2ARGFAC2Abode Cam 2

K 2021.03.03 60×95mm V1.0 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interferenceto radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Le présent émetteur radio a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal. Les types d'antenne non inclus dans cette liste, et dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur. This radio transmitter has been approved by Industry Canada to operate with the antenna types listed with the maximum permissible gain indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device. V1.0 AC2 AC2-KSZP01 105g abode

abode systems, inc Agent Authorization Company: abode systems, inc Address: 2625 Middlefield Rd #900 Palo Alto, CA 94306, United States Product Name: Abode Cam 2 Trade Mark: Abode Model Number: 104061/A FCC ID: 2ARGFAC2 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2021-03-31 Name: Mr Christopher Carney Title: CEO Company: abode systems, inc

abode systems, inc 2625 Middlefield Rd #900 Palo Alto, CA 94306, United States Date: March 31, 2021 FCC ID: 2ARGFAC2 Model Number: 104061/A To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, abode systems, inc declare that this EUT (FCC ID: 2ARGFAC2) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, (Signed) Name / Title: Mr Christopher Carney / CEO Company: abode systems, inc Address: 2625 Middlefield Rd #900 Palo Alto, CA 94306, United States Phone: (650) 443-7834 Fax: / E-Mail: [email protected]

abode systems, inc Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2021-03-31 Subject; Request for Confidentiality FCC ID: 2ARGFAC2 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Mr Christopher Carney Title: CEO

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 1. EXTERIOR PHOTOGRAPHS Fig. 1 Fig. 2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Fig. 3 Fig. 4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Fig. 5 Fig. 6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Fig. 7

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 1 LABEL AND LOCATION Size: L3.0cm*W2.0cm Material: Tagboard Glue: adhesive sticker Font color: Black Label color: White Label Location Model: 104061/A FCC ID: 2ARGFAC2 IC: 26939-AC2 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 1. INTERIOR PHOTOGRAPHS Fig. 1 Fig. 2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Fig. 3 Fig. 4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Fig. 5 Fig. 6 2.4G WIFI Antenna

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 3 Maximum Permissible Exposure Report 1. Product Information FCC ID 2ARGFAC2 Product name Abode Cam 2 Model Number 104061/A Power supply DC 5V 1000mA Adapter parameters: Input: AC 100-240V 50/60Hz 0.25A Output: DC 5V 1000mA Modulation Type IEEE 802.11b: DSSS(CCK,DQPSK,DBPSK) for 2.4G WLAN(DTS) IEEE 802.11g/n: OFDM(64QAM, 16QAM, QPSK, BPSK) for 2.4G WLAN(DTS) Channel Bandwidth 20 MHz for IEEE 802.11b/g/n 40 MHz for IEEE 802.11n Spacing 5 MHz Antenna Type Internal antenna for 2.4G WLAN(DTS) Antenna Gain 2.0 dBi (maximum) for 2.4G WLAN(DTS) Hardware version ABODE_T31GC2053 V1.4 Software version / 2.4G WLAN Operation frequency 2412-2462MHz Exposure category General population/uncontrolled environment EUT Type Production Unit Device Type Mobile Device 2. Evaluation Method Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. 3. Limit 3. 1 Refer evaluation method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 447498 D01 General 1 RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 3 3. 2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 4. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 5. Antenna Information 104061/A can only use antennas certificated as follows provided by manufacturer; Internal Identification Antenna type and antenna number Operate frequency band Maximum antenna gain Antenna 0 Internal antenna 2412 MHz – 2462 MHz 2.0 dBi 6. Conducted Power 2.4G WLAN Test Mode Channel Frequency (MHz) Measured Peak Output Power (dBm) IEEE 802.11b 1 2412 15.65 6 2437 16.92 11 2462 17.71 IEEE 802.11g 1 2412 14.77 6 2437 16.51 11 2462 17.55 IEEE 802.11n HT20 1 2412 15.32 6 2437 16.82 11 2462 17.67 IEEE 802.11n HT40 3 2422 16.02 6 2437 16.86 9 2452 17.30 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 3 7. Manufacturing Tolerance 2.4G WLAN IEEE 802.11b (Peak) Channel Channel 1 Channel 6 Channel 11 Target (dBm) 15.0 16.0 17.0 Tolerance ±(dB) 1.0 1.0 1.0 IEEE 802.11g (Peak) Channel Channel 1 Channel 6 Channel 11 Target (dBm) 15.0 16.0 17.0 Tolerance ±(dB) 1.0 1.0 1.0 IEEE 802.11n HT20 (Peak) Channel Channel 1 Channel 6 Channel 11 Target (dBm) 15.0 16.0 17.0 Tolerance ±(dB) 1.0 1.0 1.0 IEEE 802.11n HT40 (Peak) Channel Channel 3 Channel 6 Channel 9 Target (dBm) 16.0 16.0 17.0 Tolerance ±(dB) 1.0 1.0 1.0 8. Measurement Results 8.1 Standalone MPE Evaluation As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna refer to ant…

Text truncated - open the document above for the full version.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 Report No.: LCS210309117AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 37 FCC TEST REPORT For abode systems, inc Abode Cam 2 Test Model: 104061/A Prepared for : abode systems, inc Address : 2625 Middlefield Rd #900 Palo Alto, CA 94306, United States Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Shajing Street, Bao’an District, Shenzhen, Guangdong, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : March 09, 2021 Number of tested samples : 1 Serial number : Prototype Date of Test : March 09, 2021 ~ March 31, 2021 Date of Report : March 31, 2021 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 Report No.: LCS210309117AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 37 FCC TEST REPORT FCC CFR 47 PART 15 C(15.247) Report Reference No. ................. : LCS210309117AEA Date of Issue .................................. : March 31, 2021 Testing Laboratory Name ............ : Shenzhen LCS Compliance Testing Laboratory Ltd. Address .......................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Shajing Street, Bao’an District, Shenzhen, Guangdong, China Testing Location/ Procedure .......... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name ......................... : abode systems, inc Address .......................................... : 2625 Middlefield Rd #900 Palo Alto, CA 94306, United States Test Specification Standard ......................................... : FCC CFR 47 PART 15 C(15.247) Test Report Form No. .................. : LCSEMC-1.0 TRF Originator ................................ : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF .................................... : Dated 2019-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. EUT Description. .......................... : Abode Cam 2 Trade Mark ..................................... : Abode Test Model ...................................... : 104061/A Ratings ........................................... : DC 5V 1000mA Adapter parameters: Input: AC 100-240V 50/60Hz 0.25A Output: DC 5V 1000mA Result ............................................ : Positive Compiled by: Supervised by: Approved by: Lh Li/ Administrators Jin Wang / Technique principal Gavin Liang/ Manager SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 Report No.: LCS210309117AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 37 FCC -- TEST REPORT EUT......................................... : Abode Cam 2 Test Model............................... : 104061/A Applicant............................... : abode systems, inc Address.................................. : 2625 Middlefield Rd #900 Palo Alto, CA 94306, United States Telephone............................... : Fax.......................................... : Manufacturer........................ : abode systems, inc Address................................... : 2625 Middlefield Rd #900 Palo Alto, CA 94306, United States Telephone............................... : Fax.......................................... : Factory................................... : abode systems, inc Address................................... : 2625 Middlefield Rd #900 Palo Alto, CA 94306, United States Telephone............................... : Fax.......................................... : Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCS210309117AEA March 31, 2021 Date of issue SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 Report No.: LCS210309117AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 37 Revision History Revision Issue Date Revisions Revised By 000 March 31, 2021 Initial Issue Gavin Liang SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 Report No.: LCS210309117AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 5 of 37 TABLE OF CONTENTS Description ................................................................................................................................................. Page 1. GENERAL INFORMATION ................................................................................................................................... 6 1.1. DESCRIPTION OF DEVICE (EUT) ........................................................................................................................ 6 1.2. HOST SYSTEM CONFIGURATION LIST AND DETAILS .......................................................................................... 6 1.3. EXTERNAL I/O CABLE ......................................................................................................................................... 6 1.4. DESCRIPTION OF TEST FACILITY .........…

Text truncated - open the document above for the full version.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 1 of 59 Appendix A RF Test Data for 2.4G WIFI (Conducted Measurement) Product Name: Abode Cam 2 Trade Mark: Abode Test Model: 104061/A Environmental Conditions Temperature: 25  C Relative Humidity: 50% ATM Pressure: 100.0 kPa Test Engineer: Carl Fu Supervised by: Li Huan A.1 Duty Cycle Test Mode Test Channel Ant Duty Cycle[%] Verdict 11B 2437 Ant1 100 PASS 11G 2437 Ant1 100 PASS 11N20SISO 2437 Ant1 100 PASS 11N40SISO 2437 Ant1 100 PASS SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 2 of 59 Duty Cycle_11B_2437_Ant1 Duty Cycle_11G_2437_Ant1 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 3 of 59 Duty Cycle_11N20SISO_2437_Ant1 Duty Cycle_11N40SISO_2437_Ant1 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 4 of 59 A.2 Maximum Conducted Output Power Mode Channel Meas.Level [dBm] Limit [dBm] Verdict 11B LCH 15.65 30 PASS MCH 16.92 30 PASS HCH 17.71 30 PASS 11G LCH 14.77 30 PASS MCH 16.51 30 PASS HCH 17.55 30 PASS 11N20SISO LCH 15.32 30 PASS MCH 16.82 30 PASS HCH 17.67 30 PASS 11N40SISO LCH 16.02 30 PASS MCH 16.86 30 PASS HCH 17.30 30 PASS SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 5 of 59 Test Graphs 11B/LCH 11B/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 6 of 59 11B/HCH 11G/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 7 of 59 11G/MCH 11G/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 8 of 59 11N20SISO/LCH 11N20SISO/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 9 of 59 11N20SISO/HCH 11N40SISO/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 10 of 59 11N40SISO/MCH 11N40SISO/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 11 of 59 A.3 Maximum Power Spectral Density Mode Channel Meas.Level [dBm/3KHz] Limit [dBm/3KHz] Verdict 11B LCH -15.763 8 PASS MCH -14.937 8 PASS HCH -14.465 8 PASS 11G LCH -21.552 8 PASS MCH -19.885 8 PASS HCH -18.759 8 PASS 11N20SISO LCH -20.798 8 PASS MCH -19.271 8 PASS HCH -18.534 8 PASS 11N40SISO LCH -23.321 8 PASS MCH -22.127 8 PASS HCH -21.063 8 PASS Test Graphs 11B/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 12 of 59 11B/MCH 11B/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 13 of 59 11G/LCH 11G/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 14 of 59 11G/HCH 11N20SISO/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 15 of 59 11N20SISO/MCH 11N20SISO/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 16 of 59 11N40SISO/LCH 11N40SISO/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 17 of 59 11N40SISO/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 18 of 59 A.4 6dB Bandwidth Mode Channel 6dB Bandwidth [MHz] Limit [MHz] Verdict 11B LCH 10.09 ≥0.5 PASS MCH 10.10 ≥0.5 PASS HCH 10.10 ≥0.5 PASS 11G LCH 16.48 ≥0.5 PASS MCH 16.49 ≥0.5 PASS HCH 16.49 ≥0.5 PASS 11N20SISO LCH 17.62 ≥0.5 PASS MCH 17.63 ≥0.5 PASS HCH 17.62 ≥0.5 PASS 11N40SISO LCH 36.49 ≥0.5 PASS MCH 36.48 ≥0.5 PASS HCH 36.46 ≥0.5 PASS Test Graphs 11B/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 19 of 59 11B/MCH 11B/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 20 of 59 11G/LCH 11G/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 21 of 59 11G/HCH 11N20SISO/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 22 of 59 11N20SISO/MCH 11N20SISO/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 23 of 59 11N40SISO/LCH 11N40SISO/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 24 of 59 11N40SISO/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 25 of 59 A.5 Occupied Bandwidth Mode Channel Occupied Bandwidth [MHz] Limit [MHz] Verdict 11B LCH 13.054 No Limited PASS MCH 13.043 No Limited PASS HCH 13.052 No Limited PASS 11G LCH 16.697 No Limited PASS MCH 16.663 No Limited PASS HCH 16.703 No Limited PASS 11N20SISO LCH 17.537 No Limited PASS MCH 17.534 No Limited PASS HCH 17.536 No Limited PASS 11N40SISO LCH 36.446 No Limited PASS MCH 36.378 No Limited PASS HCH 36.423 No Limited PASS Test Graphs 11B/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 26 of 59 11B/MCH 11B/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 27 of 59 11G/LCH 11G/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 28 of 59 11G/HCH 11N20SISO/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 29 of 59 11N20SISO/MCH 11N20SISO/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 30 of 59 11N40SISO/LCH 11N40SISO/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 31 of 59 11N40SISO/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 Page 32 of 59 A.6 RF Conducted Spurious Emissions Mode Channel Pref [dBm] Max. Level [dBm] Limit [dBm] Verdic t 11B LCH 0.214 -37.387 -19.786 PASS MCH 1.589 -37.933 -18.411 PASS HCH 2.442 -37.563 -17.558 PASS 11G LCH -5.896 -37.831 -25.896 PASS MCH -4.315 -37.803 -24.315 PASS HCH -3.412 -36.534 -23.412 PASS 11N20 SISO LCH -5.81 -37.852 -25.810 PASS MCH -4.538 -36.269 -24.538 PASS HCH -3.902 -37.500 -23.902 PASS 11N40 SISO LCH -8.872 -37.197 -28.872 PASS MCH -7.987 -37.4…

Text truncated - open the document above for the full version.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 _______________________________________________________________________________________________ 1. TEST SETUP PHOTOGRAPHS 1.1. Photo of Radiated Emissions Measurement Fig. 1 Fig. 2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ARGFAC2 IC: 26939-AC2 _______________________________________________________________________________________________ 1.2. Photo of Conducted Emissions Measurement Fig. 3
