2AR2STAH6509Active Noise Canceling wireless headphones

Headphones 6000 Series TAH6509 User manual Register your product and get support at: www.philips.com/support 1 Important safety instructions 2 Hearing safety 2 General information 2 2 Your Active Noise Canceling wireless headphones 4 What's in the box 4 Other devices 4 Overview of your wireless headphones 5 3 Get started 6 Charge the battery 6 App download 6 Pair for the �rst time 6 Pair with another Bluetooth device 7 4 Use your headphones 8 Connect to your Bluetooth device 8 Control ANC (Active Noise Cancelation) 8 Power on/off 9 Manage your calls and music 9 Voice Assistant 9 Headphones LED indicator status 10 9 Frequently asked questions 15 Contents 5 Reset the headphones 11 6 Technical data 11 7 Notice 12 Declaration of conformity 12 Disposal of your old product and battery 12 Remove the integrated battery 12 Compliance with EMF 12 Environmental information 13 Notice of compliance 13 8 Trademarks 14 2 EN 1 Important safety instructions Hearing safety Be sure to observe the following guidelines when using your headphones. • Listen at reasonable volumes for reasonable periods of time. • Be careful not to adjust the volume continuously upwards as your hearing adapts. • Do not turn up the volume so high that you can't hear what's around you. • You should use caution or temporarily discontinue use in potentially hazardous situations. • Excessive sound pressure from headphones and headphones can cause hearing loss. • Using headphones with both ears covered while driving is not recommended and may be illegal in some areas. • For your safety, avoid distractions from music or phone calls while in traffic or other potentially dangerous environments. General information To avoid damage or malfunction: Danger  To avoid hearing damage, limit the time you use headphones at high volume and set the volume to a safe level. The louder the volume, the shorter the safe listening time is. Caution  Do not expose headphones to excessive heat.  Do not drop your headphones.  Headphones shall not be exposed to dripping or splashing. (Refer to the IP rating of speci�c product)  Do not allow your headphones to be submerged in water.  Do not charge your headphones when the connector or socket is wet.  Do not use any cleaning agents containing alcohol, ammonia, benzene, or abrasives.  Use a clean, damp cloth to clean your headphones - especially the sound conduits and the microphone holes - regularly and avoid buildup of substances such as sweat or earwax.  If any sweat or water droplets are left in the sound conduits, air holes or microphone holes, the sound level will temporarily drop or cut out entirely. This is not a malfunction. Use a soft, damp cloth to dry the headphones thoroughly. Alternatively, remove the earbud tips, turn the sound conduits downward and gently tap the headphones about �ve times on a dry cloth or similar to remove any water collected inside.  Be sure the headphones are completely dry before charging and using. Avoid using disposable alcohol pads or other substances for cleaning.  The integrated battery shall not be exposed to excessive heat such as sunshine, �re or the like.  Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.  To achieve the speci�c IP rating, the charging slot cover must be closed.  Disposal of a battery into �re or a hot oven, or mechanically crushing or cutting a battery, can result in an explosion.  Leaving a battery in an extremely high temperature surrounding environment can result in an explosion or the leakage of �ammable liquid or gas.  A battery subjected to extremely low air pressure may result in an explosion or the leakage of �ammable liquid or gas.  Replacement of a battery with an incorrect type risks severely damaging the headphones and the battery (for example, in the case of some lithium battery types).  If the headset is not used for a long time, the rechargeable battery will begin to lose its charge. To avoid this loss, please fully charge the battery at least once every three months. 3 EN Operating and storage temperatures and humidity • Store in a place where the temperature is between -20°C (-4°F) and 50°C (122 °F) with up to 90% relative humidity. • Operate in a place where the temperature is between 0°C (32°F) and 45°C (113 °F) with up to 90% relative humidity. • Battery life may be shorter in high or low temperature conditions.  To avoid risk of �re, the equipment is supplied only by external power source which output shall comply with PS1 (with output capacity less than 15W). 2 Your Active Noise Canceling wireless headphones Philips Active Noise Canceling wireless headphones Philips TAH6509 Congratulations on your purchase, and welcome to Philips! To fully bene�t from the support that Philips offers, register your product at www.philips.com/support. With these Philips headphones, you can: • Enjoy convenient wireless handsfree calls • Enjoy and control music wirelessly • Switch between calls and music • Enjoy noise cancellation USB charging cable (for charging only) Global Warranty Safety lea�et A mobile phone or device (e.g. notebook, tablet, Bluetooth adapters, MP3 players etc) which supports Bluetooth and is compatible with the headphones (see 'Technical data' on page 10). Quick start guide Other devices What's in the box 4 EN Overview of your wireless headphones ANC/Awareness mode button Multi-Function Button (MFB) USB-C charging slot LED indicator Power button Audio jack 1 2 3 4 5 6 1 2 3 4 5 6 EN 5 Connect the supplied USB charging cable to: • The USB-C charging slot on the headphones and; • The charger/USB port of a computer.  Normally, a full charge takes two hours. 6 EN LED turns white during charging and turns off when the headphones in fully charged. App download Scan the QR code/press 'Download' button or search 'Philips Headphones' in the Apple App Store or Google Play to download the app. The Philips Headphones App puts you in charge of the music you are list…

Text truncated - open the document above for the full version.

Revision: 1Form: RFT-AMER-TCB-OP-19o Date: 3/8/2024 [MMD Hong Kong Holding Limited] Attention: Application Examiner Re: Certification designating a U.S. agent for service of process pursuant to section 2.911(d)(7) of the FCC rules To whom it may concern, This letter is to confirm both [TPV-USA Corp ] Agentand [MMD Hong Kong Holding Limited] Aacknowledge consent to obligations of each party pursuant to 47 CFR part §2.911(d)(7) of the FCC rules in regard to the agent for service of process. I [Tomas Guan] HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant. I further acknowledge the requirement to maintain an agent extends for no less than one year after the termination of all marketing and importation or the conclusion of and commission-related proceeding involving the equipment and agree to immediately notify the FCC if there is any change in the status identified above. Applicant : MMD Hong Kong Holding Limited Com p any Name : Tomas Guan C ontact Name Address Telephone No Em ai l FRN Kwun Tong, Kowloon,Hong Kong :2AR2STAH6509 : 86-755-36358341 : [email protected] : 0028068138 Signature: ____________________________________ 2024-3-8 Date: ___________________________ I [Gcoff Bostwick] HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Agent. I consent to the obligation to accept service of process on behalf of the applicant in regard to the FCC ID designated above. Agent : TPV-USA CorpCompany Name : Gcoff BostwickContact Name : 6525 Carnegie Blvd., Suite #200 Charlotte, NC 28211Address : 980-890-7523Telephone No : [email protected] Signature: ____________________________________ 2024-3-8 Date : __________________________ : 0033543315FRN FCC ID : Units 1208-11,12th Floor,C-Bons International Center, 108 Wai Yip Street,

MMD Hong Kong Holding Limited CERTIFICATIONS CONCERNING “COVERED” EQUIPMENT Date:2024-02-29 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 FCC ID: 2AR2STAH6509 To Whom It May Concern: As required by section 2.911(d)(5)(i), [MMD Hong Kong Holding Limited] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. As required by section 2.911(d)(5)(ii), [MMD Hong Kong Holding Limited] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Thank you for your attention to this matter. Sincerely yours, Signature Printed Name: Tomas Guan Company: MMD Hong Kong Holding Limited Job Title: Safety & Approbation Manager Email: [email protected] Telephone: 86-755-36358341

RF_160_05 Declaration of Authorisation Date of issue 02-01-2023 (MMD Hong Kong Holding Limited) Declaration of Authorization We Name: MMD Hong Kong Holding Limited Address: Units 1208-11, 12th Floor, C-Bons International, Center, 108 Wai Yip Street, Kwun Tong, Kowloon City: Hong Kong Country: China Declare that: Name Representative of agent: Ms. Rose Liu (1) Agent Company name: BTL Inc. Address: No.3 Jinshagang 1st Road, Shixia, Dalang Town City: Dong Guan Country China is authorized to apply for Certification of the following product(s): Product description: Active Noise Canceling wireless headphones Type designation: TAH6509, TAH6509xx/yy（xx=AA-ZZ or blank denoted different color; yy=00-99 denoted different country destination） Trademark: PHILIPS, Validity/ expiry date:2025-02-28 on our behalf. Date: 2023-02-28 City: Hong Kong Name: Tomas Guan (2) Function: Safety & Approbation Manager Signature: . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 02-01-2022 RF_501, Issue 10 Company Name: MMD Hong Kong Holding Limited Address: Units 1208-11, 12th Floor, C-Bons International, Center, 108 Wai Yip Street, Kwun Tong, Kowloon City: Hong Kong Country: China To: Kiwa Netherlands B.V., Dept. FCC TCB Wilmersdorf 50 7327 AC Apeldoorn The Netherlands Subject: Request for confidentiality FCC ID: 2AR2STAH6509 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Date: 2024-02-28 Name and signature of applicant: Tomas Guan Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! The planned date should state in the RF731 application form. 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Kiwa NL B.V. at least 7 days before date of actual marketing or before expiration of the STC period

Model Declaration Letter We, the undersigning company Company Name: MMD Hong Kong Holding Limited Address: Units 1208-11, 12th Floor, C-Bons International, Center, 108 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong Hereby confirm that the following products: Product description: Active Noise Canceling wireless headphones Type designation: TAH6509, TAH6509xx/yy（xx=AA-ZZ or blank denoted different color; yy=00-99 denoted different country destination） Trademark: PHILIPS, That All versions of the Model TAH6509 and TAH6509xx/yy（xx=AA-ZZ or blank denoted different color; yy=00-99 denoted different country destination）; are electrically equal except the following difference: Only differ in model name. Date: 2024-02-28 Name: Tomas Guan Telephone: 86-755-36358341 E-mail: [email protected] Signature:

Project No.: 2312C036A Page 1 of 11 ATTACHMENT PHOTOGRAPHS OF EUT Project No.: 2312C036A Page 2 of 11 Project No.: 2312C036A Page 3 of 11 Project No.: 2312C036A Page 4 of 11 Project No.: 2312C036A Page 5 of 11

7.644mm 7.513mm 6mm 5.367mm 5.3mm 7.5mm M o d e l / 型 号 ： T A H 6 5 0 9 I C : 2 4 5 8 9 - T A H 6 5 0 9 M a d e i n C h i n a F C C I D : 2 A R 2 S T A H 6 5 0 9 D C I n p u t / 输 入 ： 5 V 1 . 0 A T P V i s i o n E u r o p e B . V . P r i n s B e r n h a r d p l e i n 2 0 0 , 1 0 9 7 J B A m s t e r d a m T h e N e t h e r l a n d s 冠 捷 视 听 科 技 （ 深 圳 ） 有 限 公 司 Refer no.:TAH6509BK/00 SN.:LAPB2316100001

Project No.: 2312C036A Page 6 of 11 Project No.: 2312C036A Page 7 of 11 Antenna Project No.: 2312C036A Page 8 of 11 Project No.: 2312C036A Page 9 of 11 Project No.: 2312C036A Page 10 of 11 Project No.: 2312C036A Page 11 of 11

Report No.: BTL-FCCP-3-2312C036A Page 1 of 6 FCC RF EXPOSURE REPORT FCC ID: 2AR2STAH6509 Project No. : 2312C036A Equipment : Active Noise Canceling wireless headphones Brand Name : PHILIPS or Test Model : TAH6509 Series Model : TAH6509xx/yy (xx=AA-ZZ or blank denoted different color; yy=00-99 denoted different country destination) Applicant : MMD Hong Kong Holding Limited Address : Units 1208-11, 12th Floor, C-Bons International Center, 108 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong Manufacturer : MMD Hong Kong Holding Limited Address : Units 1208-11, 12th Floor, C-Bons International Center, 108 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong Factory : Dongguan Laccess Electronic Technology LTD. Address : NO.20 Xiang Yang Road, Tianxin,Qiaotou Town, DongGuan City,GuangDong Province,China Date of Receipt : Jan. 29, 2024 Date of Test : Jan. 30, 2024 ~ Feb. 23, 2024 Issued Date : Mar. 19, 2024 Report Version : R01 Test Sample : Engineering Sample No.: DG2024012997 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & KDB 447498 D04 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Evan Yang Approved by : Welly Zhou Room 108, Building 2, No. 1, Yile Road, Songshan Lake Zone, Dongguan City, Guangdong 523000 China. Tel: +86-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-3-2312C036A Page 2 of 6 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note BTL-FCCP-3-2312C036A R00 Original Report. Mar. 07, 2024 Invalid BTL-FCCP-3-2312C036A R01 Updated the Distances of Section 3. Mar. 19, 2024 Valid Report No.: BTL-FCCP-3-2312C036A Page 3 of 6 1. GENERAL CONCULUSION According to FCC §§1.1307 and KDB 447498 D04, the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW). 1) Option A. 1-mW Test Exemption Per § 1.1307(b)(3)(i)(A), a single RF source is exempt RF device (from the requirement to show data demonstrating compliance to RF exposure limits, as previously mentioned) if the available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption applies to all operating configurations and exposure conditions, for the frequency range 100 kHz to 100 GHz, regardless of fixed, mobile, or portable device exposure conditions. This is a standalone exemption, and it cannot be applied in conjunction with any other test exemption. 2) Option B. SAR-Based Exemption A more comprehensive exemption, considering a variable power threshold that depends on both the separation distance and power, is provided in § 1.1307(b)(3)(i)(B). This exemption is applicable to the frequency range between 300 MHz and 6 GHz, with test separation distances between 0.5 cm and 40 cm, and for all RF sources in fixed, mobile, and portable device exposure conditions. Accordingly, a RF source is considered an RF exempt device if its available maximum time-averaged (matched conducted) power or its effective radiated power (ERP), whichever is greater, are below a specified threshold. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Report No.: BTL-FCCP-3-2312C036A Page 4 of 6 Table B2-Example Power Thresholds (mW) Frequency (MHz) Distance(mm) mW 5 10 15 20 25 30 35 40 45 50 300 39 65 88 110 129 148 166 184 201 217 450 22 44 67 89 112 135 158 180 203 226 835 9 25 44 66 90 116 145 175 207 240 1900 3 12 26 44 66 92 122 157 195 236 2450 3 10 22 38 59 83 111 143 179 219 3600 2 8 18 32 49 71 96 125 158 195 5800 1 6 14 25 40 58 80 106 136 169 3) Option C MPE-Based Exemption An alternative to the SAR-based exemption is provided in § 1.1307(b)(3)(i)(C), for a much wider frequency range, from 300 kHz to 100 GHz, applicable for separation distances greater or equal to λ/2π, where λ is the free-space operating wavelength in meters. The MPE-based test exemption condition is in terms of ERP, defined as the product of the maximum antenna gain and the delivered maximum time-averaged power. For this case, a RF source is an RF exempt device if its ERP (watts) is no more than a frequency-dependent value, as detailed tabular form in Appendix B. These limits have been derived based on the basic specifications on Maximum Permissible Exposure (MPE) considered for the FCC rules in § 1.1310(e)(1). Report No.: BTL-FCCP-3-2312C036A Page 5 of 6 In the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. Where: a = number of fixed, mobile, or portable RF sources claiming exemption using paragraph (b)(3)(i)(B) of this section for Pth, including existing exempt transmitters and those being added. b = number of fixed, mobile, or portable RF sources claiming exemption using paragraph (b)(3)(i)(C) of this section for Threshold ERP, including existing exempt transmitters and those being added. c = number of existing fixed, mobile, or portable RF sources with known evaluation for the specified minimum distance including existing evaluated transmitters. P i = the available maximum time-averaged power or the ERP, whichever is greater, for fixed, mobile, or portable RF source i at a distance between 0.5 cm and 40 cm (inclusive). P th,i = the exemption threshold power (P th ) according to paragraph (b)(3)(i)(B) of this section for fixed, mobile, or portable RF source i. ERP j = the ERP of fixed, mobile, or portable RF source j. ERP th,j = exemption threshold ERP for fixed, mobile, or portable RF source j, at a distance of at least λ/2π according to the applicable formula of paragraph (b)(3)(i)(C) of this section. Evaluated k = the maximum r…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-1-2312C036A Page 1 of 81 FCC Radio Test Report FCC ID: 2AR2STAH6509 This report concerns: Original Grant Project No. : 2312C036A Equipment : Active Noise Canceling wireless headphones Brand Name : PHILIPS or Test Model : TAH6509 Series Model : TAH6509xx/yy (xx=AA-ZZ or blank denoted different color; yy=00-99 denoted different country destination) Applicant : MMD Hong Kong Holding Limited Address : Units 1208-11, 12th Floor, C-Bons International Center, 108 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong Manufacturer : MMD Hong Kong Holding Limited Address : Units 1208-11, 12th Floor, C-Bons International Center, 108 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong Factory : Dongguan Laccess Electronic Technology LTD. Address : NO.20 Xiang Yang Road, Tianxin,Qiaotou Town, DongGuan City,GuangDong Province,China Date of Receipt : Jan. 29, 2024 Date of Test : Jan. 30, 2024 ~ Feb. 26, 2024 Issued Date : Mar. 19, 2024 Report Version : R01 Test Sample : Engineering Sample No.: DG2024012996 for radiated and AC Power Line Conducted Emissions, DG2024012997 for conducted. Standard(s) : FCC CFR Title 47, Part 15, Subpart C The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Evan Yang Approved by : Welly Zhou Room 108, Building 2, No. 1, Yile Road, Songshan Lake Zone, Dongguan City, Guangdong 523000 China. Te l : + 8 6-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-1-2312C036A Page 2 of 81 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025: 2017 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-1-2312C036A Page 3 of 81 Table of Contents Page REPORT ISSUED HISTORY 6 1 . APPLICABLE STANDARDS 7 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 2.3 TEST ENVIRONMENT CONDITIONS 9 3 . GENERAL INFORMATION 10 3.1 GENERAL DESCRIPTION OF EUT 10 3.2 DESCRIPTION OF TEST MODES 12 3.3 PARAMETERS OF TEST SOFTWARE 13 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 14 3.5 SUPPORT UNITS 15 3.6 CUSTOMER INFORMATION DESCRIPTION 15 4 . AC POWER LINE CONDUCTED EMISSIONS 16 4.1 LIMIT 16 4.2 TEST PROCEDURE 16 4.3 DEVIATION FROM TEST STANDARD 16 4.4 TEST SETUP 17 4.5 EUT OPERATING CONDITIONS 17 4.6 TEST RESULTS 17 5 . RADIATED EMISSIONS 18 5.1 LIMIT 18 5.2 TEST PROCEDURE 19 5.3 DEVIATION FROM TEST STANDARD 20 5.4 TEST SETUP 20 5.5 EUT OPERATING CONDITIONS 22 5.6 TEST RESULTS - 9 KHZ TO 30 MHZ 22 5.7 TEST RESULTS - 30 MHZ TO 1000 MHZ 22 5.8 TEST RESULTS - ABOVE 1000 MHZ 22 6 . NUMBER OF HOPPING FREQUENCY 23 6.1 LIMIT 23 6.2 TEST PROCEDURE 23 6.3 DEVIATION FROM STANDARD 23 Report No.: BTL-FCCP-1-2312C036A Page 4 of 81 Table of Contents Page 6.4 TEST SETUP 23 6.5 EUT OPERATION CONDITIONS 23 6.6 TEST RESULTS 23 7 . AVERAGE TIME OF OCCUPANCY 24 7.1 LIMIT 24 7.2 TEST PROCEDURE 24 7.3 DEVIATION FROM STANDARD 24 7.4 TEST SETUP 24 7.5 EUT OPERATION CONDITIONS 24 7.6 TEST RESULTS 24 8 . HOPPING CHANNEL SEPARATION 25 8.1 LIMIT 25 8.2 TEST PROCEDURE 25 8.3 DEVIATION FROM STANDARD 25 8.4 TEST SETUP 25 8.5 EUT OPERATION CONDITIONS 25 8.6 TEST RESULTS 25 9 . BANDWIDTH 26 9.1 LIMIT 26 9.2 TEST PROCEDURE 26 9.3 DEVIATION FROM STANDARD 26 9.4 TEST SETUP 26 9.5 EUT OPERATION CONDITIONS 26 9.6 TEST RESULTS 26 10 . MAXIMUM OUTPUT POWER 27 10.1 LIMIT 27 10.2 TEST PROCEDURE 27 10.3 DEVIATION FROM STANDARD 27 10.4 TEST SETUP 27 10.5 EUT OPERATION CONDITIONS 27 10.6 TEST RESULTS 27 11 . CONDUCTED SPURIOUS EMISSION 28 11.1 LIMIT 28 11.2 TEST PROCEDURE 28 Report No.: BTL-FCCP-1-2312C036A Page 5 of 81 Table of Contents Page 11.3 DEVIATION FROM STANDARD 28 11.4 TEST SETUP 28 11.5 EUT OPERATION CONDITIONS 28 11.6 TEST RESULTS 28 12 . MEASUREMENT INSTRUMENTS LIST 29 13 . EUT TEST PHOTO 31 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 37 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MHZ 40 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 45 APPENDIX D - RADIATED EMISSION - ABOVE 1000 MHZ 48 APPENDIX E - NUMBER OF HOPPING FREQUENCY 61 APPENDIX F - AVERAGE TIME OF OCCUPANCY 63 APPENDIX G - HOPPING CHANNEL SEPARATION 68 APPENDIX H - BANDWIDTH 70 APPENDIX I - MAXIMUM…

Text truncated - open the document above for the full version.

2. F eatu r es S MD , hi g h r e li ab ili ty, u l t r a Im pact, O mni- d ir ect i o n a l... 3. Part Number Information F 245 (C) (D) M (E) 02 (F) (A)Produc t Ty p eChi p An t enna (B) Size Code 5 .0x2.0mm (±0 .2mm ) (C) MaterialHigh K material (D) Frequency2.4 ~ 2.5GHz (E) Feeding modePIFA & S ingl e F eed ing (F) Antenna typeType=02 Shenzhen Hetuo Technology Co.,Ltd. HT5221 (A) (B) 1/6 Shenzhen Hetuo Technology Co.,Ltd. 2.4GHz 5 221 Chip Antenna: HT-5221-F245-M02 1. Applications WLAN , 80 2.11 b/g, Bl uetoot h , WLAN , etc ... 4. 00 2.3 000 4.Product dimensions 5. Electrical Specification Specification Part Number HT 5221 F245 M02 Central Frequency 2450 MHz Bandwidth120 (Min.) MHz Return Loss -10 (Max) dB Peak Gain 3.5 9 dBi Impedance 50Ohm Operating Temperature - 40～+85 °C Maximum Power4W Resistance to Soldering Heats 10 ( @ 260°C) sec. PolarizationLinear Azimuth Beamwidth Omni-directional TerminationSn (Leadless) 6. RecommendedPCB FootPrint (Unit : mm) W Figure SymbolDimension (mm) L W A L 5.00 ± 0.20 W 2.00 ± 0.30 T 1.0 ± 0.30 A 0.50± 0.20 4.0 2/6 33 0 30 -1 0 -2 0 30 0 60 -3 0 -4 0 24 012 0 21 015 0 -X 18 0 0 0 [dBd] 33 0 30 -1 0 -2 0 30 0 60 -3 0 -4 0 +Y 24 012 0 21 015 0 -X 18 0 7. Measurement Results Return Loss 7.2 Radiation Pattern - X -X -Y +Z +X - +X - ： ： -Y 27 0 90 - Y 27 0 90 +Y +Z +Y 0 0 [dBd] 3/6 20-40s 260 °C 217°C 150-200°C Pre-heating 60-150s 60-180s Time (s) 8.Reliability and Test Condictions Test item Test condition / Test method Specification Solderability JIS C 0050-4.6 JESD22-B102D *Solder bath temperature：235  5C *Immersion time：2  0.5 sec Solder：Sn3Ag0.5Cu for lead-free At least 95% of a surface of each terminal electrode must be covered by fresh solder. Leaching (Resistance to dissolution of metallization) IEC 60068-2-58 *Solder bath temperature：260  5C *Leaching immersion time：30  0.5 sec Solder : SN63A Loss of metallization on the edges of each electrode shall not exceed 25%. Bending test JIS C 0051- 7.4.1 The middle part of substrate shall be pressurized by means of the pressurizing rod at a rate of about 1 mm/s per second until the deflection becomes 1mm/s and then pressure shall be maintained for 51 sec. Measurement to be made after keeping at room temperature for 242 hours No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics under the operational temperature range within -40 ~ 85°C. Resistance to soldering heat JIS C 0050-5.4 *Preheating temperature：120~150 °C , 1 minute. *Solder temperature：2705C *Immersion time：101 sec Solder： Sn3Ag0.5Cu for lead-free Measurement to be made after keeping at room temperature for 242 hrs No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics under the operational temperature range within -40 ~ 85°C. Loss of metallization on the edges of each electrode shall not exceed 25%. 9.Soldering and Mounting Temperature ( ° C) 4/6 5/6 10.Matters needing attention in antenna application 11. S torage and Transportation Information To maintain the solderability of terminal electrodes: 1. Temperature and humidity conditions: -10~ 40°C and 30~70% RH. 2. Recommended products should be used within 6 months from the time of delivery. 3. The packaging material should be kept where no chlorine or sulfur exists in the air. Trans p ortation Conditions 1.Products should be handled with care to avoid damage or contamination from perspiration and skin oils. 2. The use of tweezers or vacuum pick up is strongly recommended for individual components. 3. Bulk handling should ensure that abrasion and mechanical shock are minimized. If space allows, it is best not to choose too small antenna size. It is best to have a large clearance area between the antenna and nearby objects; otherwise matching will become difficult and the radiation patterns will be severely distorted. The antenna should not appear below the line layout, ground layer. Antennas should not be placed too close to metal objects, such as batteries, chips, etc. , should not overlap with the battery and other metal objects. Pay attention to the internal cable (such as the battery power cord) better not too close to the antenna. A monopole antenna needs a reasonable ground surface to achieve the best results. Antenna matching in the final product solution can reduce the adjustment cycle, while in the light plate often needs repeated adjustment. If not matched, the same antenna placed on a completely different layout board may not work properly. Do not use a metal case or plastic case with metal around …

Text truncated - open the document above for the full version.
