Shenzhen Kejinming Electronic Co., Ltd Add: 1-6F,Block B7,Yintian Industrial Park Xixiang Street,Bao’an Dist. Shenzhen China Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Dear Sir/Madam, We, Shenzhen Kejinming Electronic Co., Ltd Hereby declares the following statement for FCC, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product Name: VIDEO PROJECTOR FCC ID: 2ATFT-VL208 Model Number(s): VL208, VL407, KJM-208, KJM407, KJM601, KJM602 Sincerely, Name: Ruiqi Chen/Sales Director Company: Shenzhen Kejinming Electronic Co., Ltd Address: 1-6F,Block B7,Yintian Industrial Park Xixiang Street,Bao’an Dist. Shenzhen China Phone: 0755-27489177 Fax: 0755-27489373 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 <2020-09-14> TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2ATFT-VL208 VL208, VL407, KJM-208, KJM407, KJM601, KJM602 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Ruiqi Chen/Sales Director Company: Shenzhen Kejinming Electronic Co., Ltd Address: 1-6F,Block B7,Yintian Industrial Park Xixiang Street,Bao’an Dist. Shenzhen China Phone: 0755-27489177 Fax: 0755-27489373 E-Mail: [email protected]

Shenzhen Kejinming Electronic Co., Ltd 1-6F,Block B7,Yintian Industrial Park Xixiang Street,Bao’an Dist. Shenzhen China Date: September 14, 2020 FCC ID: 2ATFT-VL208 Model Number: VL208, VL407, KJM-208, KJM407, KJM601, KJM602 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, Shenzhen Kejinming Electronic Co., Ltd declare that this EUT (FCC ID: 2ATFT-VL208) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, (Signed) Name: Ruiqi Chen Title: Sales Director Company: Shenzhen Kejinming Electronic Co., Ltd Address: 1-6F,Block B7,Yintian Industrial Park Xixiang Street,Bao’an Dist. Shenzhen China Phone: 0755-27489177 Fax : 0755-27489373 Email: [email protected]

Shenzhen Kejinming Electronic Co., Ltd 1-6F,Block B7,Yintian Industrial Park Xixiang Street,Bao’an Dist. Shenzhen China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 09/14/2020 To whom it may concern: We, Shenzhen Kejinming Electronic Co., Ltd the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2ATFT-VL208 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, (Signed) Name / Title: Ruiqi Chen/Sales Director Company: Shenzhen Kejinming Electronic Co., Ltd Address: 1-6F,Block B7,Yintian Industrial Park Xixiang Street,Bao’an Dist. Shenzhen China Phone: 0755-27489177 Fax: 0755-27489373 E-Mail: [email protected]

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ATFT- VL208 8.EXTERIOR PHOTOGRAPHS Fig.1 Fig.2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ATFT- VL208 Fig.3 Fig.4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ATFT- VL208 Fig.5 Fig.6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ATFT- VL208 Fig.7 Fig.8

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. _____________________________________________________________________________________________________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 1 of 1 LABEL AND LOCATION (Size: L5.0m x 3.5cm) Material: Tagboard Glue: adhesive sticker Font color: White Label color: Black Label Location Model No.: VL208 FCC ID: 2ATFT-VL208 Input: 12.0V4.0A For Adapter: Input:100-240V~, 50/60Hz, 1.2A Max Output:12.0V4.0A This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Made In China

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ATFT- VL208 9.INTERIOR PHOTOGRAPHS Fig.1 Fig.2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ATFT- VL208 Fig.3 Fig.4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ATFT- VL208 Fig.5 Fig.6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ATFT- VL208 Fig.7 Fig.8 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ATFT- VL208 Fig.9 Fig.10 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ATFT- VL208 Fig.11 Fig.12 BT Antenna(only RX) SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ATFT- VL208 Fig.13 Fig.14 BT Antenna SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ATFT- VL208 Fig.15 WIFI Antenna

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ATFT- VL208 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 6 FCC RF Exposure Evaluation 1. Product Information FCC ID 2ATFT- VL208 Product name VIDEO PROJECTOR Model number VL208 Additional Model No VL407, KJM-208, KJM407, KJM601, KJM602 Model Declaration PCB board, structure and internal of these model(s) are the same, So no additional models were tested Power supply Input: 12.0V4.0A For Adapter: Input:100-240V~, 50/60Hz, 1.2A Max Output:12.0V4.0A Modulation Type GFSK for Bluetooth V5.0 (DTS) IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM (64QAM, 16QAM,QPSK,BPSK) Antenna Type Internal Antenna Antenna Gain 0dBi(Max.) Hardware version / Software version / FCC Operation frequency 2402MHz-2480MHz 2412MHz-2462MHz Exposure category General population/uncontrolled environment EUT Type Production Unit Device Type Mobile Devices 2. Evaluation Method Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ATFT- VL208 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 6 3. Limit 3. 1 Refer Evaluation Method ANSI C95.1–2019: IEEE Standard for Safety Levels with Respect to Human Exposure to Electric, Magnetic, and Electromagnetic Fields, 0 Hz to 300 GHz. FCC KDB publication 447498 D01 General 1 RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices 3. 2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 4. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 5. Antenna Information Artemis Antenna can only use antennas certificated as follows provided by manufacturer; Internal Identification Antenna type and antenna number Operate frequency band Maximum antenna gain Note Antenna_0 Internal Antenna 2412MHz-2462MHz 0dBi WIFI Antenna Antenna_1 PCB Antenna 2402MHz-2480MHz 0dBi BT Antenna SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ATFT- VL208 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 6 6. Conducted Power <BT LE> Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) GFSK 0 2402 -0.037 19 2440 -0.657 39 2480 -1.918 <2.4GWIFI> Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) 11B 1 2412 11.15 6 2437 9.98 11 2462 10.47 11G 1 2412 10.57 6 2437 9.48 11 2462 9.97 11N20SISO 1 2412 10.79 6 2437 9.41 11 2462 9.93 11N40SISO 3 2422 10.96 6 2437 9.98 9 2452 10.16 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ATFT- VL208 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 6 7. Manufacturing Tolerance <BT LE> GFSK (Peak) Channel Channel 0 Channel 19 Channel 39 Target (dBm) 0 0 -1.0 Tolerance ±(dB) 1.0 1.0 1.0 <2.4GWIFI> 11B (Peak) Channel Channel 1 Channel 6 Channel 11 Target (dBm) 11.0 9.0 10.0 Tolerance ±(dB) 1.0 1.0 1.0 11G (Peak) Channel Channel 1 Channel 6 Channel 11 Target (dBm) 10.0 9.0 9.0 Tolerance ±(dB) 1.0 1.0 1.0 11N20SISO (Peak) Channel Chann…
