2AR3P-SH-NP01Niwa Grow Hub

NiwaHUBManual V0 Introduction TheNiwaHUBrevolutionizesalltraditionalpowerstrips.Usershavetheabilitytoremotely controltheindividualoutletsfromAppandreadtemperature,humidityandlightlevels. MainFeatures EasyToSetup-Plugintoexistingoutlet,followthesetupinstructionsontheApp,name yourdevice,andyouaregoodtogo. Controlfromanywhere-Stayconnectedevenwhenyou’renotathome.Controlyour electronicswiththefreeConnectedapp,fromanywhere. IndependentlyControlEachOutlet-Eachoutletcouldbecontrolledindependently,as wellasthe4USBports SurgeAndOverloadProtection-Protectsensitiveelectronicsandappliancesfrom suddenshortcircuitandpowersurgesthatcanoccurduringweatherstormsandcause irreparabledamage. Specifications Input10AAC125V50/60Hz Output15AResistive 125VMax1875W MaxLoad15Aintotal OverloadProtectionYES SurgeProtectionYES WiFinetwork2.4Gb/n/g OperatingTemperatureAndHumidity-10ºC~55ºC 10%~90%RH,Non-condensing HardwareOverview 1:MainSwitch 2:Outlet 3:USBport 4:WiFinetworkindicator 5:Powerindicator DownloadtheApp 1.Searchthekeyword“NiwaGrowHub”inAPPStoreorGooglePlaytodownloadthe App, 2.OpentheAppandregisteranaccounttologin. WiFiSetup Note:Only2.4GHzb/g/nnetworkssupported 1.Taptheaddicon“+”onthetoprightandselect“GrowHub”fromthedevicetypelist. 2.Pressandholdthe“MainSwitch”for5sandreleaseuntiltheindicatorlightis rapidlyflashingthatindicatestheswitchisreadytoconfigure. 3.EnterthepasswordoftheWIFInetworkthatyourmobiledeviceconnected,thenitwill startregisteringthedevicetothecloud. 4.Oncethedevicewasaddedsuccessfully,youwillbeabletoquicklycontrolitwithinthe App. FCCRequirement changesormodificationsnotexpresslyapprovedbythepartyresponsiblefor compliancecouldvoidtheuser’sauthoritytooperatetheequipment. ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothe followingtwoconditions: (1)thisdevicemaynotcauseharmfulinterference,and (2)thisdevicemustacceptanyinterferencereceived,includinginterferencethat maycauseundesiredoperation. Note:Thisequipmenthasbeentestedandfoundtocomplywiththelimitsfora ClassBdigitaldevice,pursuanttoPart15oftheFCCRules.Theselimitsare designedtoprovidereasonableprotectionagainstharmfulinterferenceina residentialinstallation.Thisequipmentgenerates,uses,andcanradiateradio frequencyenergy,andifnotinstalledandusedinaccordancewiththeinstructions, maycauseharmfulinterferencetoradiocommunications.However,thereisno guaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthis equipmentdoescauseharmfulinterferencetoradioortelevisionreception,which canbedeterminedbyturningtheequipmentoffandon,theuserisencouragedto trytocorrecttheinterferencebyoneormoreofthefollowingmeasures: –Reorientorrelocatethereceivingantenna. –Increasetheseparationbetweentheequipmentandreceiver. –Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthe receiverisconnected. –Consultthedealeroranexperiencedradio/TVtechnicianforhelp. ThisequipmentcomplieswithFCCradiationexposurelimitssetforthforan uncontrolledenvironment.Thisequipmentshouldbeinstalledandoperatedwitha minimumdistanceof20cmbetweentheradiator&yourbody.Thistransmitter mustnotbeco-locatedoroperatinginconjunctionwithanyotherantennaor transmitter.

FCC ID: 2AR3P-SH-NP01 FCC ID: 2AR3P-SH-NP01 FCC ID: 2AR3P-SH-NP01 FCC ID: 2AR3P-SH-NP01

niwa grow hub Model Number: SH-NP01 FCC ID: 2AR3P-SH-NP01 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2AR3P-SH-NP01 FCC ID: 2AR3P-SH-NP01 FCC ID: 2AR3P-SH-NP01

Shenzhen Huaxia Testing Technology Co., Ltd 1F., Block A of Tongsheng Technology Building, Huahui Road, Dalang Street, Longhua District, Shenzhen, China Telephone: +86-755-26648640 Fax: +86-755-26648637 Website: www.cqa-cert.com Report Template Version: V03 Report Template Revision Date: Mar.1st, 2017 RF Exposure Evaluation Report The test report is effective only with both signature and specialized stamp, The result(s) shown in this report refer only to the sample(s) tested. Without written approval of CQA, this report can’t be reproduced except in full. Report No.: CQASZ20200800830E-02 Applicant: Shenzhen Shenan Yangguang Electronics Co., Ltd Address of Applicant: Buliding 9, No.18 of Makan Rd, Xili, Nanshan, Shenzhen 518055 China Equipment Under Test (EUT): Product: niwa grow hub Model No.: SH-NP01 Brand Name: niwa FCC ID: 2AR3P-SH-NP01 Standards: 47 CFR Part 1.1307 47 CFR Part 2.1093 KDB447498D01 General RF Exposure Guidance v06 Date of Receipt: 2020-08-10 Date of Test: 2020-08-10 to 2020-08-19 Date of Issue: 2020-08-19 Test Result: PASS* *In the configuration tested, the EUT complied with the standards specified above Tested By: ( Martin Lee ) Reviewed By: ( Sheek Luo ) Approved By: ( Jack Ai ) Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200800830E-02 Page:2 of 6 1 Version Revision History Of Report Report No. Version Description Issue Date CQASZ20200800830E-02 Rev.01 Initial report 2020-08-19 Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200800830E-02 Page:3 of 6 2 Contents Page 1 VERSION .....................................................................................................................................................................2 2 CONTENTS .................................................................................................................................................................3 3 GENERAL INFORMATION ......................................................................................................................................4 3.1 CLIENT INFORMATION ...............................................................................................................................................4 3.2 GENERAL DESCRIPTION OF EUT ...............................................................................................................................4 4 SAR EVALUATION ....................................................................................................................................................5 4.1 RF EXPOSURE COMPLIANCE REQUIREMENT ..............................................................................................................5 4.1.1 Limits ..............................................................................................................................................................5 4.1.2 Test Procedure ..............................................................................................................................................5 4.1.3 EUT RF Exposure.........................................................................................................................................6 Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200800830E-02 Page:4 of 6 3 General Information 3.1 Client Information Applicant: Shenzhen Shenan Yangguang Electronics Co., Ltd Address of Applicant: Buliding 9, No.18 of Makan Rd, Xili, Nanshan, Shenzhen 518055 China Manufacturer: Shenzhen Shenan Yangguang Electroncis Co., Ltd Address of Manufacturer: SSG Group, No.18, Makan Industrial Park,Xili, Nanshan, Shenzhen, China, 518055 Factory: Shenzhen Shenan Yangguang Electroncis Co., Ltd Address of Factory: SSG Group, No.18, Makan Industrial Park, Xili, Nanshan, Shenzhen, China, 518055 3.2 General Description of EUT Product Name: niwa grow hub Model No.: SH-NP01 Trade Mark: niwa Hardware version: V1.0 Software version: V1.0.1 Operation Frequency: IEEE 802.11b/g/n(HT20): 2412MHz to 2462MHz Channel Numbers: IEEE 802.11b/g, IEEE 802.11n HT20: 11 Channels Channel Separation: 5MHz Type of Modulation: IEEE for 802.11b: DSSS(CCK,DQPSK,DBPSK) IEEE for 802.11g : OFDM(64QAM, 16QAM, QPSK, BPSK) IEEE for 802.11n(HT20) : OFDM (64QAM, 16QAM, QPSK, BPSK) Transfer Rate: IEEE for 802.11b: 1Mbps/2Mbps/5.5Mbps/11Mbps IEEE for 802.11g : 6Mbps/9Mbps/12Mbps/18Mbps/24Mbps/36Mbps/48Mbps/54Mbps IEEE for 802.11n(HT20) : 6.5Mbps/13Mbps/19.5Mbps/26Mbps/39Mbps/52Mbps/58.5Mbps/65Mbps Product Type: Mobile Portable Fix Location Test Software of EUT: EspRFtestTool (manufacturer declare) Antenna Type: PCB antenna Antenna Gain: 2.0 dBi Power Supply: 120V60Hz Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200800830E-02 Page:5 of 6 4 SAR Evaluation 4.1 RF Exposure Compliance Requirement 4.1.1 Limits According to FCC Part1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in part1.1307(b) F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4* Pi * R 2 ) Where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. 4.1.2 Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200800830E-02 Page:6 of 6 4.1.3 EUT RF Exposure 1) For WIFI Antenna Gain: 2.0dBi Antenna Gain: The maximum Gain measured in fully anechoic chamber is 1.58 in linear scale. Output Power Into Antenna & RF Exposure Evaluation Distance: Measurement Data IEEE for 802.11b mode Test channel …

Text truncated - open the document above for the full version.

Shenzhen Huaxia Testing Technology Co., Ltd 1F., Block A of Tongsheng Technology Building, Huahui Road, Dalang Street, Longhua District, Shenzhen, China Telephone: +86-755-26648640 Fax: +86-755-26648637 Website: www.cqa-cert.com Report Template Version: V04 Report Template Revision Date: 2018-07-06 TEST REPORT The test report is effective only with both signature and specialized stamp, The result(s) shown in this report refer only to the sample(s) tested. Without written approval of CQA, this report can’t be reproduced except in full. Report No.: CQASZ20200800830E-01 Applicant: Shenzhen Shenan Yangguang Electronics Co., Ltd Address of Applicant: Buliding 9, No.18 of Makan Rd, Xili, Nanshan, Shenzhen 518055 China Equipment Under Test (EUT): EUT Name: niwa grow hub Model No.: SH-NP01 Brand Name: niwa FCC ID: 2AR3P-SH-NP01 Standards: 47 CFR Part 15, Subpart C Date of Receipt: 2020-08-10 Date of Test: 2020-08-10 to 2020-08-19 Date of Issue: 2020-08-19 Test Result: PASS* *In the configuration tested, the EUT complied with the standards specified above Tested By: ( Martin Lee ) Reviewed By: ( Sheek Luo ) Approved By: ( Jack Ai ) . Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200800830E-01 Page:2 of 78 1 Version Revision History Of Report Report No. Version Description Issue Date CQASZ20200800830E-01 Rev.01 Initial report 2020-08-19 Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200800830E-01 Page:3 of 78 2 Test Summary Test Item Test Requirement Test method Result Antenna Requirement 47 CFR Part 15, Subpart C Section 15.203/15.247 (c) ANSI C63.10 2013 PASS AC Power Line Conducted Emission 47 CFR Part 15, Subpart C Section 15.207 ANSI C63.10 2013 PASS Conducted Peak & Average Output Power 47 CFR Part 15, Subpart C Section 15.247 (b)(3) ANSI C63.10 2013 PASS 6dB Occupied Bandwidth 47 CFR Part 15, Subpart C Section 15.247 (a)(2) ANSI C63.10 2013 PASS Power Spectral Density 47 CFR Part 15, Subpart C Section 15.247 (e) ANSI C63.10 2013 PASS Band-edge for RF Conducted Emissions 47 CFR Part 15, Subpart C Section 15.247(d) ANSI C63.10 2013 PASS RF Conducted Spurious Emissions 47 CFR Part 15, Subpart C Section 15.247(d) ANSI C63.10 2013 PASS Radiated Spurious Emissions 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 2013 PASS Restricted bands around fundamental frequency (Radiated Emission) 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 2013 PASS Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200800830E-01 Page:4 of 78 3 Contents Page 1 VERSION .............................................................................................................................................................. 2 2 TEST SUMMARY ................................................................................................................................................ 3 3 CONTENTS .......................................................................................................................................................... 4 4 GENERAL INFORMATION ............................................................................................................................... 5 4.1 CLIENT INFORMATION ................................................................................................................................... 5 4.2 GENERAL DESCRIPTION OF EUT ................................................................................................................. 5 4.3 TEST ENVIRONMENT AND MODE .................................................................................................................. 7 4.4 DESCRIPTION OF SUPPORT UNITS ............................................................................................................. 10 4.5 TEST LOCATION .......................................................................................................................................... 10 4.6 TEST FACILITY ............................................................................................................................................. 10 4.7 STATEMENT OF THE MEASUREMENT UNCERTAINTY ................................................................................... 11 4.8 DEVIATION FROM STANDARDS .................................................................................................................... 11 4.9 ABNORMALITIES FROM STANDARD CONDITIONS ........................................................................................ 11 4.10 OTHER INFORMATION REQUESTED BY THE CUSTOMER ............................................................................ 11 4.11 EQUIPMENT LIST ......................................................................................................................................... 12 5 TEST RESULTS AND MEASUREMENT DATA .......................................................................................... 13 5.1 ANTENNA REQUIREMENT ............................................................................................................................ 13 5.2 CONDUCTED EMISSIONS ............................................................................................................................. 14 5.3 CONDUCTED PEAK & AVERAGE OUTPUT POWER...................................................................................... 18 5.4 6DB OCCUPY BANDWIDTH .......................................................................................................................... 20 5.5 POWER SPECTRAL DENSITY ....................................................................................................................... 32 5.6 BAND-EDGE FOR RF CONDUCTED EMISSIONS .......................................................................................... 39 5.7 RF CONDUCTED SPURIOUS EMISSIONS .................................................................................................... 44 5.8 RADIATED SPURIOUS EMISSIONS ........…

Text truncated - open the document above for the full version.

FCC ID: 2AR3P-SH-NP01 1 Photographs - EUT Test Setup 1.1 Radiated Spurious Emission 9kHz~30MHz: 30MHz~1GHz: FCC ID: 2AR3P-SH-NP01 Above 1GHz: 1.2 Conducted Emission
