FCC ID : 2ATIZ-ICEQ3 RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 11.1 Friis transmission formula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1416 R= distance between observation point and center of the radiator in 20cm Pd the limit of MPE, 1mW/cm 2 . If we know the maximum gain of the nd total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. 11.2 EUT TECHNICAL DESCRIPTION Device Type BLE V4.2 Data Rate 1Mbps Modulation GFSK Operating Frequency Range 2402-2480MHz Number of Channels 40 Channels Antenna Type PCB Antenna Antenna Gain 2.5 dBi Characteristics Description Product Ice Maker Model Number ICEQ1-RZB15(B)-N8-3, ICEQ2-RZB15(B)-N8-3, ICEQ3-RZB15(B)-N8-3, ICEQ4-RZB15(B)-N8-3 Note: All models are identical except for the appearance difference, We choose ICEQ3-RZB15(B)-N8-3 for final test. IEEE 802.11 WLAN Mode Supported 802.11b 802.11g 802.11n(20MHz channel bandwidth) Modulation DSSS with DBPSK/DQPSK/CCK for 802.11b OFDM with BPSK/QPSK/16QAM/64QAM for 802.11g/n Operating Frequency Range 2412-2462MHz for 802.11b/g/n(HT20) Number of Channels 11 channels for 802.11b/g/n(HT20) Transmit Power Max 16.21dBm Antenna Type PCB Antenna Antenna Gain 2.5 dBi Power Supply AC 120V/60Hz Temperature Range -10°C ~ 50°C 11.2 Measurement Result Mode Max Measured power (dBm) Antenna gain (dBi) Antenna Gain Numeric R (cm) Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) BLE 5.09 2.5 1.78 20 0.0011 1 2.4G WIFI 16.21 2.5 1.78 20 0.0148 1 MAX RF EXPOSURE EVALUATION BLE 2.4G WIFI Summation of Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) 0.0011 0.0148 0.0159 <1 ----- The End -----
