1 ENGLISHENGLISH ENGLISHENGLISHENGLISH 2 56 34 REV 05.30.22 MADE IN CHINA Colors, style and decoration may vary. visit Arcade1up.comvisit Arcade1up.com TO SIGN UP FOR OUR MAILING LIST AND SEE A COMPLETE LIST OF GAMES TO SIGN UP FOR OUR MAILING LIST AND SEE A COMPLETE LIST OF GAMES COLLECT THEM ALLCOLLECT THEM ALL TROUBLESHOOTINGTROUBLESHOOTING Marquee will not light up. PROBLEMPOSSIBLE CAUSESOLUTION -Make sure power cord is plugged into the wall outlet and there is power to that outlet. (Plug other electrical equipment into the power outlet to make sure the outlet normally works.) -Make sure all Wires/Plugs are properly connected and all the way set in as directed in assembly instructions. -Slide ON/OFF Switch located on control deck to the ON position. -Slide upload switch on back of monitor to the ON position. -Make sure all Wires/Plugs are properly connected and all the way set in as directed in assembly instructions. -Slide Volume Switch located on control deck to the right. NOTE: Push volume slide switch right to increase volume, left to lower volume. -Turn the ON/OFF switch OFF and then back ON again. -You may need to RESET the game. Turn the ON/OFF switch to the OFF position. Unplug the game from the wall outlet and wait 60 seconds to RESET the game. Plug the game back in and turn the ON/OFF switch back to ON. -Make sure all Wires/Plugs are properly connected and all the way set in as directed in assembly instructions. -You may need to RESET the game. Turn the ON/OFF switch to the OFF position. Unplug the game from the wall outlet and wait 60 seconds to RESET the game. Plug the game back in and turn the ON/OFF switch back to ON. -Take something thin (like a business card) and place it between the button and the button housing and slide it back and forth to loosen the debris. -Look at the game control section in the instruction manual to make sure you are using the correct joystick or pressing the correct buttons to scroll through the game selection menu. -Look at the game control section in the instruction manual to make sure you are pressing the correct button to exit the game. -Make sure you are holding the exit button down for 5 seconds to exit the game. -Look at the game control section in the instruction manual to make sure you are pressing the correct game control buttons for that game. -Look at the game control loading screen on the monitor to make sure you are pressing the correct control buttons. (NOTE: The game controls that are printed on the control deck are only for the feature cabinet game. The other games in the cabinet will utilize the same buttons but react dierently.) -Look at the game control section in the instruction manual to make sure you are pressing the correct button to enter the game. -Look at the game control section in the instruction manual to make sure you are pressing the correct button to start the game. -Make sure all Wires/Plugs are properly connected and all the way set in as directed in assembly instructions. -Refer to the game control section in the instruction manual to see how many players are able to play that game. -Make sure all Wires/Plugs are properly connected and all the way set in as directed in assembly instructions. Game will not turn on. Game will turn ON, but there is no sound. You hear sound but there is no picture. One of the buttons on the control deck is stuck in the down position. You are not able to scroll through the games on the game selection menu. You are able to scroll through the games on the game selection menu, but you can’t enter a game to begin playing. You have entered the game, but you can’t get the game to start. You have entered the game, but you can’t exit the game to get back to game selection menu. The control functions that are printed on the control deck do not match the gameplay on the screen for the game you are playing. The game will not let me select 2 or 3 players for a chosen game. -Debris may have gotten between the button and the button housing. -You may be pressing the wrong button to enter the game. -You may be pressing the wrong button to exit the game. -You may not be holding down the exit button long enough. -You may be pressing the wrong game control buttons for the game you are playing. -The game may only be a 1 or 2 player game. -You may be pressing the wrong button to start the game. -You may be using the wrong joystick or pressing the incorrect buttons to scroll through the games. The game screen looks pixelated or there are lines running through the image. The game screen is frozen. -Wires/Plugs were hooked up incorrectly. -Power cord is not plugged into wall outlet. -Wires/Plugs are hooked up incorrectly. -ON/OFF Switch is in the OFF position. -Upload switch on back of monitor is in the OFF position. -Wires/Plugs were hooked up incorrectly. -Volume Switch is in the OFF position. -Wires/Plugs were hooked up incorrectly. -The game encountered a problem when processing the data. -Marquee power cord is not plugged in at the back of the monitor. -Marquee power cord is plugged into the wrong input. WARNINGWARNING TO ENJOY A SAFE GAMING ENVIRONMENT Please use the wall anchor kit that is included with the product. Make sure to locate your Arcade1UP on a at surface WARNING: Arcade1UP assumes no liability for improper installation or excessive loads placed on screws or bracket. This wall anchor is not a substitute for proper adult supervision. WARNING Serious or fatal crushing injuries can occur from furniture tip-over. To help prevent tip-over: • Set up Arcade1UP on a level oor. • Never allow children to climb or hang on product. • Always set up an anti-tip device! Use of tip-over restraints may only reduce, but not eliminate, the risk of tip-over. FCC RF RADIATION EXPOSURE STATEMENT: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and any…
