1 Convergence User Manual 335100390_RevA 2 Thanks for Using! The Manual introduces the information about CONVERGENCE installation and use. 3 To User Thank you for purchasing our intelligent converged communication device CONVERGENCE (hereinafter referred to as “the Product”). The Product greatly simplifies your life and work based on advanced techniques and exquisite craft. Please read the Manual carefully before using the Product to master the use and avoid personal injury or property loss due to miss operation. Tips  Please keep the Manual properly for further reference and use.  The Company reserves the right of changing the Manual’s software and hardware specification due to product updating or improvement. The Manual’s product specification and information are for reference only.  The Company reserves the final power of interpretation for mistakes and omissions may exist even if it is checked carefully. FCC NOTICE： This device complies with Part 15 and Part 90 of the FCC Rules and is listed. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 4 User Safety Information Please read the following safety information for using the Product at higher efficiency.  The radio can only be maintained by professional technicians. Do not disassemble the radio without permission.  Only designated power adapter, antenna and components should be used.  Do not install the Product in flammable and explosive places.  Do not install the Product in places close to explosion or detonator.  Do not use the radio with damaged antenna. A damaged antenna may cause minor burns when it comes into contact with the skin.  Do not expose the Product to direct sunlight or place it near heating device for long period.  Do not expose the Power Adapter or Backup Battery to direct sunlight or place it near heating device for long period. It shall be keep inside the shield box when use outdoor to avoid direct contact to sunlight or heating for long period.  Do not expose the Product to humid and highly-corrosive places for long period. WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. RF Radiation Information 1. This product is limited to occupational applications that can meet RF energy radiation requirements. The user must be fully aware of the RF radiation hazards and can take corresponding measures to meet the RF radiation limitation requirements. 2. Radio frequency (RF) refers to the electromagnetic frequency that can be radiated into space. It is a widely used technology in the fields of communication, medical treatment, and food processing. It will generate certain RF radiation during use. RF warning statement: To ensure optimal performance and compliance with the occupational/controlled environment RF energy exposure limits in the above standards and guidelines, users should always adhere to the following procedures: ●Antenna gain must not exceed 3dBi ●The antenna gain must be installed complying with the requirements of manufacturer or supplier, and it must be at least 40cm away from human body European Union (EU) Waste of Electrical and Electronic Equipment (WEEE) directive 5 The European Union's WEEE directive requires that products sold into EU countries must have the crossed out trash bin label on the product (or the package in some cases). As defined by the WEEE directive, this cross-out trash bin label means that customers and end-users in EU countries. Overheat Warning  Do not touch the Product with hands when the Product has been running for long period and surface temperature is too high, for the power amplifier radiator may be under high temperature. Instead, you can measure it using a thermometer.  Check the ambient temperature and ventilation of the Product and if they are unacceptable, please improve them within the shortest period possible. For example, install air conditioner, promote ventilation and reduce temperature.  Check if the RF antenna connected to transmitter is loose or damaged, and radiator temperature rise is too fast due to ultrahigh emission power when connection is poor. If so, please fasten or replace the antenna.  For other cases, please consult the local dealers for solutions. Do not use the Product until its temperature recovers to the normal range. Package Item Inspection Package items are as follows. For any loss or damage, please contact the dealer from which the product is purchased. Convergence ×1/ Adapter ×1/ RF antenna ×1/ Manual ×1/ Screw kit ×1 6 Device Overview Part List Part No. Part Name 1 Graded antenna connector (DIV) * 2 Locating antenna connector (GPS) * 3 USB1 c…

Text truncated - open the document above for the full version.

Auctus Technologies Co., Ltd. Address: 17F,Building3,China Science and Technology, Development Park,No.009,Gaoxin Road,Nanshan Dist. Shenzhen, Guangdong, China Email: [email protected] Tel: 0755-26068685 Fax: 0755-26405328 Attestation Letter DATE:2020-3-24 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ASCZAD110D Model:AD110D To whom it may concern: We, Auctus Technologies Co., Ltd. acknowledge that this device will not be marketed to USA users with the frequency band which is not allowed by rule part 90.and it is a violation of FCC rules if this device is operated on unauthorized frequencies inside the U.S.A. This equipment meets the requirements of the FCC Rules, Parts 90.203(e) and (g), as applicable. Programming of this products transmit frequencies can be performed ONLY by the manufacturer or by service or by maintenance personal. The operator can’t program transmit frequencies using the equipment’s external operation controls. This is to certify that the requirements of 47 CFR Part 90.203(j)(4) and (5) spectrum efficiency are met by the Auctus Technologies Co., Ltd.as demonstrated by the tests conducted on the sample radio provided. The tests show that the 4FSK data rate is in accordance with ETSI TS 102 361-1, that is 9600 bits per second in a 12.5 kHz bandwidth to satisfy the data rate requirement of 4800 bits per second per 6.25 kHz of channel bandwidth (7K60F1D emissions). Additionally the Digital WANET Repeater uses the AMBE+2 half-rate vocoderto compress 60 ms of normal bursts are sent in alternate 30 ms TDMA slots and so comply with the equivalence of one voice channel per 6.25 kHz bandwidth (7K60F1E emission). Sincerely, Signature: Lv enjian Projector Director

QA-FR-170-B Auctus Technologies Co., Ltd. Address: 17F,Building3,China Science and Technology, Development Park,No.009,Gaoxin Road,Nanshan Dist. Shenzhen, Guangdong, China Email: [email protected] Tel: 0755-26068685 Fax: 0755-26405328 FCC Authorization 2020/03/18 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We (Auctus Technologies Co., Ltd.), the undersigned, hereby authorize Bay Area Compliance Laboratories Corporation to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratory Corporation on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature: Lv enjian Projector Director

Auctus Technologies Co., Ltd. Address: 17F,Building3,China Science and Technology, Development Park,No.009,Gaoxin Road ,Nanshan Dist. Shenzhen, Guangdong, China Email: [email protected] Tel: 0755-26068685 Fax: 0755-26405328 FCC Confidential Authorization 202019/03/18 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2ASCZAD110D In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, ( Auctus Technologies Co., Ltd. ) hereby requests long-term confidential treatment of information accompanying this application as outlined below: • Block Diagram • Schematics • Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely Yours, Signature: Lv enjian Projector Director  Parts List/Tune up procedure

Auctus Technologies Co., Ltd. Address: 17F,Building3,China Science and Technology, Development Park,No.009,Gaoxin Road,Nanshan Dist. Shenzhen, Guangdong, China Email: [email protected] Tel: 0755-26068685 Fax: 0755-26405328 DATE:2020-3-24 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Extended Frequencies Justification Dear Sir/Madam The Radio with FCC ID: 2ASCZAD110D was designed to operate in the frequency bands 430-470MHz To aid equipment authorization in other countries which accept th United States FCC Grant for certification, Auctus Technologies Co., Ltd. is requesting that the FCC lists the frequencies 430-470MHz,Under FCC Rule part90 on the FCC Grant. Auctus Technologies Co., Ltd. attests that the radio will not be marketed to USA users with the frequency band which is not allowed by the rule part 90. Per the FCC’s KDB634817 guidance, as an alternative to listing the exact frequencies, we acknowledge that it’s a violation of the FCC Rules if this device operates on unauthorized frequencies. Frequency Range(MHz) FCC rules part 430-454MHz FCC part90 456-460MHz FCC part90 460-462.5375MHz FCC part90 462.73750-467.5375MHz FCC part90 467.7375-470MHz FCC part90 Sincerely, Signature: Lv enjian Projector Director

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ200303811-00A FCC Part 90 Page 8 of 22 §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to subpart 15.247 (i) and subpart 2.1091 systems operating under the provisions of this section shall be operated in a manner that ensures the public is not exposed to RF energy level in excess of the communication guidelines. Result Calculated Formulary: Predication of MPE limit at a given distance S = 2 4R PG  S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW). G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain. R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) Frequency (MHz) Antenna Gain Tune up conducted power Evaluation Distance Power Density MPE Limit (dBi) (numeric) (W) (cm) (mW/cm 2 ) (mW/cm 2 ) 430-470 3.0 2.0 10.5 40 1.04 1.43 The tune up conducted power was declared by the applicant. Note: To maintain compliance with the FCC’s RF exposure guidelines, place the equipment at least 40cm from nearby persons. Result: Compliance
