TAPR802 Portable Speaker TAS4405 Register your product and get support at www.philips.com/support User manual 1 EN Contents 1 Important 2 Safety 2 2 Your Wireless portable speaker 3 Introduction 3 What's in the box 3 Overview 3 3 Get started 4 Charge the built-in battery 4 Install batteries for the microphone 4 Install a micro-SD card 5 5 Power on/off 5 6 Use Bluetooth devices 6 7 Micro-SD card mode 7 8 Mix your sound with an audio source 7 Record 7 9 Product information 8 10 Notice 8 Compliance 8 Care of the environment 8 FCC Statement 9 Trademark notice 9 Contents 2 EN 1 Important Safety Warning • Never remove the casing of this product. • Never lubricate any part of this product. • Never place this product on other electrical equipment. • Keep this product away from direct sunlight, naked fames or heat. • Read and follow these instructions. • Make sure that there is enough space around the product for ventilation. • Refer all servicing to qualified service personnel. Servicing is required when the product has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the product, the product has been exposed to rain or mositure, does not operate normally, or has been dropped. • Only use attachments/accessories specified by the manufacturer. • Use only power supplies listed in this user manual. • Unplug this product during lightning stroms or when unused for long periods of time. • This product should not be exposed to dripping or splashing. • Do not place any sources of danger on the product (e.g. liquid filled objects, lighted candles). • Where the plug of the Direct Plug-in Adapter is used as the disconnect device, the disconnect device shall remain readily operable. • Do not use this product near water. • Install in accordance with the manufacturer’s instructions. • Do not install near any heat sources wuch as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 3 EN 2 Your wireless portable speaker Congratulations on your purchase, and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome. Introduction With this speaker and microphone, you can • enjoy audio from a Bluetooth device, • enjoy audio from a micro-SD card, • one touch recording to micro-SD card. What's in the box Please check and identify the contents of your package: • Wireless portable speaker • Wireless microphone • USB cable • Quick start guide • Safety sheet Quick start guide TAPR802 AAA x 2 Overview 1 4 5 2 3 6 7 8 9 a • Press and hold for 2 seconds to power on or off. b • Press to start or stop the recording of audio from both the wireless microphone and the speaker. c • Press to select Bluetooth or micro-SD card source. d / • Press to adjust the volume. e • Press to play or pause. • Press twice to skip to the next track. f Micro-USB charging port g Micro-SD card slot h Battery compartment lid i Microphone power switch 4 EN 3 Get started Always follow the instructions in this chapter in sequence. Charge the built-in battery The speaker is powered by a built-in rechargeable battery. Note •Fully charge the built-in battery before using. 5V A Connect the USB cable between the micro- USB socket on the speaker and a USB socket on your computer or a charger. LED indicator (Power) Flashing redBeing charged OffFully charged Install batteries for the microphone 1 Open the battery compartment lid. 2 Install 2 AAA alkaline batteries (not provided) with the correct polarity. 3 Close the battery compartment lid AAA x 2 5 EN Install a micro-SD card 1 Open the lid of the card slot. 2 Insert a micro-SD card (not provided) with the pin side facing down till you hear a click. Then close the lid of the card slot. 5 Power on/off 1 Press and hold for 2 seconds to power on or off the speaker. 2 sec. 2 Slide up the power switch to power on the microphone. 6 EN 6 Use Bluetooth devices With this speaker, you can enjoy audio from your Bluetooth device. Note •Make sure that the Bluetooth function is enabled on your device. •Keep away from any other electronic device that may cause interference. 1 Press and hold for 2 seconds to enter the Bluetooth pairing mode. 2 sec. 2 Select “Philips S4405” in the Bluetooth list on your device. »If a message prompts for permission for Bluetooth connection, confirm it. »If a password is required, enter 0000 and then confirm. »The speaker beeps when successfully connected. Philips S4405 BEEP 10m LED indicator (Bluetooth) Blinking blueBluetooth pairing Steady blue Bluetooth connected Note •To disconnect, disable the Bluetooth connection with this product on your device or press again to switch to micro-SD card mode. 7 EN 7 Micro-SD card mode You can enjoy audio from a micro-SD card that stores audio files. Press repeatedly to select the micro-SD source. The Bluetooth LED indicator will be turned off for micro-SD auto playback. 8 Mix your sound with an audio source Note •For the best vocal quality, keep a distance of ?? cm between the microphone and the speaker. By using the wireless microphone, you can mix your sound with an audio source Record In the Bluetooth mode, press to start or stop the recording. LED indicator (REC) Blinking redError (no micro-SD card inserted or the card is full) Solid red Recording 8 EN 9 Product information Note •Product information is subject to change without prior notice. General information Power supply: 5V 1.5A Speaker driver1.5” Charging time (Speaker) 2.5 hours Playtime6 hours Built-in Lithium battery (Speaker) 3.7V, 1500mAh Dimensions (Speaker)105 x 105 x 38 mm Weight (Speaker) 0.29 g Bluetooth Bluetooth version V4.2 Bluetooth range5 m / 16.5 ft 10 Notice Any changes or modifications made to this device that are not expressly approved by MMD Hong Kong Holding Limited may void the user’s authority to operate the product. Compliance Hereby, MMD Hong Kong Holding Limited declares that this product is …

Text truncated - open the document above for the full version.

Authority to Act as Agent [Jan.15, 2020] Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement (MMD Hong Kong Holding Limited) FCC ID: (2AR2STAS4405) To Whom It May Concern: We, (MMD Hong Kong Holding Limited), hereby authorized Intertek Testing Services to act as our Agent for the purpose of preparing application for FCC ID number (2AR2STAS4405) under all applicable parts of the FCC rules and regulations. We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: 36 months By: __________________________ Tomas Guan (Signature 1 ) (Print name) Title: Manager On behalf of: (MMD Hong Kong Holding Limited) Telephone: 86-755-36358341 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

1(1) [MMD Hong Kong Holding Limited] [Dec 20, 2019] Attention: Application Examiner RE: Request for Confidentiality Applicant: [MMD Hong Kong Holding Limited] FCC ID: [2AR2STAS4405] To Whom It May Concern: Permanent Confidentiality [Complete this section if permanent confidentiality is requested] Request is hereby submitted by [MMD Hong Kong Holding Limited] to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential:  Schematics  Detailed Block Diagrams  Detailed Operational/Functional Description Rationale for request for confidentiality: [MMD Hong Kong Holding Limited] has invested considerable time and materials in research and development to produce the referenced product. [Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us.] [Short term confidentiality: Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development.] If you have questions or need further information, please contact the undersigned. Sincerely, [Signature] [Tomas Guan] [ Manager] [MMD Hong Kong Holding Limited]

Page 1 of 3 FCC ID: 2AR2STAS4405 IC: 24589-TAS4405 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com APPENDIX 2 PHOTOS OF EUT CONSTRUCTIONAL DETAILS EUT EXTERNAL PHOTOS EUT Photo EUT Photo Page 2 of 3 FCC ID: 2AR2STAS4405 IC: 24589-TAS4405 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo Page 3 of 3 FCC ID: 2AR2STAS4405 IC: 24589-TAS4405 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo

Made in China Manufactured: Jan/2020 Serial No.: XXXXXXXXXX DC 5V1.5A Model No.: TAS4405/37 MMD Hong Kong Holding Limited, Units 1006-1007,10th Floor,C-Bons International Center,108 Wai Yip Street,KwunTong,Kowloon,Hong Kong COMPLIES WITH FCC PART 15 RULES COMPLIES WITH 21 CFR 1040.10 AND 1040.11 The device complies with part 15 of the FCC Rules. Operation is subject to following two conditions:(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAN ICES-3 (B)/NMB-3(B) FCC ID:2AR2STAS4405 IC:24589-TAS4405 Silkscreen pantonecoolxxxxx SerialNo.Label Model No.: TAS4405/37 Serial No.: XXXXXXXXXXX TAS4405/37 白底黑字贴于彩盒上 Manufactured: Jan/2020 Serial No.: XXXXXXXXXX 透明贴纸上丝印白色文字内容 贴于HIPS塑胶面 TAS4405/37 TAS4405/37 Label Location

Page 1 of 6 FCC ID: 2AR2STAS4405 IC: 24589-TAS4405 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com APPENDIX 2 PHOTOS OF EUT CONSTRUCTIONAL DETAILS EUT INTERNAL PHOTOS EUT Photo EUT Photo Antenna Page 2 of 6 FCC ID: 2AR2STAS4405 IC: 24589-TAS4405 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo Page 3 of 6 FCC ID: 2AR2STAS4405 IC: 24589-TAS4405 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo Page 4 of 6 FCC ID: 2AR2STAS4405 IC: 24589-TAS4405 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo Page 5 of 6 FCC ID: 2AR2STAS4405 IC: 24589-TAS4405 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo Page 6 of 6 FCC ID: 2AR2STAS4405 IC: 24589-TAS4405 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com EUT Photo EUT Photo

RF Exposure Requirements Product Description: Wireless speaker Model No.: TAS4405/37 FCC ID: 2AR2STAS4405 IC: 24589-TAS4405 According to the KDB 447498 D01 V06 and RSS-102 Issue 5, the following RF exposure evaluation shall to demonstrate RF exposure compliance. Bluetooth BR & EDR Frequency Range: 2402 MHz to 2480 MHz Type of Modulation: GFSK, π/4DQPSK Device category: Portable device (Distance: 5mm) The maximum conducted output power tested: - 2.21dBm The conducted output power specified is -1 dBm Tolerance: ±2 dB  FCC RF exposure The source- based time-averaging conducted output power = (-1 + 2) * Duty cycle mW = 1.259 mW (Duty Cycle ≤ 100%) Maximum Conducted Output Power: 1.259 mW Limit: 10mW Source-based time-averaged Conducted output power is 1.259 mW < 10mW  ISED RF exposure The source- based time-averaging conducted output power = (-1 + 2) * Duty cycle mW = 1.259 mW (Duty Cycle ≤ 100%) Maximum Conducted Output Power: 1.259 mW Limit: 4mW Source-based time-averaged Conducted output power is 1.259 mW < 4mW So the transmitter complies with the RF exposure requirements and the SAR is not required.
