1 Version V1 GOLFWAVER Golf Radar Sensor User Manual PMN:GOLF Waver Launch Monitor .0 2023-03 2 Revision History Date Versions Implementer Description 2023/3/17 V1.0 Xinyu Huang First Publish 1 Catalogue 1 Summarize.......................................................................................................2 1.1 System Description ............................................................................................................ 2 1.1.1 Radar sensor system .............................................................................................. 2 1.2 Product Application scope .............................................................................................. 2 2 Product specifications....................................................................................3 2.1 Specifications ....................................................................................................................... 3 2.2 Interface Description ......................................................................................................... 3 2.3 General Specifications ...................................................................................................... 4 3 Product Appearance description..................................................................5 3.1 Appearance ........................................................................................................................... 5 3.2 Device Usage........................................................................................................................ 6 4 4 Packing List................................................................................................14 2 1 Summarize The radar sensor is mainly used in the swing parameters and flight parameters of golf shots. It is connected with the Bluetooth of the Yueqiu APP on the mobile phone to display related parameters of golf, so as to facilitate customers to evaluate their own shots and provide reference data for improving their own level. 1.1 System Description 1.1.1 Radar sensor system Radar sensor system: including 5V2A power adapter, 1m Type-C Charging cable, Radar sensor; Figure 1. Block diagram of radar sensor system 1.2 Product Application scope ⚫ 应用于室内外高尔夫等非专业和专业人员提供评估的数据参考，提升自身的击 球水平和专业性。 ⚫ used in indoor and outdoor golf amateur and professional personnel to provide data to the evaluation of the reference, to raise their level and professional. Radar sensor APP 5V/2A Power adapter 3 2 Product specifications 2.1 Specifications Hardware characteristics CPU Based on STC12C5A6052 MCU Radar radio frequency module Infineon's BGT24MTR11\BGT24MR2 radar scheme is adopted WiFi/BT module ESP32-WROOM-32E WiFi module ESP8266-12F Battery 18650,2600 mAh rechargeable lithium battery Charging interface 5V/2A Machine power ≤2W Software characteristics Operating system RT-Thread 2.2 Interface Description Interface type Description Network interface 2.4G Bluetooth, 2.4G Wifi Power interface TYPE-C interface (5V2A) 2.3 General Specifications Adapter power supply 4 Power Use a 5V/2A adapter for power supply Full load power 2.5W Working environment Temperature 0°C ～ 50°C Storage Temperature -20°C ～ 70°C Humidity 20% ～ 70% Mechanical parameter Size (L*W*H) 170*100*29mm Net fuselage weight 230g Shell Painted plastic case (Yellow , Grey , Silver , Black) 5 3 Product Appearance description 3.1 Appearance Figure 2 Top view Figure 3 Side view 6 Figure 4 Rear view Figure 4 Charger and charging cable 3.2 Device Usage 3.2.1 The device interface contains the following configurations 7 Figure 5 (1) A: TYPE-C Indicates the interface Used to connect the 5V2A adapter to charge the radar sensor; (2) Power button Press the power button to turn on the machine, and the buzzer will sound 3 times. Press the power button to turn off the machine, and the buzzer will sound 1 times. (3) Positioning laser start button Button press, line laser light 20S, according to the direction of play set up radar sensor; 3.2.2 Top LED and other display instructions (1) On the startup display, if 4 green LED lights are on, the electricity quantity is greater than 85%; if 3 green LED lights are on, the electricity quantity is greater than 50%; if 2 green LED lights are on, the equal circuit is greater than 25%; 8 Figure 6 (2) Plug in the charging cable, the first light on the right is blue, indicating that the radar sensor is in the charging state; If the blue indicator is blinking, the battery is not installed or there is no battery. Figure 7 (3) During normal operation, the middle two lights are lit； 9 Figure 8 (4) The red light on the LED on the left indicates that the battery is installed backwards and needs to be installed again in the correct way； Figure 9 （5） Instructions for radar battery warehouse 10 Figure 10 3.2.3 Instructions for use (1) Download and install APP Figure 11 (2) Turn on the radar, the radar LED lights up two green lights in the middle (as shown in Figure 8); (3) Place the radar 2 meters away from the TEE position, turn on the positioning laser (start with the button on the body or start the laser in the APP), align the laser line with the center of the golf ball at the tee position, and keep the laser line in a straight line with the 11 direction of the shot; Figure 12 (4) APP Turn on the Bluetooth of the mobile phone and open the APP； 12 Figure 13 (5) Click the upper right corner to search for the device, click the corresponding Bluetooth number, the link is successful; Figure14 Search for a device and click the corresponding device Figure15 Successful connection 13 (6) Check the relevant information of radar, check the version number, upgrade the radar, APP start the positioning laser switch; Figure 16 View information about connected devices Figure 16 Top right check radar power (7) Open the driving range and other scenes, each successful shot will have the relevant parameters of golf flight; 14 Figure 17 View the motion parameters and…

Text truncated - open the document above for the full version.
