber Park, Futian District, Shenzhen China Phone: (86) 0755-82359938 Fax: (86) 0755-82359938 E-Mail: [email protected]

External Photos

Shenzhen HTT Technology Co., Ltd. Report No.: HTT202203287 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 1 of 4 Product Name: Wireless & Wired Timer Remote Control Model No.: WT-868 EUT Constructional Details External Photo Report No.: HTT202203287 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 2 of 4 Report No.: HTT202203287 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 3 of 4 Report No.: HTT202203287 Shenzhen HTT Technology Co.,Ltd. Tel: 0755-23595200 Fax: 0755-23595201 1F, Building B, Huafeng International Robotics Industrial Park,Hangcheng Road, Nanchang Community, Xixiang Street, Bao'an District, Guangdong Province, Shenzhen, China Page 4 of 4 ------End------

ID Label/Location Info

FCC ID: 2APWR-WT-868 Label and Location Size: L: 1.5cm*W: 1.0cm Label and Location FCC ID : 2APWR-WT-868
