2ASMH-PCB019Wireless Power Bank

SP Connect is a registered trademark © 2023 SP United / PATENTED SYSTEM / All rights reserved WIRELESS POWERBANK EN / DE / FR / ES Conseils de configuration pour la navigation en extérieur pendant la charge sans fil • La navigation en extérieur à température élevée réduit l'ecacité de la charge. • Utilisez une luminosité d'écran adaptative, pensez à utiliser le mode nuit, éteignez l'écran de temps en temps. • Utilisez des cartes stockées localement pour éviter le trafic de données et la consommation d'énergie. • Désactivez le trafic de données s'il n'est pas nécessaire. • Désactivez les applications inutiles fonctionnant en arrière-plan. • Éteignez l'antenne Wi-Fi lorsque vous vous déplacez. • Pour augmenter l'ecacité de la recharge, envisagez la recharge par câble. ES ¡ATENCIÓN! • Si es posible, evita utilizarlo en un entorno húmedo o a altas temperaturas. • No martillees, desmontes o vuelvas a montar el producto, ya que podrías provocar un mal funcionamiento. • Las altas temperaturas pueden reducir el rendimiento de la carga. • El consumo de energía del smartphone puede superar la potencia de carga. ¡Ajusta el teléfono en consecuencia! Consejos para navegar al aire libre con carga inalámbrica • La navegación en exteriores a altas temperaturas reduce la eficiencia de la carga. • Utiliza un brillo de pantalla adaptado, considera el uso del modo nocturno, apaga la pantalla de vez en cuando. • Utiliza mapas almacenados localmente para evitar el tráfico de datos y el consumo de energía. • Apaga el tráfico de datos si no es necesario. • Apaga las aplicaciones innecesarias que se ejecutan en segundo plano. • Apaga la antena Wi-Fi cuando estés en movimiento. • Para aumentar la eficiencia de la carga, considere la posibilidad de cargar por cable. EN ATTENTION! • Avoid use in a humid or high temperature environment if possible. • Don’t hit, disassemble or re-assemble the product - this may lead to malfunction. • High Temperatures can reduce charge eciency. • Smartphone power consumption can exceed charge power. Setup phone appropriately! Setup tips for outdoor navigation while wireless charging • Outdoor navigation at high temperature reduces charge eciency. • Use adaptive screen brightness, consider using night mode, switch o screen occasionally. • Use locally stored maps to avoid data trac and power consumption. • Turn o data trac if not needed. • Turn o unnecessary apps running in the background. • Turn o Wi-Fi antenna while you are moving. • To increase charging eciency, consider cable charging. DE ACHTUNG! • Einsatz in einer feuchten Umgebung oder bei hohen Temperaturen nach Möglichkeit vermeiden. • Nicht auf das Produkt einschlagen, zerlegen oder wieder zusammenbauen • dies kann zu Fehlfunktionen führen. • Hohe Temperaturen können die Ladeleistung verringern. • Der Stromverbrauch des Smartphones kann die Ladeleistung übersteigen. Telefon entsprechend einstellen! Einrichtungstipps für die Navigation im Freien beim kabellosen Laden • Navigation im Freien bei hohen Temperaturen verringert die Ladeleistung. • Verwende eine angepasste Bildschirmhelligkeit, erwäge den Nachtmodus und schalte den Bildschirm gelegentlich aus. • Verwende lokal gespeicherte Karten, um Datenverkehr und Stromverbrauch zu vermeiden. • Schalte den Datenverkehr aus, wenn er nicht benötigt wird. • Schalte unnötige Apps aus, die im Hintergrund laufen. • Schalte die Wi-Fi-Antenne aus, wenn du dich bewegst. • Um die Ezienz des Ladevorgangs zu erhöhen, kannst du auch mit direkt verbundenem Kabel laden. FR ATTENTION! • Si possible, éviter d'utiliser le produit dans un environnement humide ou à des températures élevées. • Ne pas frapper, démonter ou remonter le produit • cela peut entraîner un dysfonctionnement. • Des températures élevées peuvent réduire la puissance de charge. • La consommation d'énergie du smartphone peut dépasser la puissance de charge. Régler le téléphone en conséquence! USB-C Power Source or Device Stromquelle oder Gerät Source ou dispositif d'alimentation Fuente de alimentación o dispositivo IP55 Input USB-C5V/2.6A, 9V/2A QC2.0/QC3.0 PD2.0/PD3.0/PPS Wireless OutputMax 10W Charge power depends on phone model, temperature, etc. Simultaneous Output 5V/2.4A Battery Specifications Capacity: 5000 mAh Rated Capacity (5V/2.4A): 2850 mAh, Nominal Voltage: 3.7 V Energy: 18.5Wh Operating Temperature -10 to +45° C Power Consumption < 0.1 mA (Standby) Technical Specifications FCC Statement 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications However. there is no quarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement This equipme…

Text truncated - open the document above for the full version.

SP United China Add: No.3 LANE 19 QIAN RD KENGKOU VILLAGE TINGSHAN DIST HOUJIE TOWN, GUANGDONE PROVINCE, China Tel: 0769-81299945 Email: [email protected] CFR 47 §2.911(d)(5)(i)(ii) Attestation Letter Attestation Letter Date: 2023-03-30 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(i)(ii) Filing FCC ID:2ASMH-PCB019 SP United China (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. SP United China (“the applicant”) certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature Contact Person: Jason Chiang Title: Manager Company Name& Address: SP United China No.3 LANE 19 QIAN RD KENGKOU VILLAGE TINGSHAN DIST HOUJIE TOWN, GUANGDONE PROVINCE, China

QA-FR-170-B SP United China Add: No.3 LANE 19 QIAN RD KENGKOU VILLAGE TINGSHAN DIST HOUJIE TOWN, GUANGDONE PROVINCE, China Tel: 0769-81299945 Email: [email protected] FCC Authorization Date: 2023-03-30 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We , SP United China, Hereby authorizes China Certification ICT Co., Ltd (Dongguan) to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by China Certification ICT Co., Ltd (Dongguan) on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Client’s signature Printed Name: Jason Chiang Title: Manager

QA-FR-171-A SP United China Add: No.3 LANE 19 QIAN RD KENGKOU VILLAGE TINGSHAN DIST HOUJIE TOWN, GUANGDONE PROVINCE, China Tel: 0769-81299945 Email: [email protected] FCC Confidential Authorization Date: 2023-03-30 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2ASMH-PCB019 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, ( SP United China ) hereby requests long-term confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Signature: Printed Name: Jason Chiang Title: Manager

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS Port

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS Uncover ANT

China Certification ICT Co., Ltd (Dongguan) Report No.: CR230207083-00 Page 47 of 51 5 MAXIMUM PERMISSIBLE EXPOSURE (MPE) 5.1 Applicable Standard According to subpart §1.1310, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Maximum Permissible Exposure (MPE) (§1.1310) (B) Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f²) 30 30–300 27.5 0.073 0.2 30 300–1500 / / f/1500 30 1500–100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density; According with KDB 680106 D01 RF Exposure Wireless Charging Apps v03r01 clause 3 c) According to 680106 D01 RF Exposure Wireless Charging App v03r01 clause 5 b) China Certification ICT Co., Ltd (Dongguan) Report No.: CR230207083-00 Page 48 of 51 5.2 Block Diagram of Test Setup Note: The EHP-200AC Probe has a diameter of 9.2cm and a radius of 4.6cm. 5.3 Test Procedures 1) Perform H-field measurements for each edge/top surface of the host/client pair at every 2 cm, starting from as close as possible out to 20 cm 2) The highest emission level was recorded and compared with limit. 3) The EUT was measured according to the dictates of TCB Workshop “41-Part-18-&-Wireless-Power- Transfer - April 27, 2022” 0~20cm China Certification ICT Co., Ltd (Dongguan) Report No.: CR230207083-00 Page 49 of 51 5.4 Test Data: Serial Number: 229P_1 Test Date: 2023/7/21 Test Site: RF Test Mode: M3: Wireless Output 10W was the worst Tester: Vic Du Test Result: Pass Environmental Conditions: Temperature: (°C) 25.3 Relative Humidity: (%) 24 ATM Pressure: (kPa) 100.5 Test Equipment List and Details: Manufacturer Description Model Serial Number Calibration Date Calibration Due Date Narda Electric and Magnetic Field Probe-Anal yzer EHP-200AC 180ZX10204 2021/06/07 2024/06/06 * Statement of Traceability: China Certification ICT Co., Ltd (Dongguan) attests that all calibrations have been performed, traceable to National Primary Standards and International System of Units (SI). Test Data: Test distance: 0-4cm H-Field Strength: Frequency Range (kHz) Position A (A/m) Position B (A/m) Position C (A/m) Position D (A/m) Position E (A/m) Position F (A/m) Max. Percentage (%) Limit (A/m) 137 0.1205 0.7251 0.2642 0.4084 0.4638 0.2707 44.48 1.63 Test distance: 6cm H-Field Strength: Frequency Range (kHz) Position A (A/m) Position B (A/m) Position C (A/m) Position D (A/m) Position E (A/m) Position F (A/m) Max. Percentage (%) Limit (A/m) 137 0.1301 0.6221 0.2638 0.3488 0.4552 0.2504 38.17 1.63 Test distance: 8cm H-Field Strength: Frequency Range (kHz) Position A (A/m) Position B (A/m) Position C (A/m) Position D (A/m) Position E (A/m) Position F (A/m) Max. Percentage (%) Limit (A/m) 137 0.1344 0.253 0.2541 0.3417 0.2649 0.3158 20.96 1.63 Test distance: 10cm H-Field Strength: Frequency Range (kHz) Position A (A/m) Position B (A/m) Position C (A/m) Position D (A/m) Position E (A/m) Position F (A/m) Max. Percentage (%) Limit (A/m) 137 0.1309 0.2119 0.1802 0.1664 0.1908 0.2867 17.59 1.63 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230207083-00 Page 50 of 51 Test distance: 12cm H-Field Strength: Frequency Range (kHz) Position A (A/m) Position B (A/m) Position C (A/m) Position D (A/m) Position E (A/m) Position F (A/m) Max. Percentage (%) Limit (A/m) 137 0.1197 0.1864 0.143 0.1247 0.1482 0.1224 11.44 1.63 Test distance: 14cm H-Field Strength: Frequency Range (kHz) Position A (A/m) Position B (A/m) Position C (A/m) Position D (A/m) Position E (A/m) Position F (A/m) Max. Percentage (%) Limit (A/m) 137 0.1221 0.1268 0.1242 0.1249 0.1309 0.1243 8.03 1.63 Test distance: 16cm H-Field Strength: Frequency Range (kHz) Position A (A/m) Position B (A/m) Position C (A/m) Position D (A/m) Position E (A/m) Position F (A/m) Max. Percentage (%) Limit (A/m) 137 0.1204 0.1274 0.1211 0.1254 0.1411 0.1223 8.66 1.63 Test distance: 18cm H-Field Strength: Frequency Range (kHz) Position A (A/m) Position B (A/m) Position C (A/m) Position D (A/m) Position E (A/m) Position F (A/m) Max. Percentage (%) Limit (A/m) 137 0.1278 0.1277 0.1244 0.1255 0.1204 0.1201 7.84 1.63 Test distance: 20cm H-Field Strength: Frequency Range (kHz) Position A (A/m) Position B (A/m) Position C (A/m) Position D (A/m) Position E (A/m) Position F (A/m) Max. Percentage (%) Limit (A/m) 137 0.1246 0.1235 0.1256 0.1211 0.1235 0.1205 7.71 1.63 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230207083-00 Page 51 of 51 Considerations of compliance 680106 D01 RF Exposure Wireless Charging App v03r01 clause 5 b: (1) Power transfer frequency is less than 1 MHz Yes, the operation frequency is 137 kHz. (2) Output power from each primary coil is less than or equal to 15 watts. Yes, the maximum output power of primary coil is 10 Watts. (3) The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. The transfer system includes only single primary coil, and system detect and allow coupling only between individual pairs of coils. (4) Client device is placed directly in contact with the transmitter. Yes, client device is placed directly in contact with the transmitter (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). No, both mobile and portable exposure conditions apply. (6) The aggregate H-field strengths anywhere at or beyond 15 cm surrounding the device, and 20 cm away from the surface from all coils that by design can simultaneously transmit, and while those coils are simultaneously energized, are demonstrated to be less than 50% of the applicable MPE limit. Yes, the H-field measurements for each edge/top …

Text truncated - open the document above for the full version.

TEST REPORT Applicant: SP United China Address: No. 3 LANE 19 QIAN RD KENGKOU VILLAGE TINGSHAN DIST HOUJIE TOWN DONGGUAN CITY GUANGDONG PROVINCE CHINA FCC ID: 2ASMH-PCB019 Product Name: Wireless power bank Standard(s): 47 CFR Part 15, Subpart C ANSI C63.10-2013 The above equipment has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: CR230207083-00 Date Of Issue: 2023/7/22 Reviewed By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230207083-00 Page 2 of 51 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. The lab has been recognized by Innovation, Science and Economic Development Canada to test to Canadian radio equipment requirements, the CAB identifier: CN0123. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.: CR230207083-00 Page 3 of 51 CONTENTS TEST FACILITY ............................................................................................................................................................. 2 DECLARATIONS ............................................................................................................................................................ 2 DOCUMENT REVISION HISTORY ......................................................................................................................... 4 1. GENERAL INFORMATION ................................................................................................................................... 5 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ............................................................................... 5 1.2 DESCRIPTION OF TEST CONFIGURATION ................................................................................................................ 6 1.2.1 EUT Operation Condition: ............................................................................................................................. 6 1.2.2 Support Equipment List and Details .............................................................................................................. 6 1.2.3 Support Cable List and Details ...................................................................................................................... 6 1.2.4 Block Diagram of Test Setup ......................................................................................................................... 7 1.3 MEASUREMENT UNCERTAINTY .............................................................................................................................. 9 2. SUMMARY OF TEST RESULTS ......................................................................................................................... 10 3. REQUIREMENTS AND TEST PROCEDURES ................................................................................................. 11 3.1 AC LINE CONDUCTED EMISSIONS ........................................................................................................................ 11 3.1.1 Applicable Standard ..................................................................................................................................... 11 3.1.2 EUT Setup.................................................................................................................................................... 12 3.1.3 EMI Test Receiver Setup ............................................................................................................................. 12 3.1.4 Test Procedure ............................................................................................................................................. 13 3.1.5 Corrected Amplitude & Margin Calculation ................................................................................................ 13 3.2 RADIATION SPURIOUS EMISSIONS ........................................................................................................................ 14 3.2.1 Applicable Standard ..................................................................................................................................... 14 3.2.2 EUT Setup.................................................................................................................................................... 14 3.2.3 EMI Test Receiver & Spectrum Analyzer Setup ......................................................................................... 15 3.2.4 Corrected Amplitude & Margin Calculation ................................................................................................ 15 3.3 20 DB EMISSION BANDWIDTH: ..........................................................…

Text truncated - open the document above for the full version.

EXHIBIT D - TEST SETUP PHOTOGRAPHS Conducted Emissions Front View M1 Conducted Emissions Side View M1 Radiated Emission 9k-30MHz Parallel View-M1 Radiated Emission 9k-30MHz Perpendicular View-M1 Radiated Emission 9k-30MHz Ground-parallel View-M1 Radiated Emission 30M-1GHz View-M1 Radiated Emission 9k-30MHz Parallel View-M2 Radiated Emission 9k-30MHz Perpendicular View-M2 Radiated Emission 9k-30MHz Ground-parallel View-M2 Radiated Emission 30M-1GHz View-M2 Radiated Emission 9k-30MHz Parallel View-M3 Radiated Emission 9k-30MHz Perpendicular View-M3 Radiated Emission 9k-30MHz Ground-parallel View-M3 Radiated Emission 30M-1GHz View-M3 H-Field Position A Test distance 0-4cm M3 H-Field Position B Test distance 0-4cm M3 H-Field Position C Test distance 0-4cm M3 H-Field Position D Test distance 0-4cm M3 H-Field Position E Test distance 0-4cm M3 H-Field Position F Test distance 0-4cm M3
