2ARI2-KSC200SMART CARD KEY

Copyright ⓒ DEKRA Korea Co., Ltd. All rights Reserved. User Manual Manual for vehicle manufacturer Product name: SMART CARD KEY OUTLINE 1. How to useSMART CARD KEY ‐SMART CARD KEY is a part of Remote Keyless System. ‐This unit controls door lock/door unlock/trunk open/panic/remote engine start-stop/forward/backward wirelessly. 2. Introduction of Transmitter (SMART CARDKEY) -These units use the battery ‐Frequency is 433.92MHz, 6.5GHz GENERAL DESCRIPTION PRIMARY FUNCTION ‐Remote door lock/door unlock/trunk open/panic/remote engine start-stop/forward/backward ‐Operating voltage: 3V DC ‐Center freq.: 433.92MHz UWB FUNCTION -UWB signal is used to enhance vehicle security and it operates automatically under necessary conditions regardless of the user's specificactionof pressing any buttons. MANUAL 1. LOCK Button If the LOCK button is pressed, then TRANSMITTER sends the LOCK data. 2. UNLOCK Button If the UNLOCK button is pressed, then TRANSMITTER sends the UNLOCK data. 3. TRUNK Button If the TRUNK button is pressed, then TRANSMITTER sends TRUNK open data. 4. PANIC Button If the PANIC button is pressed, then TRANSMITTER sends PANIC data. 5. Remote Engine Start-Stop Button If the Remote Engine Start-Stop Button is pressed, then TRANSMITTER sends the Remote Engine Start-Stop data. 6. Forward Button If the Forward button is pressed, then TRANSMITTER sends Forward data. 7. Backward Button If the Backward Button is pressed, then TRANSMITTER sends the Backward data. FCC Information to User ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttoPart15of theFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferenceinaresidential installation.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedin accordancewiththeinstructions,maycauseharmfulinterferencetoradiocommunications.However,thereisno guaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterference toradioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,theuserisencouraged totrytocorrecttheinterferencebyoneofthefollowingmeasures: •Reorientorrelocatethereceivingantenna. •Increasetheseparationbetweentheequipmentandreceiver. •Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveriscon-nected. •Consultthedealeroranexperiencedradio/TVtechnicianforhelp. Caution Modificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoidtheuser’sauthoritytooperate theequipment. FCCComplianceInformation:ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothe followingtwoconditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptany interferencereceived,includinginterferencethatmaycauseundesiredoperation

KONA I Co., Ltd. 8F, 3, Eunhaeng-ro, Yeongdeungpo-gu, Seoul, Republic of Korea Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia MD 21046 USA Date: 20 June, 2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2ARI2-KSC200 “KONA I Co., Ltd.” certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Jemma Kim / Project Manager KONA I Co., Ltd. KONA I Co., Ltd. 8F, 3, Eunhaeng-ro, Yeongdeungpo-gu, Seoul, Republic of Korea Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia MD 21046 USA Date: 20 June, 2023 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2ARI2-KSC200 “KONA I Co., Ltd.” certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Jemma Kim / Project Manager KONA I Co., Ltd.

Certification designating a U.S. Agent for service of process: As required by section 2.911(d)(7), the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. In either scenario, the designation of the U.S. agent for service of process should be provided as an attachment to the equipment authorization application. The applicant must provide a written certification, which must: i. Be signed by both the applicant and designated agent for service of process, if the agent is different from the applicant. ii. Acknowledge the applicant’s consent and the designated agent’s obligation to accept service of process. iii. Provide a physical U.S. address and email for the designated agent. iv. Acknowledge the applicant’s acceptance to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Unofficial information provided by FCC personnel on February 14, 2023, via the monthly call with the TCB Council: The Agent for Process of Service: •cannot be a TCB or affiliated with a TCB (e.g. could not be a person who works for a TCB or a company that owns or is owned by the TCB) •cannot be a [FCC recognised] Lab or affiliated with a test lab (e.g. could not be a person who works for a Lab or a company that owns or is owned by the Lab) •Agent can be Individual Entity or a Company Entity •Agent Entity must be located in US, US address/phone •Entity acting as Agent must have FRN (best practice, put FRN on Agent Letter) •Agent letter does not have to be FCC ID specific, can be general Agent for Grantee For devices being marketed or for which marketing has ceased for less than 1 year, if the Agent for Process of Service changes, then for every TC Number the TCB must request the FCC to put application into Audit Mode and Agent Letter needs to be updated (superseded). NOTE: The U.S. Agent for Service of Process should not be confused with the authorized agent used for signing the 731 form, other cover letters within the application, and/or the agent who may interface with the TCB. KONA I Co., Ltd. 8F, 3, Eunhaeng-ro, Yeongdeungpo-gu, Seoul, Republic of Korea U.S. Agent Designation for Service of Process ATTENTION: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA REGARDING: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Approve-IT, Inc. Contact Name: Nathan Grinager Street Address: 8011 34 th Ave South, Suite 342 City/Province/Zip: Bloomington, MN 55425 Telephone No: 651-247-1678 Email: [email protected] FRN #: 0027533835 This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: Signed by (Printed Name/Title): Nathan Grinager / Co-President *This letter must be dated within 1-year (update if other terms apply) of the date the application is submitted to the TCB for device certification The Applicant confirms its explicit consent and acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name:KONA I Co., Ltd. FCC ID: 2ARI2-KSC200 Contact Name: Jemma Kim Address: 8F, 3, Eunhaeng-ro, Yeongdeungpo-gu, Seoul, Republic of Kore Zip:07237 Telephone No: +82 2-2168-7650 Email: [email protected] Applicant Signature: Date: 13 June,2023 Signed by (Printed Name/Title): Jemma kim / Project Manager June 16, 2023

Declaration of Equivalence For declaration of equality between a product variant to be certified with reference to an original product. To be issued and signed by the company responsible for the product variant. Declare on our sole responsibility that the product - Original Model Product Information Product ID: KSC200 are in all relevant parts identical to the product - Variant Model Product Information Product ID: KSC201, KSC202, KSC203, KSC204, KSC205 - The difference between (original design) and (variant design) is : KSC201 : The difference from the original model is that the number of buttons is changed from 8 to 7. KSC202 : The difference from the original model is that the number of buttons is changed from 8 to 6. KSC203 : The difference from the original model is that the number of buttons is changed from 8 to 5. KSC204 : The difference from the original model is that the number of buttons is changed from 8 to 4. KSC205 : The difference from the original model is that the number of buttons is changed from 8 to 3. (Variant model is completely same to original model(electrically and mechanically is same) We, the undersigned, hereby declare that the Second Manufacturer KONA I is identical in both design and implementation. Signed by Company Name : KONA I Co., Ltd. Name : Jemma Kim Tel :+82 2-2168-7650 Korea / 13 June,2023 (Place, date of issue) (Signature / stamp) Jemma Kim / Project Manager

KONA I Co., Ltd. 8F, 3, Eunhaeng-ro, Yeongdeungpo-gu, Seoul, Republic of Korea Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: 2ARI2-KSC200 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics / Block Diagram / Operational Description / Parts List Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. 2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days External Photos / Internal Photos / Test Setup Photos / User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and such information will be available for public review once the grant of equipment authorization is issued. Sincerely Yours, Jemma Kim / Project Manager KONA I Co., Ltd.

KONA I Co., Ltd. 8F, 3, Eunhaeng-ro, Yeongdeungpo-gu, Seoul, Republic of Korea Date: 13 June 2023 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 ,Industry Canada c.c. Timco Engineering, Inc. Certification Division 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA FCC ID : 2ARI2-KSC200 To whom it may concern: I, the undersigned, hereby authorize Technical Manager Isaac Jin of DEKRA Korea Co., Lt d.and here after referred to as DEKRA Korea Co., Ltd. to act on our behalf in all manners r elating to application for equipment authorization, including signing of all documents rela ting to these matters. Any and all acts carried out by Technical Manager Isaac Jin of DEKRA Korea Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing DEKRA Korea Co., Ltd. as our agent, we still recognize that we are responsible to: a)comply with the relevant provisions of the certification program; b)make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c)make claims regarding certification only in respect of the scope for which certification has been granted; d)do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding KONA I Co., Ltd. 8F, 3, Eunhaeng-ro, Yeongdeungpo-gu, Seoul, Republic of Korea our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Jemma Kim / Project Manager KONA I Co., Ltd. REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

Copyright ⓒ DEKRA Korea Co., Ltd. All rights Reserved. External Photos Copyright ⓒ DEKRA Korea Co., Ltd. All rights Reserved. External Photos Front Rear Copyright ⓒ DEKRA Korea Co., Ltd. All rights Reserved. External Photos Left Right Copyright ⓒ DEKRA Korea Co., Ltd. All rights Reserved. External Photos Top Bottom

Copyright ⓒ DEKRA Korea Co., Ltd. All rights Reserved. Label Informaion Copyright ⓒ DEKRA Korea Co., Ltd. All rights Reserved. Label information Location&Drawing The label needs to be located on the front side of the product, which should be found at lower left.

Copyright ⓒ DEKRA Korea Co., Ltd. All rights Reserved. Internal Photos Copyright ⓒ DEKRA Korea Co., Ltd. All rights Reserved. Internal Photos PCB Front PCB Rear Copyright ⓒ DEKRA Korea Co., Ltd. All rights Reserved. Internal Photos Inside Antenna UWB Antenna RKE Antenna

This test report shall not be reproduced, except in full, without the written approval * RF Exposure FCC ID: 2ARI2-KSC200 1. Regulation According to the KDB 447498 D04 V01, the following RF exposure evaluation shall to demonstrate RF exposure compliance. Per § 1.1307(b)(3)(i)(A), a single RF source is exempt RF device (from the requirement to show data demonstrating compliance to RF exposure limits, as previously mentioned) if the available maximum time-averaged power is no more than 1 ㎽, regardless of separation distance. This exemption applies to all operating configurations and exposure conditions, for the frequency range 100 ㎑ to 100 ㎓, regardless of fixed, mobile, or portable device exposure conditions. This is a standalone exemption, and it cannot be applied in conjunction with any other test exemption. 2. RF Exposure Compliance Issue UWB Overview Mode Frequency [㎒] Conducted power [㏈m] Average power [㎽] Limit [㎽] UWB 6 489.60 -17.22 0.02 1.00 Calculation : Maximum allowed EIRP(§15.519) = -41.30 ㏈m /㎒ (=7.4131E-05㎽/㎒) Maximum measurement bandwidth = 582.24 ㎒ Maximum antenna gain = 3.57 ㏈i Conducted average power = (7.4131E-05㎽/㎒ * 582.24 ㎒) – 3.57 ㏈i = -17.22 ㏈m = 0.02 ㎽ Conclusion: The output power of EUT is no more than 1mW, regardless of separation distance. Therefore, this EUT is exempt from SAR test.

Copyright ⓒ DEKRA Korea Co., Ltd. All rights Reserved. Antenna Datasheet DocumentDatasheet TypePCB Antenna ApplicationRF 433.92MHz PartNo.RKEAnt Revision1.0 Application RF 433.92MHz(Smart Card Key) Features PCB Antenna Size(56.15*7.65mm) Performance Optimizing with external lumped matching components DATASHEET 1 Table of Content Datasheet / PCB Antenna / RF 433.92MHz RKE Ant (Rev. 1) Rev. NoDataTitleContentsPage 02022. 07. 12New Published 12022. 08. 12Changed PCB Pattern Revision History 1. Specifications 1.1 Electrical Specifications3 1.2 Mechanical Specification3 1.3Appearance and Material3 2.PCB Design 2.1Board Dimension 3. Measurement Results6 3.1 MeasuredAntenna Gain7 3.2 Measured Radiation Patterns8 2 Datasheet / PCB Antenna / RF 433.92MHz RKE Ant (Rev. 1) NoItemSpecRemark 1Frequency Range [MHz]433.92 2VSWRMax 2.0:1 3DirectionalOmni directional 4 Impedance [Ω] Nominal 50 1.Specifications 1.1 Electrical Specifications NoItemSpecRemark 1Dimensions56.15*7.65mm 1.2 Mechanical Specification NoItemSpecRemark 1AntennaPCB Pattern*. 1)PCB Stack-up *. 2)CCL Datasheet 1.3 Appearance and Material 3 *. 1) PCB Layer Stack-up 4 Datasheet / PCB Antenna / RF 433.92MHz RKE Ant (Rev. 1) *. 2) CCL datasheet 5 Datasheet / PCB Antenna / RF 433.92MHz RKE Ant (Rev. 1) Datasheet / PCB Antenna / RF 433.92MHz RKE Ant (Rev. 1) 2. PCB Design 2.1 Board Dimension 6 Datasheet / PCB Antenna / RF 433.92MHz RKE Ant (Rev. 1) 3. Measurement Results 3.1 Measured Antenna Gain 7 Datasheet / PCB Antenna / RF 433.92MHz RKE Ant (Rev. 1) 3. Measurement Results 3.2 Measured Radiation Patterns 8 Application UWB (Ultra Wide Band, 6200~8250MHz) Features Monopole Structure Size (4.0*2.0*1.2mm 3 ) Performance Optimizing with external lumped matching components SMT Available under Pb-free Condition RoHS Compliant DATASHEET Notes The contents of this datasheet are subject to change without notice. Please confirm the specifications and delivery conditions when placing your order. AMOTECH DocumentDatasheet TypeChip Antenna ApplicationUltraWide Band Part No.AMAN402012ST02 Revision3.0 Datasheet / Chip Antenna / Ultra Wide Band AMAN402012ST02 (Rev. 3) 2 Rev. NoDateTitleContentsPage 0 2018. 09. 10New Published 1 2019. 09. 05 Addeddimension of bottom pattern 22020. 11. 05 Added dimension of antenna bottom pattern ChangedPCB design guide 32021.07. 26ChangedFrequency range and measured results Table of Content Revision History 1.Specifications3 1.1 Electrical Specifications 1.2 Mechanical Specifications 1.3 Appearance and Material 2. PCB Design for Test4 2.1 Evaluation BoardDimension 2.2 GND Fill Cut Area Dimension 2.3 PCB Design Guide 3. Measurement Results6 3.1 Typical Measurement Results (VSWR & Return-loss) 3.2 Measured Antenna Gain 3.3 Measured Radiation Patterns 4. Reliability8 5. Cautions (Recommendations)8 6. Soldering Reflow Profile8 7. Packing9 7.1 Carrier Tape Dimension 7.2 PackingQuantity 7.3 Packing Label Datasheet / Chip Antenna / Ultra Wide Band AMAN402012ST02 (Rev. 3) 3 NoItemSpec. Remark 1Frequency Range [MHz] 6200 ~ 8250 2VSWRMax 2.0:1 3 PolarizationLinear 4 Impedance [Ω]Nominal 50 The results are measured on the 30 * 20mm 2 evaluation board(EVB). No Item Spec.Remark 1Dimensions (L*W*H)4.0 * 2.0 * 1.2 mm 3 2Unit Weighttyp. 35 mg 3Operating Temperature-40 ~ 125 °C 1.1 Electrical Specifications 1.2 Mechanical Specifications NoNameFunctionMaterial 1ElectrodeRadiation ElementAg 2 MarkingIdentification Mark Ink 3 Ceramic Body-Ceramic 1.3 Appearance & Material 1. Specifications [unit : mm] Top & Side Bottom ① ③ ② Datasheet / Chip Antenna / Ultra Wide Band AMAN402012ST02 (Rev. 3) 4 2.1 Evaluation Board Dimension 2. PCB Design for Test 2.2 GND Fill Cut Area Dimension SMD pad Antenna top pattern Mask open pad for SMD 20 30 Matching circuit 5.5 Unit : mm Datasheet / Chip Antenna / Ultra Wide Band AMAN402012ST02 (Rev. 3) 5 2.3 PCB Design Guide NoPin Assignment ①N/C(Dummy pad) ② Connected feed line ③ N/C(Dummy pad) ① ② ③ Antenna top Antenna Bottom PCB pattern It should be designed with a 50ohm impedance line. Mask open for SMD Unit : mm ① ② ③ Datasheet / Chip Antenna / Ultra Wide Band AMAN402012ST02 (Rev. 3) 6 Measured VSWR of AMAN402012ST02 EVB 3.1 Typical Measurement Result (VSWR & Return-loss) 3. Measurement Result Freq. [MHz]Peak Gain [dBi]Avg. Gain [dBi]Efficiency [%] Remark 6200 1.48-3.4944.8 62462.28-2.8152.4 CH5 6490 2.70-1.9663.4 67403.57-1.3273.8 77383.36-1.1277.3 CH979872.58-2.2160.1 8237 1.80-3.0050.0 82501.89-3.1748.1 3.2 Measured Antenna Gain 100 pF Datasheet / Chip Antenna / Ultra Wide Band AMAN402012ST02 (Rev. 3) 7 3.3 Measured Radiation Patterns 2D H-Cut [θ=90, XY plane] 2D E2-Cut [φ=90, YZ plane] 2D E1-Cut [φ=0, ZX plane] 3D radiation pattern 6490 MHz @CH57987 MHz @CH9 Y E1 Z X θ 6490 MHz 7987 MHz Datasheet / Chip Antenna / Ultra Wide Band AMAN402012ST02 (Rev. 3) 8 F SMD PAD PCB 4. Reliability 5. Cautions (Recommendations ) Storage environment of parts must be at ambient temperatures of 5 to 40°C and maximum 60%RH humidity The parts should be used within 6 months from the time of delivery. If stored for over 6 months, check for solder ability before use. 6. Soldering Reflow Profile NoItemTest ConditionTest Requirements 1 Adhesive Strength of Termination Apply force on SMT chip till detached from PCB. 1. The chip shouldn’t be detached from PCB within force (F) 5 kgf. 2.The force (F) when the chip is detached from PCB is should be greater than 5 kgf. 2 Thermal Shock (Cycle) 1. Step 1 : -40 ±3°C, 30 min Step 2 : +85 ±3°C, 30 min 2. Number of cycle : 30 1. No visual damage 2. Within electric specification (VSWR) 3 High Temperature Resistance 1. Temperature : +85 ±5°C 2. Time : 96 ±hrs. 1. No visual damage 2. Within electric specification (VSWR) 4Humidity 1. Humidity : 85 % RH Temperature : +85 ±3°C 2. Time : 96 ±hrs. 1. No visual damage 2. Within electric specification (VSWR) 5Vibration 1.10-2000㎐, Amp 1.5mm, 5g 2. Time : 20 minutes, 3. 12 cycles each of 3 orientations 1. No visual damage 2. Within electric specificati…

Text truncated - open the document above for the full version.

verify No.724556778537 Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-70-5008-1021 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SRF0180-C Page (2) of (26) KCTL-TIR001-003/7 (220705) KP23-03257 REPORT REVISION HISTORY Date Revision Page No 2023-06-14 Originally issued - 2023-06-20 Updated 1,5,9 2023-07-12 Updated 12 2023-07-24 Updated 3,9,21 This report shall not be reproduced except in full, without the written approval of Eurofins KCTL Co.,Ltd. This document may be altered or revised by Eurofins KCTL Co.,Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by Eurofins KCTL Co.,Ltd. will constitute fraud and shall nullify the document. This test report is a general report that does not use the KOLAS accreditation mark and is not related to KS Q ISO/IEC 17025 and KOLAS accreditation. Note. The report No. KR23-SRF0180-B is superseded by the report No. KR23-SRF0180-C. General remarks for test reports Statement concerning the uncertainty of the measurement systems used for the tests (may be required by the product standard or client) Internal procedure used for type testing through which traceability of the measuring uncertainty has been established: Procedure number, issue date and title: Calculations leading to the reported values are on file with the testing laboratory that conducted the testing. Statement not required by the standard or client used for type testing Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-70-5008-1021 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SRF0180-C Page (3) of (26) KCTL-TIR001-006/4 (220705) KP23-03257 CONTENTS 1. General information ...................................................................................................... 4 2. Device information ........................................................................................................ 4 2.1. Frequency/channel operations ................................................................................ 4 2.2. Accessory information ............................................................................................. 4 2.3. EUT Description ...................................................................................................... 5 2.4. RF power setting in TEST SW ................................................................................ 5 3. Antenna requirement .................................................................................................... 5 4. Summary of tests .......................................................................................................... 6 5. Measurement uncertainty ............................................................................................. 7 6. Test results ................................................................................................................... 8 6.1. 10 ㏈ Bandwidth .................................................................................................... 8 6.2. Peak Power & Maximum Average Emission ......................................................... 10 6.3. Cease Transmission Time..................................................................................... 12 6.4. Radiated Spurious Emission – Above 960 ㎒ ....................................................... 13 6.5. Radiated Spurious Emission – Below 960 ㎒ ....................................................... 24 7. Measurement equipment ............................................................................................ 26 Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-70-5008-1021 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SRF0180-C Page (4) of (26) KCTL-TIR001-006/4 (220705) KP23-03257 1. General information Client : KONA I Co., Ltd. Address : 8F, 3, Eunhaeng-ro, Yeongdeungpo-gu, Seoul, Republic of Korea Manufacturer : KONA I Co., Ltd. Address : 8F, 3, Eunhaeng-ro, Yeongdeungpo-gu, Seoul, Republic of Korea Laboratory : Eurofins KCTL Co.,Ltd. Address : 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Accreditations : FCC Site Designation No: KR0040, FCC Site Registration No: 687132 VCCI Registration No. : R-20080, G-20078, C-20059, T-20056 CAB Identifier: KR0040, ISED Number: 8035A KOLAS No.: KT231 2. Device information Equipment under test : SMART CARD KEY Model : KSC200 Frequency range : 6 489.6 ㎒ Modulation technique : OFDM Number of channels : 1 ch Power source : DC 4.2 V (Battery) Antenna type : Chip Antenna Antenna gain : 3.57 ㏈i Software version : 1.0 Hardware version : 1.0 Test device serial No. : N/A Operation temperature : -20 °C ~ 50 °C 2.1. Frequency/channel operations This device contains the following capabilities: Ultra-Wideband Ch. Frequency (㎒) 5 6 489.6 Table 2.1.1. Ultra-Wideband 2.2. Accessory information Equipment Manufacturer Model Serial No. Power Source Rechargeble lithium ion battery NGK INSULATORS, LTD. EC382704P-C - 4.2V ~ 3.0V 24㎃h Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-70-5008-1021 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SRF0180-C Page (5) of (26) KCTL-TIR001-006/4 (220705) KP23-03257 2.3. EUT Description Equipment Description Channel Configuration Preamble Handheld Device 5 SP3 9 2.4. RF power setting in TEST SW Channel Configuration Preamble Frequency (㎒) Power Setting 5 SP3 9 6 489.6 - 3. Antenna requirement Requirement of FCC part section 15.203: An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator shall be considered sufficient to comply with the provisions of this section. - The transmitter has attached Dielec…

Text truncated - open the document above for the full version.

This document shall not be reproduced, except in full, without the written approval Test setup photos - Below 30 ㎒ (9 ㎑ ~ 30 ㎒) - Below 1 ㎓ (30 ㎒ ~ 1 ㎓) This document shall not be reproduced, except in full, without the written approval - Above 1 ㎓ (1 ㎓ ~ 18 ㎓) - Above 18 ㎓ (18 ㎓ ~ 40 ㎓)
