2ASQI-362210Bluetooth Speaker

VL]H[PPJ䬒⡾㓮θ&щ6'4:54+)6'4 54+5XGTMK)θ伄⩪ᣎ享θ䗽ଇ㟒: Bluetooth Speaker + Bluetooth remote This device complies with RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. When operating the device, a minimum distance of 20cm should be maintained between the radiator of the Bluetooth speaker and the user's body, and a minimum distance of 0cm should be maintained between the radiator of the Bluetooth remote control and the user's body. This device complies with RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. When operating the device, a minimum distance of 20cm should be maintained between the radiator of the Bluetooth speaker and the user's body, and a minimum distance of 0cm should be maintained between the radiator of the Bluetooth remote control and the user's body. Cet appareil est conforme aux limites d'exposition aux rayonnements du Canada établies pour un environnement non contr?lé. Cet émetteur ne doit pasêtre co-localisé ou fonctionner en conjonction avec toute autre antenne ou émetteur. Lors de l'utilisation de l'appareil, une distance minimale de 20 cm doit être maintenue entre le radiateur du haut-parleur Bluetooth et le corps de l'utilisateur, et une distance minimale de 0 cm doit être maintenue entre le radiateur de la télécommande Bluetooth et le corps de l'utilisateur. Cet appareil est conforme aux limites d'exposition aux rayonnements du Canada établies pour un environnement non contr?lé. Cet émetteur ne doit pasêtre co-localisé ou fonctionner en conjonction avec toute autre antenne ou émetteur. Lors de l'utilisation de l'appareil, une distance minimale de 20 cm doit être maintenue entre le radiateur du haut-parleur Bluetooth et le corps de l'utilisateur, et une distance minimale de 0 cm doit être maintenue entre le radiateur de la télécommande Bluetooth et le corps de l'utilisateur.

FCC ID:2ASQI-362210 IC: 24886-362210

FCC ID: 2ASQI-362210 IC: 24886-362210 HVIN: 362210

FCC ID:2ASQI-362210 IC: 24886-362210 Bluetooth antenna

RF Exposure evaluation FCC ID: 2ASQI-362210 Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information The device can only use antennas certificated as follows provided by manufacturer; Internal Identification Antenna Identification in Internal photos Antenna type and antenna number Operate frequency band Maximum antenna gain Antenna 1 ANT PCB antenna 2.4GHz – 2.5 GHz 3.0dBi 5. Conducted power and Manufacturing Tolerance GFSK Channel Channel 00 Channel 39 Channel 78 Target (dBm) 3.0 3.0 3.0 Tolerance ±(dB) 1.0 1.0 1.0 π/4DQPSK Channel Channel 00 Channel 39 Channel 78 Target (dBm) 3.0 3.0 3.0 Tolerance ±(dB) 1.0 1.0 1.0 8DPSK Channel Channel 00 Channel 39 Channel 78 Target (dBm) 4.0 4.0 4.0 Tolerance ±(dB) 1.0 1.0 1.0 BLE_1Mbps Channel Channel 00 Channel 19 Channel 39 Target (dBm) 3.0 3.0 3.0 Tolerance ±(dB) 1.0 1.0 1.0 BLE_2Mbps Channel Channel 00 Channel 19 Channel 39 Target (dBm) 3.0 3.0 3.0 Tolerance ±(dB) 1.0 1.0 1.0 6. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna is 3.0dBi for WIFI, the RF power density can be obtained. Modulation Type Max tune up power tolerance(dBm) Max Output power to antenna (mW) Antenna Gain (Numeric) Power Density at R=20cm (mW/cm2) Limit (mW/cm2) Result GFSK 4 2.5119 1.9953 0.0010 1.0000 Pass π/4DQPSK 4 2.5119 1.9953 0.0010 1.0000 Pass 8DPSK 5 3.1623 1.9953 0.0013 1.0000 Pass BLE_1Mbps 4 2.5119 1.9953 0.0010 1.0000 Pass BLE_2Mbps 4 2.5119 1.9953 0.0010 1.0000 Pass 7. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. ----------------THE END OF REPORT---------------

Antenna Describe Antenna PCB Antenna Gain 3dBi Frequency Range 2.4Ghz-2.483Ghz Connector Type Direct Location of mearement(company SHENZHENSHIXINZHONGXN name) TECHNOLOGY.CO.,LTD 2：External View Drawing Picture of antenna 3：Measurement Result 3.1 Return Loss (S11 ) 3.2 Smith Chart 3.3 Gain

FCC ID:2ASQI-362210 IC: 24886-362210 Page 1 of 38 Annex for Bluetooth BR&EDR Appendix A: 20dB Emission Bandwidth Test Result TestMode Antenna Channel 20db EBW[MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.948 2401.445 2402.393 --- PASS 2441 0.957 2440.439 2441.396 --- PASS 2480 0.954 2479.439 2480.393 --- PASS 2DH5 Ant1 2402 1.287 2401.274 2402.561 --- PASS 2441 1.287 2440.271 2441.558 --- PASS 2480 1.290 2479.268 2480.558 --- PASS 3DH5 Ant1 2402 1.269 2401.268 2402.537 --- PASS 2441 1.266 2440.268 2441.534 --- PASS 2480 1.272 2479.265 2480.537 --- PASS FCC ID:2ASQI-362210 IC: 24886-362210 Page 2 of 38 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 FCC ID:2ASQI-362210 IC: 24886-362210 Page 3 of 38 DH5_Ant1_2480 2DH5_Ant1_2402 2DH5_Ant1_2441 2DH5_Ant1_2480 FCC ID:2ASQI-362210 IC: 24886-362210 Page 4 of 38 3DH5_Ant1_2402 3DH5_Ant1_2441 3DH5_Ant1_2480 FCC ID:2ASQI-362210 IC: 24886-362210 Page 5 of 38 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Channel OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.88002 2401.466 2402.346 --- PASS 2441 0.88090 2440.463 2441.344 --- PASS 2480 0.88118 2479.462 2480.343 --- PASS 2DH5 Ant1 2402 1.1739 2401.321 2402.494 --- PASS 2441 1.1746 2440.320 2441.495 --- PASS 2480 1.1751 2479.320 2480.495 --- PASS 3DH5 Ant1 2402 1.1604 2401.327 2402.487 --- PASS 2441 1.1607 2440.326 2441.487 --- PASS 2480 1.1627 2479.326 2480.489 --- PASS FCC ID:2ASQI-362210 IC: 24886-362210 Page 6 of 38 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 FCC ID:2ASQI-362210 IC: 24886-362210 Page 7 of 38 2DH5_Ant1_2402 2DH5_Ant1_2441 2DH5_Ant1_2480 FCC ID:2ASQI-362210 IC: 24886-362210 Page 8 of 38 3DH5_Ant1_2402 3DH5_Ant1_2441 3DH5_Ant1_2480 FCC ID:2ASQI-362210 IC: 24886-362210 Page 9 of 38 Appendix C: Maximum conducted output power Test Result TestMode Antenna Channel Result[dBm] Limit[dBm] Verdict DH5 Ant1 2402 3.06 ≤30 PASS 2441 2.73 ≤30 PASS 2480 2.31 ≤30 PASS 2DH5 Ant1 2402 3.69 ≤20.97 PASS 2441 3.40 ≤20.97 PASS 2480 2.82 ≤20.97 PASS 3DH5 Ant1 2402 4.03 ≤20.97 PASS 2441 3.65 ≤20.97 PASS 2480 3.18 ≤20.97 PASS TestMode Antenna Channel Result[dBm] Antenna gain [dBi] EIRP [dBm] EIRP Limit[dBm] Verdict DH5 Ant1 2402 3.06 3 6.06 ≤36.02 PASS 2441 2.73 3 5.73 ≤36.02 PASS 2480 2.31 3 5.31 ≤36.02 PASS 2DH5 Ant1 2402 3.69 3 6.69 ≤36.02 PASS 2441 3.40 3 6.40 ≤36.02 PASS 2480 2.82 3 5.82 ≤36.02 PASS 3DH5 Ant1 2402 4.03 3 7.03 ≤36.02 PASS 2441 3.65 3 6.65 ≤36.02 PASS 2480 3.18 3 6.18 ≤36.02 PASS FCC ID:2ASQI-362210 IC: 24886-362210 Page 10 of 38 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 FCC ID:2ASQI-362210 IC: 24886-362210 Page 11 of 38 DH5_Ant1_2480 2DH5_Ant1_2402 2DH5_Ant1_2441 2DH5_Ant1_2480 FCC ID:2ASQI-362210 IC: 24886-362210 Page 12 of 38 3DH5_Ant1_2402 3DH5_Ant1_2441 3DH5_Ant1_2480 FCC ID:2ASQI-362210 IC: 24886-362210 Page 13 of 38 Appendix D: Carrier frequency separation Test Result TestMode Antenna Channel Result[MHz] Limit[MHz] Verdict DH5 Ant1 Hop 1 ≥0.638 PASS 2DH5 Ant1 Hop 1.004 ≥0.860 PASS 3DH5 Ant1 Hop 1.002 ≥0.848 PASS FCC ID:2ASQI-362210 IC: 24886-362210 Page 14 of 38 Test Graphs DH5_Ant1_Hop 2DH5_Ant1_Hop 3DH5_Ant1_Hop FCC ID:2ASQI-362210 IC: 24886-362210 Page 15 of 38 Appendix E: Time of occupancy Test Result TestMode Antenna Channel BurstWidth [ms] TotalHops [Num] Result[s] Limit[s] Verdict DH1 Ant1 Hop 0.37 330 0.122 ≤0.4 PASS DH3 Ant1 Hop 1.62 160 0.259 ≤0.4 PASS DH5 Ant1 Hop 2.87 110 0.315 ≤0.4 PASS 2DH1 Ant1 Hop 0.38 330 0.125 ≤0.4 PASS 2DH3 Ant1 Hop 1.63 160 0.261 ≤0.4 PASS 2DH5 Ant1 Hop 2.88 110 0.317 ≤0.4 PASS 3DH1 Ant1 Hop 0.38 330 0.125 ≤0.4 PASS 3DH3 Ant1 Hop 1.63 160 0.261 ≤0.4 PASS 3DH5 Ant1 Hop 2.88 110 0.317 ≤0.4 PASS Note: (1) Dwell time=Pulse time (ms) × Total Pulse number s (2) Total Pulse number= Pulse number in 3.16 s × 10 FCC ID:2ASQI-362210 IC: 24886-362210 Page 16 of 38 Test Graphs DH1_Ant1_Hop DH1_Ant1_Hop DH3_Ant1_Hop FCC ID:2ASQI-362210 IC: 24886-362210 Page 17 of 38 DH3_Ant1_Hop DH5_Ant1_Hop DH5_Ant1_Hop FCC ID:2ASQI-362210 IC: 24886-362210 Page 18 of 38 2DH1_Ant1_Hop 2DH1_Ant1_Hop 2DH3_Ant1_Hop FCC ID:2ASQI-362210 IC: 24886-362210 Page 19 of 38 2DH3_Ant1_Hop 2DH5_Ant1_Hop 2DH5_Ant1_Hop FCC ID:2ASQI-362210 IC: 24886-362210 Page 20 of 38 3DH1_Ant1_Hop 3DH1_Ant1_Hop 3DH3_Ant1_Hop FCC ID:2ASQI-362210 IC: 24886-362210 Page 21 of 38 3DH3_Ant1_Hop 3DH5_Ant1_Hop 3DH5_Ant1_Hop FCC ID:2ASQI-362210 IC: 24886-362210 Page 22 of 38 Appendix F: Number of hopping channels Test Result TestMode Antenna Channel Result[Num] Limit[Num] Verdict DH5 Ant1 Hop 79 ≥15 PASS 2DH5 Ant1 Hop 79 ≥15 PASS 3DH5 Ant1 Hop 79 ≥15 PASS

FCC ID:2ASQI-362210 IC: 24886-362210 Page 23 of 38 Test Graphs DH5_Ant1_Hop 2DH5_Ant1_Hop 3DH5_Ant1_Hop FCC ID:2ASQI-362210 IC: 24886-362210 Page 24 of 38 Appendix G: Band edge measurements Test Result TestMode Antenna ChName Channel RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 Low 2402 2.69 -46.73 ≤-17.31 PASS High 2480 1.80 -50.46 ≤-18.2 PASS Low Hop_2402 2.18 -52.65 ≤-17.82 PASS High Hop_2480 1.88 -56.08 ≤-18.12 PASS 2DH5 Ant1 Low 2402 2.31 -48.97 ≤-17.69 PASS High 2480 1.77 -51.41 ≤-18.23 PASS Low Hop_2402 0.55 -54.17 ≤-19.45 PASS High Hop_2480 1.32 -56.6 ≤-18.68 PASS 3DH5 Ant1 Low 2402 2.68 -48.28 ≤-17.32 PASS High 2480 1.72 -51.31 ≤-18.28 PASS Low Hop_2402 1.43 -54.8 ≤-18.57 PASS High Hop_2480 1.69 -56.56 ≤-18.31 PASS FCC ID:2ASQI-362210 IC: 24886-362210 Page 25 of 38 Test Graphs DH5_Ant1_Low_2402 DH5_Ant1_High_2480 DH5_Ant1_Low_Hop_2402 FCC ID:2ASQI-362210 IC: 24886-362210 Page 26 of 38 DH5_Ant1_High_Hop_2480 2DH5_Ant1_Low_2402 2DH5_Ant1_High_2480 FCC ID:2ASQI-362210 IC: 24886-362210 Page 27 of 38 2DH5_Ant1_Low_Hop_2402 2DH5_Ant1_High_Hop_2480 3DH5_Ant1_Low_2402 FCC ID:2ASQI-362210 IC: 24886-362210 Page 28 of 38 3DH5_Ant1_High_2480 3DH5_Ant1_Low_Hop_2402 3DH5_Ant1_High_Hop_2480 FCC ID:2ASQI-362210 IC: 24886-362210 Page 29 of 38 Appendix H: Conducted Spurious Emission Test Result TestMode Antenna Channel FreqRange [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 2402 Reference 2.41 2.41 --- PASS 30~3000 2.41 -55.95 ≤-17.59 PASS 3000~26500 2.41 -63.26 ≤-17.59 PASS 2441 Reference 2.27 2.27 --- PASS 30~3000 2.27 -55.8 ≤-17.73 PASS 3000~26500 2.27 -62.68 ≤-17.73 PASS 2480 Reference 1.66 1.66 --- PASS 30~3000 1.66 -55.84 ≤-18.35 PASS 3000~26500 1.66 -64.67 ≤-18.35 PASS 2DH5 Ant1 2402 Reference 2.38 2.38 --- PASS 30~3000 2.38 -56.13 ≤-17.62 PASS 3000~26500 2.38 -63.8 ≤-17.62 PASS 2441 Reference 2.15 2.15 --- PASS 30~3000 2.15 -55.74 ≤-17.85 PASS 3000~26500 2.15 -62.16 ≤-17.85 PASS 2480 Reference 1.31 1.31 --- PASS 30~3000 1.31 -47.03 ≤-18.69 PASS 3000~26500 1.31 -65.21 ≤-18.69 PASS 3DH5 Ant1 2402 Reference 1.80 1.80 --- PASS 30~3000 1.80 -55.47 ≤-18.2 PASS 3000~26500 1.80 -63.88 ≤-18.2 PASS 2441 Reference 1.83 1.83 --- PASS 30~3000 1.83 -55.87 ≤-18.17 PASS 3000~26500 1.83 -62.55 ≤-18.17 PASS 2480 Reference 1.70 1.70 --- PASS 30~3000 1.70 -53.64 ≤-18.3 PASS 3000~26500 1.70 -64.87 ≤-18.3 PASS FCC ID:2ASQI-362210 IC: 24886-362210 Page 30 of 38 Test Graphs DH5_Ant1_2402_0~Reference DH5_Ant1_2402_30~3000 DH5_Ant1_2402_3000~26500 FCC ID:2ASQI-362210 IC: 24886-362210 Page 31 of 38 DH5_Ant1_2441_0~Reference DH5_Ant1_2441_30~3000 DH5_Ant1_2441_3000~26500 FCC ID:2ASQI-362210 IC: 24886-362210 Page 32 of 38 DH5_Ant1_2480_0~Reference DH5_Ant1_2480_30~3000 DH5_Ant1_2480_3000~26500 FCC ID:2ASQI-362210 IC: 24886-362210 Page 33 of 38 2DH5_Ant1_2402_0~Reference 2DH5_Ant1_2402_30~3000 2DH5_Ant1_2402_3000~26500 FCC ID:2ASQI-362210 IC: 24886-362210 Page 34 of 38 2DH5_Ant1_2441_0~Reference 2DH5_Ant1_2441_30~3000 2DH5_Ant1_2441_3000~26500 FCC ID:2ASQI-362210 IC: 24886-362210 Page 35 of 38 2DH5_Ant1_2480_0~Reference 2DH5_Ant1_2480_30~3000 2DH5_Ant1_2480_3000~26500 FCC ID:2ASQI-362210 IC: 24886-362210 Page 36 of 38 3DH5_Ant1_2402_0~Reference 3DH5_Ant1_2402_30~3000 3DH5_Ant1_2402_3000~26500 FCC ID:2ASQI-362210 IC: 24886-362210 Page 37 of 38 3DH5_Ant1_2441_0~Reference 3DH5_Ant1_2441_30~3000 3DH5_Ant1_2441_3000~26500 FCC ID:2ASQI-362210 IC: 24886-362210 Page 38 of 38 3DH5_Ant1_2480_0~Reference 3DH5_Ant1_2480_30~3000 ********************** End **********************

Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 E-mail: [email protected] TEST REPORT FCC PART 15 SUBPART C 15.247 & RSS-247 Report Reference No.: CTL2211047022-WF01 Compiled by: ( position+printed name+signature) Happy Guo (File administrators) Tested by: ( position+printed name+signature) Gary Gao (Test Engineer) Approved by: ( position+printed name+signature) Ivan Xie (Manager) Product Name ............................ : Bluetooth Speaker Model/Type reference ................ : 362210 List Model(s) ............................... : N/A Trade Mark .................................. : Bushnell Golf FCC ID ......................................... : 2ASQI-362210 Applicant’s name ....................... : Bushnell Holdings, Inc. Address of applicant ................. : 9200 Cody St. Overland Park Kansas 66214 USA Test Firm ..................................... : Shenzhen CTL Testing Technology Co., Ltd. Address of Test Firm ................. : Floor 1-A, Baisha Technology Park, No.3011, Shahexi Road, Nanshan District, Shenzhen, China 518055 Test specification ....................... : Standard ...................................... : 47 CFR FCC Part 15 Subpart C 15.247 RSS-247 Issue 2, February 2017 TRF Originator ............................. : Shenzhen CTL Testing Technology Co., Ltd. Master TRF .................................. : Dated 2011-01 Date of receipt of test item ........ : Dec. 12, 2022 Date of sampling ........................ : Dec. 12, 2022 Date of Test Date ........................ : Dec. 12, 2022 - Jan. 03, 2023 Date of Issue .............................. : Jan. 03, 2023 Result .......................................... : Pass Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. V1.0 Page 2 of 38 Report No.: CTL2211047022-WF01 TEST REPORT Test Report No. : CTL2211047022-WF01 Jan. 03, 2023 Date of issue Equipment under Test : Bluetooth Speaker Sample No. : CTL221104702-2-S001 Model /Type : 362210 Listed Models : N/A Applicant : Bushnell Holdings, Inc. Address : 9200 Cody St. Overland Park Kansas 66214 USA Manufacturer : SHENZHEN WEIKING TECHNOLOGY CO., LTD Address : No.142 ZhangGe Road, ZhangGe Community, FuCheng Street, LongHua District, Shenzhen, GuangDong, China Test result Pass * *In the configuration tested, the EUT complied with the standards specified page 5. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the issuing testing laboratory. V1.0 Page 3 of 38 Report No.: CTL2211047022-WF01 ** Modified History ** Revisions Description Issued Data Report No. Remark Version 1.0 Initial Test Report Release 2023-01-03 CTL2211047022-WF01 Tracy Qi V1.0 Page 4 of 38 Report No.: CTL2211047022-WF01 Table of Content Page 1. SUMMARY ............................................................................................................................................................... 5 1.1. TEST STANDARDS ..................................................................................................................................................... 5 1.2. TEST DESCRIPTION ........................................................................................................................................................ 5 1.3. TEST FACILITY .............................................................................................................................................................. 6 1.4. STATEMENT OF THE MEASUREMENT UNCERTAINTY ............................................................................................................... 6 2. GENERAL INFORMATION .......................................................................................................................................... 8 2.1. ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 8 2.2. GENERAL DESCRIPTION OF EUT ...................................................................................................................................... 8 2.3. DESCRIPTION OF TEST MODES AND TEST FREQUENCY .......................................................................................................... 8 2.4. EQUIPMENTS USED DURING THE TEST .............................................................................................................................. 9 2.5. RELATED SUBMITTAL(S) / GRANT (S) .............................................................................................................................. 10 2.6. MODIFICATIONS ......................................................................................................................................................... 10 3. TEST CONDITIONS AND RESULTS ............................................................................................................................ 11 3.1. CONDUCTED EMISSIONS TEST ....................................................................................................................................... 11 3.2. RADIATED EMISSIONS AND BAND EDGE .......................................................................................................................... 14 3.3. MAXIMUM PEAK OUTPUT POWER................................................................................................................................. 24 3.4. 20DB BANDWIDTH .........................................................…

Text truncated - open the document above for the full version.

FCC ID:2ASQI-362210 IC: 24886-362210
