2ASKB-HIRES5577GHz HiResRadar for Autonomous Drive Applications

TN20Ott0593 Registergericht München HRB 116 461 USt-Id. Nr. DE 186 893 572 Geschäftsführer: Carl Jenkins, Robert Vets, Thomas Sonnauer FoA-S1-2020-08-31 Bankverbindungen Hypovereinsbank München IBAN: DE61 7002 0270 0015 7512 61 BIC Code: HYVEDEMMXXX Rechnungsanschrift Astyx GmbH Rechnungswesen Postfach 1248 85504 Ottobrunn Liefer- / Besuchsanschrift Caroline-Herschel-Str. 2 85521 Ottobrunn 1/ 1 Astyx GmbH - Postfach 1248 - 85504 Ottobrunn November 10, 2020 Certification for Astyx HiRes 6455v2 Model/FCC ID: 2ASKB-HIRES55 PMN: Hires 6455V3 The device under test is manufactured by the grantee (Astyx GmbH) and sold as an OEM product. Per CFR 47 Part 95 Subpart M, the grantee must ensure that the end-user has all applicable / appropriate operating instructions. When end-user instructions are required, as is the case with this product, the grantee must notify the OEM to notify the end-user. Astyx GmbH will supply the following information to the reseller/distributor dictating what must be included in the end user’s manual for the commercial product. INFORMATION TO BE INCLUDED IN THE END USER'S MANUAL The following information (in blue) must be included in the end product user’s manual to ensure continued FCC regulatory compliance. The ID numbers must be included in the manual if the device label is not readily accessible to the end user. The compliance paragraphs (in blue) below must be included in the user's manual. For USA: FCC ID : 2ASKB-HIRES55 US: Radiofrequency radiation exposure Information: This equipment complies with FCC and IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. US: FCC Notice Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. To the Federal Communications Commission (FCC)

Annex A 1-7426/18-01-01_AnnexA External photos of the Equipment Under Test This addendum is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Document authorized: Walla Meheza Lab Manager Radio Communications & EMC CTC advanced GmbHUntertuerkheimer Str. 6-10 66117 Saarbruecken / Germany Phone: +49 681 5 98 - 0 Fax: +49 681 5 98 - 9075 web: ctcadvanced.com e-mail: [email protected] Photos Photo 1 Photo 2 2020-11-07Document No. 1-7426/18-01-01_AnnexA2/4 Photo 3 Photo 4 2020-11-07Document No. 1-7426/18-01-01_AnnexA3/4 Document history VersionApplied changesDate of release initial release2020-11-07 - END OF DOCUMENT - 2020-11-07Document No. 1-7426/18-01-01_AnnexA4/4

Annex B 1-7426/18-01-01_AnnexB Internal photos of the Equipment Under Test This addendum is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Document authorized: Walla Meheza Lab Manager Radio Communications & EMC CTC advanced GmbHUntertuerkheimer Str. 6-10 66117 Saarbruecken / Germany Phone: +49 681 5 98 - 0 Fax: +49 681 5 98 - 9075 web: ctcadvanced.com e-mail: [email protected] Photos Photo 1 Photo 2 2020-11-07Document No. 1-7426/18-01-01_AnnexB2/7 Photo 3 Photo 4 2020-11-07Document No. 1-7426/18-01-01_AnnexB3/7 Photo 5 Photo 6 2020-11-07Document No. 1-7426/18-01-01_AnnexB4/7 Photo 7 Photo 8 2020-11-07Document No. 1-7426/18-01-01_AnnexB5/7 Photo 9 Photo 10 2020-11-07Document No. 1-7426/18-01-01_AnnexB6/7 Document history VersionApplied changesDate of release initial release2020-11-07 - END OF DOCUMENT - 2020-11-07Document No. 1-7426/18-01-01_AnnexB7/7

© CTC advanced GmbH Page 1 of 3 BNetzA - CAB - 02/21 - 102 D - P L - 1 2 0 7 6 - 0 1 - 0 3 Maximum Permissible Exposure (MPE) & Exposure evaluation Report identification number: 1-7426/18-01-03 MPE (FCC_ISED) Certification numbers and labeling requirements FCC ID 2ASKB-HIRES55 ISED number 24720-HIRES55 HVIN (Hardware Version Identification Number) 6455 0000 PMN (Product Marketing Name) 6455 FVIN (Firmware Version Identification Number) -/- HMN (Host Marketing Name) -/- This report is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Document authorised: Alexander Hnatovskiy Marco Scigliano Lab Manager Testing Manager Radio Communications & EMC Radio Communications & EMC Report no.: 1-7426/18-01-03 © CTC advanced GmbH Page 2 of 3 EUT technologies: Technologies: Max. power [dBm] Antenna gain max.: [dBi] * EIRP declared by customer conducted EIRP 77 GHz Radar typ. 10.0 max. 15.0 typ. 23.0 max. 30.0 15 dBi 23 to 30 dBm )* worst case of all antenna types, channels and modulations (overrated) Prediction of MPE limit at given distance - FCC Equation from page 18 of OET Bulletin 65, Edition 97-01 S = PG / 4π R 2 where: S = Power density P = Power input to the antenna G = Antenna gain R = Distance to the center of radiation of the antenna PG = Output Power including antenna gain The table below is excerpted from Table 1B of 47 CFR 1.1310 titled “Limits for Maximum Permissible Exposure (MPE), Limits for General Population/Uncontrolled Exposure” Frequency Range (MHz) Power Density (mW/cm 2 ) Averaging Time (minutes) 300 -1500 f/1500 30 1500 - 100000 1.0 30 where f = Frequency (MHz) Prediction: worst case Technologies: SRR Frequency (MHz) 77000 PG Declared max power (EIRP) 30 dBm R Distance 20 cm S MPE limit for uncontrolled exposure 1 mW/cm 2 Calculated Power density: 0.1990 mW/cm² Calculated percentage of Limit: 19.90% This prediction demonstrates the following: The power density levels for FCC at a distance of 20 cm are below the maximum levels allowed by regulations. Report no.: 1-7426/18-01-03 © CTC advanced GmbH Page 3 of 3 Prediction of MPE limit at given distance - ISED RSS-102, Issue 5, 2.5.2 RF exposure evaluation is required if the separation distance between the user and/or bystander and the device’s radiating element is greater than 20 cm, except when the device operates as follows: • below 20 MHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 1 W (adjusted for tune-up tolerance); • at or above 20 MHz and below 48 MHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 4.49/ƒ 0.5 W (adjusted for tune-up tolerance), where ƒ is in MHz; • at or above 48 MHz and below 300 MHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 0.6 W (adjusted for tune-up tolerance); • at or above 300 MHz and below 6 GHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 1.31 x 10 -2 ƒ 0.6834 W (adjusted for tune-up tolerance), where ƒ is in MHz; • at or above 6 GHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 5 W (adjusted for tune-up tolerance). Prediction: worst case 77 GHz Frequency 77000 MHz R Distance 20 cm P Max power input to the antenna 15 dBm G Antenna gain 15 dBi P G Maximum EIRP 30 dBm P G Maximum EIRP 1.0 W Exclusion Limit from above: 5.0 W Calculated percentage of Limit: 20.00% Conclusion: RF exposure evaluation is not required.

BNetzA - CAB - 02/21 - 102 TEST REPORT Test report no.: 1-7426/18-01-06 Testing laboratory Applicant CTC advanced GmbH Untertuerkheimer Strasse 6 – 10 66117 Saarbruecken / Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: https://www.ctcadvanced.com e-mail: [email protected] Accredited Testing Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2018-03) by the Deutsche Akkreditierungsstelle GmbH (DAkkS) The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate starting with the registration number: D-PL-12076-01. ASTYX GmbH Caroline-Herschel-Str. 2 85521 Ottobrunn / GERMANY Phone: +49 (0) 89 201 804 0 Contact: Serhat Ay & Sigmund Ott e-mail: [email protected] & [email protected] Phone: +49 173 2127350 & +49 173 2112952 Manufacturer ASTYX GmbH Caroline-Herschel-Str. 2 85521 Ottobrunn / GERMANY Test standard/s CFR 47 Part 95, Subpart M The 76-81 GHz Band Radar Service CFR 47 Part 2, Subpart J Frequency allocations and radio treaty matters; general rules and regulations For further applied test standards please refer to section 3 of this test report. Test Item Kind of test item: 77GHz Radar for Autonomous Drive Applications Model name: HiRes 6455 FCC ID: 2ASKB-HIRES55 Frequency: 76 – 81 GHz Antenna: Integrated patch antenna Power supply: 10 V to 16 V DC Temperature range: -20°C to +50°C This test report is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report authorized: Test performed: Thomas Vogler Meheza Walla Lab Manager Lab Manager Radio Communications & EMC Radio Communications & EMC Test report no.: 1-7426/18-01-06 © CTC advanced GmbH Page 2 of 56 1 Table of contents 1 Table of contents ............................................................................................................................................. 2 2 General information ......................................................................................................................................... 3 2.1 Notes and disclaimer ............................................................................................................................ 3 2.2 Application details ................................................................................................................................ 3 2.3 Test laboratories sub-contracted ......................................................................................................... 3 3 Test standard/s, references and accreditations .............................................................................................. 4 4 Reporting statements of conformity – decision rule ...................................................................................... 5 5 Test environment ............................................................................................................................................. 5 6 Test item........................................................................................................................................................... 6 6.1 General description ............................................................................................................................... 6 6.2 Additional information .......................................................................................................................... 6 7 Description of the test setup ............................................................................................................................ 7 7.1 Shielded semi anechoic chamber ......................................................................................................... 8 7.2 Shielded fully anechoic chamber ........................................................................................................ 10 7.3 Radiated measurements > 18 GHz...................................................................................................... 12 7.4 Radiated measurements > 50/85 GHz ................................................................................................ 12 8 Sequence of testing ....................................................................................................................................... 14 8.1 Sequence of testing radiated spurious 9 kHz to 30 MHz ................................................................... 14 8.2 Sequence of testing radiated spurious 30 MHz to 1 GHz .................................................................. 15 8.3 Sequence of testing radiated spurious 1 GHz to 18 GHz ................................................................... 16 8.4 Sequence of testing radiated spurious above 18 GHz ....................................................................... 17 8.5 Sequence of testing radiated spurious above 50/85 GHz with external mixers ................................ 18 9 Measurement uncertainty .............................................................................................................................. 19 10 Summary of measurement results ............................................................................................................. 20 11 Measurement results.................................................................................................................................. 21 11.1 Radiated power ................................................................................................................................ 21 11.2 Modulation characteristics .............................................................................................................. 28 11.3 Occupied bandwidth ........................................................................................................................ 29 11.4 Band edge …

Text truncated - open the document above for the full version.

Annex D 1-7426/18-01-01_AnnexD Setup photos of the Equipment Under Test This addendum is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Document authorized: Walla Meheza Lab Manager Radio Communications & EMC CTC advanced GmbHUntertuerkheimer Str. 6-10 66117 Saarbruecken / Germany Phone: +49 681 5 98 - 0 Fax: +49 681 5 98 - 9075 web: ctcadvanced.com e-mail: [email protected] Photos Photo 1 Photo 2 2020-11-13Document No. 1-7426/18-01-01_AnnexD2/4 Photo 3 Photo 4 2020-11-13Document No. 1-7426/18-01-01_AnnexD3/4 Document history VersionApplied changesDate of release initial release2020-11-13 - END OF DOCUMENT - 2020-11-13Document No. 1-7426/18-01-01_AnnexD4/4
