2ASIN-996027SIFER NFC Reader add-on kit by Inner Range

Rev 2.0 April 2020 Rev 2.0 April 2020 Installation Manual The SIFER Reader Add-on kit provides an EliteX or PrismaX Terminal with a built-in Multi-format SIFER Reader allowing user operations that require a SIFER credential.Refer to the appropriate system manual/s for EliteX, PrismaX and SIFER Readerprogramming and commissioning information.Controller Firmware CompatibilityIntegriti/Infiniti Controller: V17.0.1 (EliteX) or V18.1 (PrismaX) or later. Inception Controller: V1.3.5 or later. (EliteX only. PrismaX not supported) * North American Installations In North America, this kit must only be installed in an EliteX Terminal (P/N: 995400)For EliteX Terminal installations refer to the FCC/ISED notices on page 4.Installing this device in a PrismaX Terminal, P/N: 996400, is not permitted within NorthAmerica. Any operation of this device when installed into a PrismaX terminal host modulemay cause interference.EliteX/PrismaX Terminal Installation & User notes.When this SIFER Reader kit is fitted to an EliteX or PrismaX Terminal: 1. Mounting Surface. SIFER Readers are optimized for mounting on a non-metallic surface. Mounting the EliteX/PrismaX Terminal on a metallic surface will decreasethe read range. To improve read range on a metallic surface, a non-metallic spaceror mounting block that provides 8mm or more of separation is recommended. 2. In/Out Readers. If two SIFER products are installed back to back on either side of a Door, mount the Readers/Terminals at different heights to minimize interference. 3. Reader Zone. The optimum zone for presenting a credential to the Terminal’s SIFER Reader is in the middle of the blue & grey function & digit key section of thekeypad. i.e. Over the ‘4’, ‘5’, ‘7’ & ‘8’ keys. Inner Range SIFER Reader Add-on kit For EliteX and PrismaX* Terminals Part Number: 994721PCB&K Disclaimer The manufacturer &/or its agents take no responsibility for any damage, financial loss or injury caused to anyequipment, property or persons resulting from the correct or incorrect use of the system or its peripherals. Thepurchaser assumes all responsibility in the use of the system and its peripherals.© 2018 - 2020. Inner Range Pty. Ltd. Knoxfield. Australia. Document Part No: 634721 Email: [email protected] Web: www.innerrange.com UL Requirement s (North America) Refer to the Inner Range host LAN Module Installation manual for details of UL regulatoryrequirements.FCC (North America) This device complies with Part 15 of the FCC Rules and Innovation, Science and EconomicDevelopment Canada’s license-exempt RSS(s). Operation is subject to the following two conditions:1. This device may not cause interference; and2. This device must accept any interference, including interference that may cause undesiredoperation of the device.Class B product:This equipment has been tested and found to comply with the limits for a Class B digital device,pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protectionagainst harmful interference in a residential installation.This equipment generates, uses and can radiate radio frequency energy and, if not installed and usedin accordance with the instructions, may cause harmful interference to radio communications.However, there is no guarantee that interference will not occur in a particular installation. If thisequipment does cause harmful interference to radio or television reception, which can bedetermined by turning the equipment off & on,the user is encourage to try to correct the interference by one or more of the following measures:• Reorient or relocate the receiving antenna• Increase the separation between the equipment and receiver• Connect the equipment into an outlet on a circuit different from that to which the receiver isconnected• Consult the dealer or an experienced radio/TV technician for helpWarning: Any changes or modifications not expressively approved by Inner Range Pty Ltd could voidthe user's authority to operate this equipmentISED (Canada)L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNRd’Innovation, Sciences et Développement économique Canada applicables aux appareils radioexempts de licence. L’exploitation est autorisée aux deux conditions suivantes :1. L’appareil ne doit pas produire de brouillage;2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptibled’en compromettre le fonctionnement. CAN ICES-3 (B)/NMB-3(B) 1 4 SIFER Reader Add-on for EliteX/PrismaX. Installation Manual. SIFER Reader Add-on for EliteX/PrismaX. Installation Manual. Retaining Tabs (x2) Beeper CAUTION ! Take care not to damage the PCB surfaces or exposed components. Optical Tamper SensorLAN Connections 4-way socket. SIFER board4-pin header SIFER Reader board Hook & Loop Dots (Underneath Reader board) Hole for retaining screw Parts List- SIFER Reader PCB assembly. - 2 pairs of Self-adhesive Hook & Loop dots. - Installation Manual (This document)SpecificationsPower Supply Input: From host Terminal. Operational Current: 30mA in addition to the current already drawn by the Terminal. InstallationRefer to drawing on page 3.If the Terminal is already installed: a) Disable LAN Comms & Tamper monitoring for the Terminal prior to commencing.b) Separate the Terminal from its backplate. See Step 1 below. c) Disconnect the power, LAN and any other cabling taking care not to short any of the wires. See the Terminal’s Installation manual and relevant system manual/s for details. 1. a) Remove the retaining screw at the bottom of the case if fitted. b) Separate the front and rear (backplate) halves of the case by first applying gentle pressure to the two lower locking tabs in the bottom rear of the case with a small flat-blade screwdriver,while gently pulling the lower front of the case away from the rear. c) Next, gently pull the lower front of the housing clear of the backplate then lift upwards to release the upper locking tabs. 2. Attach two o…

Text truncated - open the document above for the full version.

May 2020 The specifications and descriptions of products and services contained in this document were correct at the time of publishing. Inner Range reserves the right to change specifications or withdraw products without notice. 1 Request for Confidentiality 18/05/2020 Subject: Confidentiality Request regarding application for certification of; FCC ID:2ASIN-996027 Pursuant to FCC 47 CRF 0.457, 0.459 the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested: Exhibit: Short Term Permanent Block Diagrams Short Term External Photo’s Short Term Permanent Internal Photo’s Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photo’s Short Term Permanent User’s Manual INNER RANGE Pty Ltd has spent substantial effort in developing this high security NFC card reader product and it is one of the few of its kind in industry that uses an inhouse designed proprietary protocol with a unique hardware design. Having the subject information easily available to “the outside world” would negate the advantage of having developed such a high security product. May 2020 The specifications and descriptions of products and services contained in this document were correct at the time of publishing. Inner Range reserves the right to change specifications or withdraw products without notice. 2 Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be withheld from public review due to materials that contain trade secrets and proprietary information. Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify FCC in the event information regarding the product or the product is made available to the public. FCC will then release the documents listed above for public disclosure to FCC Public Notice DA 04-1705 June 15,2004. R&D Testing & Compliance Manager INNER RANGE Pty Ltd Place and Date of Issue: INNER RANGE Pty Ltd 1 Millennium Court, Knoxfield, Victoria, Australia 3180 Ph: +61 (0) 3 9780 4300 Fax: +61 (0) 3 9753 3499 www.innerrange.com

February 2020 The specifications and descriptions of products and services contained in this document were correct at the time of publishing. Inner Range reserves the right to change specifications or withdraw products without notice. 1 POA 26/02/2020 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC Application for FCC ID: 2ASIN-996027 To Whom It May Concern: We, the undersigned, hereby authorize Chris Zombolas at EMC Technologies Pty Ltd to act on our behalf, to apply to the Federal Communications Commission for authorization of our equipment. Any and all acts carried out by Chris Zombolas on our behalf shall have the same effect as acts of our own. In addition, I authorize Mr. Chris Zombolas, Technical Director of EMC Technologies Pty Ltd to sign the Form 731. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, R&D Testing & Compliance Manager INNER RANGE Pty Ltd Place and Date of Issue: INNER RANGE Pty Ltd 1 Millennium Court, Knoxfield, Victoria, Australia 3180 Ph: +61 (0) 3 9780 4300 Fax: +61 (0) 3 9753 3499 www.innerrange.com

EMC Technologies Pty Ltd ABN 82 057 105 549 176 Harrick Road, Keilor Park, VIC 3042, Australia Ph: + 613 9365 1000 Fax: + 613 9331 7455 Email: [email protected] To: Federal Communications Commission ISED Canada Attention: Certification Officer Date: May 26 2020 EMC Ref: M190227 Subject: FCC and ISED Canada Original Filing: FCC ID: 2ASIN-996027 IC: 25850-996027 Company: Inner Range Pty Ltd. FCC ID: 2ASIN-996027 IC: 25850-996027 EUT: Inner Range SIFER NFC Reader add-on kit Test Firm: EMC Bayswater Pty Ltd (Accredited Test Site Designation No. AU0004) The SIFER PlugOn module works exclusively in conjunction with an InnerRange EliteX, and plugs into a socket in a cavity behind the keypad area. Inner Range Pty Ltd is applying for FCC certification approval and ISED Canada approval of this device. EMC Technologies Pty Ltd is acting as agent for Inner Range Pty Ltd in this application. Best Regards Chris Zombolas Technical Director EMC Technologies Pty Ltd 176 Harrick Road, Keilor Park, VIC 3042 Australia Ph. +61 3 9365 1000; www.emctech.com.au EMC Technologies Pty Ltd, 176 Harrick Road, Keilor Park VIC 3042 Australia www.emctech.com.au

Page 1 of 4 EMC ENGINEERS & LABORATORIES EMC Bayswater Pty Ltd 18/88 Merrindale Drive Croydon South, Victoria, 3136, Australia Telephone: +61 3 9761 5888 Facsimile: +61 3 8761 6547 Email: [email protected] ABN: 49 112 221 333 Photograph Annex A: External - EUT Photographs Inner Range Pty Ltd 995400 RevB (+996027 REVI) EliteX Terminal with RFID REPORT: E1902-1136B-2 Rev1 Annex A DATE: March, 2019 EMC Bayswater Test Report E1902-1136B-2 Rev1 Annex A Page 2 of 4 This document may not be reproduced, except in full, without written approval from EMC Bayswater Pty Ltd. Photographs Number Photograph Description 1 EUT – External views 2 3 4 5 6 7 AE – Inception Controller 8 9 AE – RFID tag 10 EMC Bayswater Test Report E1902-1136B-2 Rev1 Annex A Page 3 of 4 This document may not be reproduced, except in full, without written approval from EMC Bayswater Pty Ltd. Photograph 1 Photograph 2 Photograph 3 Photograph 4 Photograph 5 Photograph 6 EMC Bayswater Test Report E1902-1136B-2 Rev1 Annex A Page 4 of 4 This document may not be reproduced, except in full, without written approval from EMC Bayswater Pty Ltd. Photograph 7 Photograph 8 Photograph 9 Photograph 10

9960027 9 9 6 0 0 2 7

Page 1 of 5 EMC ENGINEERS & LABORATORIES EMC Bayswater Pty Ltd 18/88 Merrindale Drive Croydon South, Victoria, 3136, Australia Telephone: +61 3 9761 5888 Facsimile: +61 3 8761 6547 Email: [email protected] ABN: 49 112 221 333 Photograph Annex B: Internal - EUT Photographs Inner Range Pty Ltd 995400 RevB (+996027 REVI) EliteX Terminal with RFID REPORT: E1902-1136B-2 Rev1 Annex B DATE: March, 2019 EMC Bayswater Test Report E1902-1136B-2 Rev1 Annex B Page 2 of 5 This document may not be reproduced, except in full, without written approval from EMC Bayswater Pty Ltd. Photographs Number Photograph Description 1 EUT – Internal views 2 3 4 5 6 7 8 9 10 11 EUT – Internal views – RFID module 12 13 14 EMC Bayswater Test Report E1902-1136B-2 Rev1 Annex B Page 3 of 5 This document may not be reproduced, except in full, without written approval from EMC Bayswater Pty Ltd. Photograph 1 Photograph 2 Photograph 3 Photograph 4 Photograph 5 Photograph 6 EMC Bayswater Test Report E1902-1136B-2 Rev1 Annex B Page 4 of 5 This document may not be reproduced, except in full, without written approval from EMC Bayswater Pty Ltd. Photograph 7 Photograph 8 Photograph 9 Photograph 10 Photograph 11 Photograph 12 EMC Bayswater Test Report E1902-1136B-2 Rev1 Annex B Page 5 of 5 This document may not be reproduced, except in full, without written approval from EMC Bayswater Pty Ltd. Photograph 13 Photograph 14

Page 1 of 35 EMC Bayswater Pty Ltd EMC ENGINEERS & LABORATORIES 18/88 Merrindale Drive Croydon South, Victoria, 3136, Australia Telephone: +61 3 9761 5888 Facsimile: +61 3 8761 6547 Email: [email protected] ABN: 49 112 221 333 EMC COMPLIANCE REPORT Certification Test Report In accordance with: CFR47 FCC Part 15, Subpart C Inner Range Pty Ltd 995400 RevB (+996027 REVI) EliteX Terminal with RFID REPORT: E1902-1136B-2 Rev3 DATE: May, 2020 This report replaces the previously issued report E1902-1136B-2 Rev2 Please refer to section 2 of this report for details of any previously issued reports. Accreditation Number: 18553 Accredited for compliance with ISO/IEC 17025 The results of the tests, calibrations and/or measurements included in this document are traceable to Australian/national standards. NATA is a signatory to the ILAC Mutual Recognition Arrangement for the mutual recognition of the equivalence of testing and calibration reports. This document may not be reproduced except in full without approval from EMC Bayswater, with the exception of the certificate on page 2. EMC Bayswater Test Report E1902-1136B-2 Rev3 Page 2 of 35 Prepared & tested by: Approved by: 27/05/2020 11:51 Fabio D’Amico (EMC Test Engineer) Neville Liyanapatabendige (Manager) Date Accreditation number: 18553. The results of the tests, calibrations and/or measurements included in this document are traceable to Australian/national standards. NATA is a signatory to the ILAC Mutual Recognition Arrangement for the mutual recognition of the equivalence of testing, calibration and inspection reports. This document may not be reproduced except in full without approval from EMC Bayswater, with the exception of the certificate on page 2. Certificate of Compliance EMC Bayswater Test Report: E1902-1136B-2 Rev3 Issue Date: May, 2020 Test Sample(s): EliteX Terminal with RFID Model No: EliteX Terminal Serial No: None stated Part No: 995400 RevB (+996027 REVI) FCC ID: 2ASIN-996027 Client Details: Mr Thomas Kowalczyk Inner Range Pty Ltd 1 Millennium Court Knoxfield, Victoria, 3180, Australia Phone No: 03 9780 4300 e-mail: [email protected] Test Specification: CFR47 FCC Part 15, Subpart C Results Summary: 15.203 – Antenna Requirement Complied 15.225 (a) - Field Strength within the band 13.553 - 13.567MHz Complied 15.225 (b) - Field Strength within the bands 13.410-13.553 MHz and 13.567-13.710 MHz Complied 15.225 (c) - Field Strength within the bands 13.110-13.410 MHz and 13.710-14.010 MHz Complied 15.225 (d) - Field Strength outside the band 13.110-14.010 MHz Complied 15.225 (e) - Frequency tolerance of the carrier signal Complied 15.215 (c) - 20dB Emission Bandwidth Complied Test Date(s): 11 th to the 20 th of February, 2019 Test House (Issued By) EMC Bayswater Pty Ltd 18/88 Merrindale Drive Croydon South Victoria, 3136 Australia FCC Registration number: 527798 Designation Number: AU0004 Phone No: +61 3 9761 5888 e-mail: [email protected] Fax No: +61 3 8761 6547 Web: www.emcbayswater.com.au This is to certify that the necessary measurements were made by EMC Bayswater Pty Ltd, and that the Inner Range Pty Ltd, 995400 RevB (+996027 REVI), EliteX Terminal with RFID (Serial No: None stated), has been tested in accordance with requirements contained in the appropriate commission regulations. EMC Bayswater Test Report E1902-1136B-2 Rev3 Page 3 of 35 Accreditation number: 18553. The results of the tests, calibrations and/or measurements included in this document are traceable to Australian/national standards. NATA is a signatory to the ILAC Mutual Recognition Arrangement for the mutual recognition of the equivalence of testing, calibration and inspection reports. This document may not be reproduced except in full without approval from EMC Bayswater, with the exception of the certificate on page 2. EMC Compliance Report for Inner Range Pty Ltd Contents 1. Introduction ..................................................................................................................................... 4 2. Test Report Revision History ......................................................................................................... 4 3. Report Information .......................................................................................................................... 4 4. Summary of Results ....................................................................................................................... 5 5. Product Sample, Configuration & Modifications ......................................................................... 5 5.1. EUT Description ........................................................................................................................ 5 5.2. Product description .................................................................................................................... 6 5.3. Support Equipment .................................................................................................................... 6 5.4. Product operating modes .......................................................................................................... 6 5.5. Product operating mode for testing ........................................................................................... 6 5.6. Configuration ............................................................................................................................. 6 5.1. Modifications ............................................................................................................................. 7 6. Test Facility & Equipment .............................................................................................................. 7 6.1. Test Facility ............................................................................................................................... 7 6.2. Test Equipment ........................................................................................…

Text truncated - open the document above for the full version.

Page 1 of 4 EMC ENGINEERS & LABORATORIES EMC Bayswater Pty Ltd 18/88 Merrindale Drive Croydon South, Victoria, 3136, Australia Telephone: +61 3 9761 5888 Facsimile: +61 3 8761 6547 Email: [email protected] ABN: 49 112 221 333 Photograph Annex C: Test Configuration Photographs Inner Range Pty Ltd 995400 RevB (+996027 REVI) EliteX Terminal with RFID REPORT: E1902-1136B-2 Rev1 Annex C DATE: March, 2019 EMC Bayswater Test Report E1902-1136B-2 Rev1 Annex C Page 2 of 4 This document may not be reproduced, except in full, without written approval from EMC Bayswater Pty Ltd. Photographs Number Photograph Description 1 Radiated measurements – EUT X Orientation 2 Radiated measurements – EUT Y Orientation 3 Radiated measurements – EUT Z Orientation 4 Radiated measurements – 9kHz to 30MHz – X Antenna orientation 5 Radiated measurements – 9kHz to 30MHz – Y Antenna orientation 6 Radiated measurements – 9kHz to 30MHz – Z Antenna orientation 7 Radiated measurements – 30MHz to 1000MHz 8 Radiated measurements – 1GHz to 2GHz 9 Frequency Tolerance of Carrier Signal – Test configuration 10 EMC Bayswater Test Report E1902-1136B-2 Rev1 Annex C Page 3 of 4 This document may not be reproduced, except in full, without written approval from EMC Bayswater Pty Ltd. Photograph 1 Photograph 2 Photograph 3 Photograph 4 Photograph 5 Photograph 6 EMC Bayswater Test Report E1902-1136B-2 Rev1 Annex C Page 4 of 4 This document may not be reproduced, except in full, without written approval from EMC Bayswater Pty Ltd. Photograph 7 Photograph 8 Photograph 9 Photograph 10
