2AT88-1000021194Smart Cooking Sensor

USER MANUAL Safera Sense Smart Cooking Sensor SLI 23.12.2019 22078_01-E 2 1. Introduction 1.1. Introduction Congratulations for buying the Safera Sense Smart Cooking Sensor. This guide describes the use and maintenance of the product. Before reading, please check the Safera website for an updated version of this user manual: www.safera.com/support We wish you safe and enjoyable cooking! 1.2. Manufacturer Information The product is designed and manufactured by Safera, a Finnish company of experts in smart cooking. Safera Oy Tekniikantie 4 02150 Espoo, Finland Product support www.safera.com/support email: [email protected] tel.: +358 40 1897 146 1.3. Importer Information Safera Oy Tekniikantie 4 02150 Espoo, Finland 2. Information and Warnings 2.1. General Warnings • Using Safera Sense does not remove your responsibility of safe cooking. Read chapter 6 carefully for limitations. • Safera Sense does not replace statutory home fire alarms. Ensure that fire safety at your home follows the local regulations. • Flame cooking is prohibited under the cooker hood. Also, operating gas stove burners without pans is prohibited. • Safera Sense is meant for household use only. The appliance must not be used in professional kitchens or with cookers and hobs meant for professional use. • Safera Sense is not user serviceable. For safety and reliability reasons, do not disassemble the product. Contact Safera for all service needs. • Safera Sense controls the stove and/or oven only if it is equipped and correctly coupled with the optional Power Control Unit (PCU). 2.2. Battery Safety Information Failure to follow the instructions below may cause the batteries to leak fluid and gas, or even explode: • Do not expose batteries to excessive heat, insert them with wrong polarity, or try to recharge them. • Always replace all batteries at once, using the same make, model and age for all batteries. • Do not leave empty batteries inside the device for prolonged periods. 3 • Recycle the empty batteries according to local regulations, do not place in domestic waste. • If the leaked fluid gets into your eyes, do not rub them, as there is a risk of losing eyesight. Rinse your eyes with water and contact a physician immediately. • If the leaked fluid gets into your mouth, rinse with water and contact a physician immediately. • If the leaked fluid gets on your skin or clothes, rinse with copious amounts of water to prevent burns. 2.3. Laser Safety Information The product contains two laser light sources: 1. Class 1 laser as part of the optical distance and gesture detection system. This is an invisible infrared laser, similar to commonly used autofocus lasers in (cell phone) cameras. It is directed from the sensor lens area towards the stove area. 2. Class 3R laser as part of the air quality sensor system. This rating applies only in a case where This laser is inside the product and not directly visible for the user during normal operation. Diffused reflections may be seen if the battery cover / mounting bracket is removed. Do not stare into these reflections closely or inspect them with optical instruments. Care must be taken to not damage or disassemble the sensor unit so that the laser source becomes fully exposed. In case of accidental enclosure damage which fully exposes the visible red laser beam, avoid direct eye exposure to the beam and do not inspect it with optical instruments. In such case, remove the batteries and discontinue the use of the product. 3. Main Features 3.1. Cooking Safety Safera Sense monitors the stove area and improves cooking safety by sounding an alarm if it detects a potentially dangerous cooking situation. These situations may be, for example, an overheating pan or prolonged lack of human presence during cooking. However, please note that not all possible hazards may be detected. Also note the limitations in chapters 2.1 and 11. This functionality can be used also without a Bluetooth connection to a mobile phone. 3.2. Air Quality Safera Sense indicates and monitors kitchen air quality. This functionality requires the Safera App and Bluetooth 4 connection to a mobile phone. More accurate list of currently supported air quality sensors and values are available in the Safera App. 3.3. Smart Cooking Safera Sense’s smart cooking features helps you cook better and easier. These features include automated timers and temperature related helpers. This functionality requires the Safera App and Bluetooth connection to a mobile phone. Additional features will be added via wireless software update from the Safera App. 4. Installation 4.1. Check the Delivery Contents The following components should be included: 1. Sensor unit with pre-installed batteries (3 x AA) 2. Wall mount bracket (pre-installed) 3. Cooker hood mount bracket (not installed) 4. This user manual 4.2. Power up the Sensor Unit Detach the wall mount bracket to uncover the battery compartment by pulling it gently open. The bracket is held in place by magnets. Remove the plastic pull-off insulator 1 2 3 OK-button Battery pull-off insulator strip Sensors Extra buttons 1 & 2 Mounting tape protectors (3 pcs) 5 strip at the battery compartment. The sensor unit is now powered. 6 4.3. Mount the Sensor Unit There are two alternative mounting methods: 1. Kitchen wall Use the wall mount bracket (installed by default). The Sensor Unit should be installed levelled, so that the sensors are pointing downwards towards the stove. 2. Cooker hood bottom Use the cooker hood bracket (separate in the delivery box). The Sensor Unit should be installed levelled at on the bottom of the cooker hood. The front edge of the Sensor Unit should be positioned in the front edge of the front burners, OK-button facing the user. 1 2 7 For the most up to date mounting method and stove support information, please refer to the “install a new Safera Sense” -section in the Safera App. If unable to use the app, refer to the table below: Allowed mounting height specifications Wa…

Text truncated - open the document above for the full version.

Safera Oy Tekniikantie 4 B 02150 Espoo / FINLAND FCB011_02 //DEKRA Testing and Certification, S.A.U. // www.dekra-product-safety.com/wireless Date: August 12 th , 2019 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía C/ Severo Ochoa 2 & 6 29590 Campanillas Málaga, España Ref: Agent letter for FCC ID: 2AT88-1000021194 We, Safera Oy Tekniikantie 4 B Espoo 02150 Finland hereby authorize DEKRA Testing and Certification, S.A.U. C/ Severo Ochoa, 2 & 6, 29590 Campanillas Málaga, Spain Mr. Eduardo Pavía Rubio, e-mail: [email protected], Phone: +34 95 261 91 25 to act as our agent in the preparation of this application for equipment certification, including the signing of all documents relating to these matters. The present authorization considers the development of documents on behalf of the client, written under his own letterhead and related to the necessary information to be provided on his behalf to complete the certification process. We also hereby certify that neither we nor any party to this application are subject to a denial of U.S. Federal benefits, which include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862 because of conviction for possession or distribution of controlled substance. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by DEKRA Testing and Certification, S.A.U., still resides with us. This agreement expires one year from the current date. Sincerely, __________________________ By: Mr Samuli Lintonen Title: R&D Director Company: Safera Oy Telephone: +358400800420 e-mail: [email protected]

FCB012_02 //DEKRA Testing and Certification, S.A.U. // www.dekra-product-safety.com/wireless Date: January 27th, 2020 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía C/ Severo Ochoa 2 & 6 29590 Campanillas Málaga, España Ref: Confidentiality request for FCC ID: 2AT88-1000021194 To whom it may concern: Pursuant to §0.457(d)(1)(ii) and §0.459 of the Commission’s Rules (47 C.F.R.) and §552 (b)(4) of the Freedom of Information Act, Safera Oy hereby request requests that a part of the subject FCC application be held confidential to avoid release of sensitive information of the product to the public. For the product stated above, we request that the following information be withheld from public disclose: Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Internal Photos Short Term Permanent Operation Description Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term User’s Manual Permanent Confidentiality: The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to us and provide unjustified benefits to our competitors. Short-Term Confidentiality: We hereby request short-term confidentiality for the product stated above to avoid premature release of sensitive information prior to marketing or release of the product to the public. Release date of short term confidentiality is: 45 days from grant date marked 90 days from grant date marked 135 days from grant date marked 180 days from grant date marked Specific date: We are also aware that we are responsible to notify DEKRA in the event information regarding the product or the product is made available to the public. DEKRA will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, P.A. __________________________ By: Mr Samuli Lintonen Title: R&D Director Company: Safera Oy Telephone: +358400800420 e-mail: [email protected]

DEKRA Certification, Inc. 405 Glenn Dr. Suite 12, Sterling, VA 20164 United States of America Report No: 2595ERM.003A1 01-30-2020 FCC LISTED, REGISTRATION NUMBER: 2764.01 ISED LISTED REGISTRATION NUMBER: 23595-1 Test report No: 2595ERM.003A1 Test report FCC Rules and Regulations CFR 47, Part 15, Subpart B (10-1-18 Edition) & ICES-003 ISSUE 6 – Update April (2017) Identification of item tested Smart Cooking Sensor Trademark Safera Model and /or type reference IFU10B Other identification of the product FCCID: 2AT88-1000021194 Features Bluetooth LE Manufacturer SAFERA OY Tekniikantie 4B, 02150 Espoo, Finland. Test method requested, standard FCC Rules and Regulations CFR 47, Part 15, Subpart B (10-1-18 Edition) ICES-003 ISSUE 6 – Update April (2017) Summary IN COMPLIANCE Approved by (name / position & signature) Domingo Galvez EMC&RF Lab Manager Date of issue 01-30-2020 Report template No FDT08_21 DEKRA Certification, Inc. 405 Glenn Dr. Suite 12, Sterling, VA 20164 United States of America Report No: 2595ERM.003A1 Page 2 of 15 01-30-2020 Index Competences and guarantees .................................................................................................... 3 General conditions ...................................................................................................................... 3 Uncertainty ................................................................................................................................. 3 Data provided by the client .......................................................................................................... 4 Usage of samples ....................................................................................................................... 4 Test sample description .............................................................................................................. 5 Identification of the client............................................................................................................. 6 Testing period and place ............................................................................................................. 6 Document history ........................................................................................................................ 6 Environmental conditions ............................................................................................................ 7 Remarks and comments ............................................................................................................. 7 Testing verdicts ........................................................................................................................... 8 Summary .................................................................................................................................... 8 List of equipment used during the test......................................................................................... 8 Appendix A: Test results ............................................................................................................. 9 DEKRA Certification, Inc. 405 Glenn Dr. Suite 12, Sterling, VA 20164 United States of America Report No: 2595ERM.003A1 Page 3 of 15 01-30-2020 Competences and guarantees DEKRA Certification Inc. is a testing laboratory accredited by A2LA (The American Association for Laboratory Accreditation), to perform the tests indicated in the Certificate 2764.01 DEKRA Certification Inc. is a testing laboratory competent to carry out the tests described in this report. In order to assure the traceability to other national and international laboratories, DEKRA Certification Inc. has a calibration and maintenance program for its measurement equipment. DEKRA Certification Inc. guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at DEKRA Certification at the time of performance of the test. DEKRA Certification Inc. is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Test Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA Certification Inc. General conditions 1. This report is only referred to the item that has undergone the test. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of DEKRA Certification Inc. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written permission of DEKRA Certification Inc. and the Accreditation Bodies. Uncertainty Uncertainty (factor k=2) was calculated according to the DEKRA Certification internal document PODT000. Frequency (MHz) U(k=2) Units Conducted emission 0,009 - 30 2.69 dB Radiated emission 30-180 3.82 dB 180-1000 2.61 dB 1000-18000 2.92 dB 18000-40000 2.15 dB DEKRA Certification, Inc. 405 Glenn Dr. Suite 12, Sterling, VA 20164 United States of America Report No: 2595ERM.003A1 Page 4 of 15 01-30-2020 Data provided by the client Bluetooth Low Energy. DEKRA declines any responsibility with respect to the information provided by the client and that may affect the validity of results. Usage of samples Samples undergoing test have been selected by: The client. Sample S/01 is composed of the following elements: Control Nº Description Model Serial Nº Date of reception 2595B.001 EMC Commercial Test Sample 21…

Text truncated - open the document above for the full version.

DEKRA Certification, Inc. 405 Glenn Dr. Suite 12, Sterling, VA 20164 United States of America Report No: 2595ERM.004 01-15-2020 FCC LISTED, REGISTRATION NUMBER: 2764.01 ISED LISTED REGISTRATION NUMBER: 23595-1 Test report No: 2595ERM.004 Test report USA FCC Part 15.247, 15.209, 15.207 CANADA RSS-247, RSS-Gen Radio Frequency Devices. Operation within the bands 902 - 928 MHz, 2400 -2483.5 MHz, and 5725 - 5850 MHz Digital Transmission Systems (DTSs), Frequency Hopping Systems (FHSS) and Licence-Exempt Local Area Network (LE-LAN) Devices. Identification of item tested Smart Cooking Sensor Trademark Safera Model and /or type reference IFU10B Other identification of the product FCC ID: 2AT88-1000021194 Features Bluetooth LE Manufacturer SAFERA OY Tekniikantie 4B, 02150 Espoo, Finland. Test method requested, standard USA FCC Part 15.247, 10-1-18 Edition: Operation within the bands 902 - 928 MHz, 2400 -2483.5 MHz, and 5725 - 5850 MHz. USA FCC Part 15.209, 10-1-18 Edition: Radiated emission limits; general requirements. CANADA RSS-247 Issue 2 (February 2017). CANADA RSS-Gen Issue 5 (February 2018). Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 558074 D01 DTS Meas Guidance v04 dated 05/04/2017. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices. Summary IN COMPLIANCE Approved by (name / position & signature) Domingo Galvez EMC&RF Lab Manager Date of issue 01-15-2020 Report template No FDT08_21 DEKRA Certification, Inc. 405 Glenn Dr. Suite 12, Sterling, VA 20164 United States of America Report No: 2595ERM.004 Page 2 of 68 01-15-2020 Index Competences and guarantees .................................................................................................... 3 General conditions ...................................................................................................................... 3 Uncertainty ................................................................................................................................. 3 Data provided by the client .......................................................................................................... 4 Usage of samples ....................................................................................................................... 4 Test sample description .............................................................................................................. 5 Identification of the client............................................................................................................. 6 Testing period and place ............................................................................................................. 6 Document history ........................................................................................................................ 6 Environmental conditions ............................................................................................................ 7 Remarks and comments ............................................................................................................. 7 Testing verdicts ........................................................................................................................... 8 Summary .................................................................................................................................... 8 List of equipment used during the test......................................................................................... 9 Appendix A: Test results ........................................................................................................... 10 DEKRA Certification, Inc. 405 Glenn Dr. Suite 12, Sterling, VA 20164 United States of America Report No: 2595ERM.004 Page 3 of 68 01-15-2020 Competences and guarantees DEKRA Certification Inc. is a testing laboratory accredited by A2LA (The American Association for Laboratory Accreditation), to perform the tests indicated in the Certificate 2764.01 DEKRA Certification Inc. is a testing laboratory competent to carry out the tests described in this report. In order to assure the traceability to other national and international laboratories, DEKRA Certification Inc. has a calibration and maintenance program for its measurement equipment. DEKRA Certification Inc. guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at DEKRA Certification at the time of performance of the test. DEKRA Certification Inc. is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Test Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA Certification Inc. General conditions 1. This report is only referred to the item that has undergone the test. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of DEKRA Certification Inc. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written permission of DEKRA Certification Inc. and the Accreditation Bodies. Uncertainty Uncertainty (factor k=2) was calculated according to the DEKRA Certification internal document PODT000. Frequency (MHz) U(k=2) Units 0,009 - 30 2.69 dB 30-180 3.82 dB 180-1000 2.61 dB 1000-18000 2.92 dB 18000-40000 2.…

Text truncated - open the document above for the full version.

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 62048RAN.002 2020-01-15 Test report No: NIE: 62048RAN.002 Assessment report RF EXPOSURE REPORT ACCORDING TO FCC 47 CFR Part 2.1091 (*) Identification of item tested Smart Cooking Sensor (*) Trademark Safera (*) Model and /or type reference IFU10B Other identification of the product FCC ID: 2AT88-1000021194 Hw version: B Sw version: 1.0.0 (*) Features Bluetooth Low Energy Manufacturer SAFERA OY Tekniikantie 4 B, 02150 Espoo, Finland Test method requested, standard FCC 47 CFR Part 2.1091 Radiofrequency radiation exposure evaluation: mobile devices. IEEE Std C95.3 TM -2002 (R2008). IEEE Recommended Practice for Measurements and Computations of Radio Frequency Electromagnetic Fields With Respect to Human Exposure to Such Fields, 100 kHz–300 GHz Summary IN COMPLIANCE Approved by (name / position & signature) Miguel Lacave Antennas Lab. Manager Date of issue 2020-01-15 Report template No FAN36_01 (*) “Data provided by the client” DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 62048RAN.002 Page 2 of 7 2020-01-15 Index Competences and guarantees .................................................................................................... 3 General conditions ...................................................................................................................... 3 Data provided by the client .......................................................................................................... 3 Identification of the client............................................................................................................. 3 Document history ........................................................................................................................ 3 General description of the device under evaluation ..................................................................... 4 RF Exposure Assessment result and verdict ............................................................................... 4 Appendix A: FCC RF Exposure information ................................................................................ 5 FCC RF Exposure evaluation ................................................................................................. 6 FCC MPE Evaluation .............................................................................................................. 7 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 62048RAN.002 Page 3 of 7 2020-01-15 Competences and guarantees In order to assure the traceability to other national and international laboratories, DEKRA Testing and Certification, S.A.U. has a calibration and maintenance program for its measurement equipment. DEKRA Testing and Certification, S.A.U. guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at DEKRA Testing and Certification, S.A.U. at the time of performance of the test. DEKRA Testing and Certification, S.A.U. is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Assessment Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA Testing and Certification, S.A.U. General conditions 1. This report is only referred to the item that has undergone the assessment. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of DEKRA Testing and Certification, S.A.U.. 4. This assessment report cannot be used partially or in full for publicity and/or promotional purposes without previous written permission of DEKRA Testing and Certification, S.A.U. and the Accreditation Bodies. Data provided by the client The following data has been provided by the client: 1. Information relating to the description of the sample ("Identification of the item tested", "Trademark", "Model and/or type reference tested"). 2. Maximum output power, maximum antenna gain and use distance information. DEKRA Testing and Certification S.A.U. declines any responsibility with respect to the information provided by the client and that may affect the validity of results. Identification of the client SAFERA OY Tekniikantie 4 B, 02150 Espoo, Finland Document history Report number Date Description 62048RAN.002 2020-01-15 First release DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 62048RAN.002 Page 4 of 7 2020-01-15 General description of the device under evaluation The device under evaluation, Safera Sense, consists of a Smart Cooking Sensor with the following main features: - Sensors for monitoring the stove area and detecting cooking processes, as well as estimating indoor air quality - Processor and algorithms for detecting stove overheating, which will result in an audible alarm - Support for Bluetooth communication to smartphones and iOS / Android application in order to visualize data According to the manufacturer, during its normal use, the separation distance between the …

Text truncated - open the document above for the full version.

DEKRA Certification, Inc. 405 Glenn Dr. Suite 12, Sterling, VA 20164 United States of America Report No: 2595ERM.003A1 01-30-2020 Appendix B: Photographs DEKRA Certification, Inc. 405 Glenn Dr. Suite 12, Sterling, VA 20164 United States of America Report No: 2595ERM.003A1 Page 2 of 3 2019-08-08 Figure B1. DUT top view Figure B2. DUT rear view DEKRA Certification, Inc. 405 Glenn Dr. Suite 12, Sterling, VA 20164 United States of America Report No: 2595ERM.003A1 Page 3 of 3 2019-08-08 Figure B3. Low Range Radiated Emission Set up Figure B4. Hi Range Radiated Emission Set up

DEKRA Certification, Inc. 405 Glenn Dr. Suite 12, Sterling, VA 20164 United States of America Report No: 2595BERM.004 2019-08-08 Appendix B: Photographs DEKRA Certification, Inc. 405 Glenn Dr. Suite 12, Sterling, VA 20164 United States of America Report No: 2595BERM.004 Page 2 of 3 2019-08-08 Figure B1. DUT Conducted Sample Figure B2. DUT Top View Figure B3. DUT Rear View DEKRA Certification, Inc. 405 Glenn Dr. Suite 12, Sterling, VA 20164 United States of America Report No: 2595BERM.004 Page 3 of 3 2019-08-08 Figure B4. Radiated Setup – Low Range Figure B5. Radiated Setup- High Range
