2AT76-AP550Smart Air Purifie

P.1 AP550_User Manual_V1.5A User Manual KODAK Smart Air Purifier AP550 DUAL FAN P. 2P. 3 TABLE OF CONTENTS 1. IMPORTANT SAFETY INSTRUCTIONS 2. PRODUCT PARTS OVERVIEW 3. CONTROL PANEL 4. DISPLAY ICONS 5. OPERATION INSTRUCTIONS (AT AIR PURIFIER) 6. MOBILE APP DISPLAY ICONS 7. OPERATION INSTRUCTIONS (ON MOBILE APP) 4 10 11 12 14 22 24 8. GRANT ACCESS 9. TROUBLESHOOTING 10. SPECIFICATIONS 11. EXCLUSION FROM COVERAGE 12. FCC, IC AND CE REGULATIONS 13. WARNING 14. EC DECLARATION OF CONFORMITY 50 58 59 60 62 64 66 P. 4P. 5 1. IMPORTANT SAFETY INSTRUCTIONS WARNING: BEFORE USING KODAK SMART AIR PURIFIER, PLEASE READ THROUGH ALL THE INSTRUCTIONS AND CAU- TIONARY MARKINGS IN THE MANUAL AND ON THE AIR PURIFIER. PLEASE KEEP IT FOR FUTURE REFER- ENCE. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concern- ing use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by chil- dren without supervision. Danger • Do not let water or any other liquid or flammable de- tergent enter the air purifier to avoid electric shock and/or a fire hazard. • Do not clean the WHOLE air purifier with water, any other liquid, or a (flammable) detergent to avoid electric shock and/or a fire hazard. • Do not spray any flammable materials such as insec- ticides or fragrance around the air purifier. Warning • Check if the voltage indicated on the air purifier corre- sponds to the local power voltage before you connect the appliance. • Do not use the air purifier if the plug, the power cord, or the appliance itself is damaged. • Do not block the air inlet and outlet, e.g. by placing items on the air outlet or in front of the air inlet. • Make sure that foreign objects do not fall into the air purifier through the air outlet. P. 6P.7 • This air purifier is not a substitute for proper ventila- tion, regular vacuum cleaning, or use of an extractor hood or fan while cooking. • If the power socket used to power the air purifier has poor connections, the plug of the air purifier becomes hot. Make sure that you plug the air purifier into a properly connected power socket. • Always place and use the air purifier on a dry, stable, level, and horizontal surface. • Leave at least 30 cm free space behind and on both sides of the air purifier and leave at least 40 cm free space above the air purifier. • Do not place anything on top of the air purifier. • Do not sit or stand on the air purifier. Sitting or stand- ing on the appliance may lead to potential injury. • Make sure the reusable filter, front cover and back cov- er are properly installed before you switch on the air purifier. • Only use the original reusable filter specially intended for this KODAK Smart Air Purifier. Do not use any other filters or add any extra filters in the machine. • Avoid knocking against the air purifier (the air inlet and outlet in particular) with hard objects. • Always lift or move the air purifier by the handle on top of the machine. • Do not insert your fingers or objects into the air outlet or the air inlet to prevent physical injury or malfunc- tioning of the air purifier. • Do not use this air purifier when you have used indoor smoke-type insect repellents or in places with oily resi- dues, burning incense, or chemical fumes. • Do not use the air purifier near gas appliances, heating devices or fireplaces. • Always unplug the air purifier after use and before cleaning or carrying out other maintenance. • Do not use the air purifier in a room with major tem- perature changes, as this may cause condensation inside the air purifier. • To prevent interference, place the air purifier at least 2 meters away from other electrical appliances that use airborne radio waves such as TVs, radios, and ra- dio-controlled clocks. Caution P. 8P. 9 • The air purifier is only intended for household use un- der normal operating conditions. • If you need to move the air purifier, disconnect it from the power supply first. • When moving the air purifier, do it slowly and do not push it rapidly. • Do not move the air purifier by pulling its power cord. • This KODAK Smart Air Purifier is not intended for use by persons (including children) with reduced physi- cal, sensory or reasoning capabilities, or lack of expe- rience and knowledge, unless they have been given supervision or instruction concerning use of the ma- chine by a person responsible for their safety. • Ensure the machine is fully assembled in line with the instructions before use. • Do not allow to be used as a toy. Close attention is necessary when used by or near children. Children should be supervised to ensure that they do not play with the machine. • Use only as described in this KODAK Smart Air Purifier User Manual. Do not carry out any maintenance other than that shown in this manual, or advised by the Cus- tomer Service of this air purifier. • Suitable for dry location ONLY. Do not use outdoors or on wet surfaces and do not expose to water or rain. • Do not handle any part of the plug or machine with wet hands. • Do not operate any machine with a damaged cord or plug. Discard the machine or return to an authorized service facility for examination and/or repair. If the supply cord is damaged it must be replaced by official channel, its service agent or similarly qualified person in order to avoid a hazard. • If the machine is not working as it should, has received a sharp blow, has been dropped, damaged, left out- doors, or dropped into water, do not use and contact the Customer Service. • Do not stretch the cord or place the cord under strain. Keep cord away from heated surfaces. • Do not run cord under carpeting. Do not cover cord with throw rugs, runners or similar coverings. Do not route cord under furniture or any appliances.…

Text truncated - open the document above for the full version.

March 23, 2020 Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement Company name: ebuynow ecommerce Ltd FCC ID: 2AT76-AP550 To Whom It May Concern: We, ebuynow ecommerce Ltd hereby authorized Intertek Testing Services to act as our Agent for the purpose of preparing application for FCC ID number(2AT76-AP550) under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is Mar 23, 2020. The Limited Agency Agreement expires on Mar 23, 2025, unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Sign: Eric Lee Company name: ebuynow ecommerce Ltd Title: Vice President of Product Development

Attention: Application Examiner RE: Request for Confidentiality Applicant: ebuynow ecommerce Ltd FCC ID: 2AT76-AP550 To Whom It May Concern: Permanent Confidentiality [Complete this section if permanent confidentiality is requested] Request is hereby submitted by ebuynow ecommerce Ltd to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: • Schematics • Detailed Block Diagrams • Detailed Operational/Functional Description Rationale for request for confidentiality: ebuynow ecommerce Ltd has invested considerable time and materials in research and development to produce the referenced product. [Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us.] [For FCC certification; delete for TCB certification: The fee for confidentiality has been submitted along with the fee for certification.] If you have questions or need further information, please contact the undersigned. Sincerely, Sign: Eric Lee Company name: ebuynow ecommerce Ltd Title: Vice President of Product Development

Adaptor:

Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Job No.: 190903074GZU-002 Page: 1 of 2 FCC ID: 2AT76-AP550 RF Exposure Compliance Requirement 1. Standard requirement Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2m normally can be maintained between the user and the device. (a) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S)(mW/cm 2 ) Averaging Times ׀E׀ 2 ,׀H׀ 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842/f 4.89/f (900/f)* 6 30-300 61.4 0.163 1.0 6 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (b) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S)(mW/cm 2 ) Averaging Times ׀E׀ 2 ,׀H׀ 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 -- -- F/1500 30 1500-100000 -- -- 1.0 30 Note: f=frequency in MHz; *Plane-wave equivalent power density Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Job No.: 190903074GZU-002 Page: 2 of 2 FCC ID: 2AT76-AP550 2. MPE Calculation Method E (V/m)=(30*P*G) 0.5 /d Power Density: Pd(W/m 2 )=E 2 /377 E=Electric Field (V/m) P=Peak RF output Power (W) G=EUT Antenna numeric gain (numeric) d= Separation distance between radiator and human body (m) The formula can be changed to Pd= (30*P*G)/(377*d 2 ) From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Output power=18dBm (max. value described by client) 3. Calculated Result and Limit Antenna Gain (Numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 1.0 18 63.096 0.01255 1 Complies

ebuynow ecommerce Ltd TEST REPORT SCOPE OF WORK EMC TESTING–AP550 REPORT NUMBER 190903074GZU-001 ISSUE DATE [REVISED DATE] 07-May-2020 [---------------------] PAGES 116 DOCUMENT CONTROL NUMBER FCC WIFI-d © 2017 INTERTEK TEST REPORT Block E, No.7-2 Guang Dong Software Science Park, Caipin Road, Guangzhou Science City, GETDD Guangzhou, China Telephone: 86-20-8213 9688 Facsimile: 86-20-3205 7538 www.intertek.com This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Version: 10 June 2019 Page 2 of 116 FCC WIFI-d Applicant Name & Address : ebuynow ecommerce Ltd 1321 Blanshard St Suite 301, Victoria, BC V8W 0B6, Victoria, Canada Manufacturing Site : Foshan Shunde Alford Electronics Company Limited (subsidiary of Alford Industries Limited) Xinjiao Industrial Park, DaLiang, ShunDe, Foshan City, Guangdong Province, China. Intertek Report No: FCC ID: 190903074GZU-001 2AT76-AP550 Test standards 47 CFR PART 15 Subpart C: 2018 section 15.247 Sample Description Product : Smart Air Purifier Model No. : AP550 Electrical Rating : 15Vdc, 1.5A (Power by adaptor) Adaptor: Model name: NF-15V-1.5C-DC Input: 100-240Vac, 50/60Hz, 0.8A, Max Output: 15Vdc, 1.5A power cable: 1.8 m x 2 wires unscreened DCcable Serial No. Not Labeled Date Received : 01 April 2020 Date Test Conducted : 01 April 2020-29 April 2020 Prepared and Checked By Daniel He Project Engineer Intertek Guangzhou Approved By: Helen Ma Team Leader Intertek Guangzhou TEST REPORT Intertek Report: No: 190903074GZU-001 Version: 10 June 2019 Page 3 of 116 FCC WIFI-d CONTENT TEST REPORT ........................................................................................................................... 1 CONTENT ............................................................................................................................. 3 1.0 TEST RESULT SUMMARY ............................................................................................ 4 2.0 GENERAL DESCRIPTION ............................................................................................. 5 2.1 P RODUCT DESCRIPTION ........................................................................................................ 5 2.2 R ELATED SUBMITTAL(S) GRANTS ........................................................................................... 6 2.3 T EST METHODOLOGY .......................................................................................................... 6 2.4 T EST FACILITY ..................................................................................................................... 6 3.0 SYSTEM TEST CONFIGURATION ................................................................................. 6 3.1 J USTIFICATION .................................................................................................................... 6 3.2 EUT EXERCISING SOFTWARE ................................................................................................. 7 3.3 S PECIAL ACCESSORIES .......................................................................................................... 7 3.4 M EASUREMENT UNCERTAINTY .............................................................................................. 8 3.5 E QUIPMENT MODIFICATION ................................................................................................. 8 3.6 S UPPORT EQUIPMENT LIST AND DESCRIPTION .......................................................................... 9 4.0 MEASUREMENT RESULTS ........................................................................................ 10 4.1 A NTENNA REQUIREMENT ................................................................................................... 10 4.2 6 DB BANDWIDTH (DTS BANDWIDTH).................................................................................. 11 4.3 M AXIMUM PEAK CONDUCTED OUTPUT POWER ..................................................................... 19 4.4 P EAK POWER SPECTRAL DENSITY ......................................................................................... 27 4.5 O UT OF BAND CONDUCTED EMISSIONS ................................................................................ 35 4.6 O UT OF BAND RADIATED EMISSIONS .................................................................................... 49 4.7 R ADIATED EMISSIONS IN RESTRICTED BANDS ......................................................................... 50 4.8 B AND EDGES REQUIREMENT ............................................................................................. 107 4.9 C ONDUCTED EMISSION TEST ............................................................................................. 113 5.0 TEST EQUIPMENT LIST ........................................................................................... 116 TEST REPORT Intertek Report: No: 190903074GZU-001 Version: 10 June 2019 Page 4 of 116 FCC WIFI-d 1.0 TEST RESULT SUMMARY Test ItemTest RequirementTest MethodResult Antenna Requirement FCC PART 15 C section 15.247 (c) and Section 15.203 FCC PART 15 C section 15.247 (c) and Section 15.203 PASS 6 dB Bandwidth (DTS bandwidth) FCC PART 15 C …

Text truncated - open the document above for the full version.

1. Radiated Emissions in Restricted Bands: Below 1G: Above 1G Conducted Emission Test:
