Constant 10000 mAh Wireless Power Bank with LED Display Instruction Manual AST-WR068 1 x 10000 mAh wireless Power Bank 1 x USB to Micro-USB charging cable 1 x Instruction Manual 10000mAh poly-li battery Input power: 5V/2A USB 1 Output power: 5V/1A USB 2 Output power: 5V/2.1A Wireless Output: DC 5V/1A ON/OFF Button: Press once to view the remaining power capacity. Charging the power bank: Using USB to Micro-USB charging cable, insert the USB Charging cable into a computer to begin charging. When Charging, LED Indicator will illuminate BLUE, Once fully charged all LED lights will be illuminated. Charging with the power bank through cable: The power bank has a 2xUSB output ports, (USB1) has a maximum out 1A and (USB2) has a maximum out 2.1A . Connect the Micro-USB cable to your mobile phone/device using the appropriate connector. Connect the other end of the power bank. BLUE LED Indicator will illuminate when charging. Remove the USB cable from your mobile device when it is fully charged. Charging Mobile phones and other electronic devices with wireless output. Hold ON/OFF Button till the RED LED illuminates. Place wireless charging enable device on Wireless Charging Pad. LED will illuminate GREEN when charging. Hold turn OFF Wireless charging. Note: In order to charge devices, use only the accessory cable or the cable included with your own device by the manufacturer. WARNING–When using this product, basic precautions should always be followed, including the following: Read all the instructions before using the product. Charge the power bank fully before initial use. The unit’s full performance is achieved only after 2 or 3 completed charge and discharge cycles. To reduce the risk of injury, close supervision is necessary when the product is used near children. Do not expose the device to moisture. Do not use the device in excess of its output rating. Overload outputs above Do not use the device if damaged or explosion or risk of injury. Do not disassemble the device. Take it to or repair is required. Incorrect reassembly or temperatures above 212ºF may cause explosion. repair person using only identical replacement parts. This will ensure that the safety of the product is maintained. Do not overcharge Phone. Unit may get hot with excessive use. Remove Phone when it is fully charged. Never charge for more than 7 hours at a time. 1. a. b. 2. a. b. c. 3. a. * 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. • • • • • • What’s included: Features: LED Indicators: Instructions: F CC warning statement: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. SAFETY PRECAUTIONS: 1. 2. 3. 4. 5. 6. LED Display USB Output 1 Micro USB Input USB Output 2 ON/OFF Button Wireless Charging Pad Made in China 13. Attachments on the back of your phone can impede the effectiveness of the wireless charger, and lead to overheating. Please remove attachments from the phone before charging on this device. The distance between user and products should be no less than 20cm
March 25, 2020 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AQJK-AST-WR068-1 Product Name: Wireless Power Bank Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) Schematics Block diagram Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature>: Name:Teresa Zhong Title:Sale Company:NINGBO ALLSTAR O&E TECHNOLOGY CO., LTD.
March 25, 2020 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen Timeway Testing Labor atories/ Zone C, 1st Floor, Block B, Jun Xiang Da Building, Zhongshan Park Road West, Tong Le Village, Nanshan District, Shenzhen, China. (Name of Agent company n ame and add ress) to act as our agent in the prep aration of this a pplication for equipme nt certification. I certify that submitted documents prope rly describe the de vice or system for which equipme nt certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communica tions Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with NINGBO ALLSTAR O&E TECHNOLOGY CO.,LTD./ NO.19 HUIJIN ROAD,LUOTUO STREET,ZHENHAI, NINGBO, CHINA <Signature>: Name:Teresa Zhong Title:Sale Company:NINGBO ALLSTAR O&E TECHNOLOGY CO., LTD.
FCC ID: 2AQJK-AST-WR068-1 RF Exposure Evaluation 1 Measuring Standard KDB 680106 D01 RF Exposure Wireless Charging App v03 And KDB Tracking Number 671578 ; TCB Workshop, October 2018, 5.2 RF Exposure Procedures 2 Requirements According to the item 5 of KDB 680106 D01 RF Exposure Wireless Charging App v03: (1) Power transfer frequency is less than 1 MHz. Yes,0.1115-0.205MHz (2) Output power from each primary coil is less than or equal to 15 watts. Yes, Max power 5W (3) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils. Yes (4) Client device is placed directly in contact with the transmitter. Yes (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). No (6) The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. Yes Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Report No.: FCC2003058-H Page 2 of 5 Date: 2020-03-23 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES.It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES.reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. 3 Test Setup A: B: Report No.: FCC2003058-H Page 3 of 5 Date: 2020-03-23 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES.It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES.reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. 4 Test Procedure 1) The RF exposure test was performed in an echoic chamber; 2) The measurement probe was placed at test distance(15 cm from edges, 20 cm from top) Which is between the edge of the charger and the geometric center of probe, for test setup A; 3) In addition to what is described in KDB 680106 D01, please measure and provide magnetic and electrical field strength at a distance 10cm to 1cm at 1cm iteration, i.e. at a distance of 10cm, 9cm, 8cm, ....... 1cm. Which is between the edge of the charger and the edge of probe, for test setup B; 4) The highest emission level was recorded and compared with limit as soon as measurement of each points (A,B, C,D, E)were completed; 5) The EUT was measured according to the dictates of KDB680106D01v03; And KDB Tracking Number 671578 ; TCB Workshop, October 2018, 5.2 RF Exposure Procedures Remark:The EUT’ s test position A, B,C, D and E is valid for the E and H field measurements. 5 Test Instruments list Test Equipment Manufacturer Model No. SN. Cal.Date (mm-dd-yy) Cal.Due date (mm-dd-yy) EMF Meter NARDA ELT-400 N-0356 Oct 11, 2019 Oct 10, 2020 EMF probe NARDA B-Field Probe M-0812 Oct 11, 2019 Oct 10, 2020 6 Test Result Test Result for Test setup A: Note: Frequency Range 0.1115-0.205 (MHz); <5%, 50 %,> 90% load all have been tested, Only worse case Max load (>90%) is reported. E-Filed Strength at (15 cm from edges A, B, C, D, 20 cm from top E) surrounding the EUT (V/m) Charging Load Worse case Test Position A(V/m) Test Position B(V/m) Test Position C(V/m) Test Position D(V/m) Test Position E(V/m) Limits (V/m) Max load 1.46 1.35 1.32 1.21 1.30 614 H-Filed Strength at (15 cm from edges A, B, C, D, 20 cm from top E) surrounding the EUT (A/m) Charging Load Worse case Test Position A(A/m) Test Position B(A/m) Test Position C(A/m) Test Position D(A/m) Test Position E(A/m) Limits (A/m) Max load 0.48 0.52 0.37 0.33 0.34 1.63 Report No.: FCC2003058-H Page 4 of 5 Date: 2020-03-23 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES.It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES.reserves t…
