2ARJ5-ETAP04Access Point

ETAP04 user 's manual Suzhou Etag-Technology Electronic Technology Co., Ltd 0 / 11 ETAP04 user 's manual User No: Item No: technical support：[email protected] Document Version 1.2 Mirror Version 1.0.114 AgentVersion 1.0.10 Release Date 2022-10-22 ETAP04 user 's manual Suzhou Etag-Technology Electronic Technology Co., Ltd 1 / 11 Limited scope of use catalogue 1 Introduction ...................................................................................................................... 2 1.1 ETAP04 brief introduction ..................................................................................... 2 1.2 ETAP04 Agent brief introduction ........................................................................... 3 2 ETAP04 use ........................................................................................................................ 3 2.1 Physical description ............................................................................................... 3 2.2 Display code .......................................................................................................... 5 3 ETAP04 Agent use .............................................................................................................. 5 3.1 Main interface ....................................................................................................... 5 2.3 Parameter Configuration Description ................................................................... 6 2.4 Description of distribution network mode ............................................................ 7 2.4.1 Automatic acquisition ....................................................................................... 7 2.4.2 Automatic Area Allocation ................................................................................ 7 2.4.3 Manual Assignment ........................................................................................... 7 2.5 Description of automatic configuration ................................................................ 8 2.6 Manual Configuration Instructions ....................................................................... 8 2.7 USB flash disk configuration description ............................................................... 8 ETAP04 user 's manual Suzhou Etag-Technology Electronic Technology Co., Ltd 2 / 11 Limited scope of use 1 Introduction This document is applicable to projects based on ESL Gen3。 This document is applicable to projects based on eRetail 3.1 or higher。 1.1 ETAP04 brief introduction ERetail e-tag solution can be simply divided into four parts: upper layer customer application, eRetail 3.1 system, ETAP04 and ESL equipment。 The upper customer application refers to the data management system in the final customer business project, such as POS, SAP/ERP, WMS, HIS, etc； eRetail 3.1 system is responsible for integrating with the customer's upper application data, managing ETAP04 and ESL equipment, and packaging the upper application data and transferring it to the hardware； ETAP04，also known as the base station, or AP, is the subject object described in this manual (D33). The ESL here refers specifically to ESL Gen3.0。 The overall structure of the electronic label solution is divided as follows： POS/ERP/WMS ... eRetail 3.1 eStation TCP/IP ESL Gen 3.0 300000000001 ESL Gen 3.0 300000000001 ETAP04 It has the following characteristics： 1 Support multiple deployment modes, including traditional fixed parameter deployment, and automatic configuration for rapid deployment； 2 Support multi protocol extension: according to project requirements, the mainstream Internet of Things communication protocol extension can be added； 3 Anti network fluctuation: support local caching of large amounts of data, and protect the base station from network jitter. Specific definitions of terms： ETAP04, refers to the data node in the eRetail tag solution, which is usually called the base station or AP. The BTS contains two identity attributes: ShopCode and ID. The store number range is 0000 to 9999, and the ID range is 00 to 99. Under the same store number, the BTS ID cannot be duplicate, or there will be a logical conflict。 ETAP04 supports concurrent operations and offline data caching。 ShopCode also known as store number, is used for logical division of data (including eStaion, ESL and other data)。 ID , also known as the base station number, is designed to be forward compatible with the logic of eRetail 1.0, 2.0, and 3.0. In fact, the MAC address is the only one used for identity verification。 be careful: ShopCode and ID is the logic concept attached to ETAP04 by eRetail system。 ETAP04 user 's manual Suzhou Etag-Technology Electronic Technology Co., Ltd 3 / 11 Limited scope of use 1.2 ETAP04 Agent brief introduction The Station Agent is the deployment and configuration tool of ETAP04. It is mainly used by field implementers to configure the connection information of the redirect server to ETAP04 devices, and also used for OTA upgrading (eRetail system also supports OTA). In addition, ETAP04 Agent also provides testing functions for production personnel. For the method of recording ETAP04 firmware, please refer to F01 ETAP04 Production Operation Guide. The ETAP04 Agent is used for NET 6.0. The communication between it and ETAP04 needs to be kept in the same LAN, and the network administrator has allowed UDP data broadcast packets of the LAN。When the field implementer cannot connect to any ETAP04 device in the ETAP04 Agent, he/she should first confirm with the network administrator whether the UDP datacast packet of the LAN is disabled. 2 ETAP04 use 2.1 Physical description model ETAP04 size（L*W*H） 190mm*190mm*40mm weight 360g Interface USB 2.0 network Ethernet power supply DC 12V 1A display 4-digit digital tube ETAP04 user 's manual Suzhou Etag-Technology Electronic Technology Co., Ltd 4 / 11 Limited scope of use （Front view） （Back view） （Interface View） ETAP04 user 's manual Suzhou Eta…

Text truncated - open the document above for the full version.

Best Regards, Sincerely Yours, Signature: Typed or Printed Name: Zhang Haiyan Title: Manager Company: Suzhou Etag-Technology Corporation Add: Room 236,2/F Ming De Building, No.166 Ren ai Road, Suzhou Industrial Park, Suzhou, China Tel: 0512-62796964 Fax: 0512-62796964 E-mail: [email protected] Date: 2022-11-25 Attestation Letter FEDERAL COMMUNICATIONS COMMISSION Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: The chip PHY6212 installed in our product Access Point (model name: ETAP04, FCC ID: 2ARJ5-ETAP04), which support BLE 5.0(BLE 1Mbps and BLE 2Mbps), ANT+ and Private 2.4GHz protocol. But for the product, it only activates BLE 1Mbps, the other functions are disabled by using the software. Please contact me if there is need for any additional clarification or information.

QA-FR-170-B Company Name: Suzhou Etag-Technology Corporation Add: Room 236,2/F Ming De Building, No.166 Ren ai Road, Suzhou Industrial Park, Suzhou, China Tel: 0512-62796964 Fax: 0512-62796964 E-mail: [email protected] FCC Authorization Date: 2022-11-25 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We , Suzhou Etag-Technology Corporation, Hereby authorizes China Certification ICT Co., Ltd (Dongguan) to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by China Certification ICT Co., Ltd (Dongguan) on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Client’s signature Printed Name: Zhang Haiyan Title:Manager

QA-FR-171-A Company Name: Suzhou Etag-Technology Corporation Add: Room 236,2/F Ming De Building, No.166 Ren ai Road, Suzhou Industrial Park, Suzhou, China Tel: 0512-62796964 Fax: 0512-62796964 E-mail: [email protected] FCC Confidential Authorization Date: 2022-11-25 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2ARJ5-ETAP04 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, (Suzhou Etag-Technology Corporation) hereby requests long-term confidential treatment of information accompanying this application as outlined below: • Block Diagram • Schematics • Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Signature: Printed Name: Zhang Haiyan Title: Manager

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS Uncover chip Module 3 Antenna Module 1 Antenna Module 3 Antenna Module 2 Antenna Module 2 Antenna Module 1 Antenna Module 1 Module 3 Module 2 chip chip chip chip chip chip chip chip chip chip chip chip chip port port

China Certification ICT Co., Ltd (Dongguan) Report No.: CR221156310-00A Page 55 of 57 5. RF EXPOSURE EVALUATION 5.1 Applicable Standard FCC §15.247 (i) Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See §1.1307(b)(1) of this chapter. 5.2 Procedure According to §1.1307(b)(3)(ii)(B) Simultaneous Transmission with both SAR-based and MPE-Based Test Exemptions This case is described in detail in § 1.1307(b)(3)(ii)(B) and covers the situations where both SAR-based and MPE-based exemption may be considered for test exemption in fixed, mobile, or portable device exposure conditions. For these cases, a device with multiple RF sources transmitting simultaneously will be considered an RF exempt device if the condition of Formula (1) is satisfied. Table 1 to § 1.1307(b)(3)(i)(C) - Single RF Sources Subject to Routine Environmental Evaluation RF Source frequency (MHz) Threshold ERP (watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 0.0128 R 2 f. 1,500-100,000 19.2R 2 . China Certification ICT Co., Ltd (Dongguan) Report No.: CR221156310-00A Page 56 of 57 China Certification ICT Co., Ltd (Dongguan) Report No.: CR221156310-00A Page 57 of 57 5.3 Measurement Result Radio Frequency (MHz) λ/2 Π (mm) Distance (mm) Exemption ERP (mW) Maximum Conducted Power including Tune-up Tolerance (dBm) Antenna Gain (dBi) ERP dBmmW BLE Module 1 2402-2480 19.88 200 768 1 2.39 1.24 1.33 BLE Module 2 2402-2480 19.88 200 768 1 2.39 1.24 1.33 BLE Module 3 2402-2480 19.88 200 768 1 2.39 1.24 1.33 Note: The Value of Maximum Conducted Power including Tune-up Tolerance was declared by the customer. The BLE Modules can transmit simultaneously. =ERP BLE Module 1 / ERP th + ERP BLE Module 2 / ERP th + ERP BLE Module 3 / ERP th =1.33/768 + 1.33/768 + 1.33/768 =0.005 < 1.0 Result: The device compliant the MPE-Based Exemption at 20cm distances. ===== END OF REPORT ====

TEST REPORT Applicant: Suzhou Etag-Technology Corporation Address: Room 236,2/F Ming De Building, No.166 Ren ai Road, Suzhou Industrial Park Suzhou China FCC ID: 2ARJ5-ETAP04 Product Name: Access Point Standard(s): 47 CFR Part 15, Subpart C(15.247) ANSI C63.10-2013 KDB 558074 D01 15.247 Meas Guidance v05r02 The above equipment has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: CR221156310-00A Date Of Issue: 2022/12/21 Reviewed By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.: CR221156310-00A Page 2 of 57 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. The lab has been recognized by Innovation, Science and Economic Development Canada to test to Canadian radio equipment requirements, the CAB identifier: CN0123. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.: CR221156310-00A Page 3 of 57 CONTENTS T EST FACILITY .......................................................................................................................................... 2 DECLARATIONS .......................................................................................................................................... 2 1. GENERAL INFORMATION .................................................................................................... 5 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................... 5 1.2 DESCRIPTION OF TEST CONFIGURATION ........................................................................................... 6 1.2.1 EUT Operation Condition: ............................................................................................................................. 6 1.2.2 Support Equipment List and Details .............................................................................................................. 6 1.2.3 Support Cable List and Details ...................................................................................................................... 6 1.2.4 Block Diagram of Test Setup ......................................................................................................................... 7 1.3 MEASUREMENT UNCERTAINTY .......................................................................................................... 9 2. SUMMARY OF TEST RESULTS .......................................................................................... 10 3. REQUIREMENTS AND TEST PROCEDURES .................................................................. 11 3.1 AC LINE CONDUCTED EMISSIONS .................................................................................................... 11 3.1.1 Applicable Standard ..................................................................................................................................... 11 3.1.2 EUT Setup.................................................................................................................................................... 12 3.1.3 EMI Test Receiver Setup ............................................................................................................................. 12 3.1.4 Test Procedure ............................................................................................................................................. 13 3.1.5 Corrected Amplitude & Margin Calculation ................................................................................................ 13 3.2 RADIATION SPURIOUS EMISSIONS .................................................................................................... 14 3.2.1 Applicable Standard ..................................................................................................................................... 14 3.2.2 EUT Setup.................................................................................................................................................... 14 3.2.3 EMI Test Receiver & Spectrum Analyzer Setup ......................................................................................... 15 3.2.4 Test Procedure ............................................................................................................................................. 15 3.2.5 Corrected Amplitude & Margin Calculation ................................................................................................ 15 3.3 6 DB EMISSION BANDWIDTH: ............................................................................................................ 16 3.3.1 Applicable Standard ........................................................................................…

Text truncated - open the document above for the full version.

Product Number: 2.4G Antenna L=150mm MHF Product Name ：LY-P05-150（HUAYAO） Manufacture：Dongguan Huayao Electronic Technology Co., Ltd. 101, Floor 1, No. 5, Third Lane, Delong Road, Shatou Community, Chang'an Town, Dongguan City Index: 1. Rel iability Testing 2. Specification 3. S Parameter Test Data 4. Antenna Radiation Pattern ================================================== Page 1 Version: 1.0 Issue Date: 2022-12-07 Product Number: 2.4G Antenna L=150mm MHF Product Name ：LY-P05-150（HUAYAO） 1. Reliability Testing Test Item Procedure Requirement 1. Visual inspection Applicable methods follow specification and Dimension using x5 Check magnification 2. Rapid Changing -40 ̊C (30minutes) to After 2 hours recovery: of Temperature 90 ̊C (30minutes); 1. no visible damage 24 cycles 2. Freq. Tol.: < ±5% 3. Damp Heat 24 hours at 60 ̊C; After 2 hours recovery: 90 ~ 95% RH 1. no visible damage 2. Freq. Tol . : < ±5% 4. Endurance 24 hours at 90 ̊C After 2 hours recovery: 1. no visible damage 2. Freq Tol.: < ±5% Page 2 Version: 1.0 Issue Date: 2022-12-07 Product Number: 2.4G Antenna L=150mm MHF Product Name ：LY-P05-150（HUAYAO） 2. Specification A. Electrical Characteristics S.W.R. 2400-2500MHz:≥2.0 Antenna Gain 2 ±0.5 dBi Impedance 50 Ohm B. Material Material of Radiator Cu (Plated) Connector Type IPEX C. Environmental Operation Temperature - 30 ̊C ~ + 85 ̊C Storage Temperature - 30 ̊C ~ + 85 ̊C 3. S Parameter Test data Page 3 Version: 1.0 Issue Date: 2022-04-26 Product Number: 2.4G Antenna L=150mm MHF Product Name ：LY-P05-150（HUAYAO） Page 4 Version: 1.0 Issue Date: 2022-12-07 Product Number: 2.4G Antenna L=150mm MHF Product Name ：LY-P05-150（HUAYAO） Page 5 Version: 1.0 Issue Date: 2022-12-07 Product Number: WiFi Antenna L=150mm MHF Product Name ：LY-P05-150（HUAYAO） Page 6 Version: 1.0 Issue Date: 2022-12-07

EXHIBIT D - TEST SETUP PHOTOGRAPHS Conducted Emissions Front View-POE Power Conducted Emissions Side View-POE Power Conducted Emissions Front View-Adapter Power Conducted Emissions Side View-Adapter Power Radiated Emission Below 1GHz View- Adapter Power Radiated Emission Below 1GHz View- POE Power Radiated Emission Above 1GHz View- Adapter Power
