2AT7Y-RSERear Seat Entertainment

FCC Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: — Reorient or relocate the receiving antenna. — Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. Operations in the 5.15-5.25 GHz band are restriced to indoor usa ge only. IMPORTANT NOTE: FCC RF Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. RSS-GEN Section This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:(1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. RSS-102 RF Exposure The antenna (or antennas) must be installed so as to maintain a minimum distance of at least 20 cm between the radiation source (the antenna) and any persons. This device should not be installed or used in conjunction with any other antenna or transmitter. L’antenne (ou les antennes) doit être installée de façon à maintenir à tout instant une distance minimu m de au moins 20 cm entre la source de radiation (l’antenne) et toute personne physique. Cet appareil ne doit pas être installé ou utilisé en conjonction avec une autre antenne ou émetteur.

T&F Global Co., Ltd. April 20 th , 2020 Applicant: T&F Global Co., Ltd. FCC ID: 2AT7Y-RSE / IC: 26002-RSE To. Whom it may concern: We, T&F Global Co., Ltd. confirm that when equipped, the distance between antenna and own body is above than 200mm. Son So-Hyung / Senior Director

QA-FR-170-B T&F Global Co., Ltd. Add: 303-604, BUCHEON TECHNO PARK SSANGYONG 3CHA, 397, Seokcheon-ro, Bucheon-si, Gyeonggi-do Tel: +82-70-8894-6301 Fax: +82-31-299-2150 Email: [email protected] FCC Authorization Date: 2020-04-20 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, T&F Global Co., Ltd., the undersigned, Hereby authorizes NCT Co.,Ltd. to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by NCT Co.,Ltd. on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature: T&F Global Co., Ltd. Son So-Hyung / Senior Director

T&F Global Co., Ltd. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AT7Y-RSE Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Schematics Operational Description [RSE] BLK [RSE] SCH [RSE] OpDes The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); Exhibit Type File Name Internal Photos Manual [RSE] INT Photo [RSE] Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. Sincerely, Son So-Hyung / Senior Director

Label & Location

Internal Antenna

Electric Field strength (V/m) Magnetic field strength (A/m) Power Density (mW/cm2) Averageing time (minutes) 0.3~1.346141.63*10030 1.34~30824 / f2.19 / f*180 / f230 30~30027.50.0730.230 300~1,500f / 150030 1,500~100,000130 Model Name : FCC ID : (dBm)(dB)(dBm)(mW)(dBi)(numeric) (mW/cm2)(mW/cm2) 24023.064.062.551.881.540.00081.00PASS 24423.794.793.011.881.540.00091.00PASS 24804.975.973.951.881.540.00121.00PASS 24021.282.281.691.881.540.00051.00PASS 24421.702.701.861.881.540.00061.00PASS 24801.792.791.901.881.540.00061.00PASS 241213.0514.0525.411.881.540.00781.00PASS 243713.1014.1025.701.881.540.00791.00PASS 246213.0614.0625.471.881.540.00781.00PASS 241212.5113.5122.441.881.540.00691.00PASS 243712.6413.6423.121.881.540.00711.00PASS 246212.8013.8023.991.881.540.00741.00PASS 241212.3513.3521.631.881.540.00661.00PASS 243712.2713.2721.231.881.540.00651.00PASS 246212.3613.3621.681.881.540.00661.00PASS 51808.539.538.973.602.290.00411.00PASS 52208.219.218.343.602.290.00381.00PASS 52408.439.438.773.602.290.00401.00PASS 51808.309.308.513.602.290.00391.00PASS 52208.079.078.073.602.290.00371.00PASS 52408.199.198.303.602.290.00381.00PASS 51908.679.679.273.602.290.00421.00PASS 52308.619.619.143.602.290.00421.00PASS 51806.689.038.003.602.290.00361.00PASS 52206.419.098.113.602.290.00371.00PASS 52406.538.436.973.602.290.00321.00PASS 51907.588.587.213.602.290.00331.00PASS 52307.358.356.843.602.290.00311.00PASS 52608.489.488.873.602.290.00401.00PASS 53008.059.058.043.602.290.00371.00PASS 53208.419.418.733.602.290.00401.00PASS 52608.089.088.093.602.290.00371.00PASS 53007.958.957.853.602.290.00361.00PASS 53208.189.188.283.602.290.00381.00PASS 52708.509.508.913.602.290.00411.00PASS 53108.369.368.633.602.290.00391.00PASS 52606.669.098.113.602.290.00371.00PASS 53006.181.001.263.602.290.00061.00PASS 53206.291.001.263.602.290.00061.00PASS 52707.068.066.403.602.290.00291.00PASS 53107.168.166.553.602.290.00301.00PASS Standalone SAR test exclusion considerations RSE 2AT7Y-RSESeparation distance (R) : 20.0 cm S = EIRP/(4R2π) S = Maximum power density (mW/cm2) P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna EIRP = Equivalent Isotropic Radiated Power(mW) (=P*G) Frequency range (MHz) EDR± 1.00 Result BDR± 1.00 Frequency (MHz) Measured Maximum Output Power Tune-up tolerance Max. Power with tune-up tolerance ( P) Antenna Gain ( G) Power Density (S) Limit of Power Density (S) Modulation 2.4GHz 802.11n_HT2 0 ± 1.00 802.11g± 1.00 802.11b± 1.00 802.11n_HT2 0 ± 1.00 802.11a± 1.00 802.11n_HT4 0 ± 1.00 UNII-1 UNII-2A 802.11ac_VH T20 ± 1.00 802.11ac_VH T40 ± 1.00 802.11a± 1.00 802.11n_HT2 0 ± 1.00 802.11n_HT4 0 ± 1.00 802.11ac_VH T20 ± 1.00 802.11ac_VH T40 ± 1.00 55008.809.809.553.602.290.00441.00PASS 56008.889.889.733.602.290.00441.00PASS 57008.039.038.003.602.290.00361.00PASS 55008.339.338.573.602.290.00391.00PASS 56008.589.589.083.602.290.00411.00PASS 57007.418.416.933.602.290.00321.00PASS 55108.859.859.663.602.290.00441.00PASS 55909.1310.1310.303.602.290.00471.00PASS 56708.479.478.853.602.290.00401.00PASS 55007.288.286.733.602.290.00311.00PASS 56007.168.166.553.602.290.00301.00PASS 57006.167.165.203.602.290.00241.00PASS 55107.798.797.573.602.290.00341.00PASS 55907.998.997.933.602.290.00361.00PASS 56707.398.396.903.602.290.00311.00PASS 57458.099.098.113.602.290.00371.00PASS 57857.438.436.973.602.290.00321.00PASS 58256.717.715.903.602.290.00271.00PASS 57457.488.487.053.602.290.00321.00PASS 57857.038.036.353.602.290.00291.00PASS 58256.337.335.413.602.290.00251.00PASS 57557.988.987.913.602.290.00361.00PASS 57957.168.166.553.602.290.00301.00PASS 57456.341.001.263.602.290.00061.00PASS 57855.611.001.263.602.290.00061.00PASS 58255.191.001.263.602.290.00061.00PASS 57556.927.926.193.602.290.00281.00PASS 57956.127.125.153.602.290.00231.00PASS The EUT will only be used with a separation of 20 centimeters or greater between the antenna and the body of the user. UNII-2C 802.11a± 1.00 802.11n_HT2 0 ± 1.00 802.11n_HT4 0 ± 1.00 802.11ac_VH T20 ± 1.00 802.11ac_VH T40 ± 1.00 UNII-3 802.11a± 1.00 802.11n_HT2 0 ± 1.00 802.11n_HT4 0 ± 1.00 802.11ac_VH T20 ± 1.00 802.11ac_VH T40 ± 1.00

Certificate of Test NTP-015-F06(Rev.03) NCT.CO., LTD. NCT Co., Ltd. 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, 18511, Korea (Tel: +82-31-323-6070 / Fax: +82-31-323-6071) Report No.: NW2004-F003 Page (1) / (221) 1. Client ○ Name : T&F Global Co., Ltd. ○ Address : 604, 303DONG, 397, SEOKCHEON-RO OJEONG-GU, GYEONGGI-DO, KOREA (303-604, BUCHEON TECHNO PARK SSANGYONG 3CHA, 397, Seokcheon-ro, Bucheon-si, Gyeonggi-do, Korea) ○ Date of Receipt : 2020-03-27 2. Use of Report : FCC & IC Approval 3. Test Sample ○ Description / Model Name : Rear Seat Entertainment / RSE ○ FCC ID : 2AT7Y-RSE / IC : 26002-RSE 4. Date of Test : 2020-03-27 ~ 2020-04-07 5. Test method used : FCC Part 15 Subpart E 15.407 RSS-247 Issue 2(2017-02), RSS-GEN Issue 5(2019-03) 6. Testing Environment : ○ Temperature: (25  5) °C, Humidity: Less than 75 % R.H. * Unless specified otherwise in the individual methods, the tests were conducted on ambient conditions. 7. Test Results : Refer to the test results The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This Test Report cannot be reproduced, except in full This test report is prepared according to the requirements of ISO / IEC 17025. Affirmation Tested by Jong-Myoung, Shin (signature) Technical Manager Kyung-Taek, Lee (signature) April 20, 2020 NCT CO., LTD. (seal) Test Repot No.: NW2004-F003 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 2 of 221 Table of contents 1. General Information -------------------------------------------------------------------------------- 2. Information’s about Test Item ------------------------------------------------------------------- 3. Test Report -------------------------------------------------------------------------------------------- 3.1 Test Summary ------------------------------------------------------------------------------------- 3.2 Test Report Version ----------------------------------------------------------------------------- 3.3 Transmitter Requirements 3.3.1 Antenna Requirement --------------------------------------------------------------------- 3.3.2 26 ㏈ Bandwidth & Occupied Bandwidth -------------------------------------------- 3.3.3 6 ㏈ Bandwidth & Occupied Bandwidth --------------------------------------------- 3.3.4 Maximum Conducted Output Power --------------------------------------------------- 3.3.5 Peak Power Spectral Density ----------------------------------------------------------- 3.3.6 TX Radiated Spurious Emission -------------------------------------------------------- 3.3.7 Conducted Emission ----------------------------------------------------------------------- APPENDIX APPENDIX I TEST SETUP ---------------------------------------------------------------------- APPENDIX II TEST EQUIPMENT USED FOR TESTS ---------------------------------- APPENDIX III DUTY CYCLE CORRECTION FACTOR ---------------------------------- 3 3 5 5 6 7 8 57 73 108 142 212 213 215 217 Test Repot No.: NW2004-F003 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 3 of 221 1. General Information’s 1.1 Test Performed Laboratory : NCT Co., Ltd. Address : 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, 18511, Korea Telephone : +82-31-323-6070 Facsimile : +82-31-323-6071 FCC Designation No. : KR0166 FCC Registration Number : 409631 IC Site Registration No. : 25897 2. Information’s about Test Item 2.1 Applicant Information Company name : T&F Global Co., Ltd. Address : 604, 303DONG, 397, SEOKCHEON-RO OJEONG-GU, GYEONGGI-DO, KOREA (303-604, BUCHEON TECHNO PARK SSANGYONG 3CHA, 397, Seokcheon-ro, Bucheon-si, Gyeonggi-do, Korea) Telephone / Facsimile : +82-2-855-0501 / +82-2-855-0580 2.2 Equipment Under Test (EUT) description Test item particulars : Rear Seat Entertainment Model and/or type reference : RSE Additional model name : - Serial number : Identification Antenna type and gain : Chip Antenna with Max gain : 3.60 ㏈i Date (s) of performance of tests: : 2020-03-27 ~ 2020-04-07 Date of receipt of test item : 2020-03-27 EUT condition : Pre-production, not damaged EUT Power Source : DC 12 V Type of Modulation : OFDM Firmware version : RSE_US_K101_1.0.0 for FCC RSE_CA_K101_1.0.0 for IC Hardware version : 1.0 Test software name(version) : TeraTerm(4.105) Test Repot No.: NW2004-F003 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 4 of 221 2.3 Tested Frequency 5㎓ Band 802.11a/n_HT20 /ac_VHT20 802.11n_HT40 /ac_VHT40 Remark Channel Frequency (㎒) Channel Frequency (㎒) U-NII 1 36 5 180 38 5 190 44 5 220 48 5 240 46 5 230 U-NII 2A 52 5 260 54 5 270 60 5 300 64 5 320 62 5 310 U-NII 2C 100 5 500 102 5 510 Not supported in IC 120 5 600 118 5 590 140 5 700 134 5 670 U-NII 3 149 5 745 151 5 755 157 5 785 165 5 825 159 5 795 2.4 Transmitting Configuration of EUT Test Mode Data rate 802.11a 6 ~ 54 Mbps 802.11n_HT20 MCS 0 ~ 7 802.11n_HT40 MCS 0 ~ 7 802.11ac_VHT20 MCS 0 ~ 8 802.11ac_VHT40 MCS 0 ~ 9 Test Repot No.: NW2004-F003 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 5 of 221 3. Test Report 3.1 Test Summary Applied FCC IC Test Items Limit Test Condition Result 15.203 - Antenna Requirement FCC 15.203 Conducted C 15.407(a) - Emission Bandwidth (26 ㏈ Bandwidth) N/A C 15.407(e) RSS-247(6.2.4) Minimum Emission Bandwidth (6 ㏈ Bandwidth) > 500 ㎑ in 5725 ~ 5850 ㎒ C - RSS-GEN(6.7) Occupied Bandwidth (99%) N/A C 15.407(a) RSS-247(6.2) Maximum Conducted Output Power 5150 ~ 5250 ㎒ : < 23.97 ㏈m 5250 ~ 5350 & 5470 ~ 5725 ㎒ : < 250 ㎽ or < 11 + 10 log10(B) ㏈m, whichever power is less. (B is the 26㏈ BW.) 5725 ~ 5850 ㎒ : < 30 ㏈m C 15.407(a) RSS-247(6.2) Peak Power Spectral Density 5150 ~ 5250 ㎒ : 11 ㏈m/㎒ 5250 ~ 5350 ㎒ : 11 ㏈m/㎒ 5470 ~ 5725 ㎒ : …

Text truncated - open the document above for the full version.

Test Repot No.: NW2004-F003 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 108 of 221 3.3.5 Peak Power Spectral Density 3.3.5.1 Test Setup Refer to the APPENDIX I. 3.3.5.2 Limit Part. 15.407(a) (1) For the band 5.15 - 5.25 ㎓. (i) For an outdoor access point operating in the band 5.15 - 5.25 ㎓, the maximum power spectral density shall not exceed 17 ㏈m in any 1 ㎒ band. note1 (ii) For an indoor access point operating in the band 5.15 - 5.25 ㎓, the maximum power spectral density shall not exceed 17 ㏈m in any 1 ㎒ band. note1 (iii) For fixed point-to-point access points operating in the band 5.15 - 5.25 ㎓, transmitters that employ a directional antenna gain greater than 23 ㏈i, a 1 ㏈ reduction in maximum power spectral density is required for each 1 ㏈ of antenna gain in excess of 23 ㏈i. (iv) For mobile and portable client devices in the 5.15 - 5.25 ㎓ band, the maximum power spectral density shall not exceed 11 ㏈m in any 1 ㎒ band. note1 (2) For the 5.25 - 5.35 ㎓ and 5.47 - 5.725 ㎓ bands, the peak power spectral density shall not exceed 11 ㏈m in any 1 ㎒ band. note1 (3) For the band 5.725 - 5.85 ㎓, the maximum power spectral density shall not exceed 30 ㏈m in any 500 ㎑ band. note1,note2 Note1: If transmitting antennas of directional gain greater than 6 ㏈i are used, the peak power spectral density shall be reduced by the amount in ㏈ that the directional gain of the antenna exceeds 6 ㏈i. Note2: Fixed point - to-point U-NII devices operating in this band may employ transmitting antennas with directional gain greater than 6 ㏈i without any corresponding reduction in transmitter conducted power. Fixed, point-topoint operations exclude the use of point-to-multipoint systems, omnidirectional applications, and multiple collocated transmitters transmitting the same information. RSS-247 (1) For the band 5.15 - 5.25 ㎓. For OEM devices installed in vehicles, the maximum e.i.r.p. shall not exceed 30 ㎽ or 1.76 + 10 log10B, ㏈m, whichever is less. Devices shall implement transmitter power control (TPC) in order to have the capability to operate at least 3 ㏈ below the maximum permitted e.i.r.p. of 30 ㎽. For other devices, the maximum e.i.r.p. shall not exceed 200 ㎽ or 10 + 10 log10B, ㏈m, whichever power is less. B is the 99% emission bandwidth in megahertz. The e.i.r.p. spectral density shall not exceed 10 ㏈m in any 1.0 ㎒ band. Test Repot No.: NW2004-F003 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 109 of 221 (2) For the band 5.25 - 5.35 ㎓. For OEM devices installed in vehicles, the maximum e.i.r.p. shall not exceed 30 ㎽ or 1.76 + 10 log10B, ㏈m, whichever is less. Devices shall implement TPC in order to have the capability to operate at least 3 ㏈ below the maximum permitted e.i.r.p. of 30 ㎽. Devices, other than devices installed in vehicles, shall comply with the following: - The maximum conducted output power shall not exceed 250 ㎽ or 11 + 10 log10B, ㏈m, whichever is less. The power spectral density shall not exceed 11 ㏈m in any 1.0 ㎒ band; - The maximum e.i.r.p. shall not exceed 1.0 W or 17 + 10 log10B, ㏈m, whichever is less. B is the 99% emission bandwidth in megahertz. Note that devices with a maximum e.i.r.p. greater than 500 ㎽ shall implement TPC in order to have the capability to operate at least 6 ㏈ below the maximum permitted e.i.r.p. of 1 W. (3) For the band 5.47 - 5.60 ㎓ and 5.65 - 5.725 ㎓. The maximum conducted output power shall not exceed 250 ㎽ or 11 + 10 log10B, ㏈m, whichever is less. The power spectral density shall not exceed 11 ㏈m in any 1.0 ㎒ band. The maximum e.i.r.p. shall not exceed 1.0 W or 17 + 10 log10B, ㏈m, whichever is less. B is the 99% emission bandwidth in megahertz. Note that devices with a maximum e.i.r.p. greater than 500 ㎽ shall implement TPC in order to have the capability to operate at least 6 ㏈ below the maximum permitted e.i.r.p. of 1 W. (4) For the band 5.725 - 5.85 ㎓. For equipment operating in the band 5725-5850 ㎒, the minimum 6 ㏈ bandwidth shall be at least 500 ㎑. The maximum conducted output power shall not exceed 1 W. The output power spectral density shall not exceed 30 ㏈m in any 500 ㎑ band. If transmitting antennas of directional gain greater than 6 ㏈i are used, both the maximum conducted output power and the output power spectral density shall be reduced by the amount in ㏈ that the directional gain of the antenna exceeds 6 ㏈i. However, fixed point-to-point devices operating in this band may employ transmitting antennas with directional gain greater than 6 ㏈i without any corresponding reduction in transmitter conducted power. Fixed point-to-point operations exclude the use of point-to-multipointFootnote3 systems, omnidirectional applications and multiple collocated transmitters transmitting the same information. Test Repot No.: NW2004-F003 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 110 of 221 3.3.5.3 Test Procedure The peak power density is measured with a spectrum analyzer connected to the antenna terminal while the EUT is operating in transmission mode at the appropriate frequencies. 1) Create an average power spectrum for the EUT operating mode being tested by following the instructions in section II.E.2. for measuring maximum conducted output power using a spectrum analyzer or EMI receiver: select the appropriate test method (SA - 1, SA - 2, SA - 3, or alternatives to each) and apply it up to, but not including, the step labeled, “Compute power...”. (This procedure is required even if the maximum conducted output power measurement was performed using a power meter, method PM.) 2) Use the peak search function on the instrument to find the peak of the spectrum and record its value. 3) Make the following adjustments to the peak value of the spectrum, if applicable: a) …

Text truncated - open the document above for the full version.

Certificate of Test NTP-015-F06(Rev.03) NCT.CO., LTD. NCT Co., Ltd. 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, 18511, Korea (Tel: +82-31-323-6070 / Fax: +82-31-323-6071) Report No.: NW2004-F004 Page (1) / (14) 1. Client ○ Name : T&F Global Co., Ltd. ○ Address : 604, 303DONG, 397, SEOKCHEON-RO OJEONG-GU, GYEONGGI-DO, KOREA (303-604, BUCHEON TECHNO PARK SSANGYONG 3CHA, 397, Seokcheon-ro, Bucheon-si, Gyeonggi-do, Korea) ○ Date of Receipt : 2020-03-27 2. Use of Report : FCC & IC Approval 3. Test Sample ○ Description / Model Name : Rear Seat Entertainment / RSE ○ FCC ID : 2AT7Y-RSE / IC : 26002-RSE 4. Date of Test : 2020-03-27 ~ 2020-04-07 5. Test method used : FCC Part 15 Subpart E 15.407 RSS-247 Issue 2(2017-02) 6. Testing Environment : ○ Temperature: (25  5) °C, Humidity: Less than 75 % R.H. * Unless specified otherwise in the individual methods, the tests were conducted on ambient conditions. 7. Test Results : Refer to the test results The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This Test Report cannot be reproduced, except in full This test report is prepared according to the requirements of ISO / IEC 17025. Affirmation Tested by Jong-Myoung, Shin (signature) Technical Manager Kyung-Taek, Lee (signature) April 20, 2020 NCT CO., LTD. (seal) Test Repot No.: NW2004-F004 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 2 of 14 Table of contents 1. General Information -------------------------------------------------------------------------------- 2. Information’s about Test Item ------------------------------------------------------------------- 3. Test Report -------------------------------------------------------------------------------------------- 3.1 Test Summary ------------------------------------------------------------------------------------- 3.2 Test Report Version ----------------------------------------------------------------------------- 3.3 Dynamic Frequency Selection 3.3.1 Channel Move Time and Channel Closing Transmission Time ----------------- APPENDIX APPENDIX I TEST SETUP ---------------------------------------------------------------------- APPENDIX II TEST EQUIPMENT USED FOR TESTS ---------------------------------- 3 3 5 5 5 6 11 13 Test Repot No.: NW2004-F004 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 3 of 14 1. General Information’s 1.1 Test Performed Laboratory : NCT Co., Ltd. Address : 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, 18511, Korea Telephone : +82-31-323-6070 Facsimile : +82-31-323-6071 FCC Designation No. : KR0166 FCC Registration Number : 409631 IC Site Registration No. : 25897 2. Information’s about Test Item 2.1 Applicant Information Company name : T&F Global Co., Ltd. Address : 604, 303DONG, 397, SEOKCHEON-RO OJEONG-GU, GYEONGGI-DO, KOREA (303-604, BUCHEON TECHNO PARK SSANGYONG 3CHA, 397, Seokcheon-ro, Bucheon-si, Gyeonggi-do, Korea) Telephone / Facsimile : +82-2-855-0501 / +82-2-855-0580 2.2 Equipment Under Test (EUT) description Test item particulars : Rear Seat Entertainment Model and/or type reference : RSE Additional model name : - Serial number : Identification Antenna type and gain : Chip Antenna with Max gain : 3.60 ㏈i Date (s) of performance of tests: : 2020-03-27 ~ 2020-04-07 Date of receipt of test item : 2020-03-27 EUT condition : Pre-production, not damaged EUT Power Source : DC 12 V Type of Modulation : OFDM Firmware version : RSE_US_K101_1.0.0 for FCC RSE_CA_K101_1.0.0 for IC Hardware version : 1.0 Test software name(version) : TeraTerm(4.105) Test Repot No.: NW2004-F004 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 4 of 14 2.3 Frequency Range 5㎓ Band 802.11a/n_HT20/ac_VHT20 (㎒) n_HT40/ac_VHT40 (㎒) Remark U-NII 1 5 180 ~ 5 240 5 190 ~ 5 230 U-NII 2A 5 260 ~ 5 320 5 270 ~ 5 310 U-NII 2C 5 500 ~ 5 700 5 510 ~ 5 670 Not supported in IC U-NII 3 5 745 ~ 5 825 5 755 ~ 5 795 2.4 Transmitting Configuration of EUT Test Mode Data rate 802.11a 6 ~ 54 Mbps 802.11n_HT20 MCS 0 ~ 7 802.11n_HT40 MCS 0 ~ 7 802.11ac_VHT20 MCS 0 ~ 8 802.11ac_VHT40 MCS 0 ~ 9 Test Repot No.: NW2004-F004 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 5 of 14 3. Test Report 3.1 Test Summary Applied FCC IC Test Items Test Condition Result 15.407(h) RSS-GEN(6.3) Dynamic Frequency Selection Conducted C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable Note 2: This product will not operate U-NII 2C band in Canada(IC). The sample was tested according to the following specification: ANSI C63.10:2013, KDB789033 D02 V01, KDB644545 D03 Compliance was determined by specification limits of the applicable standard according to customer requirements. 3.2 Test Report Version Test Report No. Date Description NW2004-F004 2020-04-20 Initial issue Test Repot No.: NW2004-F004 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 6 of 14 3.3 Dynamic Frequency Selection 3.3.1 Channel Move Time and Channel Closing Transmission Time 3.3.1.1 Test Setup Refer to the APPENDIX I. 3.3.1.2 Applicability The following table from KDB 905462 D02 v02 lists the applicable requirements for the DFS testing. The device evaluated in this report is considered a client device without radar detection capability Table 1. DFS Applicability Table 1.1 DFS During normal operation Test Repot No.: NW2004-F004 Test Repot No.: NR1709-W015 211-71, Geumgok-ro, Hwaseong-si, Gyeonggi-do, Korea 18511 www.nct.re.kr TEL: +82-31-323-6070 FAX: +82-31-323-6071 Page 7 of 14 3.3.1.3 Requirements KDB 905462 D02 v02 the following are the requirements for Client Devices: a) A …

Text truncated - open the document above for the full version.

Below 30 MHz Below 1 GHz Above 1 GHz Above 18 GHz
