Owner's Manual Infrared Forehead Thermometer Model DET-306b ContentsIntroduction 12 Please read all instructions carefully and thoroughly before using this product. The DET-306b infrared forehead thermometer is specifically designed for safe use on the forehead. The Infrared Forehead Thermometer is a device capable of measuring people's body temperature by detecting the intensity of infrared light emitted from the forehead. It converts the measured heat into a temperature reading displayed on the LCD. The infrared forehead thermometer is intended for the intermittent measurement of human body temperature from the skin surface of forehead by people of all ages. When properly used, it will quickly assess your temperature in an accurate manner. forehead thermometer. 2. Do not touch the temperature probe with hands. 3. Use of this Forehead thermometer is not intended as a substitute for consultation with your physician. 4. some parts are small enough to be swallowed. 5. Never immerse this device in water or other liquids(not waterproof). 6. Do not modify this equipment without authorization of manufacturer. 7. Do not expose the thermometer to temperature extremes (below -25°C/-13°F or over 55°C/131°F) nor excessive humidity (>95%RH). 8. Keep the battery away from children. 1. There is no gender or age limitation for using infrared Do not allow children to take their temperatures unsupervised, 9.Remove battery from the device when not in operation for a long time. Warning: Introduction ......................................................02 Product Description LCD Display Introduction Basic Functions Forehead Thermometer Advantages Real Time Clock Setting ................................. . 07 Temperature Taking Hints Memory Mode Care And Cleaning Battery Replacement Specifications Troubleshooting Calibration Service Warranty Electromagnetic Compatibility Information .. ............................................... 03 ....................................... 04 ................................................... 05 ......................... 06 .. ...................................09 Illustration For Use ..............................................11 ........................................................16 Selecting A Temperature Scale ...............................17 ...............................................18 ............................................19 .....................................................20 ...................................................21 .............................................................23 ...............................................................24 ...............................................................25 ...............28 FCC Information .....................................................26 Document No.: JDET-0604-021 Article No.: 001 Version: Date of Issue: 2020- Z 09 Vital Organs Product Description 1. Probe 2. START Button 3. Button 4. / Button 5. Battery Cover Forehead Thermometer Advantages Infrared Forehead Thermometer measures core body temperature, which is the temperature of a body's vital organs. (See Figure 1) This thermometer is designed to measure the temperature of the skin surface over the temporal artery, a major artery of the head. The temporal artery is connected to the heart via the carotid artery, directly leading from the aorta, the main trunk of the arterial system. It offers constant blood flow. Therefore, body temperature changes are reflected sooner in the forehead than they are in other parts of the body such as oral, rectal and underarm. 3 6 Figure 1 1 2 3 5 4 Real Time Clock Forehead Mode Object Mode The object mode shows the actual, unadjusted surface temperatures, which is different from the body temperature. It can help you to monitor if the object temperature is suitable for the baby or patient, for example the baby's milk. → Please see the section to learn how to measure the object temperature. Illustration For Use The real time clock will be recorded with the memory function and help you to recognize each measurement result. → Please see the Real time clock setting section to learn how to setup the time in the first use. The thermometer has been designed for practical use. It's not meant to replace a visit to the doctor. Please also remember to compare the measurement result to your regular body temperature. → Please see the section to learn how to measure the body temperature. Illustration For Use Memory Mode There are each 10 sets memories for forehead and object measurements. Each memory also records the measurement date/time/mode icon. Please see the Selecting A Temperature Scale section to learn how to change between Celsius and Fahrenheit. Basic Functions LCD Display Introduction 4 5 / Switch°C°F AM and PM Low voltage sign Forehead mode Temperature Indicator Unit sign: °C or °F Temperature result Time and Date sign in Time mode Memory mode Object mode Beep Alarm If thermometer detects a body temperature ≥ 37.8°C100.0) under forehead mode, there will be a long beep sound followed by three short beep sound to warn the user. (°F Distance Detection If the object is too far away from the probe, the temperature will not be measured until the probe is moved within the measured range. 7 8 Set the time format ① Set the hour ② Set the minute ③ Set the year ④ Set the month . ⑤ Set the date ⑥ 9 10 When using thermometer for the first time, please set the parameters of the thermometer. With the thermometer off, press and hold BUTTON to enter into setting mode for 3 seconds. The device can display the time in either an AM/PM (12-hour) or a 24:00(24-hour) format. Press and release START BUTTON to select the format. With the preferred time format on the display, press BUTTON, the Hour figure is flashing automatically. Press and release the START BUTTON to advance one hour until the correct hour appears. After the hour is set, press BUTTON, the Minute figure is flashing automatically. Press and release…
