WHAT’S INCLUDED The REIGN Wireless Safety Edge Kit is a revolutionary product that will make any safety edge set up wireless. This kit allows for all major safety edge technology to work with any manufacturers operator. By using the proprietary Reign wireless technology we get extreme range and penetration from the most reliable wireless edge kit on the market. HOW I T WORKS... Congratulations on your purchase of the Transmitter Solutions Wireless Safety Edge Kit. It has been designed with state-of-the-art radio technology to allow for extreme range and penetration allowing for maximum reliability. The wireless safety edge kit comes factory paired with all the necessary components to get the system up and running quickly. Simply install the batteries to the XET-100 and supply 8-24 VAC/ DC power to the XER-100 and you will be up and running. v. 1.28.20 EXTREME RANGE WIRELESS SAFETY EDGE KIT There are two pieces that complete the wireless edge kit. This kit includes the transmitter, which is connected to the safety edge, part number XET-100. The second component of the kit is the receiver, which is connected to the operator, part number XER-100. R EIGN wire less t echno l o g y 2 CONTENTS: . . . . . . . TROUBLESHOOTING.... . . .... ..... . . . . ... . . . . . . . . . . ... . . . . . . ... . . . . . . . . . ... . . . . . . ... . .. . .. . .1 0 1 . . . P AIRING IN THE F IELD... . . . . .. . .. .. . . . . . ... . . . . . . . . . . ... . . . . . . ... . . . . . . . . . ... . . . . . . ... . .. . .1 0 J UMPERS. . . . . . . . . . . . . .. . . . . . .. . .. .. . . . . . ... . . . . . . . . . . ... . . . . . . ... . . . . . . . . . ... . . . . . . ... . .. . . . .9 D IP SWITCHES. . . . . . . . . . . . . . . . . . . . . . . . . . . . ... . . . . . . . . . . ... . . . . . . ... . . . . . . . . . ... . . . . . . ... .. . .8 POWER DETAILS.. .. . . .... ..... . . . . ... . . . . . . . . . . ... . . . . . . ... . . . . . . . . . . . . ... . . . . . . ... . . . . .. . .1 0 B OARD CONNECTIONS... . . . . .. . .. .. . . . . . ... . . . . . . . . . . . . . . . . ... . . . . . . . . . ... . . . . . . . .. . .. . .1 0 SPECIFICATIONS. . . . . . . . . . . . . .. . . . . . .. . .. . . . . . . . . . . ... . . . . . . ... . . . . . . . . . ... . . . . . . ... . .. . . . .9 FCC REGULATORY STATEMENT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . ... . . . . . . . . . ... . . . . . . ... .. . .1 W IRING. . . . . . . . . . . . . .. . . . . . .. . .. .. . . . . . ... . . . . . . . . . . ... . . . . . . ... . . . . . . . . . . . ... . . . . . . ... . .. . . . .9 L ED INDICATORS. . . . . . . . . . . . . . . . . . .. . . . . . . ... . . . . . . . . . . ... . . . . . . ... . . . . . . . . . ... . . . . . . ... .. . .8 Power Input: 8-24 Volt AC/DC Mi nimum / Maxi mum Te mperature Range: -40 °F to 185°F (-40° C to 85°C) Security Encryption: AES 3 .. 1 . (2ASPOXET100) and (2ASPOXER100) . P O W ER DE TA I L S 4 . E D I NDIC AT O R S STATUS LEDs: Craig needs to update. 1 3 1 2 3 4 5 4 2 5 5 1 POWER INPUT: BATTERY INPUT: Battery In put: 2 AA Batteries Power Input: 8 to 24 VOLTS AC/DC. 1 AMP Minimum. . REL AY DIAGRAM AND WIRING 6 7 DIP SWITCH E S 8 1 DIP SWITCHES: . JUMPERS 12 Volt Sealed Lead Acid (SLA) battery only. Solid GREEN LED indicates battery charging. Momentarily flashing GREEN LED indicates battery is charged and a trickle/conditioning charge is occurring. MORE INFO NEEDED FROM CRAIG PAI RING IN THE FIELD PAIRING 9 XRE-100 un its are not communicating: CRAIG TO FILL OUT TROUBLESHOOTING 10 The warranty period of this product is 24 months, beginning from the manufacturing date. During this period, if the product does not operate correctly, due to a defective component, the product wi ll be repaired or replaced at the sole discretion of Transmitter Solutions. This warranty does not extend to the product casing which can be damaged by conditions outside of the control of Transmitter Solutions. EXCEPT AS SET FORTH ABOVE, TRANSMITTER SOLUTIONS MAKES NO WARRANTIES REGARDING THE GOODS, EXPRESS OR IMPLIED, INCLUDING WARRANTY OF MERCHANTABILITY OR WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE. BUYER MAKES NO RELIANCE ON ANY REPRESENTATION OF TRANSMITTER SOLUTIONS, EXPRESS OR IMPLIED, WITH REGARD TO THE GOODS AND ACCEPTS THEM “AS-IS/WHERE-IS”. TRANSMITTER SOLUTIONS SELLS THE GOODS TO BUYER ON CONDITION THAT TRANSMITTER SOLUTIONS WILL HAVE NO LIABILITY OF ANY KIND AS A RESULT OF THE SALE. BUYER AGREES THAT TRANSMITTER SOLUTIONS SHALL HAVE NO LIABILITY FOR DAMAGES OF ANY KIND, WHETHER DIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING INJURIES TO PERSONS OR PROPER- TY, TO BUYER, ITS EMPLOYEES OR AGENTS, AS A RESULT OF THE SALE. BUYER ALSO AGREES TO HOLD TRANSMITTER SOLUTIONS HARMLESS FROM ANY CLAIMS BUYER, OR ANY THIRD PARTY, MAY HAVE AS A RESULT OF BUYER’S USE OR DISPOSAL OF THE GOODS. BUYER HAS READ THIS DISCLAIMER AND AGREES WITH ITS TERMS IN CONSIDERATION OF RECEIVING THE GOODS. WARRANTY 11 PH 866.975.0101 • FX 866.975.0404 www.transmittersolutions.com

FCC ID: 2ASPOXER100

Registration number: W6M21910-19422-C-1 FCC ID: 2ASPOXER100 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 7 of 14 Internal Photos Registration number: W6M21910-19422-C-1 FCC ID: 2ASPOXER100 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 8 of 14 Registration number: W6M21910-19422-C-1 FCC ID: 2ASPOXER100 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 9 of 14 Registration number: W6M21910-19422-C-1 FCC ID: 2ASPOXER100 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 10 of 14 Registration number: W6M21910-19422-C-1 FCC ID: 2ASPOXER100 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 11 of 14 Registration number: W6M21910-19422-C-1 FCC ID: 2ASPOXER100 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 12 of 14

Registration number: W6M21910-19422-C-1 FCC ID: 2ASPOXER100 Worldwide Testing Services(Taiwan) Co., Ltd. Page 16 of 39 3.2 RF Exposure Compliance Requirements FCC Rule: 15.247(b)(3) EIRP = max. conducted output power +antenna gain EIRP= 12.58 dBm + (3.32 dBi)=15.90 dBm= 38.90 mW Test equipment used: ETSTW-RE 055 3.3 Exemption Limits for Routine Evaluation according to 47 CFR FCC Part 2 Subpart J, section 2.1091 FCC OET Bulletin 65 Edition 97.01 determines the equations for predicting RF fields and applicable limits. The prediction for power density in the far-field but will over-predict power density in the near field, where it could be used for walking a “worst case” or conservative prediction. Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 20 cm normally can be maintained between the user and the device. MPE Calculation Method E ＝ Electric field (V/m) P ＝ output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to mW/cm 2 . Registration num ber: W6M21910-19422-C-1 FCC ID: 2ASPOXER100 Worldwide Testing Services(Taiwan) Co., Ltd. Page 17 of 39 Established separation distance is 20 cm. Operating frequency band: 902-928 MHz, The product meets RF exposure requirement. Because the power density of 0.0077 mW/cm 2 at 902.25 MHz is below the power density limit of 0.6015 mW/cm 2 . Limits: Limit for General Population / Uncontrolled Exposure Frequency (MHz) Power Density (mW/cm 2 ) 902.25 0.6015

of Applicant: Transmitter Solutions Address: 2480 South 3850 West, Suite B Salt Lake City, UT 84120 United States Tested and Prepared by Worldwide Testing Services (Taiwan) Co., Ltd. FCC Registration No.: TW1477, TW0020, TW1072 Industry Canada filed test laboratory Reg. No. 20037 A2LA Accredited No.: 2732.01 Report No.: W6M21910-19422-C-1 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU TAIPEI 114, TAIWAN, R.O.C. TEL: 886-2-66068877 FAX: 886-2-66068879 E-mail: [email protected] FCC PART 15 SUBPART C TEST REPORT for Reign - Safety Edge Receiver Model No.: XER-100 FCC ID: 2ASPOXER100 Registration num ber: W6M21910-19422-C-1 FCC ID: 2ASPOXER100 Worldwide Testing Services(Taiwan) Co., Ltd. Page 1 of 39 TABLE OF CONTENTS 1 GENERAL INFORMATION ...................................................................................................... 2 1.1 Notes .................................................................................................. 2 1.2 Testing laboratory .................................................................................................. 3 1.2.1 Location .................................................................................................. 3 1.2.2 Details of accreditation status .............................................................................................. 3 1.3 Details of approval holder .................................................................................................. 3 1.4 Application details .................................................................................................. 4 1.5 General information of Test item ......................................................................................... 4 1.6 Test standards .................................................................................................. 5 2 TECHNICAL TEST .................................................................................................................... 6 2.1 Summary of test results .................................................................................................. 6 2.2 Test environment .................................................................................................. 6 2.3 Test Equipment List .................................................................................................. 7 2.4 General Test Procedure ................................................................................................ 10 3 TEST RESULTS (ENCLOSURE) ............................................................................................ 12 3.1 Peak Output Power (transmitter) ....................................................................................... 13 3.2 RF Exposure Compliance Requirements ........................................................................... 16 3.3 Out of Band Radiated Emissions ....................................................................................... 18 3.4 Exemption Limits for Routine Evaluation according to 47 CFR FCC Part 2 Subpart J, section 2.1091............................ ........................................................................................ 18 3.5 Transmitter Radiated Emissions in restricted Bands ......................................................... 19 3.6 Spurious emissions (tx) ................................................................................................ 20 3.7 Carrier Frequency Separation ............................................................................................ 22 3.8 Number of Hopping Frequencies ....................................................................................... 25 3.8.1 Pseudorandom Frequency Hopping Sequence................................................................... 26 3.8.2 Coordination of hopping sequences to other transmitters ................................................. 26 3.8.3 System Receiver Hopping Capability ................................................................................ 26 3.9 Time of Occupancy (Dwell Time) ..................................................................................... 27 3.10 20dB Bandwidth ................................................................................................ 31 3.10.1 System Receiver Input Bandwidth .................................................................................... 33 3.11 Band-edge Compliance of RF Emissions .......................................................................... 34 3.12 Radiated Emissions from Receiver Section of Transceiver ............................................... 37 3.13 Power Line Conducted Emission ....................................................................................... 38 Appendix.........................................................................................................39 Registration num ber: W6M21910-19422-C-1 FCC ID: 2ASPOXER100 Worldwide Testing Services(Taiwan) Co., Ltd. Page 2 of 39 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. The test results of this test report relate exclusively to the item tested as specified in 1.5. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the …
