2AR3P-FS05DMotion-activated alert

1/2 Mile Wireless Driveway & Intruder Alert User Manual General Information How does it work The wireless driveway and intruder alert includes wireless door chime and outdoor PIR motion sensor, the wireless distance between them can be up to 2600 feet (800m) in open air. It is great for multiple applications, including: Alerting you when visitors enter your driveway. Deterring trepassers and thieves from entering your property or building. Alerting you to wildlife on your land. Using in drive-thrus to signal that a customer has pulled in, and more. This wireless driveway alert is expandable,which allows you to pair various transmitter to the receiver, such as door sensor, motion detector, push button, etc. One doorbell receiver can pair with up to 50 various transmitters and each transmitter can be set to different ringtone. One transmitter also can pair with up to 50 receivers for different rooms. Specifications Detector 1) The receiver works as an alarm buzzer or door chime, it monitors for signals coming from the Passive Infrared (PIR) motion sensor, and activates an alert in response to that signal. It also features a LED indicator so you can visually tell when an alert is coming, it can be simply plugged to an AC outlet. 2) The PIR motion sensor enables you to detect movement of people and vehicles. It will send a signal to the receiver whenever motion is detected. The motion sensors should be deployed outdoors, where there is a clear view of the driveway or the likely entry and exit paths that you plan to secure. Overview (2) Take off the back cover and turn on the battery switch, when you see the PIR sensor flashes, then you can replace the back cover and secure the screws to wait pair. We recommend mounting the motion sensor at least 3-4 ft (1m) above the ground on a sturdy, no metal surface (i.e. a wall, wooden post or tree) with the sensor detector pointed straight out over the area you wish to cover (such as up your driveway looking towards your house). This will decrease or eliminate false alarms from small animals, give you a longer area to pick up movement, and avoid unwanted alarms from nearby lawns /roads. Note: Always test that your sensor is working in your desired location before installing it. Avoid placing your sensor in a location where sunlight will shine directly into the sensor’s detector window. Direct sunlight may cause false alarms and/or damage to the PIR sensor. (1) Mark the mounting holes with a pencil. (2) If installing on a wooden surface, you only need to use the included screws. Drill out your pilot holes using a 3/32” drill bit to a depth of 3/4”. This will help you prevent stripping of the screws and hold the sensor more securely. LED Indicator Volume button Backward button Forward button Speaker AC Plug Non-rechargeable PIR Motion Sensor (1) Remove the screws from the four corners of the back of the motion sensor. Getting Started 1. Power up the indoor chime receiver Plug the receiver into the outlet, the receiver will perform better if kept away from other electrical equipment (e.g. TV, microwave) 2. Power up the PIR motion sensor The motion sensor runs on battery and operates wirelessly at a maximum distance from the receiver of 2600 feet (800m). 3. Sound volume conrol Press the volume control button on the receiver to cycle through 5 volume levels. 4. Setting ringtone for a transmitter There are 58 melodies to choose from (1) Press the Forward or Backward button to choose your favorite ringtone, the receiver playing is the ringtone selected. (2) Please follow the pairing steps below to sync the new ringtone. The new ringtone will be set for the most recently synced transmitter. (3) Different ringtone can be set for each transmitter. 5. Pairing a transmitter to the receiver 3Please select your favourite ringtone before pairing. 4Hold and press the Volume Control Button for about 5s until a “Ding-dong” is heard and the LED indicator starts flashing. You are now in pairing mode. 5Quickly activate the tramsitter within 5s to send a signal to the receiver. When the pairing (ringtone sync) is successful, activate the transmtter again, the receiver will play the selected ringtone automatically. 6. Two or more transmitters pairing: The pairing mode is available for a transmitter only each time. For two or more transmitters, please follow the pairing steps (1)-(5) once again to get transmitters paired one by one. 7. Reset: Press Music Forward Button for about 5 seconds to reset receivers to default. When receiver sounds “Dingdong” with LED flashing that means reset succeeds, settting is back to default. It comes back to the 1st music, no transmitter is paired with receiver. Hold forward button for 5s Remark: (1) Pairing mode will last for 5 seconds only. (2) Pairing mode will quit automatically after pairing is completed. If you didn’t pair the transmitter with receiver successfully, please repeat the pairing steps (4)-(5) . Receiver & Transmitter Installation Important: Prior to installation, please test the alert wireless distance. For Plug-in Receiver: Just plug receiver into standard outlet in room, then it will work. For PIR Motion Sensor:Tools you will need for installation: - Pencil - Phillips screwdriver - Electric drill with 3/32” and 7/32” drill bits (recommended) - Hammer (optional) (3) If installing on any other surface, such as brick or masonry, you will use the included screws and anchors. Drill out your pilot holes using a 7/32” drill bit to a depth of 1”. Gently tap the anchors into your pilot holes using a hammer until the anchors are flush with the mounting surface. (4) Screw the bracket base to the place you want to install. (5) Screw the back cover onto the shaft of the screws. (6) Replace the back cover and secure the screws. (7) Twist the ball onto the fixed base of the bracket just until tight. Do not over-tighten. (8) Adjust the angle of your sensor so that it is looking at your target area. Troubleshooting -1- -2- -3- -4- -5- -6- -…

Text truncated - open the document above for the full version.

Shenzhen Shenan Yangguang Electronics Co., Ltd. 2021.06.30 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Motion-activated alert Trademark: N/A MODEL : FS05D, FS06D, FS07L, FS08L, FS09L, FS10L, FS11L, FS12L FCC ID: 2AR3P-FS05D To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Henry Pien /Manager Contact information / address: West of 4 th Floor, Building 9, No. 18, Makan Road, Xili, Nanshan District, Shenzhen, 518055, China

Shenzhen Shenan Yangguang Electronics Co., Ltd. 2021.06.30 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen BCTC Testing Co., Ltd to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : Henry Pien /Manager Contact information / address: West of 4 th Floor, Building 9, No. 18, Makan Road, Xili, Nanshan District, Shenzhen, 518055, China

Shenzhen Shenan Yangguang Electronics Co., Ltd. Model Difference 2021-06-30 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA RE: LETTER OF MODEL DIFFERENCE EUT NAME: Motion-activated alert FCC ID: 2AR3P-FS05D MODEL : FS05D, FS06D, FS07L, FS08L, FS09L, FS10L, FS11L, FS12L All the model are the same circuit and RF module, except model names. Regards Sincerely Client’s signature Client’s name / title : Henry Pien / Manager Contact information / address: West of 4 th Floor, Building 9, No. 18, Makan Road, Xili, Nanshan District, Shenzhen, 518055, China

External Photos

Size:40*20mm Motion-activated alert FCC ID: 2AR3P-FS05D This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Label location

Internal Photos Antenna

No.：BCTC/RF-EMC-005 Page: 1 of 34 Edition：A.3 TEST REPORT Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2106882150E Applicant: Shenzhen Shenan Yangguang Electronics Co., Ltd. Product Name: Motion-activated alert Model/Type Ref.: FS05D Tested Date: 2021-06-05 to 2021-06-24 Issued Date: 2021-07-05 Report No.: BCTC2106882150E No.：BCTC/RF-EMC-005 Page: 2 of 34 Edition：A.3 FCC ID: 2AR3P-FS05D The test report is effective only with both signature and specialized stamp.This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full.The tested sample(s) and the sample information are provided by the client. Product Name: Motion-activated alert Trademark: N/A Model/Type Ref.: FS05D FS06D, FS07L, FS08L, FS09L, FS10L, FS11L, FS12L Prepared For: Shenzhen Shenan Yangguang Electronics Co., Ltd. Address: West of 4 th Floor, Building 9, No. 18, Makan Road, Xili, Nanshan District, Shenzhen, 518055, China. Manufacturer: Shenzhen Shenan Yangguang Electronics Co., Ltd. Address: West of 4 th Floor, Building 9, No. 18, Makan Road, Xili, Nanshan District, Shenzhen, 518055, China. Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Tangwei, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: 2021-06-05 Sample tested Date: 2021-06-05 to 2021-06-24 Issue Date: 2021-07-05 Report No.: BCTC2106882150E Test Standards FCC Part15.231 ANSI C63.10-2013 Test Results PASS Tested by: Approved by: Willem Wang/Project Handler Zero Zhou/Reviewer Report No.: BCTC2106882150E No.：BCTC/RF-EMC-005 Page: 3 of 34 Edition：A.3 TABLE OF CONTENT Test Report Declaration Page 1. VERSION ............................................................. 5 2. TEST SUMMARY ...................................................... 6 3. MEASUREMENT UNCERTAINTY ........................................ 7 4. PRODUCT INFORMATION AND TEST SETUP ............................ 8 4.1 Product Information ..................................................... 8 4.2 Test Setup Configuration ................................................ 8 4.3 Support Equipment ..................................................... 9 4.4 Channel List ........................................................... 9 4.5 Test Mode ............................................................. 9 5. TEST FACILITY AND TEST INSTRUMENT USED ........................ 10 5.1 Test Facility ........................................................... 10 5.2 Test Instrument Used .................................................. 10 6. CONDUCTED EMISSIONS ............................................. 12 6.1 Block Diagram Of Test Setup ............................................ 12 6.2 Limit ................................................................. 12 6.3 Test procedure ........................................................ 12 6.4 EUT operating Conditions ............................................... 12 6.5 Test Result ........................................................... 13 7. RADIATED EMISSIONS ............................................... 15 7.1 Block Diagram Of Test Setup ............................................ 15 7.2 Limit ................................................................. 16 7.3 Test procedure ........................................................ 18 7.4 EUT operating Conditions ............................................... 19 7.5 Test Result ........................................................... 20 8. BANDWIDTH TEST ................................................... 24 8.1 Block Diagram Of Test Setup ............................................ 24 8.2 Limit ................................................................. 24 30KHZ ................................................................... 24 8.3 Test procedure ........................................................ 24 8.4 EUT operating Conditions ............................................... 24 8.5 Test Result ........................................................... 25 9. CALCULATION OF AVERAGE FACTOR ................................ 26 10. DWEELL TIME ....................................................... 28 10.1 Block Diagram Of Test Setup .......................................... 28 10.2 Limit ................................................................ 28 10.3 Test procedure ....................................................... 28 10.4 Test Result .......................................................... 29 11. ANTENNA REQUIREMENT ............................................ 30 11.1 STANDARD REQUIREMENT .......................................... 30 Report No.: BCTC2106882150E No.：BCTC/RF-EMC-005 Page: 4 of 34 Edition：A.3 11.2 EUT ANTENNA ...................................................... 30 12. EUT PHOTOGRAPHS ................................................. 31 13. EUT TEST SETUP PHOTOGRAPHS .................................... 32 (Note: N/A means not applicable) Report No.: BCTC2106882150E No.：BCTC/RF-EMC-005 Page: 5 of 34 Edition：A.3 1. VERSION Report No. Issue Date Description Approved BCTC2106882150E 2021-07-05 Original Valid Report No.: BCTC2106882150E No.：BCTC/RF-EMC-005 Page: 6 of 34 Edition：A.3 2. TEST SUMMARY The Product has been tested according to the following specifications: No. Test Parameter Clause No Results 1 Conducted Emission §15.207 PASS 2 Fundamental &Radiated Spurious Emission Measurement 15.209,15.231b PASS 3 Occupy Bandwidth 15.231c PASS 4 Dwell time 15.231a PASS 5 Antenna Requirement 15.203 PASS Report No.: BCTC2106882150E No.：BCTC/RF-EMC-005 Page: 7 of 34 Edition：A.3 3. MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the Product as specified in CISPR 16-4-2. This uncertainty represents an expanded uncertainty expressed at approximately the 9…

Text truncated - open the document above for the full version.

Report No.: BCTC2106882150E No.：BCTC/RF-EMC-005 Page: 31 of 33 Edition：A.3 13. EUT TEST SETUP PHOTOGRAPHS Conducted emissions Report No.: BCTC2106882150E No.：BCTC/RF-EMC-005 Page: 32 of 33 Edition：A.3 Radiated Measurement Photos
