TA P X 4207/37 arty Speaker 4000 Series User manual Register your product and get support at www.philips.com/support 2EN Safety 3 Care for your product 4 Care of the environment 4 Compliance 4 Help and support 4 Hearing safety 5 Built-in battery care 5 Trademarks 5 2 Your party speaker 7 What’s in the box 7 Party speaker 8 3 Get started 9 Connect to power 9 Turn On and Off 10 Volume control 10 DBB control 10 Charge the built-in battery 10 Change light effect 11 Play from Bluetooth devices 12 Pairing for stereo mode (TWS) 12 Party link mode 13 Play audio through USB 14 Listen to an external device 14 Sing through microphone 15 Factory reset 15 Pole-Mounting your Party speaker 15 4 Product specifications 16 5 Troubleshooting 17 Contents Important safety instructions 3 1 3EN 1 Important safety instructions Read and understand all instructions before you use your product. If damage is caused by failure to follow instructions, the warranty does not apply. Safety Know these safety symbols CAUTION CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. RISK OF ELECTRIC SHOCK DO NOT OPEN This is CLASS II apparatus with double insulation, and no protective earth provided. AC voltage Use only the power supplies listed in the user manual. WARNING! Warning: risk of electric shock! The exclamatory mark is intended to alert the user to the presence of important operating instructions. Risk of electric shock or fire! • Before you make or change any connections, make sure that all devices are disconnected from the power outlet. • Never expose the product and accessories to rain or water. Never place liquid containers, such as vases, near the product. If liquids are spilt on or into the product, disconnect it from the power outlet immediately. Contact Consumer Care to have the product checked before use. • Never place the product and accessories near naked flames or other heat sources, including direct sunlight. • Never insert objects into the ventilation slots or other openings on the product. • Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable. • Disconnect the product from the power outlet before lightning storms. • When you disconnect the power cord, always pull the plug, never the cable. • Use the product in tropical and/or moderate climates. Risk of short circuit or fire! • For identification and supply ratings, see the type plate at the back or bottom of the product. • Before you connect the product to the power outlet, ensure that the power voltage matches the value printed on the back or bottom of the product. Never connect the product to the power outlet if the voltage is different. Risk of injury or damage to this product! • For wall mounting, this product must be securely attached to the wall in accordance with the installation instructions. Use only the supplied wall mount bracket (if available). Improper wall mounting may result in accident, injury or damage. If you have any query, contact Consumer Care in your country. • Never place the product or any objects on power cords or on other electrical equipment. 4EN • If the product is transported in temperatures below 5°C, unpack the product and wait until its temperature matches room temperature before connecting it to the power outlet. • Parts of this product can be made of glass. Handle with care to avoid injury and damage. Risk of overheating! • Never install this product in a confined space. Always leave a space of at least four inches around the product for ventilation. Ensure curtains or other objects never cover the ventilation slots on the product. Note •The rating label is pasted on the bottom or back of the equipment. Care for your product Use only microfiber cloth to clean the product. Care of the environment Disposal of your old product and battery Your product is designed and manufactured with high quality materials and components, which can be recycled and reused. This symbol on a product means that the product is covered by European Directive 2012/19/EU. This symbol means that the product contains batteries covered by European Directive 2013/56/EU which cannot be disposed of with normal household waste. Inform yourself about the local separate collection system for electrical and electronic products and batteries. Follow local rules and never dispose of the product and batteries with normal household waste. Correct disposal of old products and batteries helps prevent negative consequences for the environment and human health. Compliance This product complies with the radio interference requirements of the European Community. Hereby, TP Vision Europe B.V. declares that this product is in compliance with the essential requirements and other relevant provisions of RED Directive 2014/53/EU and UK Radio Equipment Regulations 2017. You can find the Declaration of Conformity on www.philips.com/support. Help and support For extensive online support, visit www.philips.com/support to: • download the user manual and the quick start guide • watch video tutorials (available only for selected models) • find answers to frequently answered questions (FAQs) • email us a question • chat with our support representative. Follow the instructions on the website to select your language, and then enter your product model number. Alternatively, you can contact Consumer Care in your country. Before you contact, note down the model number and serial number of your product. You can find this information on the back or bottom of your product. 5EN Hearing safety Listen at a moderate volume • To establish a safe volume level Listen for reasonable periods of time Using headphones at a high volume can impair your hearing. This product can produce sounds in decibel ranges that may cause hearing loss for a normal person, even for exposure less than a minute. The higher decibel ran…

Text truncated - open the document above for the full version.
