2ASWWCORNY60Smart Phone

Ajustes>Red e Internet>Tarjetas SIM, Elija SIM 1 o SIM 2 para datos móviles 3G y llamadas predeterminadas Camera Y60 Cámara Huella Dactilar Fingerprint Flash Camera Destello Cámara

2021-05-18 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen Huatongwei International Inspection Co., Ltd./ 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China / Hans Hu,. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with XINCHUANGXIN INTERNATIONAL CO.,LTD / ROOM 605 6/F, FA YUEN COMMERCIAL BUILDING, 75-77 FA YUEN STREET MONGKOK KL Agency agreement expiration date: May. 17, 2022 By: Lyra lv Signature Printed Title: sales On behalf of : XINCHUANGXIN INTERNATIONAL CO.,LTD Telephone: 18721759223

2021-05-18 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ASWWCORNY60 Product Name: Smart Phone Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operation description  BOM  Tune up These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. By: Lyra lv Signature Printed Title: sales On behalf of : XINCHUANGXIN INTERNATIONAL CO.,LTD Telephone: 18721759223

Differences Declaration To whom concern, We company XINCHUANGXIN INTERNATIONAL CO. , LTD Here by declares: The produc t model(s) Y60 Pro, Y60 Lite,Y60 Plus, Y60 Max is the same PCB layout, electronic schematic and Antenna with Y60 , which tested in Shenzhen Huatongwei International Inspection Co., Ltd., the only differences between them are model names, others are same. YUEN STREET MONGKOK KL Te l : 18721759223 E-Mail: [email protected] Sincerely yours, Name (in print): Lyra Company name: XINCHUANGXIN INTERNATIONAL CO. , LTD Company address: ROOM 605 6/F, FA YUEN COMMERCIAL BUILDING, 75-77 FA

7.EXTERNAL AND INTERNAL PHOTOS OF THE EUT External photos of the EUT M odel:Y60

Label & Location

Internal photos of the EUT M odel:Y60

Page: 1 of 17 TEST REPORT Report Reference No. .................... : CHTEW21050060 Report Verification: Project No................................. SHT2103073003EW FCC ID ............................................. : 2ASWWCORNY60 Applicant’s name ........................... : XINCHUANGXIN INTERNATIONAL CO.,LTD Address ............................................. : ROOM 605 6/F, FA YUEN COMMERCIAL BUILDING, 75-77 FA YUEN STREET MONGKOK KL Test item description .................... : Smart Phone Trade Mark ....................................... : CORN Model/Type reference ....................... : Y60 Listed Model(s) ................................. : Y60 Pro,Y60 Lite,Y60 Plus, Y60 Max Standard ......................................... : 47 CFR FCC Part 15 Subpart B Date of receipt of test sample...........: Apr. 01, 2021 Date of testing..............................: Apr. 02, 2021- May. 10, 2021 Date of issue.................................: May. 11, 2021 Result .................. ........................: Pass Compiled by ( position+printed name+signature) .. : File administrators Silvia Li Supervised by ( position+printed name+signature) .. : Project Engineer Aaron Fang Approved by ( position+printed name+signature) .. : RF Manager Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely corresponds to the test sample. Report No.: CHTEW21050060 Page: 2 of 17 Issued: 2021-05-11 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) Contents 1. TEST STANDARDS AND REPORT VERSION ........................................... 3 1.1. Test Standards 3 1.2. Report version information 3 2. TEST DESCRIPTION .................................................................... 4 3. SUMMARY ............................................................................... 5 3.1. Client Information 5 3.2. Product Description 5 3.3. EUT operation mode 5 3.4. Configuration of Tested System 5 3.5. Support unit used in test configuration 6 4. TEST ENVIRONMENT ................................................................... 7 4.1. Testing Laboratory Information 7 4.2. Environmental conditions 7 4.3. Statement of the measurement uncertainty 7 4.4. Equipments Used during the Test 8 5. TEST CONDITIONS AND RESULTS ..................................................... 9 5.1. Conducted Emissions Test 9 5.2. Radiated Emissions Test 12 6. TEST SETUP PHOTOS OF THE EUT .................................................. 16 7. EXTERNAL AND INTERNAL PHOTOS OF THE EUT .................................. 17 Report No.: CHTEW21050060 Page: 3 of 17 Issued: 2021-05-11 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) 1. TEST STANDARDS AND REPORT VERSION 1.1. Test Standards The tests were performed according to following standards: 47 CFR FCC Part 15 Subpart B - Unintentional Radiators ANSI C63.4: 2014 – American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40GHz 1.2. Report version information Revision No. Date of issue Description N/A 2021-05-11 Original Report No.: CHTEW21050060 Page: 4 of 17 Issued: 2021-05-11 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) 2. TEST DESCRIPTION Test Item Section in CFR 47 Result Test Engineer Conducted Emissions 15.107(a) PASS Jiongsheng Feng Radiated Emissions 15.109(a) PASS Pan Xie Note: The measurement uncertainty is not included in the test result. Report No.: CHTEW21050060 Page: 5 of 17 Issued: 2021-05-11 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) 3. SUMMARY 3.1. Client Information Applicant: XINCHUANGXIN INTERNATIONAL CO.,LTD Address: ROOM 605 6/F, FA YUEN COMMERCIAL BUILDING, 75-77 FA YUEN STREET MONGKOK KL Manufacturer: Shenzhen Chiteng Technology Co.,LTD Address: Second Floor,Area A, Building 4, Huiye Technology Workshop, Guanguang Road, Tangjia Community, Gongming Street, Guangming New District, Shenzhen, Guangdong 3.2. Product Description Name of EUT: Smart Phone Trade Mark: CORN Model No.: Y60 Listed Model(s) Y60 Pro,Y60 Lite,Y60 Plus, Y60 Max Power supply: DC 3.8V Adapter information: Model:CS001 Input: AC100-240V, 50/60Hz, 0.15A Output: 5.0Vdc, 1.0A 3.3. EUT operation mode Test mode Describe Camera recording mode Keep the EUT in Camera recording status Video Playing mode Keep the EUT in Video Playing status Data exchange mode Keep the EUT in Data exchange with PC status Pre-scan all of above modes. Only show Camera recording mode for conducted emission and data exchange mode for radiated emission which is the worst case on the report. 3.4. Configuration of Tested System Report No.: CHTEW21050060 Page: 6 of 17 Issued: 2021-05-11 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) 3.5. Support unit used in test configuration Item Equipment Manufacturer Model No. FCC ID / FCC DoC Data Cable Power Cord 1 PC DELL OptiPlex 3020 MT FCC DoC N/A Unshielded 1.8m 2 Monitor DELL E1912Hf FCC DoC N/A Unshielded 1.8m 3 Keyboard DELL SK8115 FCC DoC Unshielded, 1.5m N/A 4 Mouse DELL MS111-T FCC DoC Unshielded, 1.5m N/A 5 Printer EPSON L101 FCC…

Text truncated - open the document above for the full version.

6.TEST SETUP PHOTOS OF THE EUT Conducted Emissions (AC Mains) Radiated Emissions (30MHz-1GHz) Radiated Emissions (Above 1GHz) Model:Y60
