Wireless charger instruction sheet The diagram of installation 4 5 1 2 3 Charging area Indicator Light area Connector for power supply Instruction sheet USB cable Wireless charger’s charging method 1) Connect wireless charging pad to a power source via included micro USB cable. Charging pad entering standby mode with red indicator light on. 2) Place your portable device in the center area of the charging pad, charging begins with blue color indicator light on. 3) All lights turn off when charging completed. Product specs: Product model: WP003 Main function: wireless charging transmitter Charging type: one-on-one charge corresponding area Input Specs: DC 5V/1A Output Specs: 5V/800mA Effiective Distance: 4 to 6MM Conversion efficiency: ≥70% Charging methods: induction model Working frequency: Accessories: USB cable, Wireless charging pad Instruction sheet, warning card 110.5-205 KHz How to Use Correctly? ( FCC Caution. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help.

2020-03-20 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AQBD-WP003 Product Name: folding wireless charger stand Model name: WP003 Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) Schematics Block diagram Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Sincerely, Name: Dongsheng Huang Title: General Manger Company: FUJIAN YOUTONG INDUSTRIES CO.,Ltd.

2020-03-20 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen STS Test Services Co., Ltd., 1/F., Building B, Zhuoke Science Park, No.190, Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China (Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with FUJIAN YOUTONG INDUSTRIES CO.,Ltd., Building 7, Scud Industrial Park, No. 70, Rujiang East Road, Kuai’ an, Mawei, Fuzhou, China (Applicant Name and address) Sincerely, Name: Dongsheng Huang Title: General Manger Company: FUJIAN YOUTONG INDUSTRIES CO.,Ltd.

Page 1 of 3 Report No.: STS2003171 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Page 2 of 3 Report No.: STS2003171 Photo 3 Photo 4 Page 3 of 3 Report No.: STS2003171 Photo 5 Photo 6

Label Note: The label is silk-screen on the sample folding wireless charger stand Model name: WP003 FCC ID: 2AQBD-WP003 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. W:35mm W:18m m L:30mm

Page 1 of 2 Report No.: STS2003171 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Antenna Page 2 of 2 Report No.: STS2003171 Photo 3 Photo 4

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC TEST REPORT Report No.: STS2003171W01 Issued for FUJIAN YOUTONG INDUSTRIES CO.,Ltd. Building 7, Scud Industrial Park, No. 70, Rujiang East Road, Kuai’ an, Mawei, Fuzhou, China Product Name: folding wireless charger stand Brand Name: N/A Model Name: WP003 Series Model: N/A FCC ID: 2AQBD-WP003 Test Standard: FCC Part 15 Subpart C S T L A B S Page 2 of 21 Report No.: STS2003171W01 TEST RESULT CERTIFICATION Applicant’s Name ................... : FUJIAN YOUTONG INDUSTRIES CO.,Ltd. Address .................................. : Building 7, Scud Industrial Park, No. 70, Rujiang East Road, Kuai’ an, Mawei, Fuzhou, China Manufacture's Name .............. : FUJIAN YOUTONG INDUSTRIES CO.,Ltd. Address .................................. : Building 7, Scud Industrial Park, No. 70, Rujiang East Road, Kuai’ an, Mawei, Fuzhou, China Product Description Product Name ........................ : folding wireless charger stand Brand Name ......................... : N/A Model Name ........................... : WP003 Series Model .......................... : N/A Test Standards ...................... : FCC Part 15 Subpart C Test Procedure ....................... : ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ................................: Date of receipt of test item ..........: 05 Mar. 2020 Date (s) of performance of tests .: 06 Mar. 2020 ~ 09 Mar. 2020 Date of Issue ............................. : 10 Mar. 2020 Test Result ..................................: Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Vita Li) Page 3 of 21 Report No.: STS2003171W01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACTORY 5 1.2 MEASUREMENT UNCERTAINTY 5 2. GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF THE EUT 6 2.2 DESCRIPTION OF THE TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 9 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 10 3. CONDUCTED EMISSION TEST RESULT (SECTION 15.207) 11 3.1 POWER LINE CONDUCTED EMISSION LIMITS 11 3.2 TEST PROCEDURE 12 3.3 TEST SETUP 12 3.4 EUT OPERATING CONDITIONS 12 3.5 TEST RESULTS 13 4. RADIATED& FIELD EMISSION TEST RESULT (SECTIOU 15.209 ) 15 4.1 LIMIT 15 4.2 TEST PROCEDURE 15 4.3 TEST SETUP 16 4.4 TEST RESULTS 17 5. 20 DB BANDWIDTH TEST 20 5.1 LIMIT 20 5.2 TEST SETUP 20 5.3 TEST RESULTS 20 APPENDIX-PHOTOS OF TEST SETUP 21 Page 4 of 21 Report No.: STS2003171W01 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 10 Mar. 2020 STS2003171W01 ALL Initial Issue Page 5 of 21 Report No.: STS2003171W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.209（a） Radiated emission, Spurious Emission PASS 2.1049 20 dB Bandwidth PASS 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainly 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 30-1GHz ±6.7dB 4 All emissions, radiated 1G-6GHz ±5.5dB 5 All emissions, radiated>6G ±5.8dB 6 Conducted Emission (9KHz-150KHz) ±4.43dB 7 Conducted Emission (150KHz-30MHz) ±5dB Page 6 of 21 Report No.: STS2003171W01 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name folding wireless charger stand Trade Name N/A Model Name WP003 Series Model N/A Model Difference N/A Channel List Please refer to the Note 2. Antenna Type Please refer to the Note 3. Equipemnt Category Non-ISM frequency Operating frequency 110.5-205KHZ Modulation Type ASK Power Rating: Input: 5V 1A Hardware version number N/A Software version number N/A Connecting I/O Port(s) Please refer to the Note 1. Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User’s Manual. 2. Channel List Channel Frequency (KHz) Channel Frequency (KHz) Channel Frequency (KHz) 00 170.8 3. Table for Filed Antenna Ant. Brand Model Name Antenna Type Connector NOTE 1 N/A WP003 Coil N/A Antenna Page 7 of 21 Report No.: STS2003171W01 2.2 DESCRIPTION OF THE TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 Charging+TX Mode For Conducted Emission Final Test Mode Description Mode 1 Charging+TX Mode For Radiated Em…
