2AT6X-CETUSPROBeta Cetus Pro

Product
List 1
x
Cetus
Pro Brushless

Quadcopter




























1
x
LiteRadio
2
SE
Transmitter


























1
x
VR02
FPV
Goggles



Box
Contents 2
x
BT2.0
450 mAh
1S
Lipo
Battery




1
x
BT2.0
Battery
Charger
1
x
USB
Charging
Cable
(Type-C) 1
x
Type-C
to
FC
Adapter 1
x
Prop
Removal
Tool 4
x
40mm
-Blade
Prop
(Replacement) 1
x
Portable
Storage
Bag Preflight
Checks 1.Verify
that
all
components
are
included,
without
damage and the airframe is with no deformation. 2.Verify
that
propellers
and
motors
are
installed
correctly and stably. 3.Ensure
that propellers
do
not
scratch
against
frame
ducts
and
motors
spin
smoothly. 4.Verify
batteries
(of
quadcopter,
remote
control
radio
transmitter,
and
FPV
goggles)
are
fully
charged.
5.Be
sure
pilot
is
familiar
with
all
flight
controls.
(Find
“Remote
Control
Radio
Transmitter”). 6.Always
keep
a
safe
distance
in
all
directions
around
the
quadcopter
to
avoid
collisions (1 meter or more).
Operate
the
quadcopter
in
open
space. Quick
Start
Guide Quick
Start Before
flying,
verify
that
remote
control
radio
transmitter
is
successfully
connected
to
the
quadcopter,
all
basic
controls
are
functional,
and
that
the
quadcopter
can
take
off
normally. ● Step
1:
On
the
remote
control
radio
transmitter,
set
the
“throttle”
joystick
and
four
switches on the top
to
the
lowest
setting.
Long
press
the
power
button
on
remote
control
radio
transmitter
for
5
seconds
until
it
beeps
three
times,
then
release.
The
remote
control
radio
transmitter
power
indicator
will
quickly
flash
red,
then
remain
blue, which means it is powered on. ● Step
2:
Install
the
battery
into
the
battery
mounting
slot
under
the
quadcopter. Ensure that the
direction
of
the
battery interface and that of the quadcopter power
cord
is
consistent. Connect
the
quadcopter
with the
battery,
then
place
the
quadcopter
on
a
level
floor.
Wait
2-3
seconds
until
its
status
LED
lights
to
remain
blue which indicates that the initialization of the quadcopter is complete and it is connected with the remote control radio
transmitter. ● Step
3:
Move
switch
SA
up
to
arm
the
quadcopter.
The
throttle
joystick
must
be
at
the
lowest
position
or
the
quadcopter
will
not
arm.
The
motors
will
spin
slowly.
Move
switch
SA
down
to
disarm
the
quadcopter
and the motors will stop spinning.
These
steps
verify
the
quadcopter
and
remote
control
radio
transmitter
are
working.
Proceed
with
flight
operation.


Flight
Operation ● Step
4:
Re-arm
quadcopter
(step
3).
Motors
will
spin
at
a
low
speed.
Throttle
(left)
Joystick: ● Up/down
controls
rate
of
ascent/
descent. ● Left/Right
controls
counterclockwise/
clockwise
rotation
(yaw). Direction
(right)
Joystick:
● Up/down
controls
forward/
backward. ● Left/right
controls
left/
right. Before
flying
with
goggles,
it
is
recommended
to
practice
and
become
familiar
with
the
controls
and
sensitivity
of
the
joysticks
by following the above-mentioned operation steps.
Caution: 1.
Find
a
suitable
open place for the first
flight.
2.
Push
the
joysticks
slowly,
especially
the
throttle
joystick. 3.

If
the
quadcopter
becomes
out
of
control
or
collides
with
objects, disarm
the
quadcopter
(push
switch
SA
down)
quickly and motors will stop spinning.
● Step
5:
Land
quadcopter
steadily
and
keep
it
disarmed (push
switch
SA
down), as shown below:
● Step
6:
Disconnect
and
remove
the
battery
from
the
quadcopter.
A
long
press
of
the
power
button
on
the
remote
control
radio
transmitter
will
turn
it
off
after
three
beeps. First
Person
View
(FPV) First-person
view
(FPV)
is
the
real-time
transmission
of
the
camera
to
FPV
goggles.
● Take
out
the
goggles,
install
the
headband.
● Slide
the
power
switch
to
the
right.
The
screen
lights
up
and
the
VR02
goggles
turn
on.
● Long
press
the
“S”
button
for
1
second
to
enable
fast
frequency
search.
After
3
seconds,
a
beep
will
sound
and
the
corresponding
FPV
cross-machine
screen
is
displayed
in
the
goggles,
indicating
that
the
frequency
search
is
complete.
On-Screen
Display
(OSD) After
band
search,
flight
information
is
shown
on
the
display
along
with
the
FPV
image.
This
information
is
called
On-screen
Display
(OSD), as shown below: OSD
Information ● Goggles
band
and
channel,
frequency,
and
goggles
power
level
are
shown
at
the
top
of
the
screen.
● The
flight
status
of
the
quadcopter
is
displayed
in
the
center,
DISARM
means
locked
status,
LOW
VOL
means
the
quadcopter
battery
voltage
is
low,
and
RX
LOSS
means
the
quadcopter
cannot
communicate
with
the
radio
transmitter
(control
of
the
quadcopter
is
lost) ● Receiver
protocol,
quadcopter
battery
voltage,
flight
mode,
and
flight
time
are
shown
at
the
bottom
of
the
screen.
Flight
Modes The
flight
mode
is
displayed
in
the
lower
right
corner
of
the
flight
screen,
corresponding
to
the
flight
mode
of
quadcopter.
Pilots
can
choose
different
flight
modes
according
to
different
flight
environments
and
their
flight
control
skills. 1.Adaption
mode:
When
the
quadcopter
is
in
the
air,
center
both
sticks
at
the
same
time
and
the
quadcopter
will
self
stabilized
and
just
hover
in
place.
The
quadcopter
will
automatically
adjust
the
flight
height
according
to
the
terrain
and
the
horizontal
attitude
will
be
automatically
maintained.
This
mode
is
suitable
for
simple
terrain.
The
quadcopter
has
the
auxiliary
flight
function,
which
can
assist
in
adjusting
flight
altitude
and
maintaining
the
horizontal
attitude.
A
MODE
is
displayed
in
the
OSD. 2.Sport
mode:
When
the
quadcopter
is
in
the
air,
it
will
automatically
maintain
a
horizontal
attitude.
Pilot
can
control
the
pitch
or
roll
angle
of
the
quadcopter
through
the
direction
joystick.
Compared
with
Adaption
mode,
the
quadcopter
in
Sport
mode
can
tilt
with
a
larger
pitch
angle.
Pilots

can
use
the
throttle
joystick
to
keep
the
quadcopter
flying
within
the
required
altitude
range
and
adjust
the
flying
altitude
according
to
the
terrain.
The
quadcopter
will
return
to
a
horizontal
attitude
when
the
direction
joystick
is
centered.
T…
