3.Bluetooth Speaker On/Off B85无线充蓝牙音箱 使用B85无线充蓝牙音箱之前；请阅读使用说明书 适用范围 ◆ 一 接口示意图：. 2.无线充电指示灯 ◇输入电压：DC 5V/2A ◇音频输出功率：5W*2 ◇信噪比：≧90db ◇无线充电输出：5W ◇内置锂电池:2000mAH 二.产品参数： 三.操作说明： bluetooth speaker WITH wireless charger Range of Application ◆ 1. Transmitter Wireless Charger 2.Wireless Charger Indicator Product Parameters ◇Input Voltage: DC 5V/2A ◇Audio Output Power: 5W * 2 ◇SNR: ≧ 90 db ◇Wireless Charger Power: 5W ◇Wireless Charger Output: 5V/1A ◇Built-in Battery For Speaker: 2000mAH Operation Instruction ◇Red indicator is on when connecting the product with DC 5V/2A adaptor or other mobile power supply devices. ◇Mobile device is in charging when placing wireless charging enabled device on the wireless charging panel of the product. ◇Wireless charging function is not available for mobile device, an extra wireless receiver is needed to connect with mobile device firstly, and then placing the mobile device on the panel of the product, the wireless charging function works. ◇Blue indicator is continuously on when charging mobile device with wireless charger. B85 请勿把产品放在离医疗设备20cm以内的范围， 防止出现设备干扰现象。 请勿将金属磁铁等异物放置于产品无线充线圈 位置上，防止出现高温对人体造成烫伤危害； 请在用本产品对您的其它设备充电前,去除被 充电设备与本产品接触面的金属饰物。 在不使用的情况下，请把产品充电器从插座上 拔除，避免消耗无线充使用寿命或造成损坏。 ◇ ◇ ◇ ◇ 四.安全须知： 本设备符合FCC规则。 操作符合以下两个条件： （1)该设备不会产生有害干扰，(2)设备必须接受 任何干扰，包括可能会造成不良操作的干扰因素。未 经专利方许可的任何修改和变更都可能导致使用者无 权使用该设备。本设备已经过测试，符合FCC规则第 15页对B类数字设备的限制， 这些限制旨在住宅安装 过程中对使用者遭受有害干扰提供合理的保护。该设 备使用中会产生辐射射频能量，如若不按照说明指示 安装和使用，会对无线通讯造成有害干扰。同时，也 本 五.FCC警告： 为防止使用过程中出现危险情况,请阅读该安全 须知。 请不要在无线充过热时直接触，防止对人体 造成烫伤危害。 请不要把产品放置在加热器，微波炉，电饭 煲，高压锅等加热设备附近，防止造成产品 过热并引发火灾。 请不要摔跌、撞击产品，避免产品出现爆炸 情况。 儿童使用时，请在成人监护下确保正常操作。 请勿在低温潮湿的环境下使用，正常使用环 境0-50°C。 请勿擅自拆卸，维修产品。 请勿把磁条卡片和产品放置在一起，避免出现 消磁现象。 ◇ ◇ ◇ ◇ ◇ ◇ ◇ 对无线广播或电视接收产生有害干扰，而这可以通过 开关设备来控制，则鼓励用户尝试通过一个或多个以 下措施来消除干扰。 - 重新定位或重新定位接收天线。 - 增加设备和接收器之间的距离。 - 将设备连接到与接收器连接的电路不同的电路插座上。 - 咨询经销商或有经验的广播/视频技术人员以获得帮助。 该设备已经过评估，符合一般无线射频暴露要求。 该装置可以在不受限制的便携式曝光条件下使用。 无法保证在特定安装中不会发生干扰。如果该设备 These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful I nterference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help.The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. 4.MICRO USB 1.无线充发射器 3.蓝牙播放开关 4.MICRO USB 67.5mm 150mm 150mm 67.5mm 蓝牙模式播放功能： 1）拨动蓝牙开关至ON位置，即可开起蓝牙模式。 2）手机打开蓝牙，找到蓝牙名为“B85”的设备 进行配对可。 ◇将无线充蓝牙音箱连接DC 5V/2A的适配器或 者其它移动电源设备，此时红灯亮。 ◇将带有无线接收器的手机等设备放在无线充 蓝牙音箱的无线充电面板上，手机显示充电 状态。 ◇如果手机没有内置无线接收器，则需将手机 连接无线接收板。而后再放到无线充到无线 充电面板上，手机显示充电状态。 ◇无线充电器给手机充电时，蓝灯呼吸亮。 Music Playing in Bluetooth Mode: a) Activate bluetooth mode by powering the product and shifting the bluetooth switch to “ON”. b) Activate the bluetooth function in mobile device, and pairing the bluetooth name “B85”. Safety Information Please read the safety instructions to preventing from any dangerous situations when using the product. ◇ Please do not directly touch the over-heated panel of the product, just in case any burn hazard. ◇ Please do not place the product, closing to heater, microwave oven, rice cooker, pressure cooker and other heating devices, to prevent the product from overheating and any risks of fire. ◇ Please do not violently drop or hit the product to avoid explosions of the product. ◇ Please ensure normal operation under adult supervision when the product being used by children. ◇ Please do not use the product in low temperature and humid environment, the normal operational environment is 0-50°C. ◇ Please do not personally disassemble and repair the product. Please read the user manual before using B85 bluetooth speaker with wireless charger Product Illustration ◇ Please do not place the magnetic cards with the product to prevent from demagnetization. ◇ Please do not place the product with medical equipment in 20 cm to prevent device interference. ◇ Do not place foreign objects such as metal magnets on the wireless charging coil of the product to prevent high temperature from causing burns. ◇ Before using this product to charge your other devices, please remove the metal ornaments on the contact surface of the charged device and this product. ◇ When not in use, please unplug the product charger from the socket to avoid consuming the life of the wireless charger or causing damage. FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: a ) The device may not cause harmful interference. b ) The device must accept,any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. The distance between user and products should be no less than 20cm

Supplier's Declaration of Conformity This Declaration of Conformity that the following designated product Product Name:bluetooth speaker with wireless charger Trademark:N/A ModeNo.:B85 Serial Number:MATCO59 Test standard:FCC CFR Title 47 Part 15 Subpart B; 47 CFR Part 18; 680106 D01 RF Exposure Wireless charging APP v03 (Product Identification) It is herewith confirmed and found to comply with the requirements set up by regulation for the evaluation of electromagnetic compatibility. This device complies with Part 15 and Part 18 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) this device must accept any interference received, including interference that may cause undesired operation. This declaration is the responsibility of the Applicant: Shenzhen Doageas Technology Co., Ltd. 5/F, 4th Bldg , HedianlndustrialPark,Guanlan, Longhua, Shenzhen, Guangdong518110, China Identification of regulation/standards: 47 CFR Part 18, Measurement Procedure: ANSI C63.10:2013,ANSI C63.4:2014, FCC OST/MP-5:1986, It is only valid in connection with the test report number: BLA-EMC-202005-A80-01 BLA-EMC-202005-A80-04 Responsible Party – U.S. Contact Information Corporation : Shenzhen Doageas Technology Co., Ltd. Address : 5/F, 4th Bldg, Hedian Industrial Park, Guanlan, Longhua, Shenzhen, Guangdong 518110, China. City, State: Shenzhen, Guangdong Zip Code :518110 contact information :0755-82956575 Supplier's Sign:Denly Zheng Date:2020-7-28

Model No.: B85

WIRELESS CHARGING MOUSE PAD Model:Q102 FCC ID:2AQ2W-Q102 Item No.:2953BLK Power Input:DC 5V/1.5A Wireless Power Output:DC 5V/1A S/N:19-05-318157 MADE IN CHINA 32.00 mm 1 9 . 4 0 m m WIRELESS CHARGING MOUSE PAD Model:Q102 Item No.:2953BLK Power Input:DC 5V/1.5A Wireless Power Output:DC 5V/1A S/N:19-05-318157 MADE IN CHINA 32.00 mm 1 9 . 4 0 m m FCC ID:2AQ2W-B85 2500MAH INPUT:5V/2A OUTPUT:5V/1A Made in China 32.00 mm 1 9 . 4 0 m m

Model No.: B85

Page 1 of4 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] TEST REPORT Product Name : blue tooth speaker with wireless charger Brand Mark : N/A Model No. : B85, MATCO59 FCC ID : 2AQ2W-B85 Report Number : BLA-EMC-202005-A80-04 Date of Sample Receipt : 2020/5/28 Date of Test : 2020/6/1 to 2020/6/12 Date of Issue : 2020/7/15 Test Standard : 47 CFR Part 1.1307, Part 2.1093, KDB 447498 Test Result : Pass Prepared for: Shenzhen Doageas Technology Co., Ltd. 5/F,4thBldg ,HedianlndustrialPark,Guanlan,Longhua, Shenzhen,Guangdong518110,China Prepared by: BlueAsia of Technical Services(Shenzhen) Co.,Ltd. IOT Test Centre of BlueAsia No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen,China TEL: +86-755-28682673 FAX: +86-755-28682673 Compiled by: Review by: Approved by: Date: 2020/7/15 Report No.: BLA-EMC-202005-A80-04 Page 2 of4 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] REPORT REVISE RECORD Version No. Date Description 00 2020/7/15 Original Report No.: BLA-EMC-202005-A80-04 Page 3 of4 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] 1.1 RF Exposure Compliance Requirement 1.1.1 Standard Requirement According to KDB447498D01 General RF Exposure Guidance v06 Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Exclusion Threshold condition, listed below, is satisfied. 1.1.2 Limits The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation 17  The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation DISTANCE IS < 5 MM, A DISTANCE OF 5 MM IS APPLIED TO DETERMINE SAR TEST EXCLUSION Report No.: BLA-EMC-202005-A80-04 Page 4 of4 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] 2 EUT RF EXPOSURE EVALUATION Operational Mode: EDR （8-DPSK worst case） Channel Maximum Peak Conducted Output Power (dBm) Tune up tolerance (dB) Maximum tune-up Power(dBm) Maximum tune-up Power(mW) Calculated value Exclusion threshold 2402MHz 5.80 ±1 6.80 4.79 1.48 3 2441MHz 5.65 ±1 6.65 4.62 1.44 3 2480MHz 5.31 ±1 6.32 4.29 1.35 3 Conclusion: the calculated value ≤3.0, SAR is exempted. ----END OF REPORT---- The test report is effective only with both signature and specialized stamp, The result(s) shown in this report refer only to the sample(s) tested. Without written approval of BlueAsia, this report can’t be reproduced except in full.

Page 1 of71 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] TEST REPORT Product Name: blue tooth speaker with wireless charger Brand Mark: DOAGEAS Model No.: B85, MATCO59 FCC ID: 2AQ2W-B85 Report Number: BLA-EMC-202005-A80-02 Date of Sample Receipt : 2020/5/28 Date of Test: 2020/6/1 to 2020/6/12 Date of Issue : 2020/7/15 Test Standard: 47 CFR Part 15, Subpart C 15.247 Test Result:Pass Prepared for: Shenzhen Doageas Technology Co., Ltd. 5/F, 4thBldg ,HedianlndustrialPark, Guanlan, Longhua, Shenzhen,Guangdong518110,China Prepared by: BlueAsia of Technical Services(Shenzhen) Co.,Ltd. IOT Test Centre of BlueAsia No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen,China TEL: +86-755-28682673 FAX: +86-755-28682673 Compiled by:Review by: Approved by:Date: 2020/7/15 Report No.: BLA-EMC-202005-A80-02 Page 2 of71 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] REPORT REVISE RECORD Version No.DateDescription 002020/7/15Original Report No.: BLA-EMC-202005-A80-02 Page 3 of71 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] TABLE OF CONTENTS 1 TEST SUMMARY ........................................................................................................................................6 2 GENERAL INFORMATION .........................................................................................................................7 3 GENERAL DESCRIPTION OF E.U.T. .........................................................................................................7 4 TEST ENVIRONMENT ................................................................................................................................8 5 TEST MODE ................................................................................................................................................8 6 MEASUREMENT UNCERTAINTY ..............................................................................................................8 7 DESCRIPTION OF SUPPORT UNIT...........................................................................................................9 8 LABORATORY LOCATION .........................................................................................................................9 9 TEST INSTRUMENTS LIST ..................................................................................................................... 10 1 ANTENNA REQUIREMENT ..................................................................................................................... 14 1.1 CONCLUSION ............................................................................................................................................................ 14 2 CONDUCTED SPURIOUS EMISSIONS .................................................................................................. 15 2.1 LIMITS ................................................................................................................................................................... 15 2.2 BLOCK DIAGRAM OF TEST SETUP .......................................................................................................................... 15 2.3 TEST DATA .............................................................................................................................................................. 16 3 HOPPING CHANNEL NUMBER.............................................................................................................. 17 3.1 LIMITS ................................................................................................................................................................... 17 3.2 BLOCK DIAGRAM OF TEST SETUP .......................................................................................................................... 17 3.3 TEST DATA .............................................................................................................................................................. 17 4 CARRIER FREQUENCIES SEPARATION .............................................................................................. 18 4.1 LIMITS ................................................................................................................................................................... 18 4.2 BLOCK DIAGRAM OF TEST SETUP .......................................................................................................................... 18 4.3 TEST DATA .............................................................................................................................................................. 18 5 20DB BANDWIDTH .................................................................................................................................. 19 5.1 BLOCK DIAGRAM OF TEST SETUP .......................................................................................................................... 19 5.2 TEST DATA .............................................................................................................................................................. 19 6 CONDUCTED PEAK OUTPUT POWER ................................................................................................. 20 6.1 LIMITS ................................................................................................................................................................... 20 6.2 BLOCK DIAGRAM OF…
