2ARI5-MJ2-01Wireless Power Bank

MagEZ Juice 2 User Manual Welcome&Intro Package Includes Key Features Compatibility Quick Guide Buttons and LED Indicators Spec Warranty Exclusion Important Customer Service FCC WARNING Thank you for purchasing the PITAKA MagEZ Juice 2. You can slide MagEZ Juice 2 in the Dock to use it as a wireless charging dock, or you can slide MagEZ Juice 2 up f rom the Dock to use it as a wireless power bank. Contents Welcome & Intro 1 2 3 4 4 10 12 15 16 16 17 18 1 Package Includes 1. MagEZ Juice 2 Power Bank *1 2MagEZ Juice 2 Dock *1 3. Charger *1 4. Document Kit *1 ①② ③④ 2 Key Features Magnetic Attach. Best Compatible with MagEZ Case and MagEZ Case Pro. Universal Compatibility: Works with all Qi-enabled devices. Compact & ergonomic design. Comfortable to hold in hands. Safe and reliable. Designed to provide overvoltage protection, under-voltage protection, over-temperature protection, overcurrent protection, short-circuit protection and FOD. Wireless charging stand with pass-thru charging technology which powers your phone in priority while assign juices synchronously to the power bank battery. You can set up the Dock on table with washable reusable gel. 3 Compatibility Quick Guide With the slide-or-detach design, you can slide up to take your phone with the MagEZ Juice Which is automatically attached to use the power bank on-the-go, or you can take your phone by detaching f rom the Dock. All wireless charging receiving devices that support Qi standard. 4 1.If you're using a MagEZ Case, place it on your smartphone. Preparing Your Phone to Use With MagEZ Juice 2 5 2.If you're using an iPhone 12 it can be used with or without a MagEZ Case. 1.Push the power button to turn on the power bank. Charge Your Phone Using the MagEZ Juice 2 Power Bank 6 2.Attach the power bank to the back of your device. Use MagEZ Juice 2 as a desktop stand while charging. 7 1.Slide the power bank into the dock. 8 3.Slide up your phone and power bank to remove them together. 2.Attach your phone to the power bank. 9 4.Remove your phone to leave the power bank in the dock. *Scan QR code for video instruction. Buttons and LED Indicators 10 Button LED indicators 11 When clicking the button once, the LED indicators will light on as below; When connecting the MagEZ Juice 2 with power, the LED indicators will light on based on the remaining battery and keep blinking. When charging your phone with the MagEZ Juice 2, the LED indicators will light on based on the remaining battery. Battery Percentage Indication *Applicable only when home button is clicked. 0% ~ 25% 25% ~ 50% 50% ~ 7 5% 75% ~ 100% Spec 12 Width Length Thickness Battery Capacity Input Output Wireless Output Transmission Distance Transmission Efficiency Operating Temperature Storage Temperature Wireless Charging Frequency 61.91mm 107.60mm 12.62mm 67.90mm 113.80mm 99.70mm Specification 2800mAh DC 5V/0.5A DC 5V/0.5A DC 5V/1A 8mm 75% Max -10~30 -20~60 110KHZ-205KHZ MagEZ Juice 2 Dock Items 13 61.91 mm 107.60 mm 12.62 mm MagEZ Juice 2 14 99.70 mm67.90mm 113.80 mm Dock The PITAKA MagEZ Juice 2 is warranted for 12 months f rom the date of purchase. The MagEZ Juice 2 is warranted to be f ree defects in materials and function under regular use for the lifetime of the product. A defect is defined as an imperfection or flaw that is produced by a manufacturing error, including malfunction of wireless charging or surface defect, etc. This warranty is non-transferable and covers only the original end-user purchaser. PITAKA will only authorize the warranty claim if the product was purchased from the official store or authorized dealer. MODIFICATION: Any change or modification of this device will void the warranty. 15 Warranty Damages don’t cover those resulting f rom abuse, not correctly maintained, alteration or misuse (including disassemble, drops), abnormal wear and tear, cosmetic damages that do not affect the functionality. 1.Do not disassemble the MagEZ Juice 2 or attempt to modify it in any way. 2.Do not attempt to power the MagEZ Juice 2 with any connector other than Type-C connector. 3.Do not attempt to replace any part of the MagEZ Juice 2. 4.Do not keep the MagEZ Juice 2 in a high-tem- perature environment, including heat caused by intense sunlight or other forms of heat. Do not place it in fire or other excessively hot environ- ments. 5.Do not throw the MagEZ Juice 2 in any common dustbin. 16 Important Exclusion 6.All parts have gone through a thorough quality assurance inspection. If you find that your MagEZ Juice 2 is excessively hot, is emitting odor, is deformed, abraded or is experiencing or demonstrating an abnormal phenomenon, immediately stop all product use and contact manufacturer. 7.If theMagEZ Juice 2 is intended by the purchaser to be used by a minor, purchasing adult agrees to provide detailed instructions and warnings to any minor prior to use. Failure to do so is the sole responsibility of the purchaser, who agrees to indemnify manufacturer for any unintended use/misuse by a minor. Phone+852 9202 6223 E-mail: [email protected] Website: www.ipitaka.com 17 Customer Service This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio f requency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communica- tions. However, there is …

Text truncated - open the document above for the full version.

FCCID:2ARI5-MJ2-01

LabelLocationOnEUT Label ProductName:WirelessPowerBank ModelNo.:MJ2-01 FCCID:2ARI5-MJ2-01 ThisdevicecomplieswithPart15oftheFCCRules.Operation issubjecttothefollowingtwoconditions: (1)Thisdevicemaynotcauseharmfulinterference,and (2)Thisdevicemustacceptanyinterferencereceived,including interferencethatmaycauseundesiredoperation.

FCCID:2ARI5-MJ2-01 ANT

version01 ShenzhenLingyiInnovationTechCo.,Ltd. DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.:MJ2-01 FCCID:2ARI5-MJ2-01 fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsforinternalantennatype(s) describedbelow: ModelNo.ofantenna:MJ2-01 Typeofantenna:InductiveloopcoilAntenna Gainoftheantenna:0dBi Frequencyrange:110.1-205KHz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Companyname: ShenzhenLingyiInnovationTechCo.,Ltd. Address:ShenzhenLingyiInnovationTechCo.,Ltd.12F,BlockC,CentralAvenueBuilding,Xixiang BLVDWest,BaoanDistrict,ShenzhenChina City:Shenzhen ZIP/Postalcode:N/A Country:China Place:ChinaDate: 2021-01-13 Signature:
