2AR2STAS1505Wireless Speaker

User manual TAS1505 Register your product and get support at www.philips.com/support EN1 Contents 1 Important 2 Safety 2 2 Your wireless speaker 3 Introduction 3 What's in the box 3 Overview of the speaker 3 3 Get started 4 Charge the built-in battery 4 4 4 Play from Bluetooth devices 5 Play from Bluetooth devices 5 Control playback 5 5 Product information 6 6 Troubleshooting 7 General 7 Bluetooth 7 7 Notice 8 Compliance 8 Care of the environment 8 FCC Statement 8 Trademark notice 9 2EN 1 Important Safety Important safety instructions •Make sure that the power supply voltage CC corresponds to the voltage on the back or the underside of the unit. •The speaker shall not be exposed to dripping or splashing. •Do not place any source of danger on the speaker (e.g. liquid filled objects, lit candles). •Make sure that there is enough free space around the speaker for ventilation. •Please use the speaker safely in an environment with temperature between •Only use attachments and accessories specified by the manufacturer. Battery safety precautions •Danger of explosion if a battery is incorrectly replaced. Replace only with the same or equivalent type. •A battery (battery pack or battery installed) shall not be exposed to excessive heat such as sunshine, fire or the like. •A battery in extreme high or low temperatures during use, storage or transportation, and low air pressure at high altitude can pose safety hazards. •Do not replace a battery with an incorrect type that can defeat a safeguard (for example, some lithium battery types). •Disposing a battery into fire or a hot oven, mechanically crushing or cutting a battery can result in an explosion. •Leaving a battery in an extremely high temperature surrounding, or an extremely low air pressure environment may result in an explosion or leakage of flammable liquid or gas. Warning •Never remove the casing of this speaker. •Never lubricate any part of this speaker. •Place this speaker on a flat, hard and stable surface. •Never place this speaker on other electrical equipment. •Only use this speaker indoors. Keep this speaker away from water, moisture and liquid-filled objects. •Keep this speaker away from direct sunlight, naked flames or heat. •Risk of explosion if a battery is replaced by an incorrect type. 3EN 2Your portable speaker Congratulations on your purchase, and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome. What's in the box Check and identify the contents of your package: Overview of the speaker Indicate battery or Bluetooth connection status. Speaker USB cable Quick start guide Safety sheet Worldwide warranty Lanyard 1 2 3 LED indicator DC IN • •Charge the built-in battery. Turn the speaker on or o. 4EN 3 Get started Always follow the instructions in this chapter in sequence. Charge the built-in battery Turn on/off To turn the speaker on, press and hold " " for two seconds. You will hear the prompt sound and Blue LED indicator blinks. Auto off in 15 minutes if no Bluetooth connection. 5V 0.5 A To turn the speaker off, press and hold " " for two seconds. You will hear the prompt sound and Blue LED indicator turn off. Charge the built-in battery The speaker is powered by a built-in rechargeable battery. Connect the USB-C socket on the speaker to an outlet (5V 0.5A) by using the provided USB cable. When the speaker is being charged, Power on LED is solid Red. When the speaker is fully charged, LED is solid Blue. When the speaker is being charged, Power o„ LED is solid Red. When the speaker is fully charged, LED is o„. Note · Before use, fully charge the built-in battery. · The USB Type C socket is for charging only. · It takes you approximately two hours to fully charge the battery. · Rechargeable battery has a limited number of charge cycles. Battery life and number of charge cycles vary by use and settings. 5EN 4 Play from Bluetooth devices With this speaker,you can listen to audio from Bluetooth-enabled devices. Note The speaker can memorize a maximum of eight paired devices. The ninth paired device will replace the first one. Any obstacle between this speaker and a Bluetooth device can reduce the operational range. Keep away from any other electronic device that may cause interference. The operational range between this speaker and a Bluetooth device is approximately 20 meters (66 feet). Connect a device 1 »The LED indicator blinks blue. 2 On your Bluetooth device, enable Bluetooth and search for Bluetooth devices that can be paired. 3 Select [Philips S1505] displayed on your device for pairing and connection. If necessary, input “0000” as the pairing password. »After successful pairing and connection, you'll hear the prompt sound, and the LED indicator turns solid blue. If you cannot find [Philips S1505] on your device, hold down the Power button for 2 seconds to power off before rebooting, and long press it for 2 seconds to enter into pairing mode. 4 Play audio on your Bluetooth device to start streaming music. Tip · You can use your Bluetooth device to control play. LED indicator (blue) IndicatorBluetooth connection status Fast blinking (2Hz)Pairing Slow blinking (1Hz)Connecting Solid blueConnected Disconnect a device Disable Bluetooth on your device; or Move the device beyond the communication range. »The speaker beeps twice, and the LED indicator blinks blue. Note Before connecting another Bluetooth device, disconnect the current device first. Reconnect a device When you turn on the speaker, it will reconnect the last connected device automatically; If not, select [Philips S1505] on your Bluetooth device to start connection. •To clear the pairing information, press and hold for 5 seconds until you hear the prompt sound, and the LED indicator blinks blue. Press for 2 seconds to turn the speaker on. 2.5W RMS 6EN 0.14 150Hz-18kHz 1.5" 80 64 x 64 x 78mm 3.7 V,480 mAh V5.0 A2DP V1.3, AVRCP V1.6 Bluetooth Profile 20 Operation Ambient IP protection class 0 ~…

Text truncated - open the document above for the full version.

8 hours playtime 8 heures d’autonomie 8 horas de reproducción Strap strap Cordón de transporte IPX7 water resistant IPX7 résistant à l’eau Resistencia al agua IPX7 Waterproof Speaker Enceinte étanche Resistente al agua Altavoz inalámbrico For an optimal experience register your product at: www.philips.com/welcome MMD Hong Kong Holding Limited, Units 1006-1007, 10th Floor, C-Bons International Center, 108 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong. | Authorised Representative: UKCA Experts Ltd., Dept 302, 43 Owston Road, Carcroft, Doncaster, DN6 8DA, United Kingdom. | TP Vision Europe B.V., Prins Bernhardplein 200, 1097 JB Amsterdam, The Netherlands. | TP Vision Singapore Pte Ltd., 31 Ubi Road, Aztech Building #04-01, Singapore (408694). | FABRICA AUSTRAL DE PRODUCTOS ELECTRICOS S.A., Esmeralda 910 - 1°piso, (C1007ABL) - C.A.B.A. – Argentina. | TPV USA Corp., 6525 Morrison Blvd #200 Charlotte, NC – 28211, USA. | TOP VICTORY ELECTRONICS DE MEXICO, S.A. DE C.V. RFC: TVE060508JFA Laguna de términos 221, 602 Piso 6 Torre A Colonia Granada, C.P. 11520 Miguel Hidalgo, Ciudad de México, México. Импортер на территорию России и Евразийского экономического союза принимает претензии потребителей в случаях, предусмотренных Законом РФ «О защите прав потребителей» 07.02.1992 N 2300-1», в отношении товара, приобретенного на территории Российской Федерации. Юридическое лицо, принимающее претензии в отношении товара, приобретенного на территории Республики Беларусь ООО «ЦТИ», Минск, 220004, ул.Короля, 26, тел: +375 17 3425678, +375 17 3435678. Изготовитель: «MMД ГОНКОНГ ХОЛДИНГ ЛИМИТЕД» помещения1006, 10 этаж, Международный центр С-Бонс, 108 Вай Ип Стрит,Куньтхон, Коулун, Гонконг. Филиал изготовителя: «GANZHOUDEHUIDA TECHNOLOGY CO., LTD.» Dehuida Science and Technology Park, Huoyanshan Road, Anyuan District, Ganzhou City, Jiangxi Province. P.R China. Өндіруші: «MMД ГОНКОНГ ХОЛДИНГ ЛИМИТЕД» помещения 1006,10 этаж, Международный центр С-Бонс, 108 Вай Ип Стрит, Куньтхон,Коулун, Гонконг. Өндірушінің филиалы: «GANZHOU DEHUIDAECHNOLOGY CO., LTD.» Dehuida Science and Technology Park,Huoyanshan Road, Anyuan District, Ganzhou City, Jiangxi Province. P.R China. | Импортер на территорию России и Евразийского экономического союза: ООО «Ти Пи Ви Си-Ай-Эс», Российская Федерация, 196626, г. Санкт-Петербург, пос. Шушары, Московское шоссе, д.177А. | Ресей жəне Еуразия экономикалық одақтың территориясында импортшысы: «Ти Пи Ви Си-Ай-Эс» ЖШҚ Ресей Федерациясы, 196626, г. Санкт-Петербург қ. Шушары ауылы, Мəскеулік ш., 177, лит А. Дата изготовления указана на стикере в формате ММГГ,где ММ - номер месяца производства, ГГ- последние две цифры года производства.| Дайындалған уақыты ААЖЖ,осында АА - шығарылған айдың нөмірімен, ЖЖ - шығарылған мерзімінің жылдың соңғы екі цифры форматында жабыстырмада көрсетілген.| Условия хранения: стандартные при нормальных значениях климатических факторов внешней среды.| Сақтау шарттары: қоршаған ортаның климаттық факторларының қалыпты мөлшерлерінде стандартты. Bluetooth 5.0 | Частотный диапазон Bluetooth передатчика | Жиiлiк диапазоны Bluetooth таратқыш: 2,402 – 2,480 ГГц | Радиус действия/Радиустың қозғалысы: 20м | Gross weight / Масса брутто / Брутто салмағы : 0.22кг | Net weight / Масса нетто / Таза салмақ : 0.18 кг | Made in china / Сделано в Китаe / Қытайда жасап шығарылған Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license. This product has been manufactured by and is sold under the responsibility of MMD Hong Kong Holding Limited or one of its aliates, and MMD Hong Kong Holding Limited is the warrantor in relation to this product. ÉLÉMENTSD’EMBALLAGE RAMATEL C-25174 Raccol ta C ar ta 91 mm 149 mm 10 mm

Authority to Act as Agent [August 1, 2021] Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement (MMD Hong Kong Holding Limited) To Whom It May Concern: We, (MMD Hong Kong Holding Limited), hereby authorized Shenzhen UnionTrust Quality and Technology Co., Ltd. to act as our Agent for the purpose of preparing application all applicable parts of the FCC rules and regulations. We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: 36 months By: __________________________ Tomas Guan (Signature 1 ) (Print name) Title: Manager On behalf of: (MMD Hong Kong Holding Limited) Telephone: 86-755-36358341 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

1(1) [MMD Hong Kong Holding Limited] [April 6, 2022] Attention: Application Examiner RE: Request for Confidentiality Applicant: [MMD Hong Kong Holding Limited] FCC ID: [2AR2STAS1505] To Whom It May Concern: Permanent Confidentiality [Complete this section if permanent confidentiality is requested] Request is hereby submitted by [MMD Hong Kong Holding Limited] to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential:  Schematics  Detailed Block Diagrams  Detailed Operational/Functional Description Rationale for request for confidentiality: [MMD Hong Kong Holding Limited] has invested considerable time and materials in research and development to produce the referenced product. [Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us.] [Short term confidentiality: Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development.] If you have questions or need further information, please contact the undersigned. Sincerely, [Signature] [Tomas Guan] [ Manager] [MMD Hong Kong Holding Limited]

Page 1 of 3 FCC ID: 2AR2STAS1505 IC: 24589-TAS1505 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: Unit D/E of 9/F and 16/F, Block A, Building 6, Baoneng science and technology park, Longhua district, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com APPENDIX 2 PHOTOS OF EUT CONSTRUCTIONAL DETAILS EUT EXTERNAL PHOTOS EUT Photo EUT Photo Page 2 of 3 FCC ID: 2AR2STAS1505 IC: 24589-TAS1505 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: Unit D/E of 9/F and 16/F, Block A, Building 6, Baoneng science and technology park, Longhua district, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo Page 3 of 3 FCC ID: 2AR2STAS1505 IC: 24589-TAS1505 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: Unit D/E of 9/F and 16/F, Block A, Building 6, Baoneng science and technology park, Longhua district, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo

2021.06.01 0.2V 2020.06.08 0.1V 2021.10.28 0.3V 2021.11.12 0.4V 2022.03.22 0.5V 73522/SDPPI/2021 4619 73522/SDPPI/2021 4619

Page 1 of 3 FCC ID: 2AR2STAS1505 IC: 24589-TAS1505 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: Unit D/E of 9/F and 16/F, Block A, Building 6, Baoneng science and technology park, Longhua district, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com APPENDIX 2 PHOTOS OF EUT CONSTRUCTIONAL DETAILS EUT INTERNAL PHOTOS EUT Photo EUT Photo Page 2 of 3 FCC ID: 2AR2STAS1505 IC: 24589-TAS1505 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: Unit D/E of 9/F and 16/F, Block A, Building 6, Baoneng science and technology park, Longhua district, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo BT Ant. Page 3 of 3 FCC ID: 2AR2STAS1505 IC: 24589-TAS1505 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: Unit D/E of 9/F and 16/F, Block A, Building 6, Baoneng science and technology park, Longhua district, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo

Page 1 of 9 Report No.: 220324013RFC-2 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: Unit D/E of 9/F and 16/F, Block A, Building 6, Baoneng science and technology park, Longhua district, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-RSS102-V1.1 SAR TEST EXCLUSION EVALUATION REPORT Product Name: Wireless Speaker Trade Mark: or PHILIPS Model No./HVIN: TAS1505 Add. Model No.: TAS1505/37, TAS1505/00, S1505, S1505/00, S1505x/yy, TAS1505x/yy (“x” can be A to Z or nil; “yy” can be 00-99 or nil for country code) Report Number: 220324013RFC-2 Test Standards: FCC 47 CFR Part 2.1093 RSS-102 Issue 5 FCC ID: 2AR2STAS1505 IC: 24589-TAS1505 Test Result: PASS Date of Issue: April 6, 2022 Prepared for: MMD Hong Kong Holding Limited Unit 1006, 10th Floor, C-Bons International Center, 108 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong Prepared by: Shenzhen UnionTrust Quality and Technology Co., Ltd. Unit D/E of 9/F and 16/F, Block A, Building 6, Baoneng science and technology park, Longhua district, Shenzhen, China TEL: +86-755-2823 0888 FAX: +86-755-2823 0886 Prepared by: Reviewed by: Kieron Luo Eric Yu Project Engineer Project Supervisor Approved by: Date: April 6, 2022 Kevin Liang Assistant Manager Page 2 of 9 Report No.: 220324013RFC-2 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: Unit D/E of 9/F and 16/F, Block A, Building 6, Baoneng science and technology park, Longhua district, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-RSS102-V1.1 Version Version No. Date Description V1.0 April 6, 2022 Original Page 3 of 9 Report No.: 220324013RFC-2 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: Unit D/E of 9/F and 16/F, Block A, Building 6, Baoneng science and technology park, Longhua district, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-RSS102-V1.1 CONTENTS 1. GENERAL INFORMATION ....................................................................................................................................... 4 1.1 CLIENT INFORMATION ........................................................................................................................................ 4 1.2 EUT INFORMATION ............................................................................................................................................ 4 1.3 PRODUCT SPECIFICATION SUBJECTIVE TO THIS STANDARD ................................................................................. 4 1.4 OTHER INFORMATION ......................................................................................................................................... 5 1.5 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................................................................... 5 1.6 DEVIATION FROM STANDARDS ............................................................................................................................ 5 1.7 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................................. 5 1.8 OTHER INFORMATION REQUESTED BY THE CUSTOMER ........................................................................................ 5 2. EQUIPMENT LIST .................................................................................................................................................... 5 3. SAR TEST EXCLUSION EVALUATION ................................................................................................................... 6 3.1 REFERENCE DOCUMENTS FOR EVALUATION ........................................................................................................ 6 3.2 EXEMPTION LIMITS FOR ROUTINE EVALUATION – SAR EVALUATION .................................................................... 6 3.2.1 SAR TEST EXCLUSION THRESHOLD ........................................................................................................ 6 3.2.2 TEST PROCEDURE ................................................................................................................................. 8 3.3 MPE CALCULATION RESULTS ............................................................................................................................ 8 3.3.1 FOR BT ................................................................................................................................................. 8 APPENDIX 1 PHOTOS OF TEST SETUP ....................................................................................................................... 9 APPENDIX 2 PHOTOS OF EUT CONSTRUCTIONAL DETAILS ................................................................................... 9 Page 4 of 9 Report No.: 220324013RFC-2 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: Unit D/E of 9/F and 16/F, Block A, Building 6, Baoneng science and technology park, Longhua district, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-RSS102-V1.1 1. GENERAL INFORMATION 1.1 CLIENT INFORMATION Applicant: MMD Hong Kong Holding Limited Address of Applicant: Unit 1006, 10th Floor, C-Bons International Center, 108 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong Manufacturer: MMD Hong Kong Holding Limited Address of Manufacturer: Unit 1006, 10th Floor, C-Bons International Center, 108 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong 1.2 EUT INFORMATION Product Name: Wireless Speaker Model No. / HVIN: TAS1505 Add. Model No.: TAS1505/37, TAS1505/00, S1505, S1505/00, S1505x/yy, TAS1505x/yy (“x” can be A to Z or nil; “yy” can be 00-99 or nil for country code) Trade Mark: or PHILIPS DUT Stage: Production Unit EUT Supports Function: (Provided by the customer) 2.4 GHz ISM Band: Bluetooth V5.0(Only support BR + EDR) Software Version: V1.3 (…

Text truncated - open the document above for the full version.

Page 1 of 48 Report No.: 220324013RFC-1 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: Unit D/E of 9/F and 16/F, Block A, Building 6, Baoneng science and technology park, Longhua district, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-RSS247-V1.1 FCC & ISED TEST REPORT Product Name: Wireless Speaker Trade Mark: or PHILIPS Model No. / HVIN: TAS1505 Add. Model No.: TAS1505/37, TAS1505/00, S1505, S1505/00, S1505x/yy, TAS1505x/yy (“x” can be A to Z or nil; “yy” can be 00-99 or nil for country code) Report Number: 220324013RFC-1 Test Standards: FCC 47 CFR Part 15 Subpart C RSS-247 Issue 2 RSS-Gen Issue 5 FCC ID: 2AR2STAS1505 IC: 24589-TAS1505 Test Result: PASS Date of Issue: April 6, 2022 Prepared for: MMD Hong Kong Holding Limited Unit 1006, 10th Floor, C-Bons International Center, 108 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong Prepared by: Shenzhen UnionTrust Quality and Technology Co., Ltd. Unit D/E of 9/F and 16/F, Block A, Building 6, Baoneng science and technology park, Longhua district, Shenzhen, China TEL: +86-755-2823 0888 FAX: +86-755-2823 0886 Prepared by: Reviewed by: Kieron Luo Eric Yu Project Engineer Project Supervisor Approved by: Date: April 6, 2022 Kevin Liang Assistant Manager Page 2 of 48 Report No.: 220324013RFC-1 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: Unit D/E of 9/F and 16/F, Block A, Building 6, Baoneng science and technology park, Longhua district, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-RSS247-V1.1 Version Version No. Date Description V1.0 April 6, 2022 Original Page 3 of 48 Report No.: 220324013RFC-1 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: Unit D/E of 9/F and 16/F, Block A, Building 6, Baoneng science and technology park, Longhua district, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-RSS247-V1.1 CONTENTS 1. GENERAL INFORMATION ....................................................................................................................................... 4 1.1 CLIENT INFORMATION ........................................................................................................................................ 4 1.2 EUT INFORMATION ............................................................................................................................................ 4 1.2.1 GENERAL DESCRIPTION OF EUT ............................................................................................................ 4 1.2.2 DESCRIPTION OF ACCESSORIES .............................................................................................................. 4 1.3 PRODUCT SPECIFICATION SUBJECTIVE TO THIS STANDARD ................................................................................. 5 1.4 OTHER INFORMATION ......................................................................................................................................... 5 1.5 DESCRIPTION OF SUPPORT UNITS ...................................................................................................................... 5 1.6 TEST LOCATION ................................................................................................................................................. 6 1.7 TEST FACILITY ................................................................................................................................................... 6 1.8 DEVIATION FROM STANDARDS ............................................................................................................................ 6 1.9 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................................. 6 1.10 OTHER INFORMATION REQUESTED BY THE CUSTOMER ........................................................................................ 6 1.11 MEASUREMENT UNCERTAINTY ........................................................................................................................... 7 2. TEST SUMMARY ...................................................................................................................................................... 8 3. EQUIPMENT LIST .................................................................................................................................................... 9 4. TEST CONFIGURATION ........................................................................................................................................ 10 4.1 ENVIRONMENTAL CONDITIONS FOR TESTING ...................................................................................................... 10 4.1.1 NORMAL OR EXTREME TEST CONDITIONS ............................................................................................. 10 4.1.2 RECORD OF NORMAL ENVIRONMENT AND TEST SAMPLE ........................................................................ 10 4.2 TEST CHANNELS ............................................................................................................................................. 10 4.3 EUT TEST STATUS .......................................................................................................................................... 10 4.4 PRE-SCAN .................................................................................................................................................... 11 4.4.1 PRE-SCAN UNDER ALL PACKETS AT MIDDLE CHANNEL .............................................................................. 11 4.4.2 WORST-CASE DATA PACKETS ................................................................................................................ 11 4.4.3 TESTED CHANNEL DETAIL .......................................................................................................…

Text truncated - open the document above for the full version.

Page 31 of 48 Report No.: 220324013RFC-1 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: Unit D/E of 9/F and 16/F, Block A, Building 6, Baoneng science and technology park, Longhua district, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-RSS247-V1.1 Pulse Width Number of Pulses in 3.16 Seconds π/4DQPSK_2-DH1 π/4DQPSK_2-DH3 π/4DQPSK_2-DH5 Page 32 of 48 Report No.: 220324013RFC-1 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: Unit D/E of 9/F and 16/F, Block A, Building 6, Baoneng science and technology park, Longhua district, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-RSS247-V1.1 Pulse Width Number of Pulses in 3.16 Seconds 8DPSK_3-DH1 8DPSK_3-DH3 8DPSK_3-DH5 Page 33 of 48 Report No.: 220324013RFC-1 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: Unit D/E of 9/F and 16/F, Block A, Building 6, Baoneng science and technology park, Longhua district, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-RSS247-V1.1 5.7 CONDUCTED OUT OF BAND EMISSION Test Requirement: FCC 47 CFR Part 15 Subpart C Section 15.247(d) RSS-247 Issue 2, Section 5.5 Test Method: ANSI C63.10-2013 Section 6.10.4 & Section 7.8.8 Limit: In any 100kHz bandwidth outside the frequency bands in which the spread spectrum intentional radiator in operating, the radio frequency power that is produced by the intentional radiator shall be at least 20dB below that in the 100kHz bandwidth within the band that contains the highest level of the desired power. Test Procedure: Remove the antenna from the EUT and then connect a low loss RF cable from the antenna port to the spectrum analyzer. Use the following spectrum analyzer settings: Step 1:Measurement Procedure REF a) Set instrument center frequency to 2400 MHz or 2483.5 MHz. b) Wide enough to capture the peak level of the emission operating on the channel closest to the band edge, as well as any modulation products that fall outside of the authorized band of operation. c) Set the RBW = 100 kHz. d) Set the VBW ≥ 3 x RBW. e) Detector = peak. f) Sweep time = auto couple. g) Sweep points ≥ 2 x Span/RBW h) Trace mode = max hold. i) Allow the trace to stabilize. j) Set the marker on the emission at the band edge, or on the highest modulation product outside of the band, if this level is greater than that at the band edge. Enable the marker-delta function, and then use the marker-to-peak function to move the marker to the peak of the in-band emission. Step 2:Measurement Procedure OOBE a) Set RBW = 100 kHz. b) Set VBW ≥ 300 kHz. c) Detector = peak. d) Sweep = auto couple. e) Trace Mode = max hold. f) Allow trace to fully stabilize. g) Use the peak marker function to determine the maximum amplitude level. Note: The cable loss and attenuator loss were offset into measure device as an amplitude offset. Test Setup: Refer to section 4.5.3 for details. Instruments Used: …

Text truncated - open the document above for the full version.
