INTERTEK TESTING SERVICES FCC ID: 2AQA6-H6144 RF Exposure Report The Equipment Under Test (EUT) is a RGBIC LED Strip Lights, RGBIC LED Strip Lights with BT5.0 (BLE only) operating in 2402-2480MHz, 2.4G Wi-Fi function operating at 2412-2462MHz. The EUT is powered by AC 100-240V. Bluetooth and WIFI transmitters use different antennas and can transmit simultaneously, For more detailed features description, please refer to the user’s manual. Bluetooth Version: 5.0 BLE Antenna Type: Internal antenna Antenna Gain: 2.1dBi. Modulation Type: GFSK The normal radiated output power (e.i.r.p) is: -0.9 dBm (tolerance: ± 4dB). The normal conducted output power is: -3 dBm (tolerance: ± 4dB). According to the KDB 447498: The Maximum peak radiated emission for the EUT is 96.2dBμV/m at 3m in the frequency 2402MHz The EIRP = [(FS*D) ^2 / 30] mW = 0.97 dBm which is within the production variation. The Minimum peak radiated emission for the EUT is 91.8 dBμV/m at 3m in the frequency 2480MHz The EIRP = [(FS*D) ^2 / 30] mW = -3.43 dBm which is within the production variation. According to FCC Part 2.1091, this unlicensed transmitting device is categorically excluded from routine environmental evaluation for RF exposure prior to equipment authorization or use, According to the KDB 447498 and OET 65, the simple calculation as below: The maximum radiated power = 3.1dBm = 2.0417mW From above data, the exposed power density at a distance (R) of 20cm from the center of radiation of the antenna for 2.4GHz band can be calculated according to OET 65 as follow: = 2.0417mW/ 4πR^2 = 0.0004 mW/cm^2 The MPE limit is 1.0 mW/cm^2 for general population and uncontrolled exposure in the 2.4GHz frequency range according to FCC Part 1.1310. As the measured power density at 20cm from the transmitter is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum 20cm separation between the transmitter's radiating structure and body of the user or nearby persons. INTERTEK TESTING SERVICES FCC ID: 2AQA6-H6144 2.4G WIFI Function: Modulation Type: CCK, BPSK, QPSK, 16QAM, 64QAM, DQPSK, DBPSK Antenna Type: Internal antenna Antenna Gain: 1.5 dBi The nominal conducted output power specified: 17dBm (Tolerance: ± 1.2dB) The nominal radiated output power specified: 18.5dBm (Tolerance: ± 1.2dB) The maximum conducted output power for the EUT is 18.08 dBm in the frequency 2.462GHz 802.11b mode which is within the production variation. The minimum conducted output power for the EUT is 17.43 dBm in the frequency 2.412GHz 802.11g mode which is within the production variation. According to FCC Part 2.1091, this unlicensed transmitting devices is categorically excluded from routine environmental evaluation for RF exposure prior to equipment authorization or use, According to the KDB 447498 and OET 65, the simple calculation as below: For Maximum Permissible Exposure (MPE) evaluation of the product, the maximum power density at 20 cm from this transmitter shall be less than the General Population / Uncontrolled MPE limit in OET Bulletin 65. The maximum E.I.R.P = 17dBm+1.2dB+1.5dBi=19.7dBm=93.33mW The source-based time averaged maximum radiated power = 93.33mW x Duty Cycle = 93.33mW From above data, the exposed power density at a distance (R) of 20cm from the center of radiation of the antenna can be calculated according to OET Bulletin 65 as follow: = 93.33mW / 4πR^2 = 0.019 mW/cm^2 The MPE limit is 1.0 mW/cm^2 for general population and uncontrolled exposure in the Wi-Fi frequency range according to FCC Part 1.1310. As the measured power density at 20cm from the transmitter is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum 20cm separation between the transmitter's radiating structure and body of the user or nearby persons. Transmitter Duty Cycle Calculation The EUT transmit continuously during the test, the duty cycle is 1. INTERTEK TESTING SERVICES FCC ID: 2AQA6-H6144 Simultaneous Transmission Evaluation For Simultaneous transmitting of 2.4GHz WiFi and Bluetooth transmitters, According to 865664D02 2.2 d) 1): The sum of the ratios of the spatially averaged results to the applicable frequency dependent MPE limits = 0.0004/1 + 0.019/1 = 0.0194 < 1 Since the sum of the MPE ratios for all simultaneously transmitting antennas incorporated in the device is ≤ 1.0, the EUT is considered to satisfy MPE compliance for simultaneous transmission operations. The following RF exposure statement or similar sentence is proposed to be included in the user manual: “FCC RF Radiation Exposure Statement Caution: This Transmitter must be installed to provide a separation distance of at least 20 cm from all persons.”

Shenzhen Intellirocks Tech. Co., Ltd. TEST REPORT SCOPE OF WORK FCC TESTING– H6144, H6143, H614C REPORT NUMBER 201119014SZN-003 ISSUE DATE [REVISED DATE] 08 April 2021 [---------------------] PAGES 55 DOCUMENT CONTROL NUMBER FCC ID 247_b © 2017 INTERTEK Intertek Report No.: 201119014SZN-003 This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, Shenzhen, P.R. China. Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Version: 01-November-2017 Page: 1 of 55 FCC ID 247_b TEST REPORT 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, Shenzhen, P.R. China. Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 www.intertek.com Shenzhen Intellirocks Tech. Co., Ltd. Application For Certification FCC ID: 2AQA6-H6144 RGBIC LED Strip Lights Model: H6144, H6143, H614C Brand Name: Govee, Minger 2.4GHz Wi-Fi Transceiver Report No.: 201119014SZN-003 We hereby certify that the sample of the above item is considered to comply with the requirements of FCC Part 15, Subpart C for Intentional Radiator, mention 47 CFR [10-1-19] Prepared and Checked by: Approved by: Mandy Chen Peter Kang Engineer Senior Technical Supervisor Date: 08 April 2021 Intertek Report No.: 201119014SZN-003 Version: 01-November-2017 Page: 2 of 55 FCC ID 247_b TEST REPORT MEASUREMENT/TECHNICAL REPORT This report concerns (check one) Original Grant X Class II Change Equipment Type: DTS - Part 15 Digital Transmission Systems (Wi-Fi transmitter portion) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until : date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [10-01- 19] Edition] provision. Report prepared by: Mandy Chen Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, Shenzhen, P.R. China. Tel: (86 755) 8614 0684 Fax: (86 755) 8601 6752 Intertek Report No.: 201119014SZN-003 Version: 01-November-2017 Page: 3 of 55 FCC ID 247_b TEST REPORT Table of Contents 1.0 Summary of Test results ............................................................................................... 4 2.0 General Description ...................................................................................................... 5 2.1 Product Description ........................................................................................................... 5 2.2 Related Submittal(s) Grants ............................................................................................... 5 2.3 Test Methodology .............................................................................................................. 5 2.4 Test Facility ........................................................................................................................ 5 3.0 System Test Configuration ............................................................................................ 6 3.1 Justification ........................................................................................................................ 6 3.2 EUT Exercising Software ..................................................................................................... 6 3.3 Special Accessories ............................................................................................................ 6 3.4 Measurement Uncertainty ................................................................................................. 7 3.5 Equipment Modification .................................................................................................... 7 3.6 Support Equipment List and Description .......................................................................... 7 4.0 Measurement Results ................................................................................................... 8 4.1 Maximum Conducted Output Power at Antenna Terminals ................................................. 8 4.2 Minimum 6 dB RF Bandwidth ............................................................................................ 9 4.3 Maximum Power Density Reading ................................................................................... 15 4.4 Out of Band Conducted Emissions ................................................................................... 21 4.5 Out of Band Radiated Emissions ...................................................................................... 34 4.6 Transmitter Radiated Emissions in Restricted Bands ........................................................ 35 4.7 Field Strength Calculation ................................................................................................ 36 4.8 Radiated Spurious Emission ............................…
