2AQA6-H5108Smart Thermometer R1

H5108 英语说明书 版本：1.0 料号： 成型尺寸：60X60(mm) 材质：80G书页纸 工艺：单色印刷 折叠方式：骑马钉 页数：16页 Refrigerator Thermometer with Wi-Fi Gateway Model:H5108+H5151 User Manual 01 English Included in the Box SKU H5151 Gateway H5108 Thermometer AAA Battery (include) Probe Cable Lanyard Holder 3M Adhesive Tape User Manual H5108001 0 1 2 1 1 1 1 1 B5108001 0 2 4 2 2 2 2 1 B5108101 1 1 2 1 1 1 1 1 B5108102 1 2 4 2 2 2 2 1 At a Glance 02 ❶ ❷ Indicator Light Function Button ❸ Power Prongs ❶ ❷ ❸ Working Status Powered for the First Time Searching and Connecting to Wi-Fi Indicator Status Slowly Flashes Red and Blue Quickly Flashes Blue Gateway （H5151） 03 Short press (when pairing with the gateway) OperationStatus / Function Confirm pairing Set Up Your Gateway Downloading Govee Home App To download Govee Home App, scan the QR code or search for “Govee” in the Apple App Store® (iOS) or Google Play Store (Android). ❶ Follow the in-app instructions to complete pairing. Open Govee Home App, tap the "+" icon at the top right corner and select "H5151". ❷ ❸ 04 The Wi-Fi Gateway icon is at the top right corner of the “Device”page. Note: Make sure your 2.4GHz Wi-Fi network is functioning properly before pairing the Wi-Fi Gateway to the network. Please check the above steps and try again if paring fails. Specifications ❹ ModelH5151 MaterialABS Size35*50*38 mm（1.4*2.3*1.5 in.） Weight45g（1.6 oz.） Power100-240V AC 50/60Hz Network ConnectivityBlutooth 4.2, Wi-Fi IEEE 802.11b/g/n 2.4GHz 05 Short press (when pairing with the gateway) Confirm pairing Short press Switch between °F and °C OperationStatus / Function At a Glance Lanyard ❶ Bluetooth Connected ❷ Battery Power ❸ Temperature ❹ Unit Switch ❺ Probe Cable ❻ ❶ ❷ ❸ ❹ ❺ ❻ Refrigerator Thermometer（H5108） 06 To download Govee Home App, scan the QR code or search for “Govee” in the Apple App Store® (iOS) or Google Play Store (Android). Set Up Your Refrigerator Thermometer Power on your device Pull out the insulation sheet and plug the probe into it. ❶ Download Govee Home App ❷ 07 Add your device to Govee Home App Open Govee Home, tap “+” icon at the top right corner and select “H5108”. Follow instructions in app to complete connecting. ❸ Turn on the remote function (If there is no gateway, you can skip this step) Enter the details page of product and select "Setting - Remote Control". Choose to bind the nearest gateway. ❹ Installing the product Attach the thermometer onto the refrigerator(Using magnetic attachment or a Lanyard). Insert the probe into the holder. Adjust the length of the cable and put the holder into the refrigerator. ❺ 08 Specifications ModelH5108 MaterialABS Size62*62*21 mm（2.4*2.4*0.8 in.） Weight88g（3.2 oz.） Power2*AAA Batteries Device Operating Temp-4°F to 140°F（-20°C to 60°C） Probe Temperature-40°F to 158°F（-40°C to 70°C） Probe Accuracy±0.9°F（±0.5°C） Network ConnectivityBlutooth Low Energy 4.2 or above 09 Problem Gateway cannot connect to Wi-Fi. Temperature displays "--". Possible Cause Gateway does not support 5GHz Wi-Fi. Wi-Fi contains special characters. Wi-Fi is out of range. The probe hasn't been plugged into the thermometer. Probe is damaged. Solution Connect the gateway to 2.4GHz Wi-Fi. Change the Wi-Fi name and password. Keep the gateway and router within 100m. Insert the probe. Purchase a new probe. Troubleshooting The thermometer doesn't work. The thermometer sends delayed alerts or does not alert. Gateway is offline. Battery is dead. App doesn't have permission. The interval of anti-false alarm mode is long. Shorten the distance between the gateway and router. Replace the battery. Enable notification permissions for Govee Home App. Set to shorten the anti-false alarm interval. 10 Warning The device should work in an environment with a temperature ranging from -20°C ~ 60°C and humidity from 0%RH to 99%RH. ❶ Do not disassemble the device violently. Do not immerse the device in the water. ❷ ❸ 11 Customer Service Warranty: 12-Month Limited Warranty Support: Lifetime Technical Support Email: [email protected] Official Website: www.govee.com @Govee.smarthome@Goveeofficial @govee.official @govee_official @Govee FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: (1) Reorient or relocate the receiving antenna. (2) Increase the separation between the equipment and receiver. (3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. (4) Consult the dealer or an experienced radio/TV technician for help. FCC Radio Frequency Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Responsible party : Name: GOVEE MOMENTS(US) TRADING LIMITED Address: 2501 Chatham Rd Suite R Springfield IL 62704 …

Text truncated - open the document above for the full version.

-ShenzhenIntellirocksTech.Co.,Ltd.- TheinformationprovidedinthisletterisbasedonthereferencedrulepartsofTitle47oftheCFRaswellasKDB986446D01. Anexpirationdateforthisletterdoesnotexist.IncasetheU.S.agentchanges,thegranteeisobligatedtonotifytheFCCwithin30daysvia thegrantingTCB. FederalCommunicationsCommission AuthorizationandEvaluationDivision EquipmentAuthorizationBranch 7435OaklandMillsRoad Columbia,MD21046 5/18/23 U.S.AgentDesignation NameandcompanyofU.S.agent:GOVEEMOMENTS(US)TRADINGLIMITED PhysicalU.S.addressofagent:2501ChathamRdSuiteRSpringfieldIL62704,USA FRNofU.S.agent:0033426016 EmailaddressofU.S.agent:[email protected] [Shenzhen Intellirocks Tech. Co., Ltd.] acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: [2A7VD-H5108]): m [GOVEEMOMENTS(US)TRADINGLIMITED]acknowledgestheirobligationtoacceptserviceof processonbehalfof[ShenzhenIntellirocksTech.Co.,Ltd.]. [ShenzhenIntellirocksTech.Co.,Ltd.]withtheFRN[0027657980]acceptsitsobligationtomaintain anagentforserviceofprocessintheUnitedStatesfornolessthanoneyearaftereitherthegrantee haspermanentlyterminatedallmarketingandimportationoftheapplicableequipmentwithintheU.S., ortheconclusionofanyCommission-relatedadministrativeorjudicialproceedinginvolvingthe equipment,whicheverislater. Bysigningthisform,weconfirmtheaboveandthatweareawareoftheapplicationrequirements listedunder§2.911(d)(7). Sincerely, Signature [EricPan] [Manager] [ShenzhenIntellirocksTech.Co.,Ltd.] Signature [TinaLiu] [CertificationManager] [GOVEEMOMENTS(US)TRADINGLIMITED] 4 8 _ [ m o d e l ] U S _ A g e n t _ 2 . 9 1 1 ( d ) ( 7 ) - U , V 0 4

ShenzhenIntellirocksTech.Co.,Ltd. TheinformationprovidedinthisletterisbasedonthereferencedrulepartsofTitle47oftheCFRaswellasKDB986446D01. FederalCommunicationsCommission AuthorizationandEvaluationDivision EquipmentAuthorizationBranch 7435OaklandMillsRoad Columbia,MD21046 9/28/23 Towhomitmayconcern: We,[ShenzhenIntellirocksTech.Co.,Ltd.],herebycertifythattheequipmentforwhich authorizationissought(FCCID:[2AQA6-H5108])isnot“covered”equipmentprohibitedfrom receivinganequipmentauthorizationpursuantto§2.903oftheFCCrules. Wealsocertifythat,asofthedateofthefilingoftheapplication,wearenotidentifiedontheCovered List(https://www.fcc.gov/supplychain/coveredlist)asanentityproducing“covered”equipment. Bysigningthisform,weconfirmtheaboveandthatweareawareoftheapplicationrequirements listedunder§2.911(b)and(d)(5)and(6). Sincerely, EricPan Manager [ShenzhenIntellirocksTech.Co.,Ltd.] 6 2 _ [ m o d e l ] C o v e r e d E q u _ 2 . 9 1 1 ( d ) ( 5 ) ( i ) a n d ( i i ) - U , V 0 2

ProjectNo.:18220WC301787Page1of4 Code:AB-RF-05-b AppendixII--ExternalPhotograph ProjectNo.:18220WC301787Page2of4 Code:AB-RF-05-b ProjectNo.:18220WC301787Page3of4 Code:AB-RF-05-b ProjectNo.:18220WC301787Page4of4 Code:AB-RF-05-b

Smart Thermometer R1 Model: H5108 Power: 2*AAA/3V 40mA FCC ID: 2AQA6-H5108 Shenzhen Intellirocks Tech. Co., Ltd. SN: Made in China H5108镭雕文件李梦霞2023.08.07V1.1 正面背面 红色字符镭雕

ProjectNo.:18220WC301787Page1of3 Code:AB-RF-05-b AppendixIII--InternalPhotograph ProjectNo.:18220WC301787Page2of3 Code:AB-RF-05-b ANT ProjectNo.:18220WC301787Page3of3 Code:AB-RF-05-b

RFEXPOSUREEVALUATION FCCID:2AQA6-H5108 AccordingtoFCC1.1310:Thecriterialistedinthefollowingtableshallbeused toevaluatetheenvironmentimpactofhumanexposuretoradiofrequency(RF) Radiationasspecifiedin§1.1307(b): RoutineSARevaluationreferstothatspecificallyrequiredby§2.1093,using measurementsorcomputersimulation.WhenroutineSARevaluationisnot required,portabletransmitterswithoutputpowergreaterthantheapplicable lowthresholdrequireSARevaluationtoqualifyforTCBapproval. Channel (MHz) Maximum output power (dBm) Tuneup tolerance (dBm) MaxTuneUp Power(dBm) Distance (mm) Calculation results Limit Operating Mode 24022.312.31 ±1 3.3150.6643 GFSK24402.422.42±13.4250.6873 24801.461.46±12.4650.5553 Result:NoStandaloneSARtestisrequired.

Page1of22 AppendixTestData ReportNo.:18220WC30178701TestSampleNo.:1-2-2 StartTestDate: 2023.08.23 FinishTestDate:2023.08.26 TestEngineer:Auditor: Temperature:25.2 °C RelativeHumidity:48% Pressure:102kPa AppendixA:DTSBandwidth TestResult TestModeAntennaFrequency[MHz]DTSBW[MHz]FL[MHz]FH[MHz]Limit[MHz]Verdict BLE_1MAnt1 24020.6882401.6522402.3400.5PASS 24400.6802439.6642440.3440.5PASS 24800.6722479.6722480.3440.5PASS Page2of22 TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page3of22 Page4of22 AppendixB:OccupiedChannelBandwidth TestResult TestModeAntennaFrequency[MHz]OCB[MHz]FL[MHz]FH[MHz] BLE_1MAnt1 24021.02962401.49592402.5255 24401.02572439.49592440.5216 24801.02722479.49802480.5252 Page5of22 TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page6of22 Page7of22 AppendixC:Maximumconductedoutputpower TestResultPeak TestModeAntennaFrequency[MHz] ConductedPeak Power[dBm] Conducted Limit[dBm] Verdict BLE_1MAnt1 24022.31≤30PASS 24402.42≤30PASS 24801.46≤30PASS Page8of22 TestGraphsPeak BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page9of22 Page10of22 AppendixD:Maximumpowerspectraldensity TestResult TestModeAntennaFrequency[MHz]Result[dBm/3kHz]Limit[dBm/3kHz]Verdict BLE_1MAnt1 2402-12.82≤8.00PASS 2440-12.43≤8.00PASS 2480-13.42≤8.00PASS Page11of22 TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page12of22 Page13of22 AppendixE:Bandedgemeasurements TestResult TestModeAntennaChName Frequency [MHz] RefLevel[dBm]Result[dBm]Limit[dBm]Verdict BLE_1MAnt1 Low24021.59-57.89≤-18.41PASS High24800.98-56.92≤-19.03PASS TestGraphs BLE_1M_Ant1_Low_2402 BLE_1M_Ant1_High_2480 Page14of22 AppendixF:ConductedSpuriousEmission TestResult TestModeAntenna Frequency [MHz] FreqRange [MHz] RefLevel [dBm] Result[dBm]Limit[dBm]Verdict BLE_1MAnt1 2402 Reference0.680.68---PASS 30~10000.68-68.52≤-19.32PASS 1000~265000.68-53.21≤-19.32PASS 2440 Reference1.641.64---PASS 30~10001.64-69.24≤-18.36PASS 1000~265001.64-52.50≤-18.36PASS 2480 Reference0.600.60---PASS 30~10000.60-69.23≤-19.4PASS 1000~265000.60-53.41≤-19.4PASS Page15of22 TestGraphs BLE_1M_Ant1_2402_0~Reference BLE_1M_Ant1_2402_30~1000 BLE_1M_Ant1_2402_1000~26500 Page16of22 BLE_1M_Ant1_2440_0~Reference BLE_1M_Ant1_2440_30~1000 Page17of22 BLE_1M_Ant1_2440_1000~26500 BLE_1M_Ant1_2480_0~Reference Page18of22 BLE_1M_Ant1_2480_30~1000 BLE_1M_Ant1_2480_1000~26500 Page19of22 Page20of22 AppendixG:DutyCycle TestResult TestModeAntennaFrequency[MHz] ONTime [ms] Period [ms] DutyCycle [%] DutyCycle Factor[dB] BLE_1MAnt1 240219.0019.001000.00 244019.0019.001000.00 248019.0019.001000.00 Page21of22 TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page22of22 ---End---

ReportNo.:18220WC30178701FCCID:2AQA6-H5108Page1of29 Code:AB-RF-05-b FCCTestReport Applicant:ShenzhenIntellirocksTech.Co.,Ltd. Address: No.2901-2904,3002,BlockC,Section1, ChuangzhiYunchengBuilding,Liuxian Avenue,XiliCommunity,XiliStreet,Nanshan District,Shenzhen,Guangdong,China ProductName:SmartThermometerR1 ReportDate:Sept.27,2023 ShenzhenAnbotekComplianceLaboratoryLimited ReportNo.:18220WC30178701FCCID:2AQA6-H5108Page2of29 Code:AB-RF-05-b Contents 1.GeneralInformation............................................................................................................................................6 1.1.ClientInformation....................................................................................................................................6 1.2.DescriptionofDevice(EUT)..................................................................................................................6 1.3.AuxiliaryEquipmentUsedDuringTest.................................................................................................7 1.4.DescriptionofTestConfiguration..........................................................................................................7 1.5.DescriptionOfTestSetup......................................................................................................................8 1.6.TestEquipmentList.................................................................................................................................9 1.7.MeasurementUncertainty....................................................................................................................10 1.8.DescriptionofTestFacility...................................................................................................................10 1.9.Disclaimer...............................................................................................................................................11 2.SummaryofTestResults.................................................................................................................................12 3.ConductedEmissionTest................................................................................................................................13 3.1.TestStandardandLimit........................................................................................................................13 3.2.TestSetup...............................................................................................................................................13 3.3.TestProcedure.......................................................................................................................................13 3.4.TestData.................................................................................................................................................13 4.RadiationSpuriousEmissionandBandEdge.............................................................................................14 4.1.TestStandardandLimit........................................................................................................................14 4.2.TestSetup...............................................................................................................................................14 4.3.TestProcedure.......................................................................................................................................15 4.4.TestData.................................................................................................................................................16 5.MaximumPeakOutputPowerTest...............................................................................................................24 5.1.TestStandardandLimit........................................................................................................................24 5.2.TestSetup...............................................................................................................................................24 5.3.TestProcedure.......................................................................................................................................24 5.4.TestData.................................................................................................................................................24 6.6dBOccupyBandwidthTest...........................................................................................................................25 6.1.TestStandardandLimit........................................................................................................................25 6.2.TestSetup...............................................................................................................................................25 6.3.TestProcedure.......................................................................................................................................25 6.4.TestData.................................................................................................................................................25 7.PowerSpectralDensityTest...........................................................................................................................26 7.1.TestStandardandLimit........................................................................................................................26 7.2.TestSetup...............................................................................................................................................26 7.3.TestProcedure.......................................................................................................................................26 7.4.TestData.................................................................................................................................................26 8.100kHzBandwidthofFrequencyBandEdgeRequirement.....................…

Text truncated - open the document above for the full version.

version01 ShenzhenIntellirocksTech.Co.,Ltd. DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.:H5108 FCCID:2AQA6-H5108 fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsfor internal antennatype(s) describedbelow: ModelNo.ofantenna:H5108 Typeofantenna:ShrapnelAntenna Gainoftheantenna:1.73dBi Frequencyrange:2400-2500MHz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Companyname:ShenzhenIntellirocksTech.Co.,Ltd. Address:No.2901-2904,3002,BlockC,Section1,ChuangzhiYunchengBuilding, LiuxianAvenue,XiliCommunity,XiliStreet,NanshanDistrict,Shenzhen, Guangdong,China City:XiliStreet,NanshanDistrict,Shenzhen ZIP/Postalcode:518000 Country:China Place:Date:9/28/2023 Signature:

Antennatestreport TestLaboratoryDongguanYijiaElectronicCo.,LTD Address No.59MuyuRoad,ShatouCommunity,Chang'anTown,Dongguan City,GuangdongProvince Contact:Mr.Gan13823198410 ModelH5108 1.Testprocedures NameParameterMethodStandardNo. Mobile communication antenna VSWR Genericspecificaitonforantennasusedin themobilecommunications GB/T9410-2008 AntennaGain Radiationpattern Antenna Radiationefficiency IEEEStandardTestProceduresfor Antennas ANSI/IEEEStd149 -1979 2.TestEquipment EquipmentModelNo. Serial No. ManufactureCalibration Date Next calibration Date 24probe Microwave chamber MPS2450Multi- probeOTAme asurementsystems 5*5*5 YJ-PB-F01XH-IOE2022.09.012023.09.01 NetworkAnalyzer ZVB8YJ-RD-15 ROHDE&SCH WARS 2022.08.252023.08.25 Widebandradio Communication tester CMW500YJ-RD-16 ROHDE&SCH WARS 2022.08.252023.08.25 3.DUTSetupPhoto 4.BluetoothAntennaPhysicalSize 5.BluetoothAntennaType&Gain Type:metalsheetAntenna Frequency/MHzGain/dBi 2400 1.50 2410 1.58 24201.43 24301.34 24401.26 2450 1.66 24601.28 24701.64 24801.42 24901.73 2500 1.43 6.BluetoothAntennaPatternPicture 2400MHz 2450MHz 2500MHz Testerby：Wuxianming

ProjectNo.:18220WC301787Page1of1 Code:AB-RF-05-b AppendixI--TestSetupPhotograph PhotoofRadiationEmissionTest(below1GHz) PhotoofRadiationEmissionTest(above1GHz)
