2ARQB-PROBEWIFI2IoT Probe

Sentek Pty Ltd

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jan 29, 2026
Application Purpose: Original Equipment
Equipment Note: IoT Probe
Frequency Range: 2402.00000000 - 2480.00000000
Company: Sentek Pty Ltd
Country: Australia

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Sentek IoT Probe Quick Start Guide INTRODUCTION What’s in the box? • Sentek IoT Probe • Sentek Drill & Drop Bluetooth Probe What you Need to Get Started • Access Point • Android Mobile Device with Bluetooth Capability • Google Play Store Account Quick Start • Open Google Play Store on the Android Mobile device • Type Sentek Connect on the search bar • Install the Sentek Connect App on the Android Mobile device • Follow the steps to set up your phone and the Bluetooth Drill & Drop probe Minimum requirements • Mobile device must be running Android version 4.3 or later • Requires Bluetooth 4 capability SETUP ACCESS POINT 1. Open Google Play Store and type nRF Device Manager in the search bar. Install the Device Manager App on your Android Mobile Device. 2. Open the App and Grant Bluetooth Permissions. Select Allow when the App prompts to connect to nearby devices 3. Click on the symbol located on the right hand side upper corner of the screen and ensure the only devices advertising SMP UUID option is unticked. 4. Connect to the Sentek IoT Probe from the list by clicking on the name. 5. Click on the Shell command option located at the bottom right hand side of the screen. In the Shell command box, send the following commands to set your access point: set set wifi/ap_name “name” set set wifi/ap_key “key” Note: In place of “name” – type your access point name In place of “key” – type your access point key. SETUP – Sentek Connect App 1. After successful installation of the Sentek Connect App, complete the Introduction Wizard by following the instructions provided on the App. 2. On the Scan screen of the App, WiFi Power can be observed by the cloud icon on the App. 3. Connect to the probe can be seen in the App in the Sim Status Field. When the Connection is made, the status will change from Not Registered to Registered. FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. RF exposure statement: The transmitter must not be colocated or operated in conjunction with any other antenna or transmitter. This equipment complies with the FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a Minimum distance of 20cm between the radiator and any part of your body.

RF Exposure Info

ShenzhenCTLTestingTechnologyCo.,Ltd. Tel:+86-755-89486194E-Mail:[email protected] RFExposureevaluation ReportReferenceNo.....................:CTL2509225031-WFH Compiledby: (position+printedname+signature) GaryGao Testedby: (position+printedname+signature) HappyGuo Approvedby: (position+printedname+signature) IvanXie ProductName ................................. : IoTProbe Model/Typereference .................... :WiFi ListModel(s) .................................... :WiFiV1.3,WiFiV1.5,WiFiLink TradeMark ....................................... : N/A FCCID...............................................: 2ARQB-PROBEWIFI2 Applicant’sname ........................... : SentekPtyLtd Addressofapplicant.....................: 77MagillRoad,Stepney5069,SouthAustralia,Australia TestFirm ........................................... : ShenzhenCTLTestingTechnologyCo.,Ltd. AddressofTestFirm ..................... : Floor1-A,BaishaTechnologyPark,No.3011,ShahexiRoad, NanshanDistrict,Shenzhen,China518055 Testspecification ........................... : Standard............................................: 47CFR§1.1310 47CFR§2.1091 KDB447498D01GeneralRFExposureGuidancev06 TRFOriginator .................................. : ShenzhenCTLTestingTechnologyCo.,Ltd. MasterTRF.......................................:Dated2017-01 Dateofreceiptoftestitem..........: October13,2025 DateofTest .................................... : October13,2025-January14,2026 DateofIssue....................................: January16,2026 Result................................................: Pass ShenzhenCTLTestingTechnologyCo.,Ltd.Allrightsreserved. Thispublicationmaybereproducedinwholeorinpartfornon-commercialpurposesaslongasthe ShenzhenCTLTestingTechnologyCo.,Ltd.isacknowledgedascopyrightownerandsourceofthe material.ShenzhenCTLTestingTechnologyCo.,Ltd.takesnoresponsibilityforandwillnotassume liabilityfordamagesresultingfromthereader'sinterpretationofthereproducedmaterialduetoits placementandcontext. V1.0Page2of11ReportNo.:CTL2509225031-WFH TESTREPORT TestReportNo.:CTL2509225031-WFH January16,2026 Dateofissue ProductName: IoTProbe SampleNo:CTL250922503003,CTL250922503077 CTL250922503078,CTL250922503079 Model/Type: WiFi ListedModels : WiFiV1.3,WiFiV1.5,WiFiLink Applicant: SentekPtyLtd Address : 77MagillRoad,Stepney5069,SouthAustralia,Australia Manufacturer:SentekPtyLtd Address : 77MagillRoad,Stepney5069,SouthAustralia,Australia Thetestresultspresentedinthisreportrelateonlytotheobjecttested. Thisreportshallnotbereproduced,exceptinfull,withoutthewrittenapprovaloftheissuingtesting laboratory. V1.0Page3of11ReportNo.:CTL2509225031-WFH **ModifiedHistory** RevisionDescriptionIssuedDataReportNo.Remark Version1.0InitialTestReportReleaseJanuary16,2026CTL2509225031-WFHTracyQi V1.0Page4of11ReportNo.:CTL2509225031-WFH Contents 1GENERALINFORMATION..................................................................................................................................................5 1.1ENVIRONMENTALCONDITIONS................................................................................................................................................5 1.2PRODUCTDESCRIPTION.........................................................................................................................................................5 1.3TESTFACILITY.......................................................................................................................................................................6 1.4STATEMENTOFTHEMEASUREMENTUNCERTAINTY......................................................................................................................6 2METHODOFMEASUREMENT...........................................................................................................................................7 2.1APPLICABLESTANDARD..........................................................................................................................................................7 2.2EVALUATIONMETHODANDLIMIT...........................................................................................................................................7 3CONDUCTEDPOWERRESULTS.........................................................................................................................................9 4MANUFACTURINGTOLERANCE......................................................................................................................................10 5EVALUATIONRESULTS.....................................................................................................................................................11 5.1STANDALONEEVALUATION....................................................................................................................................................11 5.2SIMULTANEOUSASSESSMENT................................................................................................................................................11 6CONCLUSION..................................................................................................................................................................11 V1.0Page5of11ReportNo.:CTL2509225031-WFH 1GENERALINFORMATION 1.1Environmentalconditions Duringthemeasurementtheenvironmentalconditionswerewithinthelistedranges: NormalTemperature:25°C-35°C RelativeHumidity:35%-55% AirPressure:101KPa 1.2ProductDescription ProductName: IoTProbe Model/Typereference:WiFi Powersupply: DC3.7VfrombatteryorDC5Vfromadapter TestVoltage:DC3.7VfrombatteryorDC5Vfromadapter BluetoothLowEnergy Supportedtype:BluetoothLowEnergy Modulation:GFSK Operationfrequency: 2402MHzto2480MHz Channelnumber:40 Channelseparation: 2MHz Antennatype:PCBAntenna Antennagain:-2.03dBi 2.4GWi-Fi Supportedtype:IEEE802.11b/g/n Modulation: IEEE802.11b:DSSS IEEE802.11g/IEEE802.11n(HT20)/IEEE802.11n(HT40) Operationfrequency: IEEE802.11b/IEEE802.11g/IEEE802.11n(HT20): 2412MHz~2462MHz IEEE802.11n(HT40)::2422MHz…

Text truncated - open the document above for the full version.

Test Setup Photos

FCCID:2ARQB-PROBEWIFI2Page 1 of 3 ReportNo.:CTL2509225031-WF TestSetupPhotosoftheEUT FCCID:2ARQB-PROBEWIFI2Page 2 of 3 ReportNo.:CTL2509225031-WF FCCID:2ARQB-PROBEWIFI2Page 3 of 3 ReportNo.:CTL2509225031-WF

Test Report

ShenzhenCTLTestingTechnologyCo.,Ltd. Floor1-A,BaishaTechnologyPark,No.3011,ShahexiRoad,NanshanDistrict,Shenzhen,China518055 Tel:+86-755-89486194E-mail:[email protected] Annexfor2.4GWi-Fi TestReportNo.:CTL2509225031-WF02 TABLEOFCONTENTS Annexfor2.4GWi-FiTestReportNo.:CTL2509225031-WF02................................................................1 1.Bandwidth................................................................................................................................................3 1.1TestResult.....................................................................................................................................3 1.1.1OBW....................................................................................................................................3 1.1.26dBBW................................................................................................................................3 1.2TestGraph.....................................................................................................................................4 1.2.1OBW....................................................................................................................................4 1.2.26dBBW..............................................................................................................................10 2.MaximumConductedOutputPower.....................................................................................................16 2.1TestResult...................................................................................................................................16 2.1.1Power.................................................................................................................................16 3.MaximumPowerSpectralDensity........................................................................................................17 3.1TestResult...................................................................................................................................17 3.1.1PSD...................................................................................................................................17 3.2TestGraph...................................................................................................................................18 3.2.1PSD...................................................................................................................................18 4.UnwantedEmissionsInNon-restrictedFrequencyBands...................................................................24 4.1TestResult...................................................................................................................................24 4.1.1Ref.....................................................................................................................................24 4.1.2CSE...................................................................................................................................24 Annexfor2.4GWi-FiTestReportNo.:CTL2509225031-WF02 FCCID:2ARQB-PROBEWIFI2 Page2/40 4.2TestGraph...................................................................................................................................25 4.2.1Ref.....................................................................................................................................25 4.2.2CSE...................................................................................................................................31 Annexfor2.4GWi-FiTestReportNo.:CTL2509225031-WF02 FCCID:2ARQB-PROBEWIFI2 Page3/40 1.Bandwidth 1.1TestResult 1.1.1OBW Mode TX Type Frequency (MHz) ANT 99%OccupiedBandwidth(MHz) Verdict ResultLimit 802.11bSISO 2412113.009/Pass 2437113.107/Pass 2462113.106/Pass 802.11gSISO 2412118.147/Pass 2437118.317/Pass 2462118.439/Pass 802.11n (HT20) SISO 2412118.962/Pass 2437119.106/Pass 2462119.150/Pass 802.11n (HT40) SISO 2422137.402/Pass 2437137.244/Pass 2452136.947/Pass 1.1.26dBBW Mode TX Type Frequency (MHz) ANT 6dBBandwidth(MHz) Verdict ResultLimit 802.11bSISO 241219.274>=0.5Pass 243719.713>=0.5Pass 246219.703>=0.5Pass 802.11gSISO 2412116.797>=0.5Pass 2437117.027>=0.5Pass 2462116.950>=0.5Pass 802.11n (HT20) SISO 2412117.877>=0.5Pass 2437117.966>=0.5Pass 2462118.190>=0.5Pass 802.11n (HT40) SISO 2422136.399>=0.5Pass 2437136.188>=0.5Pass 2452135.837>=0.5Pass Annexfor2.4GWi-FiTestReportNo.:CTL2509225031-WF02 FCCID:2ARQB-PROBEWIFI2 Page4/40 1.2TestGraph 1.2.1OBW 802.11b_LCH_2412MHz_Ant1(SISO)_NTNV 802.11b_MCH_2437MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2509225031-WF02 FCCID:2ARQB-PROBEWIFI2 Page5/40 802.11b_HCH_2462MHz_Ant1(SISO)_NTNV 802.11g_LCH_2412MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2509225031-WF02 FCCID:2ARQB-PROBEWIFI2 Page6/40 802.11g_MCH_2437MHz_Ant1(SISO)_NTNV 802.11g_HCH_2462MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2509225031-WF02 FCCID:2ARQB-PROBEWIFI2 Page7/40 802.11n(HT20)_LCH_2412MHz_Ant1(SISO)_NTNV 802.11n(HT20)_MCH_2437MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2509225031-WF02 FCCID:2ARQB-PROBEWIFI2 Page8/40 802.11n(HT20)_HCH_2462MHz_Ant1(SISO)_NTNV 802.11n(HT40)_LCH_2422MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2509225031-WF02 FCCID:2ARQB-PROBEWIFI2 Page9/40 802.11n(HT40)_MCH_2437MHz_Ant1(SISO)_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2509225031-WF02 FCCID:2ARQB-PROBEWIFI2 Page10/40 1.2.26dBBW 802.11b_LCH_2412MHz_Ant1(SISO)_NTNV 802.11b_MCH_2437MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2509225031-WF02 FCCID:2ARQB-PROBEWIFI2 Page11/40 802.11b_HCH_2462MHz_Ant1(SISO)_NTNV 802.11g_LCH_2412MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2509225031-WF02 FCCID:2ARQB-PROBEWIFI2 Page12/40 802.11g_MCH_2437MHz_Ant1(SISO)_NTNV 802.11g_HCH_2462MHz_Ant1(SISO)_NTNV Annexfor2.4GWi-FiTestReportNo.:CTL2509225031-WF02 FCCID:2ARQB-PROBEWIFI2 Page13/40 802.11n(HT20)_LCH_2412MHz_Ant1(SISO…

Text truncated - open the document above for the full version.

Test Report

ShenzhenCTLTestingTechnologyCo.,Ltd. Tel:+86-755-89486194E-mail:[email protected] TESTREPORT 47CFRPart15,SubpartC15.247 ReportReferenceNo.....................:CTL2509225031-WF02 Compiledby: (printedname+signature) GaryGao Reviewedby: (printedname+signature) HappyGuo Approvedby: (printedname+signature) IvanXie ProductName ................................. : IoTProbe Model/Typereference .................... :WiFi ListModel(s)....................................:WiFiV1.3,WiFiV1.5,WiFiLink TradeMark.......................................: N/A FCCID...............................................: 2ARQB-PROBEWIFI2 Applicant’sname...........................: SentekPtyLtd Addressofapplicant ..................... : 77MagillRoad,Stepney5069,SouthAustralia,Australia TestFirm...........................................: ShenzhenCTLTestingTechnologyCo.,Ltd. AddressofTestFirm.....................: Floor1-A,BaishaTechnologyPark,No.3011,ShahexiRoad, NanshanDistrict,Shenzhen,China518055 Testspecification...........................: Standard ............................................ :47CFRPart15,SubpartC15.247:Operationwithinthebands 902-928MHz,2400-2483.5MHzand5725-5850MHz. TRFOriginator..................................: ShenzhenCTLTestingTechnologyCo.,Ltd. MasterTRF ....................................... :Dated2011-01 Dateofreceiptoftestitem..........: October13,2025 DateofTestDate............................: October13,2025-January14,2026 DateofIssue .................................... : January16,2026 Result................................................: Pass ShenzhenCTLTestingTechnologyCo.,Ltd.Allrightsreserved. Thispublicationmaybereproducedinwholeorinpartfornon-commercialpurposesaslongasthe ShenzhenCTLTestingTechnologyCo.,Ltd.isacknowledgedascopyrightownerandsourceofthe material.ShenzhenCTLTestingTechnologyCo.,Ltd.takesnoresponsibilityforandwillnotassume liabilityfordamagesresultingfromthereader'sinterpretationofthereproducedmaterialduetoits placementandcontext. V1.0Page2of29ReportNo.:CTL2509225031-WF02 TESTREPORT TestReportNo.:CTL2509225031-WF02 January16,2026 Dateofissue EquipmentunderTest: IoTProbe SampleNo:CTL250922503003,CTL250922503077 CTL250922503078,CTL250922503079 Model/Type: WiFi ListedModels : WiFiV1.3,WiFiV1.5,WiFiLink Applicant: SentekPtyLtd Address : 77MagillRoad,Stepney5069,SouthAustralia,Australia Manufacturer: SentekPtyLtd Address : 77MagillRoad,Stepney5069,SouthAustralia,Australia TestresultPass* *Intheconfigurationtested,theEUTcompliedwiththestandardsspecifiedpage5. Thetestresultspresentedinthisreportrelateonlytotheobjecttested. Thisreportshallnotbereproduced,exceptinfull,withoutthewrittenapprovaloftheissuingtesting laboratory. Thedevice(ProductName:IoTProbe)ModelsName:WiFi,WiFiV1.3,WiFiV1.5,WiFiLinkhavesame electrical,PCBandBOM,onlythecolourandmodel’snamesaredifferentformarketingrequirements. V1.0Page3of29ReportNo.:CTL2509225031-WF02 **ModifiedHistory** RevisionsDescriptionIssuedDataReportNo.Remark Version1.0InitialTestReportReleaseJanuary16,2026CTL2509225031-WF02TracyQi V1.0Page4of29ReportNo.:CTL2509225031-WF02 TableofContentsPage 1.SUMMARY.......................................................................................................................................................................5 1.1.TESTSTANDARDS............................................................................................................................................................5 1.2.TESTDESCRIPTION...............................................................................................................................................................5 1.3.TESTFACILITY.....................................................................................................................................................................6 1.4.STATEMENTOFTHEMEASUREMENTUNCERTAINTY.....................................................................................................................6 1.5.AUXILIARYEQUIPMENTINFORMATION...........................................................................................................................7 2.GENERALINFORMATION.................................................................................................................................................8 2.1.ENVIRONMENTALCONDITIONS...............................................................................................................................................8 2.2.GENERALDESCRIPTIONOFEUT.............................................................................................................................................8 2.3.DESCRIPTIONOFTESTMODESANDTESTFREQUENCY................................................................................................................9 2.4.EQUIPMENTSUSEDDURINGTHETEST...................................................................................................................................10 2.5.RELATEDSUBMITTAL(S)/GRANT(S)....................................................................................................................................10 2.6.MODIFICATIONS................................................................................................................................................................10 3.TESTCONDITIONSANDRESULTS...................................................................................................................................11 3.1.CONDUCTEDEMISSIONSTEST..............................................................................................................................................11 3.2.RADIATEDEMISSIONSANDBANDEDGE.................................................................................................................................14 3.3.MAXIMUMCONDUCTEDOUTPUTPOWER.............................................................................................................................24 3.4.POWERSPECTRALDENSITY..........…

Text truncated - open the document above for the full version.

Test Report

ShenzhenCTLTestingTechnologyCo.,Ltd. Floor1-A,BaishaTechnologyPark,No.3011,ShahexiRoad,NanshanDistrict,Shenzhen,China518055 Tel:+86-755-89486194E-mail:[email protected] AnnexforBluetoothLowEnergy TestReportNo.:CTL2509225031-WF01 TABLEOFCONTENTS AnnexforBluetoothLowEnergyTestReportNo.:CTL2509225031-WF01..............................................1 1.Bandwidth................................................................................................................................................3 1.1TestResult.....................................................................................................................................3 1.1.1OBW....................................................................................................................................3 1.1.26dBBW................................................................................................................................3 1.2TestGraph.....................................................................................................................................4 1.2.1OBW....................................................................................................................................4 1.2.26dBBW................................................................................................................................7 2.MaximumConductedOutputPower.....................................................................................................10 2.1TestResult...................................................................................................................................10 2.1.1Power.................................................................................................................................10 2.2TestGraph...................................................................................................................................11 2.2.1Power.................................................................................................................................11 3.MaximumPowerSpectralDensity........................................................................................................14 3.1TestResult...................................................................................................................................14 3.1.1PSD...................................................................................................................................14 3.2TestGraph...................................................................................................................................15 3.2.1PSD...................................................................................................................................15 4.UnwantedEmissionsInNon-restrictedFrequencyBands...................................................................18 4.1TestResult...................................................................................................................................18 4.1.1Ref.....................................................................................................................................18 AnnexforBluetoothLowEnergyTestReportNo.:CTL2509225031-WF01 FCCID:2ARQB-PROBEWIFI2 Page2/26 4.1.2CSE...................................................................................................................................18 4.2TestGraph...................................................................................................................................19 4.2.1Ref.....................................................................................................................................19 4.2.2CSE...................................................................................................................................22 AnnexforBluetoothLowEnergyTestReportNo.:CTL2509225031-WF01 FCCID:2ARQB-PROBEWIFI2 Page3/26 1.Bandwidth 1.1TestResult 1.1.1OBW Mode TX Type Frequency (MHz) ANT 99%OccupiedBandwidth(MHz) Verdict ResultLimit 1MSISO 240211.039/Pass 244011.047/Pass 248011.043/Pass 2MSISO 240212.051/Pass 244012.069/Pass 248012.056/Pass 1.1.26dBBW Mode TX Type Frequency (MHz) ANT 6dBBandwidth(MHz) Verdict ResultLimit 1MSISO 240210.711>=0.5Pass 244010.697>=0.5Pass 248010.698>=0.5Pass 2MSISO 240211.173>=0.5Pass 244011.166>=0.5Pass 248011.166>=0.5Pass AnnexforBluetoothLowEnergyTestReportNo.:CTL2509225031-WF01 FCCID:2ARQB-PROBEWIFI2 Page4/26 1.2TestGraph 1.2.1OBW 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV AnnexforBluetoothLowEnergyTestReportNo.:CTL2509225031-WF01 FCCID:2ARQB-PROBEWIFI2 Page5/26 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV AnnexforBluetoothLowEnergyTestReportNo.:CTL2509225031-WF01 FCCID:2ARQB-PROBEWIFI2 Page6/26 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV AnnexforBluetoothLowEnergyTestReportNo.:CTL2509225031-WF01 FCCID:2ARQB-PROBEWIFI2 Page7/26 1.2.26dBBW 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV AnnexforBluetoothLowEnergyTestReportNo.:CTL2509225031-WF01 FCCID:2ARQB-PROBEWIFI2 Page8/26 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV AnnexforBluetoothLowEnergyTestReportNo.:CTL2509225031-WF01 FCCID:2ARQB-PROBEWIFI2 Page9/26 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV AnnexforBluetoothLowEnergyTestReportNo.:CTL2509225031-WF01 FCCID:2ARQB-PROBEWIFI2 Page10/26 2.MaximumConductedOutputPower 2.1TestResult 2.1.1Power Mode TX Type Frequency (MHz) MaximumPeakConductedOutputPower(dBm) Verdict ANT1Limit 1MSISO 2402-12.68<=30Pass 2440-10.41<=30Pass 2480-9.97<=30Pass 2MSISO 2402-12.79<=30Pass 2440-10.44<=30Pass 2480-10.04<=30Pass Note1:AntennaGain:Ant1:-2.03dBi; AnnexforBluetoothLowEnergyTestReportNo.:CTL2509225031-WF01 FCCID:2ARQB-PROBEWIFI2 Page11/26 2.2TestGraph 2.2.1Power 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV AnnexforBluetoothLowEnergyTestReportNo.:CTL2509225031-WF01 FCCID:2ARQB-PROBEWIFI2 Page12/26 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV AnnexforBluetoothLowEnergyTe…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

Michael mportmann

[email protected]Fax: +61 883661900

Technical Contact

HOORAY INDUSTRY LLCCindy Wu

[email protected]

1408 Pinon Place, Fullerton, · United States

Test Firm

Shenzhen CTL Testing Technology Co., Ltd.Tracy Qi

[email protected]

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	100.00 µW
2	15C	2.41 GHz - 2.46 GHz	46.60 mW

Confidentiality

Long Term

Grant Notes

Output Power listed is peak conducted. This device supports 802.11b, 802.11g and 802.11n with a 20 MHz and 40 MHz bandwidth mode. RF exposure compliance is addressed for 1.1310 and 2.1091 MPE limits. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. End Users must be provided with transmitter operation conditions for satisfying RF exposure compliance.
